  1. PayPay Step Merge Journey
    Scaling Out Transaction Aggregation
    Ville Misaki
    Oct, 2021
    1

    View Slide

  2. 2
    ● Ville Misaki
    ● From Helsinki, Finland
    ○ Currently living in Fukuoka, Japan – WFA
    ● Back-end software engineer
    ○ Since January 2021
    ○ Customer Lifecycle Management team
    Self Introduction

    View Slide

  3. 3
    ● What is PayPay Step?
    ○ Original Architecture
    ● PayPay Step Merge
    ○ Problem Statement
    ○ Scaling Out
    ○ Maintaining Accuracy
    ○ Speed vs. Batch
    ○ Special Edge Cases
    ● Outcome
    Agenda

    View Slide

  4. 4
    ● Monthly basic cash-back campaign
    ● Use more this month; get more cash-back next month
    ○ 50 txn ≥100 yen and/or ≥100,000 yen total value
    ○ 0.5% → 1% → 1.5%
    ● Original campaign 2020-04-01 ~ 2021-07-31
    What is PayPay Step?
    Counting
    period
    Effective
    period

    View Slide

  5. 5
    ● User’s current progress queried from transaction history
    ○ Aggregated as needed
    ■ User’s transaction count (≥100 yen) & value for target month
    ○ Always up-to-date – but heavy load on DB
    Original Architecture
    1
    2

    View Slide

  6. 6
    ● Campaign renewal project
    ○ Including other Yahoo! JAPAN services – “merge”
    ○ Campaign status visible from many new places
    ● New campaign rules from 2021-08-01 ~
    PayPay Step Merge

    View Slide

  7. 7
    ● Expecting a lot more traffic
    ○ We want to support 10,000+ RPS for status API
    ○ Need to be able to scale out
    ● Aggregation of transactions when viewing status
    ○ Heavy DB query
    ● Still keep near real-time
    ○ Users should see their purchases being reflected
    ○ Just caching results would cause lag
    Problem Statement

    View Slide

  8. 8
    ● Move aggregation to be done after transactions
    ○ Each user’s aggregated campaign status stored in DynamoDB
    ○ Very fast fetch of current status for scaling out
    Scaling Out

    View Slide

  9. 9
    ● Aggregation for campaign done in batches
    ○ Extra verification and control over data
    ○ Re-aggregation in case of issues or campaign rule changes
    Maintaining Accuracy

    View Slide

  10. 10
    ● Lambda architecture
    ○ Speed and batch processing
    ● Synchronize aggregations
    ○ Aggregation as daily changes
    ○ Boundary set by speed aggregation
    ● Special edge cases
    ○ Exactly-once Processing
    ○ Re-aggregation
    ○ Campaign rule changes
    Speed vs. Batch

    View Slide

  11. 11
    ● At least once
    ○ Provided by platform on each step
    ○ All events of transaction have its full history for filling gaps
    ■ E.g. Created → Completed → Refunded
    ○ Daily monitoring batch
    ● At most once
    ○ Deduplicate with transaction table
    Exactly-once Processing

    View Slide

  12. 12
    ● The world is not perfect
    ○ Mis-configurations, system trouble, bugs...
    ● Aggregation may need corrections
    ○ Speed aggregation – aggregated once
    ○ Batch aggregation – inherent re-aggregation
    Re-aggregation

    View Slide

  13. 13
    ● Campaign rules are not written in stone
    ● Two-month campaigns
    ○ Count and effective periods overlap
    ● Old and new campaign side by side
    ○ Versioning of results during batch – aggregate for both versions
    ○ Campaign configured with desired version
    Campaign Rule Changes
    July August September
    Counting v0 v1 v1
    Effective v0 v0 v1

    View Slide

  14. 14
    ● Lambda architecture
    ○ Combination of speed and batch processing
    ● Reached scalability goals
    ○ 10,000+ RPS for read
    ○ Near real-time aggregation
    ○ Robust, future-proof foundation
    ● The campaign is running
    ○ Check it out!
    Outcome

    View Slide

  15. Thank You
    15
