Game Development with Unity from an Android Point of View

Julien Salvi
November 27, 2020

Game Development with Unity from an Android Point of View

Developing mobile games with Unity has become more and more popular these years, and Unity developers often need to tackle OS specific challenges.

Through this talk you will discover how to work with Unity as an Android Developer. You will see how to build Unity plugins using the JNI and Java/Kotlin, which is the most efficient way to link Unity with the Android framework.

Every Unity project can be exported as an Android Studio project with a Gradle support. You'll also see how you can integrate Unity inside a native Android Java/Kotlin application, or how to get a full control of the build process so you can benefit from the best of both worlds.

Julien Salvi

November 27, 2020

More Decks by Julien Salvi

Other Decks in Programming


  1. Game Development with Unity from an Android Point of View

    Place your screenshot here Julien Salvi
  2. Android addict since Froyo PAUG, Punk & IPA! You can

    find me at @JulienSalvi Julien Salvi Senior Android Engineer @ aircall
  3. × Game Development on Android × Building Unity Plugins ×

    Unity from Android Studio × Unity as a Library
  4. 1. Game Development on Android A global overview

  5. Place your screenshot here Major Game engines for Android

  6. “More than 50% of new mobile games are made with

  7. Place your screenshot here Trusted by many studios

  8. × Available on Windows, Mac and Linux × 2D, 3D

    games or AR/VR apps × Fast prototyping, fast scripting × Supporting most of the 3D and 2D formats Great Asset Store! Game development on Android Building Android apps with Unity
  9. × OpenGL and Vulkan support × Bridge to native platforms

    × Android Studio project export × Java and Kotlin support Game development on Android Building Android apps with Unity
  10. 2. Building Unity Plugins Android to the rescue!

  11. Building Unity plugins Game Developers with Unity × Build apps

    with C# scripts × Control the rendering pipeline × Cross-platform shader compilation Bring the best experience at a high frame rate!
  12. For our fellow Unity developers

  13. Building Plugins for Unity 13

  14. × Build your plugin using Java/Kotlin or C/C++ × Android

    plugins might be: .jar, .aar or .so × Add Java or Kotlin classes directly into your Unity Project Build an Android Plugin for Unity
  15. Android Plugin for Unity For example let us build a

    player plugin for Unity Call player methods from Unity
  16. Unity They are best friends! Let’s eat some C# and

  17. J N I Java / Kotlin code C/C++ code Plugin

  18. public class PlayerBridge { private Context ctx; public PlayerBridge(Context ctx)

    {} public void addSubtitles(String path) {} public void doOnMainThread(boolean playWhenReady) {} public int getTrackCount() {} } Android Plugin for Unity
  19. Calling a JAVA/Kotlin object from Unity AndroidJavaObject localMediaPlayer = null;

    using (AndroidJavaClass javaUnityPlayer = new AndroidJavaClass("com.unity3d.player.UnityPlayer")) { using (currentActivity = javaUnityPlayer.GetStatic<AndroidJavaObject>("currentActivity")) { localMediaPlayer = new AndroidJavaObject("my/plugin/vr/PlayerBridge", currentActivity); if (localMediaPlayer != null) { // Do some work with your java object outside the Android UI thread localMediaPlayer.Call("addSubtitles", subtitleURL); int count = localMediaPlayer.Call<int>("getTrackCount"); currentActivity.Call("runOnUiThread", new AndroidJavaRunnable(() => { // Do some work on Android UI thread localMediaPlayer.Call("doOnMainThread", true); })); } } }
  20. Function inside your plugin Define the plugin function in your

    Unity script extern "C" { float FooPluginFunction (); } C/C++ Plugin [DllImport ("PluginName")] private static extern float FooPluginFunction ();
  21. Better performances when you call your Java plugin through the

    JNI Important: JVM loading jint JNI_OnLoad(JavaVM* vm, void* reserved) { JNIEnv* jni_env = 0; vm->AttachCurrentThread(&jni_env, 0); return JNI_VERSION_1_6; } Java and C/C++ Plugin
  22. Your C++ method in your JNI plugin JNIEXPORT jstring JNICALL

    Java_js_NativePlugin_getHiString(JNIEnv * env, jobject obj) { return env->NewStringUTF("Ciao droidcon Italy! Hope you have fun"); } C/C++ from Java or Kotlin
  23. JNI method for calling a method in a Java class

    JNIEXPORT jobject JNICALL Java_com_example_NativeClass_nativeMethod(JNIEnv* env) { jclass cls_JavaClass = env->FindClass("com/your/java/Class"); // find class definition jmethodID mid_JavaClass = env->GetMethodID (cls_JavaClass, "<init>", "()V"); // find constructor method jobject obj_JavaClass = env->NewObject(cls_JavaClass, mid_JavaClass); // create object instance return env->NewGlobalRef(obj_JavaClass); // return object with a global reference } Java and C/C++ Plugin
  24. static void UNITY_INTERFACE_API OnRenderEvent(int eventID) { switch((GLEvent)eventID) { case Initialize

    : InitMediaSurface(); break; case Shutdown : mediaSurface->Shutdown(); mediaSurface = NULL; break; case Update: mediaSurface->Update(); break; case Resize: mediaSurface->ResizeTexture(); break; } } Java and C/C++ Plugin static void UNITY_INTERFACE_API OnRenderEvent(int eventID); enum GLEvent { Initialize = 0, Shutdown = 1, Update = 2, Resize = 3 }; Sending event to the native surface for low-level rendering
  25. Set a native callback and dispatch an event to the

    native plugin from Unity // Set the native callback from Unity _inptr_native_callback_delegate = Marshal.GetFunctionPointerForDelegate(NativeCallback); // Native method from the plugin CINEVR_AndroidNative_SetNativeCallback(_inptr_native_callback_delegate); Java and C/C++ Plugin // Get native callback from the plugin to queue for Unity's renderer to invoke IntPtr _renderFunc = CINEVR_AndroidNative_GetRenderEventFunc(); // Dispatch the event to native plugin GL.IssuePluginEvent(_renderFunc, GLEventType.Initialize);
  26. From Kotlin C/C++ from Java or Kotlin external fun getHiString():

    String From Java public native String getHiString(); From Kotlin init { System.loadLibrary("sample-jni") } From Java static { System.loadLibrary("sample-jni"); }
  27. × Support available from 2018.2 × Add your files in

    a dedicated folder in the Asset Folder × Build with Gradle only × Use the AndroidJavaObject class to call methods in your plugin Building Unity Plugins Using Java or Kotlin source files as plugins
  28. × Enable Custom Gradle Templates property on the Player window

    × Override the generated mainTemplate.gradle file × You can also provide your own settings.gradle file Building Unity Plugins Add Gradle dependencies to your Unity project
  29. 3. Unity from Android Studio Live from the studios!

  30. That’s what we want!

  31. × Export your Unity project with Gradle or IL2CPP as

    Build System × Enable Symlink Sources if you have Java or Kotlin source files Unity from Android Studio Exporting a Unity Project
  32. × Have a full control of the build workflow ×

    Easily add Android code × Easy library management × Modify generated code Unity from Android Studio Exporting a Unity Project
  33. UnityPlayerActivity overview public class UnityPlayerActivity extends Activity { protected UnityPlayer

    mUnityPlayer; // don't change it, referenced from native code @Override protected void onCreate(Bundle savedInstanceState) { requestWindowFeature(Window.FEATURE_NO_TITLE); super.onCreate(savedInstanceState); getWindow().setFormat(PixelFormat.RGBX_8888); // <-- This makes xperia play happy mUnityPlayer = new UnityPlayer(this); setContentView(mUnityPlayer); mUnityPlayer.requestFocus(); } }
  34. Override the UnityPlayerActivity public class OverrideExample extends UnityPlayerActivity { @Override

    protected String updateUnityCommandLineArguments(String cmdLine) { if (Utils.preferVulkan()) return Utils.appendCommandLineArgument(cmdLine, "-force-vulkan"); else if (Utils.preferES2()) return Utils.appendCommandLineArgument(cmdLine, "-force-gles20"); else return cmdLine; // let Unity pick the Graphics API based on PlayerSettings } }
  35. 4. Unity as a library \ (•◡•) /

  36. Unity as a library Android loves Unity × Available since

    Unity 2019.3 × Add Unity content (AR/VR, 2D/3D games) directly to your Android apps × Proper library integration
  37. × Same way as it was before for exporting your

    project for Android Studio × Do not forget to enable Symlink Sources if you have Java or Kotlin source files Unity from Android Studio Exporting a Unity project as a library
  38. None
  39. class MainUnityActivity : OverrideUnityActivity() { protected fun onCreate(savedInstanceState: Bundle?) {

    super.onCreate(savedInstanceState) goBackBtn.setOnClickListener { _ -> showHomeActivity() } sendMsgBtn.setOnClickListener { _ -> UnitySendMessage("AndroidBuddy", "ChangeColor", "green") } finishBtn.setOnClickListener { _ -> finish() } } } Override the OverrideUnityActivity
  40. Unity as a library Limitations × Fullscreen rendering only ×

    Only one instance of the Unity runtime is supported × You may need to adapt your plugins to work properly × Might add a big dependency to the app
  41. Live demo! (from unity to Android)

  42. Unity as a library Want to know more? 01 02

    03 https://blogs.unity3d.com/2019/06/17/add-features-powered-by -unity-to-native-mobile-apps Unity as a Library https://forum.unity.com/threads/using-unity-as-a-library-in-nat ive-ios-android-apps.685195/ Using Unity as a library in native iOS/Android apps https://forum.unity.com/threads/integration-unity-as-a-library- in-native-android-app.685240/ Integration Unity as a library in native Android app
  43. Eh! What about Android from a Unity Point of view?

    random person in the audience - right now (maybe)
  44. I was about to tell them!

  45. Unity and android Android from a Unity Point of View

    × Easy to build on Android × Graphic libs support (OpenGL/Vulkan) Easy compat with ShaderLab × No need to dig into the Android documentation
  46. Unity and android Android from a Unity Point of View

    × How it is implemented under the hood × Building UI components × Integrating Unity games into Android apps… but Unity as a library is there!
  47. Want to know more? https://developer.android.com/game Android Game Development https://medium.com/@cinemur/73ec7e83dd5c ExoPlayer

    for building powerful VR players on Cardboard and GearVR https://docs.unity3d.com/Manual/PluginsForAndroid.html Building Unity Plugins for Android
  48. GraZie ! Have fun with Unity and Android! Any questions?
