Going from a monolith to a multi-module project is a long process, that requires careful planning and a well-thought strategy, especially in medium-large teams.

The TIER application is evolving to a multi-module structure and this talk will be the logbook of the journey, covering the approach that we followed and the philosophy behind the choices that we’ve made with both the mobile platforms in mind.

I will tell you how to balance the entire process without harming the regular feature delivery schedule, where to start modularizing and improvements to the build tools to make life less miserable.

Transcript

1. @marcoGomier Marco Gomiero 👨💻 Senior Android Engineer @ TIER
 Google Developer Expert for Kotlin Forging the path from monolith to multi-module app
2. @marcoGomier 🧑💻 👩💻
3. @marcoGomier 🧑💻 👩💻 👨💻 👨💻 👨💻 🧑💻 👩💻 👩💻 👨💻 👩💻 👨💻 👨💻 👨💻 👨💻 👩💻 👩💻
4. @marcoGomier 🧑💻 👩💻 👨💻 👨💻 👨💻 🧑💻 👩💻 👩💻 👨💻 👩💻 👨💻 👨💻 👨💻 👨💻 👩💻 👩💻
5. @marcoGomier 🧩 Reusable modules 🤓 Simplify development 🧑💻 Split responsibilities & clarify ownership 🚀 Improved build time Modularization in a nutshell
6. @marcoGomier There is not a "right way" Disclaimer:
7. @marcoGomier #1 Decide your architecture
8. @marcoGomier Standard module layers App Features Libraries
9. :shell :features:feat1 :features:feat1-contract :libraries:lib1 :libraries:lib2 :features :libraries :libraries:lib3 TIER module layers :clients :app :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract :features:feat2 :features:feat2-contract
10. :shell :features:feat1 :features:feat1-contract :libraries:lib1 :libraries:lib2 :features :libraries :libraries:lib3 TIER module layers :clients :app :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract :features:feat2 :features:feat2-contract
11. @marcoGomier Shell • Shared core common code • Should not be a new monolith with a different name 😅 • Not depend on upper layers :shell
12. :shell :features:feat1 :features:feat1-contract :libraries:lib1 :libraries:lib2 :features :libraries :libraries:lib3 TIER module layers :app :features:feat2 :features:feat2-contract :clients :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract
13. @marcoGomier :clients:client1 :clients:client1-mock :clients:client1-contract Clients • Encapsulate the usage of external
 libraries and dependencies
 • Every client has a contract, an implementation and a mock module
14. @marcoGomier Client: contract • A contract for the outside world • Contains Interfaces and Data Classes • Can depend on shell @marcoGomier :clients:locationprovider-contract interface LocationProvider { fun getUserLocation(): UserLocation } data class UserLocation( val latitude: Double, val longitude: Double, ) :clients:client1-contract
15. @marcoGomier Client: implementation :clients:client1 • The implementation of the contract • Just an abstraction without any business logic • Has a dependency on its contract • Can depend on shell • Invisible for other modules (except for :app) @marcoGomier :clients:locationprovider internal class LocationProviderImpl( ... ): LocationProvider { override fun getUserLocation(): UserLocation { // Return a location from the GPS } }
16. @marcoGomier Client: mock :clients:client2-mock @marcoGomier :clients:locationprovider-mock internal class MockLocationProvider( ... ): LocationProvider { override fun getUserLocation(): UserLocation { // Return a location from a mock provider } } • An implementation of the contract that returns fake data • Has a dependency on its contract • Can depend on shell • Invisible for other modules (except for :app)
17. :shell :features:feat1 :features:feat1-contract :features TIER module layers :app :features:feat2 :features:feat2-contract :clients :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract :libraries:lib1 :libraries:lib2 :libraries :libraries:lib3
18. @marcoGomier :libraries:lib1 Libraries • Small reusable components • Can depend on other libraries, clients or shell
19. :shell TIER module layers :app :clients :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract :libraries:lib1 :libraries:lib2 :libraries :libraries:lib3 :features:feat1 :features:feat1-contract :features :features:feat2 :features:feat2-contract
20. @marcoGomier Features • A specific feature, could be user-facing or not • Every feature has a contract and
 an implementation module :features:feat1 :features:feat1-contract
21. @marcoGomier Feature: contract • A contract for the outside world • What a feature can do and how it can be launched • Contains Interfaces and Data Classes • Can depend on libraries, clients or shell @marcoGomier :features:location-contract interface LocationUseCase { fun getLocation(): Observable<Location> fun getLatestLocation(): Single<Location> fun fetchLocation(): Single<Location> } data class Location( val latitude: Double, val longitude: Double, ) :features:feat1-contract
22. @marcoGomier Feature: implementation :features:feat1 • The implementation of the contract • Has a dependency on its contract • Can depend on other feature contracts, libraries, clients or shell • Invisible for other modules (except for :app) @marcoGomier :features:location internal class LocationUseCaseImpl( ... ) : LocationUseCase { override fun getLocation(): Observable<Location> { ... }
 ... }
23. @marcoGomier Contract modules: why? :features:feat1-contract :features:feat2 :features:feat2-contract :clients:client1 :clients:client1-contract :features:feat1
24. @marcoGomier Contract modules: why? • Low coupling: avoid knowledge of inner workings. • Risk of need to import lot of transitive dependencies, when a module depends on many others • Avoid increasing incremental build time
25. :shell :features:feat1 :features:feat1-contract :libraries:lib1 :libraries:lib2 :features :libraries :libraries:lib3 TIER module layers :clients :app :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract :features:feat2 :features:feat2-contract
26. @marcoGomier App • App initialization • Dependency Injection setup • Link all the module together • It should be as slim as possible :app
27. :shell :features:feat1 :features:feat1-contract :libraries:lib1 :libraries:lib2 :features :libraries :libraries:lib3 TIER module layers :clients :app :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract :features:feat2 :features:feat2-contract
28. :shell :libraries:lib1 :libraries:lib2 :features :libraries :libraries:lib3 TIER module layers :clients :app :clients:client1 :clients:client1-mock :clients:client1-contract :clients:client2 :clients:client2-mock :clients:client2-contract :features:feat1 :features:feat1-contract :features:feat2 :features:feat2-contract :legacy
29. @marcoGomier Legacy • A huge module with the non-modularized codebase • Extract future features from here • Try to not put any new code in it • Can depend on feature contracts, libraries, clients or shell :legacy
30. @marcoGomier How to enforce this structure? • Documentation • “Computer says no” 🤖
31. @marcoGomier #2 Start doing things
32. @marcoGomier Starting point • Select a feature to start with • Can be a feature with UI or without UI • A non UI feature will be easier: less things to figure out (spoiler: navigation) • Extract Ride Handling to :features:ride
33. @marcoGomier Find shared deps → Dependecies Analysis
34. @marcoGomier
35. @marcoGomier • Figure out shared dependencies • Move them to :shell • Extract the Ride Handling into a new module Start modularizing
36. @marcoGomier 🎉
37. :app :features:ride :features:ride-contract :features :shell
38. :app :features:ride :features:ride-contract :features :shell :legacy
39. @marcoGomier Extract UI Features • Time to extract a UI feature • How to navigate between feature modules? • 🚧 ⛔
40. @marcoGomier #3 Rethink Navigation
41. @marcoGomier Current Navigation Status • Jetpack Navigation • Every “feature” has its own navigation graph • Not a single Activity Architecture • Mostly every “feature” has its own hosting Activity
42. @marcoGomier ShopActivity ArticleList ArticleDetail PurchaseSuccess
43. @marcoGomier :features:shop ShopActivity ArticleList ArticleDetail PurchaseSuccess :features:map MapActivity Map ShopActivity Start a feature from another module
44. @marcoGomier :features:map MapActivity Map QRScannerActivity :features:qr-scanner QRScannerActivity Intro Scan Start a feature from another module and get a result back
45. @marcoGomier :features:customersupport CustomerSupport Add a Fragment in the current flow ShopActivity ArticleList ArticleDetail CustomerSupport :features:shop
46. @marcoGomier Some issues • Start a feature from another module
 ⛔ Deeplink with a single activity that includes all the graphs • Start a feature and get a result back
 ⛔ Not out-of-the-box with Jetpack Navigation • Add a Fragment in the current navigation graph
 ⛔ Not out-of-the-box with Jetpack Navigation
47. @marcoGomier First idea • Start a feature from another module
 💡 Start the Activity from the Contract • Start a feature and get a result back
 ⛔ Not out-of-the-box with Jetpack Navigation • Add a Fragment in the current navigation graph
 ⛔ Not out-of-the-box with Jetpack Navigation
48. @marcoGomier First idea • Start a feature from another module
 💡 Start the Activity from the Contract • Start a feature and get a result back
 💡 Start Activity for result from the Contract • Add a Fragment in the current navigation graph
 ⛔ Not out-of-the-box with Jetpack Navigation
49. @marcoGomier First idea • Start a feature from another module
 💡 Start the Activity from the Contract • Start a feature and get a result back
 💡 Start Activity for result from the Contract • Add a Fragment in the current navigation graph
 💡 Get the Fragment instance from the Contract. Every feature module subcomponent exposes a Router interface that will be implemented by the callers
50. @marcoGomier First idea: some issues • Lot’s of boilerplate • The Activity needs to subscribe on navigation event • Navigating to somewhere depends on the implementation details: Activity, Fragment, Bottom sheet, etc
51. @marcoGomier 💡 A “Navigation SDK”
52. @marcoGomier https://medium.com/inside-aircall/why-did-we-move-away-from-navigation-component-f2160f7c3f4b
53. @marcoGomier Navigation SDK Router Activity, Fragment, Extras, Transitions … Destination Destination ViewModel Feature Module Navigator App Module RouteResolver Navigation SDK: how it works Route
54. @marcoGomier Navigation SDK :features:shop-contract object ShopDestination : Destination :app internal object AppRouteResolver { fun resolveRoute(destination: Destination): Route = when (destination) { is ShopDestination -> { fragmentRoute<ShopActivity, ShopHomeScreenFragment>() } else -> { throw IllegalArgumentException( "Router resolver not implemented for destination: $destination", ) } } }
55. @marcoGomier Navigation SDK :features:smap class MapViewModel( private val router: Router, ) : ViewModel() { fun navigateToShop() { router.navigateTo(ShopDestination) } }
56. @marcoGomier New navigation approach • Everything happens in the ViewModel • Less boilerplate to write • The navigation logic can be unit-tested
57. @marcoGomier #4 Improve Gradle Setup
58. @marcoGomier Dependency Management • Some version numbers were hardcoded • Switch to Gradle Version Catalog for managing dependencies [versions] io-reactivex-rxjava2-rxandroid = "2.1.1" io-reactivex-rxjava2-rxkotlin = "2.4.0" com-jakewharton-rxrelay = "2.1.1" [libraries] com-jakewharton-rxrelay = { module = "com.jakewharton.rxrelay2:rxrelay", version.ref = "com-jakewharton-rxrelay" } io-reactivex-rxjava2-rxandroid = { module = "io.reactivex.rxjava2:rxandroid", version.ref = "io-reactivex-rxjava2-rxandroid" } io-reactivex-rxjava2-rxkotlin = { module = "io.reactivex.rxjava2:rxkotlin", version.ref = "io-reactivex-rxjava2-rxkotlin" } [bundles] rxjava2 = ["io-reactivex-rxjava2-rxandroid", "io-reactivex-rxjava2-rxkotlin", "com-jakewharton-rxrelay"] @marcoGomier gradle/libs.versions.toml
59. @marcoGomier Dependency Management • Some version numbers were hardcoded • Switch to Gradle Version Catalog for managing dependencies • Bundles are awesome [bundles] feature-common-deps = ["androidx-appcompat", "androidx-constraintlayout", "androidx-recyclerview"] feature-testing = [“junit”, "androidx-io-mockk"] @marcoGomier gradle/libs.versions.toml
60. @marcoGomier Module Configuration → Convention Plugins plugins { id 'com.tier.app.android.feature' id 'kotlin-android' } dependencies { ... }
61. @marcoGomier Convention Plugins per module layers com.tier.app.android.application com.tier.app.android.feature com.tier.app.android.library com.tier.app.android.client com.tier.app.android.base.library app: features: libraries: clients: shell:
62. @marcoGomier More 🤖 • CookieCutter template to create a new feature or library module. • Automatically add custom project configuration
63. @marcoGomier #5 Restart doing things
64. @marcoGomier Restarting point • More utility modules are required for more complex UI feature modules: (testing tools, feature-flags, etc)
 • Now a UI feature can be extracted 🎉
65. @marcoGomier #6 Conclusions
66. @marcoGomier July 2021 Timeline Architecture Decisions
67. @marcoGomier July 2021 Timeline Nov 2021 Sept 2021 Aug 2021 :features:ride creation :shell
 creation Architecture Decisions Feb 2022 May 2022 Apr 2022 March 2022 Ready for bigger UI module More utility modules First UI feature module Gradle improvements • Took almost a year to have everything in place First Navigation discussion
68. @marcoGomier Timeline July 2021 Nov 2021 Sept 2021 Aug 2021 :features:ride creation :shell
 creation Architecture Decisions Feb 2022 May 2022 Apr 2022 March 2022 Ready for bigger UI module More utility modules First UI feature module Gradle improvements First Navigation discussion Jun 2022 New
 Modules
69. @marcoGomier July 2021 Timeline Nov 2021 Sept 2021 Aug 2021 First Navigation discussion :features:ride creation :shell
 creation Architecture Decisions Feb 2022 May 2022 Apr 2022 March 2022 Ready for bigger UI module More utility modules First UI feature module Gradle improvements Jun 2022 Nov 2022 Navigation SDK New
 Modules Now Jan 2023 Dec 2022 More and more modules Clients
 Layer Convention plugins
70. @marcoGomier Timeline Jun 2022 Nov 2022 Navigation SDK New
 Modules Now Jan 2023 Dec 2022 More and more modules Clients
 Layer Convention plugins • More than 160 modules so far 🧩 • Sometime the “best decisionTM” is not the best one
71. @marcoGomier Conclusions • A long and difficult journey but totally worth it • There’s no perfect recipe • Don't be afraid to fail • Don’t rush it • Don’t refactor You will have a chance to find “hidden pearls” of your project 😅
72. Resources • https://developer.android.com/guide/navigation/navigation-multi-module • https://www.droidcon.com/2019/11/15/android-at-scale-square/ • https://medium.com/inside-aircall/why-did-we-move-away-from-navigation-component- f2160f7c3f4b • https://github.com/slackhq/slack-gradle-plugin • https://github.com/cookiecutter/cookiecutter • https://docs.gradle.org/current/userguide/platforms.html • https://github.com/android/nowinandroid/blob/main/docs/ModularizationLearningJourney.md • https://slack.engineering/stabilize-modularize-modernize-scaling-slacks-mobile-codebases/ • https://slack.engineering/stabilize-modularize-modernize-scaling-slacks-mobile-codebases-2/ • https://www.youtube.com/watch?v=K65M6jpyN4Y • https://github.com/android/nowinandroid/tree/main/build-logic • https://developer.squareup.com/blog/herding-elephants/
73. @marcoGomier Marco Gomiero 👨💻 Senior Android Engineer @ TIER
 Google Developer Expert for Kotlin Thank you! Twitter: @marcoGomier
