How we Automated our Relationship

Want to automate your home? Come learn how to sharpen your skills in Node, APIs, and the Internet of Things while making laundry, cooking, & calendar projects that improve your life and relationship.

It’s not every day you have a couple of devs (Daphne Liu and Tiger Oakes), who are also a couple, offer to teach us how hacking has kept them happy & sane.

Transcript

1. How we automated Tiger Oakes × Daphne Liu
2. Tiger Oakes Daphne Liu @notwoods@hachyderm.io Software Dev working on Microsoft Loop @thebetterdaphne@twitter.com Frontend Dev working on Lyft web app & design systems
3. • Communication • Transparency • Teamwork ... all of which we Keys to our relationship @notwoods × @thebetterdaphne
4. Who's doing them today?
5. No more chores chart. Couples Better than couples therapy. Family I hope your kid knows how to code. Roommates Yourself It’s time to get your life together. Who’s the talk for? @notwoods × @thebetterdaphne
6. Notion & Trello decide what you’re eating this week Recipes Laundry Vibration sensors tell you when your laundry is done Meetings Lights & IoT indicate when you’re in “Do not Disturb” mode Use Node.js, APIs & IoT for @notwoods × @thebetterdaphne
7. Get started without writing any code! • https://github.com/NotWoods/automate-our-relationship @notwoods × @thebetterdaphne
8. Recipes Notion & Trello decide what you’re eating this week @notwoods × @thebetterdaphne
9. Being adult is hard You’re hungry Too hangry to think and cook You try to cook No recipes & no groceries You got groceries You forget about them, they grow moldy
13. Feeding Schedule @notwoods × @thebetterdaphne Taiwanese minced pork on rice Lo mein Lomo saltado Meat jun + mashed cauliflower 3 cup chicken + Eggplant Chicken adobo + Carrot Lo mein Air fry orange tofu + Broccoli Kale + Sweet potato salad Cold sesame noodle Air fry orange tofu + Broccoli Taiwanese egg pancake Veggie patty + Some veggie Korean Egg Tofu Thai coconut soup Beef chow mein
14. Feeding Schedule M TU W TH F SA SU Lunch Eat out Dinner Eat out @notwoods × @thebetterdaphne Taiwanese minced pork on rice Lo mein Lomo saltado Meat jun + mashed cauliflower 3 cup chicken + Eggplant Chicken adobo + Carrot Air fry orange tofu + Broccoli Kale + Sweet potato salad Cold sesame noodle Air fry orange tofu + Broccoli Taiwanese egg pancake Veggie patty + Some veggie
15. Feeding Schedule M TU W TH F SA SU Lunch Dinner @notwoods × @thebetterdaphne
16. 1. Pull from recipe list in Notion 2. Assign meals onto days in Trello 3. Add the ingredients onto our grocery list in Trello. @notwoods × @thebetterdaphne
17. @notwoods × @thebetterdaphne
18. Trello Notion • API • Comes with UI (property, tags, link) • Templates • API • Comes with UI (similar to our list) • Drag and drop • Works offline Why Notion & Trello? @notwoods × @thebetterdaphne
19. 1. Pull from recipe list in Notion 2. Assign meals onto days in Trello 3. Add the ingredients onto our grocery list in Trello. @notwoods × @thebetterdaphne
20. https://developers.notion.com • Fetch array of pages • Fetch array of blocks in a page Notion API @notwoods × @thebetterdaphne
21. // Query Notion database using API // https://developers.notion.com/reference/post-database-query queryDatabases(databaseId, body) { return fetch(`${this.notionUrl}/v1/databases/${databaseId}/query`, { method: "post", body: JSON.stringify(body), headers: { "Authorization": `Bearer ${this.token}`, "Notion-Version": "2022-06-28", "Content-Type": "application/json", } }); } @notwoods × @thebetterdaphne
22. import { shuffle } from 'd3-array'; const recipes: DatabasePage[] = await notionApi.queryDatabases(...); shuffle(recipes); 1. Pick random meals @notwoods × @thebetterdaphne
23. 1. Pull from recipe list in Notion 2. Assign meals onto days in Trello 3. Add the ingredients onto our grocery list in Trello. @notwoods × @thebetterdaphne
24. https://developer.atlassian.com /cloud/trello/ • Add cards to lists • Add checklists to cards Trello API @notwoods × @thebetterdaphne
25. // Create new Trello card using API // https://developer.atlassian.com/cloud/trello/rest/api-group-cards/ createCard(card) { const query = new URLSearchParams(card); query.set("key", this.key); query.set("token", this.token); return fetch(`${this.trelloUrl}/1/cards`, { method: "post", query, headers: { "Content-Type": "application/json" } }); } @notwoods × @thebetterdaphne
27. const [groceryList, ...weekdays] = await trelloApi.listsOnBoard(ID); // For each weekday column... for (const [i, weekday] of weekdays.entries()) { await trelloApi.deleteAllCardsInList(weekday.id); await addRecipeAsCard(recipes[lunchPos(i)], weekday.id); await addRecipeAsCard(recipes[dinnerPos(i)], weekday.id); } 2. Assign meals to days @notwoods × @thebetterdaphne
28. function addRecipeAsCard(recipe, listId) { // Populate the content in a card const name = await notionApi.retrievePageTitle(recipe.id); const card = await trelloApi.createCard({ idList, name, urlSource: recipe.url, }); if (recipe.cover) { await trelloApi.createAttachmentOnCard(card.id, { url: recipe.cover.external.url, setCover: true, }); } @notwoods × @thebetterdaphne
31. Script so far Get recipes Fetch recipes as array Randomize Shuffle the array Get lists Get the id of every Trello list Add cards Add two cards per list @notwoods × @thebetterdaphne
32. import { NotionApi } from './api.js'; // Hardcode API key const NOTION_API_KEY = "43273z8u3w"; const notionApi = new NotionApi(NOTION_API_KEY); // Run immediately using top-level await const blocks = await notionApi.queryDatabase(); @notwoods × @thebetterdaphne
33. Tools for building shiny web apps Database Postgres/Mongo Bundler Webpack/Vite/Parcel Auth Auth0/Passport
34. 1. Pull from recipe list in Notion 2. Assign meals onto days in Trello 3. Add the ingredients onto our grocery list in Trello. @notwoods × @thebetterdaphne
35. @notwoods × @thebetterdaphne
36. async function extractShoppingListItems(blocks) { // Find heading name "Shopping list" const listHeading = await moveToHeading(blocks, /shopping list/i); if (!listHeading) { // No shopping list return []; } ... 3. Extract ingredients @notwoods × @thebetterdaphne
37. const ingredients = []; switch (block.type) { // Add list items to result list case "bulleted_list_item": case "to_do": ingredients.push(block[block.type]); break; // just skip paragraphs, usually subheaders or empty lines case "paragraph": break; ... 3. Extract ingredients @notwoods × @thebetterdaphne
38. switch (block.type) { ... // Break when entering a new heading at the same or above level case "heading_1": case "heading_2": case "heading_3": if (headingLevels[block.type] <= headingLevels[listHeading.type]) { continueLoop = false; } break; } 3. Extract ingredients @notwoods × @thebetterdaphne
39. @notwoods × @thebetterdaphne
40. const allIngredients = []; for (const recipe of recipes) { const blocks = await notionApi.blockChildren(recipe.id); try { const ingredients = await extractShoppingListItems(blocks); ingredients.push(...ingredients); } catch (error) { console.warn("Couldn't get ingredients", recipe, error); } } 4. Export grocery list @notwoods × @thebetterdaphne
41. 4. Export grocery list @notwoods × @thebetterdaphne const checklist = await trelloApi.createChecklistOnCard(card.id); for (const ingredient of ingredients) { await trelloApi.createCheckItems(checklist.id, ingredient); }
42. Future Work Choose recipes with overlapping ingredients. Handle batch cooking one large meal for multiple days. Notes You can help us by contributing to the repo! https://github.com/ NotWoods/ automate-our-relationship @notwoods × @thebetterdaphne
43. • http://recipes.tigerxdaphne.com • https://github.com/NotWoods/automate-our-relationship @notwoods × @thebetterdaphne for recipes
44. Meetings Lights & IoT indicate when you’re in “Do not Disturb” mode Lights & IoT indicate when you’re in “Do not Disturb” mode @notwoods × @thebetterdaphne
45. Connects to WiFi Control power programmatically Lights are plugged in Smart plugs @notwoods × @thebetterdaphne
46. Home Assistant API https://home-assistant.io/ • Universal API for talking to smart home devices (ex. smart plug) • Host on a server ◦ Raspberry Pi ◦ Virtual machine ◦ Buy one from them @notwoods × @thebetterdaphne
47. Google Calendar API https://developers.google.com /calendar/api • Pull upcoming events @notwoods × @thebetterdaphne
48. Event emitters class EventNode extends EventEmitter { transform(event) { if (event.type === 'busy') { this.emit('data', event); } } } const filterBusy = new EventNode(); otherEventNode.on('data', (event) => filterBusy.transform(event) ); Emit events Filter data Send to devices @notwoods × @thebetterdaphne
49. Calendar event flow Calendars Emit whenever a calendar event is starting Devices Turn light on when meeting starts Filtering Filter out non- meeting events Timer setTimeout until meeting ends
50. Multiple calendar event flow Calendar 1 Devices Filtering Timer Calendar 2 Calendar 3
51. https://nodered.org/ • Built on Node.js • Low-code, drag and drop UI • Integrates with Home Assistant • Get additional nodes as npm modules Node-RED @notwoods × @thebetterdaphne
52. UI & function nodes @notwoods × @thebetterdaphne
53. Calendars Emit whenever a calendar event is starting Filtering Filter out non- meeting events Devices Turn light on Timer Turn light off @notwoods × @thebetterdaphne
54. Calendars Emit whenever a calendar event is starting @notwoods × @thebetterdaphne
55. Filtering Filter out non- meeting events @notwoods × @thebetterdaphne
56. Devices Turn light on, immediately @notwoods × @thebetterdaphne
57. Timer Turn light off, after delay @notwoods × @thebetterdaphne // Send event after a delay const delay = end.getTime() - Date.now(); setTimeout(() => { node.send(msg) }, delay);
58. • https://home-assistant.io/ • https://nodered.org/ • https://github.com/NotWoods/automate-our-relationship @notwoods × @thebetterdaphne for meetings
59. Laundry Vibration sensors tell you when your laundry is done @notwoods × @thebetterdaphne
60. @notwoods × @thebetterdaphne
61. Node-RED Sensors • Device in your house to measure real life information • May get disconnected • May not report data when you want • May not detect events you care about Building a laundry system No machine data • Washer's on/off state isn't stored in a database
62. Reports movement events $20 device Uses Zigbee instead of WiFi to communicate Aqara Vibration Sensor @notwoods × @thebetterdaphne
63. Zigbee WiFi Devices wirelessly connect to hub, which connects to internet Devices wirelessly connect to router, which connects to internet Smart hubs and protocols
64. Zigbee hub All these devices connect through the same Zigbee hub Aqara Philips Hue IKEA Tradri Zigbee hub
65. Washer Dryer Placing sensors
66. Notes • device_id: which sensor sent the event • command: event type • args.strength: vibration strength Sensor events { "device_id": "587afb97ab882bd1", "command": "vibration_strength", "args": { "strength": 4 } } { "device_id": "587afb97ab882bd1", "command": "vibration_strength", "args": { "strength": 29 } } { "device_id": "1732994c20ae4142", "command": "vibration_strength", "args": { "strength": 32 } } { "device_id": "587afb97ab882bd1", "command": "vibration_strength", "args": { "strength": 24 } } @notwoods × @thebetterdaphne
67. 24 @notwoods × @thebetterdaphne
68. Sensor Listening for vibration sensor events Threshold Check if the previous event was above 24 and new event is below 24 Notify Send announcement message to Google Home speakers @notwoods × @thebetterdaphne
69. Sensor Listening for vibration sensor events @notwoods × @thebetterdaphne
70. Threshold Check if the previous event was above 24 and new event is below 24 @notwoods × @thebetterdaphne const THRESHOLD = 24; if (lastStrength >= THRESHOLD && strength < THRESHOLD) { node.send(msg); }
71. Notify Send announcement message to Google Home speakers @notwoods × @thebetterdaphne
72. // const THRESHOLD = 24; const THRESHOLD = 29; if (lastStrength >= THRESHOLD && strength < THRESHOLD) { node.send(msg); } @notwoods × @thebetterdaphne
73. • https://amazon.com/Aqara-Sensor/dp/B07PJT939B • https://amazon.com/Zigbee-USB-Hub/dp/B09KXTCMSC • https://github.com/NotWoods/automate-our-relationship @notwoods × @thebetterdaphne for laundry
74. • Communication • Transparency • Teamwork ... all of which we Keys to our relationship @notwoods × @thebetterdaphne
75. Do you have any questions? tigeroakes.com @notwoods@hachyderm.io daphneliu.com @thebetterdaphne@twitter.com Let’s chat about home automation, web apps, or improv!
76. Do you have any questions? tigeroakes.com @notwoods daphneliu.com @thebetterdaphne CREDITS: This presentation template was created by Slidesgo, including icons by Flaticon, and infographics & images by Freepik
