Azure Route Exchange Phil Huang <
[email protected]
> Sr. Cloud Solution Architect
2022/11/29 以 Azure VMware Solution 為例
Challenge Azure Networking
FortiGate 60E wan1 Public IP: x.x.x.x internal1 192.168.100.254/24 Surface 192.168.100.6/24
Azure VMware Solution 10.7.0.0/22 D-MSEE
On-premise Source IP: 192.168.100.6 vCenter IP of Azure VMware Solution
in Canada Central : 10.7.0.2
Hint Azure Networking
Azure VMware Solution 連線特性 Already enable VMware NSX-T Edge •
一座 Azure VMware Solution 提供 2 種 Peering 方式 1. Azure ExpressRoute 2. Azure ExpressRoute Global Reach (對方也須具備 ExpressRoute 才能用) • 預設狀況下,AVS BGP Peering 是由 Azure 所自動設定 • AS Path: 64513 (AVS BGP ASN) -> 65100 -> ... -> 398656 -> 12076 -> Customer Managed ASN
Azure ExpressRoute 連線特性 Private Connection to Microsoft Cloud Ref: https://learn.microsoft.com/en-us/azure/route-server/expressroute-vpn-support
• 若已具備 ExpressRoute 且須連到指定 Azure VNet, 則需在該 Azure VNet 使用 Virtual Network Gateway (VNG) 並採用 ExpressRoute Type 接入網 路 • 若有需要跟其他線路進行路由,則需要在該 Azure VNet 使用 Azure Route Server,並啟用 Branch-to- Branch 協助路由宣告 (Route Propagate)
Virtual Network Gateway 使用特性 Access to Azure virtual network •
Virtual Network Gateway 提供 2 種 Gateway Type,可共存 同一個 Azure VNet 1. VPN 2. ExpressRoute • 若需與 Azure Route Server 交換路由,則需要滿足下列條件
觀察 BGP Peer 及 Learned Routes 狀態 Virtual Network Gateway
• 選擇 VPN Gateway > Monitoring > BGP Peers
Azure Route Server 使用特性 Enables exchange route information with Azure
virtual networks • 預設狀況下,Azure Route Server 會啟用 BGP,且 ASN 為 65515 • 無需額外進行 BGP Peer 操作,預設自動跟所在 Azure VNet 之 GatewaySubnet 進行路由交換
Route Exchange with Static Route between ExpressRoute and S2S VPN
Case 1 Common Use Case!!!
Ref: FortiGate 60E wan1 Public IP: x.x.x.x internal1 192.168.100.254/24 Surface
192.168.100.6/24 • No BGP • Static Route Only Azure VMware Solution 10.7.0.0/22 D-MSEE ExpressRoute vnet-hub 10.10.0.0/24 ExpressRoute Gateway GatewaySubnet 10.10.0.0/27 AzureRouteSubnet 10.10.0.32/27 ars-hub ASN: 65515 private-ip: 10.10.0.37 private-ip: 10.10.0.36 S2S VPN Gateway pip-vpn-1 pip-vpn-2 pip-er pip-ars private-ip-1: 10.10.0.14 private-ip-2: 10.10.0.15 ASN: 65515 Solution - Create VNet - Create ExpressRoute Gateway (Basic SKU) - Create VPN Gateway - Active-Active Mode - Enable BGP - ASN: 65515 - Create Azure Route Server - Enable branch-to-branch
Ref: FortiGate 60E wan1 Public IP: x.x.x.x internal1 192.168.100.254/24 Surface
192.168.100.6/24 • No BGP • Static Route Only vWAN 10.10.0.0/24 ExpressRoute Gateway GatewaySubnet 10.10.0.0/27 AzureRouteSubnet 10.10.0.32/27 ars-hub ASN: 65515 private-ip: 10.10.0.37 private-ip: 10.10.0.36 S2S VPN Gateway pip-vpn-1 pip-vpn-2 pip-er pip-ars private-ip-1: 10.10.0.14 private-ip-2: 10.10.0.15 ASN: 65515 Azure VMware Solution 10.7.0.0/22 D-MSEE ExpressRoute Solution - Create vWAN - Create vHub
Case 1 Azure VMware Solution NSX-T T0 BGP ASN: 64513
10.7.0.0/22
Route Exchange with eBGP between ExpressRoute and S2S VPN Case
2
Ref: FortiGate 60E ASN: 65533 wan1 Public IP: x.x.x.x internal1
192.168.100.254/24 Surface 192.168.100.6/24 • BGP ASN: 65533 Azure VMware Solution 10.7.0.0/22 D-MSEE ExpressRoute vnet-hub 10.10.0.0/24 ExpressRoute Gateway GatewaySubnet 10.10.0.0/27 AzureRouteSubnet 10.10.0.32/27 ars-hub ASN: 65515 private-ip: 10.10.0.37 private-ip: 10.10.0.36 S2S VPN Gateway pip-vpn-1 pip-vpn-2 pip-er pip-ars private-ip-1: 10.10.0.14 private-ip-2: 10.10.0.15 ASN: 65515 Solution - Create VNet - Create ExpressRoute Gateway (Basic SKU) - Create VPN Gateway - Active-Active Mode - Enable BGP - ASN: 65515 - Create Azure Route Server - Enable branch-to-branch
Case 2: Route Traffic Azure VMware Solution NSX-T T0 BGP
ASN: 64513 10.7.0.0/22 ASN: 65533
Route Exchange with multi eBGP between ExpressRoute and S2S VPN
Case 3
Ref: FortiGate 60E ASN: 65533 wan1 Public IP: x.x.x.x internal1
192.168.100.254/24 Surface 192.168.100.6/24 Azure VMware Solution 10.7.0.0/22 D-MSEE ExpressRoute vnet-hub 10.10.0.0/24 ExpressRoute Gateway GatewaySubnet 10.10.0.0/27 AzureRouteSubnet 10.10.0.32/27 ars-hub ASN: 65515 private-ip: 10.10.0.37 private-ip: 10.10.0.36 S2S VPN Gateway pip-vpn-1 pip-vpn-2 pip-er pip-ars private-ip-1: 10.10.0.14 private-ip-2: 10.10.0.15 ASN: 300 Solution - Create VNet - Create ExpressRoute Gateway (Basic SKU) - Create VPN Gateway - Active-Active Mode - Enable BGP - ASN: 300 - Create Azure Route Server - Enable branch-to-branch
Case 3: Route Traffic ASN: 300 Azure VMware Solution NSX-T
T0 BGP ASN: 64513 10.7.0.0/22
Conclusion Azure Networking • 若於地端並無配置 BGP 設計,僅具有 Static Route /
Policy Route,則可以透過 Case 1 方式將路由接入 至 Azure • 若地端有 BGP 設定,則可透過 Case 2 與 Azure Private ASN 65515 進行路由交換 • 若有特殊架構規劃需求,則可透過 Case 3 或額外建立 NVA (如 FRRouting on Azure VM / 3rd party SD- WAN / vRouter 等) 實踐
Invent with purpose.
