Android API Integration Tests with Mocked Endpoints

Android API Integration Tests with Mocked Endpoints

Android developers often fetch data from HTTP endpoints to display it on the device. These endpoints can be a major source of frustration, especially when they are backed by complex legacy systems. One easy source of testing that will actually speed the pace of development from the beginning is end-to-end integration tests with those endpoints. However, in the end the tests can only be as stable as the environment they’re testing. I shall present a framework for creating these tests and partially automate creating an OkHttp interceptor that will provide mocked responses to ensure the stability of the tests. With this framework and this interceptor, integration tests can distinguish between a failure caused by a change to the behavior of the endpoint and a failure caused by a change to the application source.

1f47666b9f447ac8640c6ff2cd9e6f0a?s=128

politedog

July 13, 2017
Tweet

Transcript

  1. Android API Integration Tests with Mocked Endpoints Chris Koeberle @kodi

    Bottle Rocket bit.ly/cdk-mock-pdf
  2. Agenda • Problem statement • Requirements • Testing network calls

    • Mocking network responses
  3. The Problem • Android apps fetch data from HTTP endpoints

    to display it on the device • If backend systems are designed with mobile in mind, this can be straightforward and easy • When working with one or more legacy systems, just constructing the request and parsing the response can be a challenge • Reducing the iteration time when trying to diagnose weird hijinks is paramount
  4. Solutions • The worst way to do this is to

    run the app • Tools like Postman, Charles, and Fiddler can help solve problems but don’t leave you with working code • Integration tests allow you to test the full stack without worrying about UI or waiting to install the APK • In principle, you can have the entire networking layer proved out without a single Activity • In order for the integration tests to have ongoing value, they must be able to distinguish between a local failure and a remote failure • If we’re calling an endpoint that has side effects, we might want to limit how often we actually call the endpoint
  5. Requirements • Dependency Injection or Service Locator • OkHttp •

    Some way of getting off the main thread • If they way you get off the main thread has problems with the Looper, you might need to mock your own Looper • Patience dependencies {
 compile 'com.android.support:appcompat-v7:25.0.1'
 compile fileTree(dir: 'libs', include: ['*.jar'])
 testCompile fileTree(include: ['*.jar'], dir: 'testlibs')
 testCompile 'junit:junit:4.12'
 testCompile 'org.mockito:mockito-core:1.10.19'
 compile ‘io.reactivex.rxjava2:rxandroid:2.0.1'
 compile ‘io.reactivex.rxjava2:rxjava:2.1.1'
 compile 'com.bottlerocketstudios:groundcontrol:1.1.3'
 compile ‘com.squareup.okhttp3:okhttp:3.8.1'
 compile ‘com.google.code.gson:gson:2.8.0’
 compile 'joda-time:joda-time:2.7'
 compile 'com.jakewharton.timber:timber:4.4.0'
 }
  6. The Example • Most confusing, archaic legacy systems are private

    • It’s harder to see what’s going on when you’re looking at something confusing, anyway • Being able to call POST endpoints that create content generally requires login • Login will also make it harder to see the important stuff • So let’s look at Github, which will let us create an anonymous gist • This simpler example covers most of the difficulties I’ve faced in supporting a hundred different endpoints • Follow along at bit.ly/cdk-mock-git
  7. Dependency Injection • Dependency injection allows us to change how

    things are mocked in tests on the fly. • This example uses ServiceLocator pattern instead of dependency injection public class ServiceLocator {
 Map<Class<?>, Object> mLocatorMap;

 private ServiceLocator() {
 mLocatorMap = new HashMap<>();
 }

 private static class SingletonHolder {
 static final ServiceLocator instance = new ServiceLocator();
 }

 private static ServiceLocator getInstance() {
 return SingletonHolder.instance;
 }

 public static <T> void put(Class<T> type, T instance) {
 if (type == null) { throw new NullPointerException(); }
 getInstance().mLocatorMap.put(type, instance);
 }

 public static <T> T get(Class<T> type) {
 return (T) getInstance().mLocatorMap.get(type);
 }
 } public class ServiceInjector {
 public static <T> T resolve(Class<? extends T> type) {
 return ServiceLocator.get(type);
 }
 } ServiceLocator.put(RxEndpoints.class, new RxEndpointsImpl()); Flowable<User> flowable = ServiceInjector .resolve(RxEndpoints.class) .getUser("bottlerocketapps");
  8. OkHttp • Need to set up OkHttpClient so it can

    be injected • This is a good practice for other reasons - TLS support on 4.4, etc. public class OkHttpClientUtil {
 private static final long READ_TIMEOUT = 120;

 public static OkHttpClient getOkHttpClient(Context context, MockBehavior mock) {
 OkHttpClient okHttpClient = null;
 OkHttpClient.Builder builder = new OkHttpClient.Builder();
 if(mock != MockBehavior.DO_NOT_MOCK) {
 builder.addInterceptor(new MockedApiInterceptor(context, mock));
 }
 okHttpClient = builder
 .readTimeout(READ_TIMEOUT, TimeUnit.SECONDS)
 .retryOnConnectionFailure(false)
 .build();
 return okHttpClient;
 }
 } … ServiceLocator.put(OkHttpClient.class, OkHttpClientUtil.getOkHttpClient(null, MockBehavior.MOCK)); … subscriber.onNext(ServiceInjector.resolve(OkHttpClient.class).newCall(request).execute());
  9. RxJava • RxJava is very flexible. This isn’t the only

    way; it’s likely not the best way. • This uses RxJava 2.1.1 private Flowable<Response> getResponse(final HttpUrl url) { return Flowable.fromCallable(new Callable<Response>() { @Override public Response call() throws Exception { System.out.println(url); Request request = ServiceInjector.resolve(ServiceConfiguration.class).getRequestBuilder() .url(url) .build(); return ServiceInjector.resolve(OkHttpClient.class).newCall(request).execute(); } }); } @Override
 public Flowable<User> getUser(String userName) {
 HttpUrl url = ServiceInjector.resolve(ServiceConfiguration.class).getUrlBuilder()
 .addPathSegment(USER)
 .addPathSegment(userName)
 .build();
 return getResponse(url)
 .flatMap(new FetchString())
 .flatMap(new ToJson<User>(UserImpl.class));
 }
  10. RxJava • These functions support the flatMaps on the previous

    page private class FetchString implements Function<Response, Flowable<String>> { @Override public Flowable<String> apply(final Response response) { return Flowable.fromCallable(new Callable<String>() { @Override public String call() throws Exception { if (!response.isSuccessful()) { throw new IOException(response.message()); } String responseString = response.body().string(); System.out.println(responseString); return responseString; } }); } } private class ToJson<T> implements Function<String, Flowable<T>> { private final Class mTargetClass; private ToJson(Class mTargetClass) { this.mTargetClass = mTargetClass; } @Override public Flowable<T> apply(final String s) { return Flowable.fromCallable(new Callable<T>() { @Override public T call() throws Exception { return (T) ServiceInjector.resolve(Gson.class).fromJson(s, mTargetClass); } }); } }
  11. Testing the Observable • The only testing framework we need

    is Junit • We have a few dependencies that stay the same for all the tests • So we’ll have a base test that sets those up public class BaseApiTest {
 @Before
 public void setup() {
 ServiceLocator.put(RxEndpoints.class, new RxEndpointsImpl());
 ServiceLocator.put(ServiceConfiguration.class, new ServiceConfigurationImpl());
 ServiceLocator.put(Gson.class, GsonUtil.getGson());
 }
 } • RxEndpoints is our collection of RxJava observable creators • ServiceConfiguration would allow us to change to a staging environment • Gson can be frustrating, but it makes setting up examples very fast!
  12. Testing the Observable • Each test injects its own OkHttpClient

    so it can control mocking • This is not a unit test; just validate enough to know that the response makes sense. • Here, for example, we just make sure that: • The call completed • We found one organization with the orgName bottlerocketstudios • Its name is Bottle Rocket Studios @Test public void testOrganization() { ServiceLocator.put(OkHttpClient.class, OkHttpClientUtil.getOkHttpClient(null, MockBehavior.MOCK)); Flowable<Organization> flowable = ServiceInjector.resolve(RxEndpoints.class).getOrg("bottlerocketstudios"); TestSubscriber<Organization> testSubscriber = new TestSubscriber<>(); flowable.subscribe(testSubscriber); testSubscriber.assertComplete(); List<Organization> orgList = testSubscriber.values(); assertEquals(orgList.size(), 1); assertEquals(orgList.get(0).getName(), "Bottle Rocket Studios"); }
  13. Testing the Observable • Sometimes, we need to chain calls

    - retrieving a list of items, then fetching detail about one item • Here, for example, we get a list of gists, then we retrieve detail for the first one in the list and expect it to have the same description • Again, the goal here is not to prove anything about the objects, but to validate that we’re calling the endpoints successfully public class GistTest extends BaseApiTest { @Test public void testAllGists() { ServiceLocator.put(OkHttpClient.class, OkHttpClientUtil.getOkHttpClient(null, MockBehavior.MOCK)); Flowable<Gist[]> flowable = ServiceInjector.resolve(RxEndpoints.class).getGists(); TestSubscriber<Gist[]> testSubscriber = new TestSubscriber<>(); flowable.subscribe(testSubscriber); testSubscriber.assertComplete(); List<Gist[]> gists = testSubscriber.values(); Gist gist = gists.get(0)[0]; Flowable<Gist> gistFlowable = ServiceInjector.resolve(RxEndpoints.class).getGist(gist.getId()); TestSubscriber<Gist> gistTestSubscriber = new TestSubscriber<>(); gistFlowable.subscribe(gistTestSubscriber); Gist detailGist = (Gist) gistTestSubscriber.values().get(0); assertEquals(detailGist.getDescription(), gist.getDescription()); } }
  14. Testing the Observable • What if we make a call

    with side effects? • Every time I run this test, it will create a new, identical gist • Eventually, GitHub will flag my entire IP for spamming! private static final String CREATE_FILE_NAME = "AbstractMockedInterceptor.java"; private static final String CREATE_DESCRIPTION = "An OkHttp Interceptor that returns mocked results if it has them."; @Test public void createGist() throws IOException { ServiceLocator.put(OkHttpClient.class, OkHttpClientUtil.getOkHttpClient(null, MockBehavior.MOCK_ONLY)); Gist gist = new GistImpl(); gist.setDescription(CREATE_DESCRIPTION); gist.addFile(CREATE_FILE_NAME, readFromAsset("mocks/javaclass")); Flowable<Gist> flowable = ServiceInjector.resolve(RxEndpoints.class).createGist(gist); TestSubscriber<Gist> testSubscriber = new TestSubscriber<>(); flowable.subscribe(testSubscriber); testSubscriber.assertComplete(); List<Gist> gistList = testSubscriber.values(); Gist resultGist = gistList.get(0); Flowable<Gist> gistFlowable = ServiceInjector.resolve(RxEndpoints.class).getGist(resultGist.getId()); TestSubscriber<Gist> gistTestSubscriber = new TestSubscriber<>(); gistFlowable.subscribe(gistTestSubscriber); Gist detailGist = gistTestSubscriber.values().get(0); assertEquals(detailGist.getDescription(), CREATE_DESCRIPTION); }
  15. A Mocked Interceptor • http://tinyurl.com/cdk-mock public abstract class AbstractMockedApiInterceptor implements

    Interceptor {
 public AbstractMockedApiInterceptor(Context context, MockBehavior mock) {
 if (context != null) { mContext = context.getApplicationContext(); } else { mContext = null; }
 mMockBehavior = mock;
 }

 @Override
 public Response intercept(Chain chain) throws IOException {
 Request request = chain.request();
 NetworkCallSpec mockFound = null;
 for (NetworkCallSpec spec : mResponseList) {
 if (spec.matches(request.url(), request.method(), stringifyRequestBody(request))) {
 mockFound = spec;
 Response.Builder builder = new Response.Builder();
 String bodyString = resolveAsset("mocks/"+spec.mResponseFilename);
 bodyString = substituteStrings(bodyString, request);
 if(bodyString != null) {
 ResponseBody body = ResponseBody.create(MediaType.parse(getMockedMediaType()), bodyString);
 builder = builder.body(body).request(request).protocol(Protocol.HTTP_1_1).code(spec.mResponseCode).message(spec.mResponseMessage);
 }
 if (!ignoreExistingMocks()) {
 noteThatThisFileWasUsed(spec.mResponseFilename);
 return builder.build();
 }
 }
 }
 if (fetchNetworkResults()) {
 Response response = chain.proceed(request);
 response = memorializeRequest(request, response, mockFound);
 return response;
 }
 throw new IOException("Unable to handle request with current mocking strategy");
 }

 protected boolean fetchNetworkResults() { return mMockBehavior != MockBehavior.MOCK_ONLY; }
 protected boolean ignoreExistingMocks() { return mMockBehavior == MockBehavior.LOG_ONLY; }
 protected String getMockedMediaType() { return "json"; }
 }
  16. A Mocked Interceptor • The basic flow: • Iterate through

    the list of response specifications • If one matches, build a response from it and return it • If none matches, make the network call and save it for future use public abstract class AbstractMockedApiInterceptor implements Interceptor {
 @Override
 public Response intercept(Chain chain) throws IOException {
 Request request = chain.request();
 NetworkCallSpec mockFound = null;
 for (NetworkCallSpec spec : mResponseList) {
 if (spec.matches(request.url(), request.method(), stringifyRequestBody(request))) {
 mockFound = spec;
 Response.Builder builder = new Response.Builder();
 String bodyString = resolveAsset("mocks/"+spec.mResponseFilename);
 bodyString = substituteStrings(bodyString, request);
 if(bodyString != null) {
 ResponseBody body = ResponseBody.create(MediaType.parse(getMockedMediaType()), bodyString);
 builder = builder.body(body).request(request).protocol(Protocol.HTTP_1_1).code(spec.mResponseCode).message(spec.mResponseMessage);
 }
 if (!ignoreExistingMocks()) {
 noteThatThisFileWasUsed(spec.mFilename);
 return builder.build();
 }
 }
 }
 if (fetchNetworkResults()) {
 Response response = chain.proceed(request);
 response = memorializeRequest(request, response, mockFound);
 return response;
 }
 throw new IOException("Unable to handle request with current mocking strategy");
 }
 }
  17. Matching Requests public static class NetworkCallSpec {
 private final String

    mRequestUrlPattern;
 private String mRequestMethod;
 private Map<String, String> mRequestQueryParameters;
 private String mRequestBody;
 private Set<String> mRequestBodyContains;
 private int mResponseCode;
 private String mResponseMessage;
 private final String mResponseFilename;

 public boolean matches(HttpUrl url, String method, String body) {
 if (!url.encodedPath().matches(mRequestUrlPattern)) { return false; }
 if (!mRequestMethod.equalsIgnoreCase(method)) { return false; }
 if (mRequestMethod.equalsIgnoreCase("POST") && !TextUtils.isEmpty(mRequestBody) && !mRequestBody.equalsIgnoreCase(body)) {
 return false;
 }
 … • NetworkCallSpec defines what requests will match a given response • Start with the easiest, fastest cases - if the url doesn’t match, if the method doesn’t match, if we require a particular POST body
  18. Matching Requests • Then do the more expensive checks -

    if we’re looking for a string inside the POST body, or if we need to find particular parameters • Header values can use regular expressions for matching … for (String contains : mRequestBodyContains) {
 if (!body.contains(contains)) {
 return false;
 }
 }
 }
 for (Map.Entry<String, String> kvp : mRequestQueryParameters.entrySet()) {
 boolean foundKey = false;
 boolean foundValue = false;
 for (String key : url.queryParameterNames()) {
 if (key.matches(kvp.getKey())) {
 foundKey = true;
 String value = url.queryParameter(key);
 if (value != null && value.matches(kvp.getValue())) {
 foundValue = true;
 }
 if (value == null && (kvp.getValue() == null || kvp.getValue() == "" || kvp.getValue().equalsIgnoreCase("null"))) {
 foundValue = true;
 }
 }
 }
 if (!foundKey || !foundValue) {
 return false;
 }
 }
 return true;
 }
  19. Building Responses • Once we have identified a mocked response,

    we do our best to make it look like it originally did - within the limits of what our app cares about • If we’re running as a JUnit test, we don’t have a context, and we read from test/resources/mocks/ • If we’re running in the app, we read from assets/mocks/ • Use build.gradle Copy task to copy from assets/ into test/resources/ Response.Builder builder = new Response.Builder();
 String bodyString = resolveAsset("mocks/"+spec.mFilename);
 bodyString = substituteStrings(bodyString, request);
 if(bodyString != null) {
 ResponseBody body = ResponseBody.create(MediaType.parse(getMockedMediaType()), bodyString);
 builder = builder.body(body).request(request).protocol(Protocol.HTTP_1_1).code(spec.mResponseCode).message(spec.mResponseMessage);
 }
 if (!ignoreExistingMocks()) {
 noteThatThisFileWasUsed(spec.mFilename);
 return builder.build();
 } private String resolveAsset(String filename) {
 if (mContext != null) {
 return getAssetAsString(mContext, filename);
 } else {
 try {
 return readFromAsset(filename);
 } catch (IOException e) {
 Timber.e(e, "Error reading from asset - this should only be called in tests.");
 }
 }
 return null;
 }

  20. Saving New Mocks • When we retrieve a new file,

    we save it so we can mock it • Build up the code to register the NetworkCallSpec, and save off the file • Add everything that could be used to specify the endpoint, and then manually delete things that don’t make sense private Response memorializeRequest(Request request, Response response, NetworkCallSpec mockFound) {
 Response.Builder newResponseBuilder = response.newBuilder();
 try {
 String responseString = response.body().string();
 List<String> segments = request.url().encodedPathSegments();
 String endpointName = segments.get(segments.size() - 1);
 String callSpecString = "mResponseList.add(new NetworkCallSpec(\""+request.url().encodedPath()+"\", \"::REPLACE_ME::\")";
 if (response.code() != HttpURLConnection.HTTP_OK) {
 callSpecString += ".setResponseCode("+response.code()+")";
 endpointName += "-"+response.code();
 }
 if (!TextUtils.isEmpty(response.message()) && !response.message().equalsIgnoreCase("OK")) {
 callSpecString += ".setResponseMessage(\""+response.message()+"\")";
 }
 if (!request.method().equalsIgnoreCase("GET")) {
 callSpecString += ".setRequestMethod(\""+request.method()+"\")";
 endpointName += "-"+request.method();
 }
 if (request.url().querySize()>0) {
 for (String key : request.url().queryParameterNames()) {
 callSpecString += ".addRequestQueryParameter(\""+key.replace("[", "\\\\[").replace("]", "\\\\]")+"\", \""+request.url().queryParameter(key)+"\")";
 }
 }
 … mResponseList.add(new NetworkCallSpec("/users/bottlerocketstudios", "bottlerocketstudios"));
  21. Saving New Mocks • Save the entire body of a

    POST request, even though it’s not a good practice to try to match on the whole body - at least it’s available • Make the name unique so that the new file won’t overwrite something • If we’re on device, write to our FilesDir. In test, it just goes to the app root … String body = stringifyRequestBody(request);
 if (body != null) {
 callSpecString += ".addRequestBody(\""+body.replace("\"", "\\\"").replace("\\u003d", "\\\\u003d")+"\")";
 endpointName += "-"+body.hashCode();
 }
 requestSpecString += ");";
 if (endpointName.length()>100) {
 endpointName = ""+endpointName.hashCode();
 }
 endpointName = getUniqueName(endpointName);
 callSpecString = callSpecString.replace("::REPLACE_ME::", endpointName);
 if (mockFound != null) {
 callSpecString += " // duplicate of existing mock "+mockFound.mPattern;
 if (!TextUtils.isEmpty(mockFound.mRequestBody)) {
 callSpecString += " with body "+mockFound.mRequestBody;
 }
 }
 callSpecString += "\n";
 writeToFile(callSpecString, responseString, endpointName);
 newResponseBuilder.body(ResponseBody.create(response.body().contentType(), responseString));
 } catch (IOException e) {
 Timber.e("Unable to save request to "+request.url().toString()+" : ", e);
 }
 return newResponseBuilder.build();
 }
  22. Substitutions • Sometimes, the response must be modified before being

    returned, for example, the expiration date of a token must be modified to be in the future • NetworkCallSpec can include a substitution pattern that will make these replacements private static interface StringSubstitutor {
 String replaceOneString(String body, Request request);
 boolean matchesFound(String body);
 } private String substituteStrings(String bodyString, Request request) {
 // Because each match can get replaced with something different, we have to reset the matcher after every replacement.
 // This way of doing things happens to enforce this in a non-obvious way, because we create a new matcher every time.
 for (StringSubstitutor substitutor : mSubstitutorList) {
 while (substitutor.matchesFound(bodyString)) {
 bodyString = substitutor.replaceOneString(bodyString, request);
 }
 }
 return bodyString;
 } private static final Pattern DATE = Pattern.compile(“%DATE[^%]*%"); private static class DateSubstitutor implements StringSubstitutor {
 @Override
 public String replaceOneString(String body, Request request) {
 Matcher dateMatcher = DATE.matcher(body);
 dateMatcher.find();
 String match = dateMatcher.group();
 Map<String, String> query = getQueryFromUri(match);
 LocalDate date = new LocalDate();
 if(query.containsKey(OFFSET_PARAMETER)) {
 date = date.plusDays(Integer.parseInt(query.get(OFFSET_PARAMETER)));
 }
 body = dateMatcher.replaceFirst(date.toString());
 return body;
 } }
  23. Back to the Test with Side Effects • Now, we

    set up this test to run MockBehavior.MOCK_ONLY • If the Interceptor finds a mock, it will return that mock • If not, it will return an error private static final String CREATE_FILE_NAME = "AbstractMockedInterceptor.java";
 private static final String CREATE_DESCRIPTION = "An OkHttp Interceptor that returns mocked results if it has them.";
 @Test
 public void createGist() throws IOException {
 ServiceLocator.put(OkHttpClient.class, OkHttpClientUtil.getOkHttpClient(null, MockBehavior.MOCK_ONLY));
 Gist gist = new GistImpl();
 gist.setDescription(CREATE_DESCRIPTION);
 gist.addFile(CREATE_FILE_NAME, readFromAsset("mocks/javaclass"));
 Observable<Gist> observable = ServiceInjector.resolve(RxEndpoints.class).createGist(gist);
 TestSubscriber<Gist> testSubscriber = new TestSubscriber<>();
 observable.subscribe(testSubscriber);
 testSubscriber.assertCompleted();
 List<Gist> gistList = testSubscriber.getOnNextEvents();
 Gist resultGist = gistList.get(0);
 Observable<Gist> gistObservable = ServiceInjector.resolve(RxEndpoints.class).getGist(resultGist.getId());
 TestSubscriber<Gist> gistTestSubscriber = new TestSubscriber<>();
 gistObservable.subscribe(gistTestSubscriber);
 Gist detailGist = gistTestSubscriber.getOnNextEvents().get(0); assertEquals(detailGist.getDescription(), CREATE_DESCRIPTION);
 }
  24. Photo Credits • Pete - Storage Array
 https://www.flickr.com/photos/comedynose/7048321621 • Copyright:

    Joi Ito, Attribution 2.0 Generic - Vacuum Tubes
 https://www.flickr.com/photos/joi/494429939 • Copyright: Sven, Attribution 2.0 Generic - Giant Heat Sink
 https://www.flickr.com/photos/flickrsven/2790410292 • Copyright: Andrew Magill, Attribution 2.0 Generic - Patient Dog
 https://www.flickr.com/photos/amagill/7798874692/ • Neil Dalphin - Spider
 https://www.flickr.com/photos/136758431@N05/32665099125 • Joe deSousa - Gears
 https://www.flickr.com/photos/mustangjoe/22711070429 • Bernard Spragg. NZ - Bull Kelp
 https://www.flickr.com/photos/volvob12b/9667991371 • Mark Jones - Eye
 https://www.flickr.com/photos/131211911@N03/16958804881 • Susan Young - Northern Mockingbird
 https://www.flickr.com/photos/95782365@N08/24329013583 • Bernard Spragg. NZ - Sunset on the Roof
 https://www.flickr.com/photos/volvob12b/14284648729 • Chris Koeberle - Building • Chris Koeberle - Metronome • Michael D Beckwith - Leeds Corn Exchange
 https://www.flickr.com/photos/118118485@N05/12644596004 • Smithsonian Institution - Supernova Bubble
 https://www.flickr.com/photos/smithsonian/5393241197
  25. Questions?
