Øredev 2017: Cool ConstraintLayout

Huyen's presentation at Øredev 2017 on cool things about and cool things to do with ConstraintLayout on Android.

Transcript

1. HUYEN TUE DAO
   @QUEENCODEMONKEY
   COOL
   CONSTRAINT
   LAYOUT


   View Slide

2. COOL THINGS ABOUT
   CONSTRAINT LAYOUT
   COOL THINGS TO DO
   WITH CONSTRAINT LAYOUT


   View Slide

3. WHAT IS THE
   CONSTRAINT
   LAYOUT?


   View Slide

4. RELATIONSHIPS BETWEEN VIEWS
   RELATIVE LAYOUT++
   + (≈LINEARLAYOUT)
   EXPRESSIVE
   PERFORMANT


   View Slide

5. UNBUNDLED
   SUPPORTS API 9+
   UI BUILDER
   USABLE WITH XML ONLY
   1.1.0 BETA 3 → 2017.10.12


   View Slide

6. HOW DOES IT
   WORK?


   View Slide

7. CONSTRAINTS
   EQUATIONS
   SOLVER
   7
   HOW DOES IT WORK?


   View Slide

8. HOW DOES IT WORK?
   CONSTRAINTS
   EQUATIONS
   SOLVER
   POSITION
   FIXED
   WRAP CONTENT
   MATCH CONSTRAINT
   RATIO
   PERCENT
   EDGE
   CENTER
   BASELINE
   CIRCULAR (1.1)
   DIMENSION OTHER
   8
   CHAINS
   CONSTRAINT SET
   PLACEHOLDERS
   GUIDELINES
   GROUPS
   BARRIERS


   View Slide

9. CONSTRAINTS
   EQUATIONS
   SOLVER
   LINEAR SYSTEM OF EQUATIONS/INEQUALITIES
   9
   HOW DOES IT WORK?
   11 + … + 1n =
   11 + … + 1n ≤
   11 + … + 1n ≥


   View Slide

10. CONSTRAINTS
    EQUATIONS
    SOLVER
    CASSOWARY
    LINEAR ARITHMETIC
    CONSTRAINT SOLVING
    ALGORITHM
    VIEW BOUNDS
    10
    HOW DOES IT WORK?


    View Slide

11. CONSTRAINTLAYOUT, INSIDE AND OUT: PART 2 DAVE SMITH


    View Slide

12. LET’S TAKE
    A QUICK
    TOUR


    View Slide

13. View Slide

14. CONSTRAINT
    LAYOUT
    CHEAT SHEET


    View Slide

15. SOURCE
    TARGET
    EDGE CONSTRAINT


    app:layout_constraintLeft_toLeftOf="parent"


    app:layout_constraint_toOf=“a_view"


    View Slide

16. CENTER CONSTRAINT


    app:layout_constraintHorizontal_bias="0.75"


    View Slide

17. BASELINE CONSTRAINT
    app:layout_constraintBaseline_toBaselineOf="@+id/view"


    View Slide

18. CIRCULAR CONSTRAINT
    app:layout_constraintCircle="@id/centerTextView"
    app:layout_constraintCircleAngle="90"
    app:layout_constraintCircleRadius="@dimen/circular_radius"


    View Slide

19. SIZE CONSTRAINTS


    View Slide

20. !!!
    app:layout_constraintWidth_percent=".75"
    app:layout_constraintHeight_percent=".5"
    !!!
    app:layout_constraintDimensionRatio="1:1"


    View Slide

21. GUIDELINES


    View Slide

22. android:layout_width="wrap_content"

    android:layout_height="wrap_content"

    android:id="@+id/guideline_start"

    android:orientation="vertical"

    app:layout_constraintGuide_begin="16dp" />





    android:layout_width="wrap_content"

    android:layout_height="wrap_content"

    android:id="@+id/horizontal"

    android:orientation="horizontal"

    app:layout_constraintGuide_percent="0.37" />


    View Slide

23. BARRIERS


    View Slide

24. android:id="@+id/barrier"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    app:barrierDirection="end"
    app:constraint_referenced_ids="title,artist" !/>


    View Slide

25. GROUPS


    View Slide

26. SO WHAT CAN
    WE DO WITH
    CONSTRAINT
    LAYOUT?


    View Slide

27. public class SquareImageView extends ImageView {
    @Override

    protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {

    super.onMeasure(widthMeasureSpec, heightMeasureSpec);



    final int size = Math.min(getMeasuredWidth(), getMeasuredHeight());

    setMeasuredDimension(size, size);

    }


    View Slide

28. android:id=“@+id/square_image”

    android:layout_width="0dp"

    android:layout_height="0dp"

    app:layout_constraintDimensionRatio=“W,1:1"


    View Slide

29. View Slide

30.

    H,16:10

    app:layout_constraintDimensionRatio=“@string/hero_ratio"


    View Slide

31. IS IT REALLY
    BETTER THAN
    RELATIVE
    LAYOUT?


    View Slide

32. STYLING ANDROID
    CONSTRAINTLAYOUT
    PART 6


    View Slide

33. View Slide

34. private fun updateManualAnchors() {

    val size = anchorMinSize + seekBar.progress

    val halfSize = Math.round(size * 0.5f)

    val horizontalMargin =
    resources.getDimensionPixelSize(R.dimen.content_margin_horizontal) - halfSize

    val verticalMargin =
    resources.getDimensionPixelSize(R.dimen.alignment_rectangle_margin_vertical) - halfSize

    updateManualAnchor(frameAnchorTop, size, verticalMargin, 0, 0, 0)

    updateManualAnchor(frameAnchorStart, size, 0, horizontalMargin, 0, 0)

    updateManualAnchor(frameAnchorBottom, size, 0, 0, verticalMargin, 0)

    updateManualAnchor(frameAnchorEnd, size, 0, 0, 0, horizontalMargin)

    }



    private fun updateManualAnchor(anchor: View, size: Int,

    marginTop: Int, marginStart: Int,

    marginBottom: Int, marginEnd: Int) {

    val layoutParams = anchor.layoutParams as FrameLayout.LayoutParams
    layoutParams.width = size

    layoutParams.height = size

    layoutParams.topMargin = marginTop

    layoutParams.bottomMargin = marginBottom

    layoutParams.marginStart = marginStart

    layoutParams.marginEnd = marginEnd
    anchor.layoutParams = layoutParams

    }
    WITH CONSTRAINTLAYOUT
    JUST CHANGE THE SIZE…


    View Slide

35. WHAT WAS THAT
    ABOUT LINEAR
    LAYOUT?


    View Slide

36. CHAINS. CHAINS. CHAINS.
    FROM CONSTRAINTLAYOUT DOCUMENTATION


    View Slide

37. SPREAD INSIDE CHAIN
    android:id=“@+id/spread_inside_head”

    app:layout_constraintHorizontal_chainStyle="spread_inside"

    … />


    View Slide

38. android:id=“@+id/weighted_chain_head

    android:layout_width="0dp"

    android:layout_height="wrap_content"

    app:layout_constraintHorizontal_chainStyle="spread"

    app:layout_constraintHorizontal_weight=“1" />
    android:id=“@+id/next
    android:layout_width="0dp"

    android:layout_height="wrap_content"

    app:layout_constraintHorizontal_weight="2" />
    android:id=“@+id/last

    android:layout_width="0dp"

    android:layout_height="wrap_content"

    app:layout_constraintHorizontal_weight="1" />
    38
    WEIGHTED CHAIN


    View Slide

39. android:id=“@+id/packed_chain_head”

    app:layout_constraintHorizontal_chainStyle="packed"

    app:layout_constraintHorizontal_bias="0.12" />
    39
    PACKED CHAIN


    View Slide

40. View Slide

41. View Slide

42. A CONSTRAINT
    LAYOUT SPECIAL
    CONSTRAINT SET


    View Slide

43. CONSTRAINT SET
    CREATE/SAVE/APPLY
    CREATE MANUALLY
    CLONE A LAYOUT FILE
    CLONE A CONSTRAINT LAYOUT
    AWESOME WITH TRANSITIONS
    DEFINE SET OF CONSTRAINTS
    PROGRAMMATICALLY


    View Slide

44. View Slide

45. View Slide

46. // Inflate initial layout as usual.
    setContentView(R.layout.activity_constraintset_01)
    // Get references to controls

    constraintLayout = findViewById(R.id.constraint_layout) as ConstraintLayout



    // Load ConstraintSets.

    constraintSet01.clone(constraintLayout)

    constraintSet02.clone(this, R.layout.activity_constraintset_02)
    …some time later…
    // Toggle ConstraintSets.
    TransitionManager.beginDelayedTransition(constraintLayout)

    if (original) constraintSet02.applyTo(constraintLayout)

    else constraintSet01.applyTo(constraintLayout)

    original = !original
    44


    View Slide

47. YES, LIST ITEMS
    CAN BE
    CONSTRAINT
    LAYOUTS


    View Slide

48. CONSTRAINT SET
    IN LIEU OF
    CUSTOM
    VIEWGROUP


    View Slide

49. CUSTOM
    VIEW GROUPS
    GENERALIZED, REUSABLE LAYOUTS
    PERFORMANT COMPOSITE LAYOUTS
    LAYOUT IS LOW-LEVEL (X, Y)
    EVEN SIMPLE ONES = MUCH CODE
    ADVANCED LAYOUTS… WOAH


    View Slide

50. @Override

    protected void onLayout(boolean changed, int left, int top, int right, int bottom) {

    MarginLayoutParams layoutParams = (MarginLayoutParams) icon.getLayoutParams();



    // Figure out the x-coordinate and y-coordinate of the icon.

    int x = getPaddingLeft() + layoutParams.leftMargin;

    int y = getPaddingTop() + layoutParams.topMargin;



    // Layout the icon.

    icon.layout(x, y, x + icon.getMeasuredWidth(), y + icon.getMeasuredHeight());



    // Calculate the x-coordinate of the title: icon's right coordinate +

    // the icon's right margin.

    x += icon.getMeasuredWidth() + layoutParams.rightMargin;



    // Add in the title's left margin.

    layoutParams = (MarginLayoutParams) titleView.getLayoutParams();

    x += layoutParams.leftMargin;



    // Calculate the y-coordinate of the title: this ViewGroup's top padding +

    // the title's top margin

    y = getPaddingTop() + layoutParams.topMargin;



    // Layout the title.

    titleView.layout(x, y, x + titleView.getMeasuredWidth(), y + titleView.getMeasuredHeight());



    // The subtitle has the same x-coordinate as the title. So no more calculating there.



    // Calculate the y-coordinate of the subtitle: the title's bottom coordinate +

    // the title's bottom margin.

    y += titleView.getMeasuredHeight() + layoutParams.bottomMargin;

    layoutParams = (MarginLayoutParams) subtitleView.getLayoutParams();



    // Add in the subtitle's top margin.

    y += layoutParams.topMargin;



    // Layout the subtitle.

    subtitleView.layout(x, y,

    x + subtitleView.getMeasuredWidth(), y + subtitleView.getMeasuredHeight());

    }
    @Override
    protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
    // Measure icon.
    measureChildWithMargins(icon, widthMeasureSpec, 0, heightMeasureSpec, 0);
    // Figure out how much width the icon used.
    MarginLayoutParams lp = (MarginLayoutParams) icon.getLayoutParams();
    int widthUsed = icon.getMeasuredWidth() + lp.leftMargin + lp.rightMargin;
    int heightUsed = 0;
    // Measure title
    measureChildWithMargins(
    titleView,
    // Pass width constraints and width already used.
    widthMeasureSpec, widthUsed,
    // Pass height constraints and height already used.
    heightMeasureSpec, heightUsed
    );
    // Measure the Subtitle.
    measureChildWithMargins(
    subtitleView,
    // Pass width constraints and width already used.
    widthMeasureSpec, widthUsed,
    // Pass height constraints and height already used.
    heightMeasureSpec, titleView.getMeasuredHeight());
    // Calculate this view's measured width and height.
    // Figure out how much total space the icon used.
    int iconWidth = icon.getMeasuredWidth() + lp.leftMargin + lp.rightMargin;
    int iconHeight = icon.getMeasuredHeight() + lp.topMargin + lp.bottomMargin;
    lp = (MarginLayoutParams) titleView.getLayoutParams();
    // Figure out how much total space the title used.
    int titleWidth = titleView.getMeasuredWidth() + lp.leftMargin + lp.rightMargin;
    int titleHeight = titleView.getMeasuredHeight() + lp.topMargin + lp.bottomMargin;
    lp = (MarginLayoutParams) subtitleView.getLayoutParams();
    // Figure out how much total space the subtitle used.
    int subtitleWidth = subtitleView.getMeasuredWidth() + lp.leftMargin + lp.rightMargin;
    int subtitleHeight = subtitleView.getMeasuredHeight() + lp.topMargin + lp.bottomMargin;
    // The width taken by the children + padding.
    int width = getPaddingTop() + getPaddingBottom() +
    iconWidth + Math.max(titleWidth, subtitleWidth);
    // The height taken by the children + padding.
    int height = getPaddingTop() + getPaddingBottom() +
    Math.max(iconHeight, titleHeight + subtitleHeight);
    // Reconcile the measured dimensions with the this view's constraints and
    // set the final measured width and height.
    setMeasuredDimension(
    resolveSize(width, widthMeasureSpec),
    resolveSize(height, heightMeasureSpec)
    );
    }


    View Slide

51. CONSTRAINT
    SET IN LIEU OF
    CUSTOM
    VIEWGROUP


    View Slide

52. private fun addRow(view: View) {

    constraintLayout.addView(view)



    val id = view.id

    constraintSet.constrainWidth(id, MATCH_CONSTRAINT)

    constraintSet.constrainHeight(id, rowHeight)



    // Constrain new view vertically.

    val target = if (lastRowId  PARENT_ID) TOP else BOTTOM

    constraintSet.connect(id, TOP, lastRowId, target)
    // Constrain new view horizontally.

    constraintSet.connect(id, START, PARENT_ID, START)

    constraintSet.connect(id, END, PARENT_ID, END)



    // Toggle elevation to elevate last added view.

    constraintSet.setElevation(id, resources.getDimension(R.dimen.elevation))

    constraintSet.setElevation(lastViewId, 0f)



    // Apply constraints.

    constraintSet.applyTo(constraintLayout)
    50


    View Slide

53. private fun addRowItem(view: View) {

    …

    constraintLayout.addView(view)



    val id = view.id



    // Initialize width and height of new view.

    constraintSet.constrainWidth(id, MATCH_CONSTRAINT)

    constraintSet.constrainHeight(id, rowHeight)



    // Constrain new view vertically.

    val target = if (lastRowId  PARENT_ID) TOP else BOTTOM

    constraintSet.connect(id, TOP, lastRowId, target)
    51


    View Slide

54. // Update current row.

    currentRowIds.add(id)

    // Re-create horizontal chain with other row items.

    constraintSet.createHorizontalChainRtl(

    PARENT_ID, START,

    PARENT_ID, END,

    currentRowIds.toIntArray(), FloatArray(currentRow.size, { 1f }),

    CHAIN_SPREAD_INSIDE)



    // Toggle elevation to elevate last added view.

    constraintSet.setElevation(id, resources.getDimension(R.dimen.elevation))

    constraintSet.setElevation(lastViewId, 0f)



    // Apply constraints.

    constraintSet.applyTo(constraintLayout)
    52


    View Slide

55. SERIOUSLY
    COOL THINGS IN
    CONSTRAINT
    LAYOUT


    View Slide

56. constraintLayout.update {
    guideline(R.id.content_start, VERTICAL_GUIDELINE, LEFT, getDimenSize(R.dimen.keyline_start))
    guideline(R.id.content_top, HORIZONTAL_GUIDELINE, TOP, getDimenSize(R.dimen.content_padding_top))
    constrain(R.id.image) {
    width = MATCH_CONSTRAINT_SPREAD
    height = MATCH_CONSTRAINT_SPREAD
    start = START of PARENT_ID
    top = TOP of PARENT_ID
    end = END of PARENT_ID
    bottom = BOTTOM of PARENT_ID
    }
    constrain(R.id.title) {
    width = WRAP_CONTENT
    height = WRAP_CONTENT
    end = END of R.id.content_start
    top = TOP of R.id.content_top
    }
    constrain(R.id.artist) {
    width = WRAP_CONTENT
    height = WRAP_CONTENT
    start = END of R.id.title
    top = BOTTOM of R.id.title
    }
    }
    54
    CONSTRAINT SET DSL
    github.com/queencodemonkey/the-road-to-kotlintown-ii


    View Slide

57. ANDROID DEVELOPERS BACKSTAGE
    EPISODE 50: CONSTRAINT LAYOUT


    View Slide

58. CONSTRAINTLAYOUT CREW
    JOHN HOFORD
    @JOHNHOFORD
    NICOLAS ROARD
    @CAMAELON
    ADVANCED ANIMATIONS & CONSTRAINTLAYOUT
    DROIDCON SAN FRANCISCO 2017


    View Slide

59. View Slide

60. THANK YOU!
    SPEAKERDECK.COM/QUEENCODEMONKEY
    YOUTUBE.COM/ANDROIDDIALOGS
    RANDOMLYTYPING.COM
    HUYEN TUE DAO
    @QUEENCODEMONKEY
    QUEENCODEMONKEY/PRESENTATION-COOL-CONSTRAINTLAYOUT


    View Slide

61. REFERENCES
    59
    CONSTRAINT LAYOUT APIS DOCUMENTATION
    https://developer.android.com/reference/android/support/constraint/package-summary.html
    BUILD A RESPONSIVE UI WITH CONSTRAINTLAYOUT
    developer.android.com/training/constraint-layout/index.html
    ANDROID DEVELOPERS BACKSTAGE: EPISODE 50: CONSTRAINT LAYOUT
    androidbackstage.blogspot.com/2016/06/episode-50-constraint-layout.html
    USING CONSTRAINTLAYOUT TO DESIGN YOUR VIEWS | CODE LABS
    codelabs.developers.google.com/codelabs/constraint-layout/index.html
    ANDROID LAYOUTS: A NEW WORLD | GOOGLE I/O 2016
    https://youtu.be/sO9aX87hq9c
    ADVANCED ANIMATIONS & CONSTRAINTLAYOUT
    https://speakerdeck.com/camaelon/advanced-animations-and-constraintlayout
    ADVANCED CONSTRAINTLAYOUT
    http://cfp.devoxx.us/2017/talk/XOD-8930/Advanced_ConstraintLayout


    View Slide

62. REFERENCES
    60
    CONSTRAINTLAYOUT
    https://speakerdeck.com/writtmeyer/constraintlayout-1
    CONSTRAINTLAYOUT – PART 1
    blog.stylingandroid.com/constraintlayout-part-1/
    CONSTRAINTLAYOUT, INSIDE AND OUT: PART 1
    http://wiresareobsolete.com/2016/07/constraintlayout-part-1/
    SOME THOUGHTS ON ANDROID’S NEW CONSTRAINTLAYOUT AND ANDROID STUDIO’S NEW DESIGN EDITOR
    http://www.grokkingandroid.com/thoughts-on-constraintlayout-and-design-editor/
    BUILD A UI WITH LAYOUT EDITOR
    developer.android.com/studio/write/layout-editor.html
    WHAT'S NEW IN ANDROID DEVELOPMENT TOOLS | GOOGLE I/O 2016
    https://youtu.be/csaXml4xtN8
    THE EXPERTS' GUIDE TO ANDROID DEVELOPMENT TOOLS | GOOGLE I/O 2016
    https://youtu.be/hHnTIMjd1Y8
    JOHN HOFORD & NICOLAS ROARD : CONSTRAINTLAYOUT | ANDROID DIALOGS
    https://youtu.be/hHnTIMjd1Y8


    View Slide
