  1. Level Up with Android Build Variants

  2. Why do I care? • It’d be nice to build

    multiple variants of an Android app from a single code base • Common variants include: ◦ debug/release ◦ free/paid ◦ dev/staging/production
  3. With Eclipse and Ant • Code base contained in library

    project • Needed an additional project for each variant which referenced library project
  4. None
  5. With Android Studio and Gradle • All contained in single

    project • Define Build Types and Product Flavours in build.gradle file • Create src directories to hold code specific to each build type/flavour
  6. None
  7. Build Types • Define how to build and package your

    app • debug and release build types created by default • Can create your own
  8. signingConfigs { release { storeFile file( 'release.keystore' ) storePassword 'verysecurepassw0rd'

    keyAlias 'release' keyPassword 'verysecurepassw0rd' } } buildTypes { release { minifyEnabled true shrinkResources true proguardFiles getDefaultProguardFile( 'proguard-android.txt' ), 'proguard-rules.pro' signingConfig signingConfigs.release } debug{ applicationIdSuffix ".debug" signingConfig null } }
  9. Product Flavours • Provide alternative code, resources or configuration •

    Examples: ◦ Different API endpoints for dev/staging/production environment ◦ Free/paid version
  10. Free / Paid • Provide alternative resources and code by

    creating flavour directory • Gradle creates combination of each Build Type and Product Flavour
  11. productFlavors{ free{ applicationId "com.physphil.android.sandbox.free" } paid{ applicationId "com.physphil.android.sandbox.pro" } }

    } dependencies { compile fileTree(dir: 'libs', include: ['*.jar']) compile 'com.android.support:appcompat-v7:22.2.1' compile 'de.greenrobot:eventbus:2.4.0' // Only full version requires network calls paidCompile 'com.squareup.retrofit:retrofit:1.9.0' paidCompile 'com.squareup.okhttp:okhttp:2.2.0' }
  12. None
  13. Free / Paid

  14. Dev / Staging / Production • Define flavour for each

    server environment • Store API base URL in a Config class • Create directory in src for each flavour, which contains an instance of Config
  15. buildTypes { release { minifyEnabled true shrinkResources true proguardFiles getDefaultProguardFile(

    'proguard-android.txt' ), 'proguard-rules.pro' signingConfig signingConfigs.release } debug { applicationIdSuffix ".debug" signingConfig null } } productFlavors { dev staging production }
  16. None
  17. That’s Not All! • Modify more build parameters • Include

    libraries, code, Activities etc only when required • Lots of examples in official docs
  18. Additional Resources • http://tools.android.com/tech-docs/new-build- system/user-guide • https://developer.android. com/tools/building/configuring-gradle.html • http://www.vogella.

    com/tutorials/AndroidBuild/article.html
  19. Questions?
