2016 - Maxime Beauchemin - Caravel - A data visualization, exploration and dashboarding platform

Description
Airbnb developed Caravel to provide all employees with interactive access to data while minimizing friction. Caravel's main goal is to make it easy to slice, dice and visualize data. It empowers each and everyone to perform analytics at the speed of thought.
​
Abstract
Topics include:
* Intuitively visualizing datasets while filtering, pivoting, and changing views
* Creating and sharing simple dashboards
* Caravel's rich set of visualizations
* Caravel's extensible, high-granularity security/permission model allowing intricate rules on who can access individual features and the dataset
* Caravel's enterprise-ready authentication with integration with major authentication providers (database, OpenID, LDAP, OAuth, and REMOTE_USER through Flask AppBuilder)
* Caravel's simple semantic layer, allowing users to control how data sources are displayed in the UI by defining which fields should show up in which drop-down and which aggregation and function metrics are made available to the user
* Caravel’s deep integration with Druid
* Caravel’s integration with most RDBMS through SQLAlchemy
* How Javascript/Node/D3/React can cohabit and work well along with Python/Pypi/Flask
​
Bio
Maxime Beauchemin works at Airbnb as part of the Data Tools team, developing open source products that reduce friction that help generating insight from data. He is the creator and a leading maintainer of Apache Airflow [incubating] (a workflow engine) and Caravel (a data visualization platform). Before Airbnb, Maxime worked at Facebook on computation frameworks around engagement and growth analytics, at Yahoo! on social properties analytics, and at Ubisoft as a data warehouse architect.

https://youtu.be/Wt1xH41gXhs

Transcript

1. Caravel an open source data visualization platform
2. * explore your data! * create interactive dashboards * share discoveries Caravel
3. The Vision Any visualization Any database microscopic amount of work
4. Maxime Beauchemin
5. * Data is too strategic to depend on vendors! * Tableau doesn’t support Presto & Druid * Tableau extracts don’t scale well * Buying means lock-in and increasing costs * We need deep integration with our stack * We’re builders not buyers!
6. Live demo!
15. Brains! Bogdan Kyryliuk Vera Liu Maxime Beauchemin Jeff Feng Alanna Scott
16. How do we use Python?
17. Flask App Builder * Authentication / permission / role management * CRUD! * Babel (translation framework) * Bootstrap / dynamic navbar / font-awesome
18. Flask [App Builder] vs Django Pros * Airbnb was already using Flask / SqlAlchemy * FAB’s CRUD doesn’t require an Admin, all models ship with a `show` permission * FAB has a lean codebase, it’s easy to contribute to it Cons * Few guarantees on quality / security / support * A lot less features than Django has to grow into * Not much of a community (yet)
19. SQLAlchemy
20. Pandas * Crafting the right JSON for the visualization: * pivot_table * groupby * multi-sorts * … * Time series transforms: * rolling functions * resampling * period shifts * period ratios
21. Package and distribute * setup tools * nose / coverage (tests) * alembic (db migrations) * requires.io (dependency tracking) * coveralls.io (coverage reporting) * landscape.io (code quality reporting) * sphinx (documentation) * pypi (`pip install caravel` )
22. The Frontend Stack * Javascript frontend * npm / ES6 / webpack / React * d3.js! * nvd3.org
23. Security * Provided by Flask AppBuilder (python web framework) * Easily integrate with: OpenID, LDAP, REMOTE_USER, OAUTH, or use the builtin database * Ships with 3 roles: * Admin (all access) * Alpha (all access but cannot alter permissions) * Gamma (per-datasource / table access) * Fine grain controls to create new roles
24. A thin Semantic Layer * Verbose names and long descriptions for columns and metrics * Add calculated fields and metrics as SQL expression * Set how individual columns are exposed
25. Druid.io Integration
26. Event Logs MySQL Dumps Gold Hive Cluster HDFS Spark Cluster Airpal Airflow Scheduling Presto Cluster Silver Hive Cluster HDFS Replication Kafka Sqoop Tableau S3 Caravel ! Druid
27. Caching! * Provided by flask-cache * Backends: memcache, redis, filesystem, memory, … * cascading timeout configuration * UI is upfront about staleness * allows to force-refresh
28. Open Source FTW !
29. * Grow a community! * Ship “SQL Lab” * Ship visualizations & controls as React.js components * Reactify the whole app * DSL for the semantic layer * UX -> smoothen common flows What’s next?
30. github.com/airbnb/caravel
31. Q?
