1. Active/Passive HA FortiGate Pair with External and Internal Azure Load Balancer Phil Huang <phil.huang@microsoft.com> Sr. Cloud Solution Architect | CNCF Ambassador 2024/10/27 Fortinet on Azure
2. Fortinet/azure-templates
3. Base: Fortinet / azure-templates https://github.com/fortinet/azure-templates/tree/main/FortiGate/Active-Passive-ELB-ILB
4. Differences This templates mainly have internet capability, but I don't need internet connection here, so I added Private load balancer by myself.
5. Azure
6. Route Table View
7. Effective Routes: vm-blue
8. Effective Routes: vm-yellow Additional UDRs need to be written to override the Vnet Peering routes ILB
9. Effective Routes: vm-red
10. Effective Routes: vm-green Same as vm-red
11. External/Internal Load Balancer: Health Probes The Health Probes will need to work with FGT’s internal setting “config system probe-respone” https://github.com/fortinet/azure-templates/blob/main/FortiGate/Active-Passive-ELB-ILB/doc/config-ha.md
12. External/Internal Load Balancer: Health Probe Status If the FGT are configured in Active-Passive mode, it is expected that the 2nd firewall WILL NOT respond to Load Balancer
13. External/Internal Load Balancer: Rules External Private LB Internal Private LB External Private LB (172.16.0.10) Internal Private LB (172.16.0.68) Traffic transiting via FGT VMs https://github.com/fortinet/azure-templates/blob/main/FortiGate/Active-Passive-ELB-ILB/doc/config-inbound-connections.md#when-to-enable-the-floating-ip-in-the-azure-load-balancing-rule Traffic transiting via FGT VMs If you will need to use Ipsec Tunnels, you will need to disable Floating IP
14. FortiGate
15. Interface View (FGT A) External Interface Internal Interface HA Sync Interface Mgmt Interface
16. Enable Specific probe config on TCP/8008 https://community.fortinet.com/t5/FortiGate/Technical-Tip-FortiGate-VM-probe-on-Azure-or-AWS-load-balancer/ta-p/250184
17. Static Route: Static Route to Azure DNS https://learn.microsoft.com/en-us/azure/load-balancer/load-balancer-custom-probe-overview#probe-source-ip-address 168.63.129.16/32 Interface GW IP Interface Name You MUST ALLOW 168.63.129.16/32 in any Azure NSG and FortiGate Firewall Policy
18. Static Route: Route via External Interface External CIDRs External Interface GW IP External Interface Name
19. Static Route: Route via Internal Interface Internal CIDRs Internal Interface GW IP Internal Interface Name
20. Firewall Policy Should be disable NAT Since there is a need for East-West (Spoke to Spoke) Vnet traffic, this needs to be set specifically, otherwise the default will be denied !!! Please config the FGT Firewall Policy according to the actual situation
21. Scenario 1: FGT HA Failover Test
22. Scenario 1: FGT HA Failover Test Before
23. Scenario 1: FGT HA Failover After
24. Scenario 1: FGT HA Result (failover)
25. Scenario 1: FGT HA Result (failback)
26. Scenario 2: Network Reachable
27. Scenario 2: Network Reachability Test (Blue)
28. Scenario 2: Network Reachability Test (Blue)
29. Scenario 2: Network Reachability Test (Green / Red)
30. Scenario 2: Network Reachability Test (Green / Red)
31. Scenario 2: Network Reachability Test (Yellow)
32. Scenario 2: Network Reachability Test (Yellow)
33. Scenario 3: Latency
34. Scenario 3: Latency Since all my testing VM are b1ms models and do not support accelerated network capability, I do not perform this test
