  1. Programming with Futures,
    Lattices, and Quiescence
    Philipp Haller
    KTH Royal Institute of Technology
    Sweden
    @philippkhaller
    1

    View Slide

  2. 2

    View Slide

  3. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Have we solved concurrent programming, yet?
    There are promising concurrent programming models
    and abstractions!
    3
    • Monitors
    • Futures, promises
    • Async/await
    • STM
    • Actors
    • Join-calculus
    • Agents
    • CSP
    • Reactive streams
    • …

    View Slide

  4. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Background
    • Authored or co-authored:
    – Scala Actors
    – Scala futures and promises
    – Scala Async
    • Contributed to Akka
    • Akka.js project at Typesafe
    4
    More proposals and
    research projects:
    •Scala Joins
    •FlowPools
    •Spores
    ..

    View Slide

  5. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Why are there so many?
    The problem with concurrency:
    – It’s difficult!
    – Multiple hazards:
    • Race conditions
    • Deadlocks
    • Livelocks
    • Violation of fairness
    5

    View Slide

  6. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Non-Determinism
    • At the root of several hazards
    • Example 1:
    6
    @volatile var x = 0
    def m(): Unit = {
    Future {
    x = 1
    }
    .. // does not access x
    x = 2
    }
    What’s the value of x
    • when m returns?
    • when the future is
    completed?

    View Slide

  7. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Non-Determinism
    • At the root of several hazards
    • Example 2:
    7
    @volatile var x = 0
    def m(): Unit = {
    Future {
    x = 1
    }
    Future {
    x = 2
    }
    .. // does not access x
    }
    What’s the value of x
    • when m returns?
    • when the futures
    are completed?

    View Slide

  8. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Reordering not always a problem!
    • Example 3:
    8
    import scala.collection.concurrent.TrieMap
    val set = new TrieMap[Int, Int]
    Future {
    set.put(1, 0)
    }
    set.put(2, 0)
    Eventually, set contains
    both 1 and 2, always
    Bottom line: it depends on the datatype

    View Slide

  9. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    … and its operations!
    • Example 4:
    9
    val set = new TrieMap[Int, Int]
    Future {
    set.put(1, 0)
    }
    Future {
    if (set.contains(1)) {
    ..
    }
    }
    set.put(2, 0)
    Result depends
    on schedule!

    View Slide

  10. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Important questions
    Q1:

    How do we know we have written a deterministic
    concurrent program?
    – What about Heisenbugs?
    • No race in 1’000’000 runs, race in run 1’000’001
    10
    Goal: simple criteria that guarantee determinism

    View Slide

  11. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Important questions
    Q2:

    How do we ensure expressivity while providing
    determinism?
    – Draconian restrictions undesired!
    11
    Goal: reconcile determinism and expressivity

    View Slide

  12. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Approach
    • Extend futures and promises with:
    – Lattice-based operations
    – Quiescence
    – Resolution of cyclic dependencies
    • Evaluation in terms of expressivity and performance
    – Case study: static analysis of JVM bytecode
    12
    Crucial for
    determinism!
    Increases
    expressivity!

    View Slide

  13. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Enter Reactive Async
    Programming model based on two core abstractions:

    cells and cell completers
    – Cell[K,V] extends Future[V]
    – CellCompleter[K,V] extends Promise[V]
    – V must have an instance of a lattice type class
    • Monotonic updates
    13

    View Slide

  14. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Example
    • Given a social graph
    – vertex = user
    • Traverse graph and collect IDs of “interesting” users
    • Graph large => concurrent traversal
    14

    View Slide

  15. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Solution
    • Collect IDs of interesting users in a cell
    • Cell contains set of integers
    15
    OK: subsets of the set of
    all integers form a lattice

    View Slide

  16. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Cell with user IDs
    (code simplified)
    16
    implicit object IntSetLattice extends Lattice[Set[Int]] {
    val empty = Set()
    def join(left: Set[Int], right: Set[Int]) = left ++ right
    }
    // add a user ID
    userIDs.putNext(Set(theUserID))
    val userIDs = CellCompleter[Set[Int]]
    Bounded

    join-semilattice

    View Slide

  17. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Reading the result
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    – There may still be ongoing concurrent activities
    – Manual synchronization (e.g., latches) error-prone
    • Solution:
    17
    Koyaanisqatsi
    Quiescence

    View Slide

  18. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Quiescence
    • Intuitively: situation when values of cells are
    guaranteed not to change any more
    • Technically:
    – No concurrent activities ongoing or scheduled
    which could change values of cells
    – Detected by the underlying thread pool
    18

    View Slide

  19. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Revisiting the example
    19
    // add a user ID
    userIDs.putNext(Set(theUserID))
    ..
    val pool = new HandlerPool
    val userIDs = CellCompleter[Set[Int]](pool)
    // register handler
    // upon quiescence: read result value of cell
    pool.onQuiescent(userIDs.cell) { collectedIDs =>
    ..
    }
    Safe to read
    from cell when pool
    quiescent!

    View Slide

  20. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Handler pools
    Execution context with extensions:
    – Event-driven quiescence API
    – Resolution of dependencies between cells
    20
    Dependency resolution?

    View Slide

  21. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Expressing concurrent dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    • Important purpose: express concurrent dataflow
    • Problem:
    21
    What if the dataflow graph is cyclic?
    Like futures
    fut
    fun
    fut’
    pred
    fut’’
    fut.map(fun).filter(pred)
    Futures

    View Slide

  22. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Dataflow graphs
    Example:
    • Static analysis of JVM bytecode
    • Task:

    Determine purity of methods
    • Rules:
    – A method is impure if it accesses a non-final field
    – A method is impure if it calls an impure method
    – …
    22
    A B
    C
    “calls”

    View Slide

  23. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Cycle resolution
    • What if upon quiescence cells are empty and there is a
    dependency cycle?
    • Idea:

    Pluggable resolution policies
    • Example:

    Purity analysis should resolve all cells

    in cycle to “pure”, since could not show impurity
    23
    A B
    C

    View Slide

  24. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Specifying resolution policies
    • Role of the first type parameter of Cell[K,V]
    • Example:
    24
    object PurityKey extends Key[Purity] {
    def resolve[K cells.map(cell => (cell, Pure))
    ..
    }
    closed strongly-
    connected component
    resolve all
    cells to Pure

    View Slide

  25. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Purity analysis: set up
    25
    for {
    classFile method } {
    val methodCompleter = CellCompleter(pool, PurityKey)
    pool.execute {
    analyze(project, methodCompleter, classFile, method)
    }
    }
    val analysisDoneFuture = pool.quiescentResolveCells()

    View Slide

  26. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Evaluation
    • Static analysis of JVM bytecode using the OPAL
    framework (OPen extensible Analysis Library)
    – Newly developed, highly adaptable bytecode toolkit
    – Fully concurrent
    • Rewrote purity analysis and immutability analysis
    • Ran analysis on JDK 8 (rt.jar)
    – 18’591 class files, 163’268 methods, 77’128 fields
    26
    http://www.opal-project.de

    View Slide

  27. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Preliminary results
    • RA’s implementation not yet optimized
    27
    RA 15% faster than OPAL’s implementation with
    • code size reduced by a factor of two
    • determinism properties

    View Slide

  28. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Ongoing and future work
    • Benchmarking and optimization
    • Determinism as an effect
    – Determinism guaranteed by type checker
    – Effect system for Dotty
    • Macro support à la Async?
    28

    View Slide

  29. Programming with Futures, Lattices, and Quiescence — Philipp Haller
    Reactive Async: conclusion
    • New concurrent programming model
    – Lattices and quiescence for determinism
    – Resolution of cyclic dependencies
    • Promising preliminary results
    • Future: static checking of determinism via effects
    29
    https://github.com/phaller/reactive-async
    Thank you!
