The Kitchen's Finally Burned Down: DLP Security Bakeoff

The Kitchen's Finally Burned Down: DLP Security Bakeoff

(As presented by Zach Lanier and Kelly Lum at Black Hat Asia 2016)

Despite a plethora of data security and protection standards and certifications, companies and their systems are still leaking information like a sieve. For instance, Data Loss Prevention (DLP) solutions have often been touted as the "silver bullet" that will keep corporations from becoming the next headline. With deployment models ranging from a fat agent on an endpoint, to a blinky-lights box surveilling all network traffic, to some unified threat management gateway with DLP secret sauce, these solutions are ripe for bypass -- or worse.

This talk will discuss our previous and current research into a handful of DLP solutions, including their capabilities and their shortcomings. We will demonstrate flaws in administrative and programmatic interfaces and the inspection engines themselves.

Zach Lanier

March 24, 2016
Tweet

More Decks by Zach Lanier

Other Decks in Technology

Transcript

  1. THE KITCHEN'S FINALLY BURNED
    DOWN: DLP SECURITY BAKEOFF
    BLACK HAT ASIA 2016
    ZACH LANIER & KELLY LUM

    View Slide

  2. AGENDA
    ▸ DLP overview
    ▸ Targets / Component breakdown
    ▸ Assessment criteria/Methodology
    ▸ Findings (by target)
    ▸ Conclusion / Q&A

    View Slide

  3. WHO ARE *WE*?
    ▸ Zach Lanier, Director of Research at Cylance
    ▸ Old net, web/app, mobile/embedded security research/pen
    test type
    ▸ Co-author, "Android Hacker's Handbook" (Wiley, April
    2014)
    ▸ Kelly Lum, Security Engineer at Tumblr
    ▸ “There’s a bird. Bird. A bird.”
    ▸ Adjunct professor of Application Security at NYU

    View Slide

  4. WHY DLP?
    ▸ Used to be a hot-button topic
    ▸ Panacea to solve all data leakage woes
    ▸ “Keeps honest people from doing dumb
    things”
    ▸ Data breaches and “files falling off the back of a
    digital truck” spurred DLP

    View Slide

  5. WHY WE CHOSE TO LOOK AT DLP
    ▸ Curious about attack surface, reliability, etc.
    ▸ Like other security products, DLP agents/appliances often have high privileges
    or are “ideally” situated (i.e. see all the traffic, monitor/access all the things)
    ▸ Testing the “security of security products” is always interesting
    ▸ Big vendor buys small vendor, integrates then shelves them…meaning
    security is often overlooked


    View Slide

  6. PREVIOUS (NOT US) RESEARCH
    ▸ A bunch of blog posts and whitepapers by Securosis
    ▸ “Defeating DLP”, Matasano, BlackHat USA 2007
    ▸ “Gone in 60 Minutes: Stealing Sensitive Data from Thousands of Systems
    Simultaneously with OpenDLP”, Andrew Gavin, DEFCON 19
    ▸ Many others...

    View Slide

  7. DLP ARCHITECTURE EXAMPLE

    View Slide

  8. DLP ARCHITECTURE EXAMPLE

    View Slide

  9. DLP WORKFLOW EXAMPLE - TREND MICRO

    View Slide

  10. TARGETS

    View Slide

  11. ROUND ONE: "BIG"* VENDORS
    Trend Micro DLP Management Appliance 5.6 Linux
    DLP Endpoint Agent 5.6 Windows
    Sophos Astaro UTM Appliance 9.201 Linux
    Sophos Enterprise Console 5.2.1r2 Windows
    Sophos Endpoint Security N/A Windows
    Websense TRITON Management Server 7.8.3 Windows
    Data Protector Endpoint Agent 7.8.3 Windows, Linux, OS X
    Data Security Protector Appliance 7.8.3 Linux
    OpenDLP OpenDLP 0.5.1 Linux
    Vendor Product Version OS
    * - and an open source product, for good measure

    View Slide

  12. TREND MICRO
    ▸ Windows endpoint agent - monitoring and policy enforcement on client
    machines
    ▸ Acts like a “legitimate” rootkit and hides itself
    ▸ Network agent - virtual appliance; monitors network traffic
    ▸ Remote crawler - for digital assets on machines not on corporate network
    ▸ Management server - Linux-based virtual appliance

    View Slide

  13. WEBSENSE
    ▸ TRITON management server - unified management console; Apache Coyote on Windows,
    backed by MSSQL DB
    ▸ Windows, OS X, Linux endpoint agents
    ▸ File and network drivers
    ▸ Can also monitor clipboard operations
    ▸ Linux-based “Protector” appliance
    ▸ Restricted “admin” shell
    ▸ Crawler agents can index/identify sensitive documents

    View Slide

  14. SOPHOS
    ▸ Enterprise Management Console - fat/native, Windows-based unified
    management console
    ▸ Whole lotta .NET…
    ▸ Sophos endpoint security - antivirus + DLP + … (Windows, OS X, Linux)

    View Slide

  15. OPENDLP
    ▸ Typically Linux virtual appliance
    ▸ Apache + a lot of Perl
    ▸ Windows agent
    ▸ File system crawler and document parser (PCRE-based)
    ▸ SSHFS-based crawler
    ▸ And some Metasploit modules (wtf?)

    View Slide

  16. ON THE UBIQUITY OF KEYVIEW…
    ▸ “kvoop” binary (“KeyView OOP”) showed up a lot
    ▸ Part of KeyView Filter SDK, used for parsing and normalizing various data and document formats
    ▸ Used in numerous DLP products, messaging servers, and "big data" platforms
    ▸ e.g. “EPClassifier” in Websense spawns kvoop processes to handle documents

    View Slide

  17. BECAUSE "PR" AND "LEGAL", THE VENDORS/
    PRODUCT NAMES (FOR OUR SECOND ROUND OF
    RESEARCH) HAVE BEEN CHANGED FOR THE
    PURPOSES OF THIS PRESENTATION
    DISCLAIMER :(

    View Slide

  18. ROUND TWO: NICHE/SMALL(ER) VENDORS
    Alpha Alpha DLP Management Virtual Appliance Linux
    Alpha DLP Endpoint Agent Windows
    Bravo Bravo DLP Management Server Windows
    Bravo DLP Endpoint Agent Windows, OS X
    Charlie Charlie DLP Management Virtual Appliance Linux
    Charlie DLP Agent Windows, Linux, OS X
    Dingus Dingus DLP Central Console Virtual Appliance Linux
    Dingus Network DLP Virtual Appliance Linux
    Dingus DLP Endpoint Agent Windows
    Vendor Product OS

    View Slide

  19. ALPHA DLP
    ▸ An amalgamation of everything you hate:
    ▸ Previously OSS product, closed after acquisition!
    ▸ Admin panel entirely in Flash!
    ▸ Windows agent is a horrifying Frankenstein of:
    ▸ .NET...Java....and Erlang.
    ▸ Uses Action Message Format for communications!
    ▸ Backend: Apache + Jetty + MySQL

    View Slide

  20. BRAVO DLP
    ▸ Windows-based management console (MMC snap-in)
    ▸MS SQL DB backend
    ▸ Windows-based content monitoring server (separate service from management console)
    ▸ Windows endpoint agent
    ▸All sorts of drivers (NDIS, TDI, FS, etc.) and hooks
    ▸OS X endpoint agent
    ▸Similar to Windows agent, but with less support for certain operations
    ▸Tons of open source / free libs
    ▸Boost, FreeDCE, etc.

    View Slide

  21. CHARLIE DLP
    ▸ Linux (Ubuntu) virtual appliance
    ▸ Windows endpoint agent
    ▸File monitor / scanner service
    ▸Clipboard monitor
    ▸Net traffic / URL monitoring
    ▸ Linux endpoint agent (Ubuntu/Debian)
    ▸File monitor / scanner daemon
    ▸GNOME / KDE notification tray thing
    ▸ OS X endpoint agent
    ▸Didn't really evaluate this
    ▸Also does a bunch of MDM-type stuff, but
    didn't look at this

    View Slide

  22. DINGUS DLP (WHICH IS A TOTALLY HYPOTHETICAL VENDOR/PRODUCT)
    ▸ Linux (CentOS) virtual appliance (management)
    ▸ Dingus Network DLP Appliance
    ▸Linux (CentOS) virtual appliance
    ▸In-line, tap/SPAN, etc. to monitor (or proxy) traffic
    ▸ Windows endpoint agent
    ▸Usual rigamarole - monitor clipboard, filesystem, network traffic/URLs, etc.

    View Slide

  23. ASSESSMENT
    CRITERIA/
    METHODOLOGY

    View Slide

  24. METHODOLOGY
    Network Appliance Parsers (docs and configuration) Invalid/mangled files
    Update/Deployment mechanism Protocol analysis; crypto/signing
    Operating System Configuration auditing
    Hardening practices
    Endpoints/Agents Parsers (docs and configuration) Invalid/mangled files
    Update/Deployment mechanism Protocol analysis; crypto/signing
    Drivers and Services Hardening practices/config
    Fuzzing (i.e. IOCTLs, network, etc.)
    Management Server Web Server/Web App OWASP Top 10 type stuff
    Database Configuration auditing
    Sensitive data storage
    Operating System Configuration auditing
    Hardening practices
    Target Component Test(s)

    View Slide

  25. FINDINGS

    View Slide

  26. GENERAL OBSERVATIONS
    ▸ Little to no hardening on (Linux) appliances
    ▸ Many services run as root
    ▸ Lack of exploit mitigations (beyond intrinsic/baseline OS mitigations)
    ▸ Highly privileged endpoint agent software out of the box (root, LOCALSYSTEM)
    ▸ General absence of security best practices
    ▸ Comms encryption, webappsec101, etc.
    ▸ Occasional bug inheritance
    ▸Outdated JREs, FreeDCE, etc.

    View Slide

  27. FINDINGS -
    TREND MICRO

    View Slide

  28. TREND MICRO - XSS

    View Slide

  29. TREND MICRO - CSRF

    View Slide

  30. TREND MICRO - PLAINTEXT CRAWLER COMMS

    View Slide

  31. FINDINGS -
    SOPHOS

    View Slide

  32. SOPHOS MANAGER/ENDPOINT: WHAT WE DIDN’T FIND
    ▸ Majority of code implemented in .NET
    ▸ Utilizes most of the MS core libraries,
    which means:
    ▸ DB best practices
    ▸ Contextualized Input/Output
    ▸ Standardized Encryption Libraries

    View Slide

  33. SOPHOS/ASTARO UTM: NOT A WHOLE LOT…
    ▸ Most services chroot’ed (eh…), drop
    privs
    ▸ Web app fairly clean (just a few really
    low impact “issues”)
    ▸ Tight network- and login-access control
    restrictions

    View Slide

  34. FINDINGS -
    OPENDLP

    View Slide

  35. OPENDLP - CSRF

    View Slide

  36. FINDINGS -
    WEBSENSE

    View Slide

  37. ON WEBSENSE POLICIES...
    ▸ Websense DLP policy objects include keywords,
    regexes, etc.
    ▸ Regex entries are actually Python pickled
    objects
    ▸ TRITON management server encrypts, bundles
    policies/files, pushes to agents and appliances

    View Slide

  38. WEBSENSE PROTECTOR & ENDPOINT - CODE EXEC
    Say a local admin on TRITON
    server replaces “.pic” file with
    custom pickled objects…
    Our awful

    pickle POC;

    after

    overwriting a

    “legitimate”

    policy file
    Reverse
    shell from
    Protector

    after policy
    update

    View Slide

  39. FINDINGS -
    ALPHA DLP

    View Slide

  40. ALPHA DLP - SERVER/ ADMIN FINDINGS
    ▸ The Good:
    ▸ No CSRF
    ▸ No obvious XSF
    ▸ Proper use of Hibernate - no SQLi
    ▸ The Bad:
    ▸ No authentication on MySQL database
    ▸ User hashes are not salted
    ▸ Frequent crashes

    View Slide

  41. ALPHA DLP - AGENT FINDINGS
    ▸ Heavy use of marshalling between Java and Erlang
    ▸ Potential heap corruption?
    ▸ Packaged an oooooold JRE



    ▸ Path manipulation in accessing Erlang rules
    ▸ No assembly signing on .NET assemblies… #waitforit

    View Slide

  42. ALPHA DLP - AGENT MODIFICATION

    View Slide

  43. FINDINGS -
    BRAVO DLP

    View Slide

  44. BRAVO DLP
    ▸ Probably the most complex/sophisticated of all the
    ones we analyzed
    ▸ Also the one we most heavily reversed
    ▸ tl;dr - Spent too much time, found very little, got
    lazy moved on
    ▸ Use of DCERPC for agent<->server comms
    is...good?
    ▸ Benefit from NTLMSSP and "packet
    privacy" (encrypted)
    ▸ Except for OS X agent, which is all plaintext
    comms

    View Slide

  45. FINDINGS -
    CHARLIE DLP

    View Slide

  46. CHARLIE DLP - MANAGEMENT SERVER
    ▸ No anti-CSRF tokens
    ▸ Pretty much all operations are done REST-fully
    ▸ Example: CSRF an admin, delete policy by ID

    View Slide

  47. CHARLIE DLP - MANAGEMENT SERVER
    ▸ Unauthenticated registration of new (or arbitrary) endpoint agents via SOAP API
    ▸ Also injecting CDATA with JS rendered in admin console
    Super amazing
    JS alert() skillz

    View Slide

  48. FINDINGS -
    DINGUS DLP

    View Slide

  49. BECAUSE "PR" AND "LEGAL", THE FOLLOWING VENDOR, DESPITE
    BEING REDACTED, SHOULD BE CONSIDERED *TOTALLY HYPOTHETICAL*
    (ALSO, WE HAND DREW SOME SCREENSHOTS BECAUSE, AGAIN,
    *TOTALLY HYPOTHETICAL*)
    ADDITIONAL DISCLAIMER :(

    View Slide

  50. DINGUS - NETWORK DLP APPLIANCE
    ▸ Support account that's TOTALLY not a
    backdoor
    ▸ Reverse SSHes to some Eastern European-
    based SSH proxy
    ▸ Same (non-password protected) DSA key
    across every appliance
    ▸ Allows "support" to log in as root on
    appliance
    ▸ Invoked from web UI
    ▸ Combined with CSRF = reverse tunnel
    wherever

    View Slide

  51. DINGUS - NETWORK DLP APPLIANCE
    CSRF + command injection
    Note the semicolon

    View Slide

  52. DINGUS - NETWORK DLP APPLIANCE
    CSRF + command injection

    View Slide

  53. DINGUS - NETWORK DLP APPLIANCE
    Numerous whitelisted (NOPASSWD) sudoers entries for apache
    arbitrary package

    installation, anyone?

    View Slide

  54. DINGUS DLP - CENTRAL CONSOLE
    ▸ Unauthenticated DB
    management script
    ▸ Clear DB, rebuild,
    update, etc.

    View Slide

  55. DINGUS - NETWORK DLP/CENTRAL CONSOLE
    ▸ Synchronization channel is just
    straight up plaintext PostgreSQL
    comms...with simple auth
    ▸ Just username + DB name
    (HYPOTHETICAL example:
    appliance:appliance)
    ▸ Pushes ACLs and rules down to
    appliance from Console
    (Yes, that is a hand drawn Wireshark “screenshot”)

    View Slide

  56. A NOTE ON DLP
    BYPASSES

    View Slide

  57. EVASION IS INEVITABLE
    ▸ Unsupported or obscure file formats, protocols, or
    unexpected network behavior
    ▸ Think: fragment/datagram reassembly ordering
    ▸ Obfuscated or encrypted files
    ▸ Steganography, anyone?
    ▸ How many of your users have elevated (admin,
    sudo/root) privileges?
    ▸ e.g. disable endpoint agents

    View Slide

  58. ▸ Defenses add weaknesses
    ▸ "Caveat emptor"
    ▸ Every new piece of infrastructure is additional attack
    surface
    ▸ Security companies should know better
    ▸ If a scanner can find it, what’s your excuse?
    ▸ Know what/who you’re defending against
    ▸ An advanced insider probably has own abilities
    BLACK HAT ASIA TAKEAWAYS

    View Slide

  59. QUESTIONS?
    [email protected]
    @aloria
    [email protected]
    @quine

    View Slide
