Why MVI? Model View Intent -- The curious case of yet another pattern

All of us are aware of many architectural patterns like MVC, MVP, MVVM, etc. It was not long ago when we had started applying MVP or MVVM to our projects. It was not an easy task to refactor existing code to adopt these patterns, plus the cost of bringing the whole team to the same level was not insignificant. These patterns brought along many advantages like separation of logic and better testing.

We are happy with where our codebase is at the moment and it’s test coverage. Why do we then need to move to a new pattern now? What real problem does this pattern solve? Are all my efforts gone in vain now that we have a new pattern?

There have been multiple talks about MVI, so let's take a different approach & instead of jumping directly into code, let's answer the above questions first using the approach below:

In this talk:
- We will learn about the main problem that this pattern solves - The State Problem, What it is and how MVI solves it.
- We will also learn that MVI can also be applied on top of our existing patterns.
- We need not completely change the style that we have already adopted. Instead we can modify our existing style to take the advantage of the reactive flow and achieve better state management.

Transcript

1. Why MVI?
   “Curious case of yet another pattern"
   Garima Jain
   @ragdroid


   View Slide

2. @ragdroid
   @droidconBos
   Why MVI?
   MVP / MVVM -> MVI


   View Slide

3. @ragdroid
   @droidconBos
   Part 1
   Why MVI?


   View Slide

4. @ragdroid
   @droidconBos
   MVI


   View Slide

5. @ragdroid
   @droidconBos
   Model View Intent


   View Slide

6. @ragdroid
   @droidconBos
   State View Intention
   Model View Intent


   View Slide

7. @ragdroid
   @droidconBos
   User
   Intent
   State
   View
   State View Intention


   View Slide

8. @ragdroid
   @droidconBos
   User
   Intent
   State
   View
   Interacts
   Changes
   Updates
   Seen
   State View Intention


   View Slide

9. @ragdroid
   @droidconBos
   Model View Intent
   State


   View Slide

10. @ragdroid
    @droidconBos
    State
    Single Source of Truth


    View Slide

11. @ragdroid
    @droidconBos
    printing
    length
    completed
    noInternet
    loggedIn
    size
    scanning
    index
    State
    sPullToRefreshing
    List
    isButtonEnabled
    pageNo
    electedItem
    isChecked
    e
    r
    r
    o
    r
    M
    s
    g
    i
    s
    V
    i
    s
    i
    B
    l
    e
    i
    s
    L
    o
    a
    d
    i
    n
    g
    sLoadMore
    pen
    r
    u
    n
    n
    i
    n
    g
    active
    l
    i
    k
    e
    d
    l
    o
    c
    a
    t
    i
    o
    n
    i
    d
    l
    e


    View Slide

12. @ragdroid
    @droidconBos
    State


    View Slide

13. @ragdroid
    @droidconBos
    ItemsFragment
    State


    View Slide

14. @ragdroid
    @droidconBos
    State {
    loading = true
    items = EMPTY
    }
    State


    View Slide

15. @ragdroid
    @droidconBos
    State {
    loading = false
    items = EMPTY
    emptyStateVisible = true
    }
    State


    View Slide

16. @ragdroid
    @droidconBos
    State {
    loading = false
    refreshing = true
    items = EMPTY
    emptyStateVisible = true
    }
    State


    View Slide

17. @ragdroid
    @droidconBos
    State {
    loading = false
    refreshing = false
    items = EMPTY
    emptyStateVisible = false
    errorMsg = “No Internet”
    }
    State


    View Slide

18. @ragdroid
    @droidconBos
    State {
    loading = false
    refreshing = false
    items = List
    emptyStateVisible = false
    errorMsg = “”
    }
    State


    View Slide

19. @ragdroid
    @droidconBos
    State Problem


    View Slide

20. @ragdroid
    @droidconBos


    View Slide

21. @ragdroid
    @droidconBos
    View Presenter Data
    User Time


    View Slide

22. @ragdroid
    @droidconBos
    View Presenter
    showLoading( )
    Result : [ ]
    Data
    User
    start()
    refresh()
    loadItems( )
    setRefreshing( )
    Result : [ ]
    showEmptyState( )
    hideLoading( )
    showEmptyState( )
    hideLoading( )??
    refresh( )


    View Slide

23. @ragdroid
    @droidconBos
    Presenter
    loadItems( )
    refresh( )
    Multiple Inputs


    View Slide

24. @ragdroid
    @droidconBos
    Presenter
    showEmptyState( )
    hideLoading( )
    showEmptyState( )
    hideLoading( )??
    Multiple Outputs !!!


    View Slide

25. @ragdroid
    @droidconBos
    State of UI coordinated by Presenter (or VM)
    Presenter, Business Logic and View : own states.
    MVI: Single Source of Truth : Hannes Model / View State
    MVI: Presenter has a single output : f(x) = y OR f(a,b,c) = y
    State Problem


    View Slide

26. @ragdroid
    @droidconBos
    MVP / MVVM -> MVI
    Part 2


    View Slide

27. @ragdroid
    @droidconBos
    MVPI


    View Slide

28. @ragdroid
    @droidconBos
    View Presenter Data
    State {
    loading = true
    refreshing = false
    items = EMPTY
    emptyStateVisible = false
    errorMsg = “”
    }
    UIEvent
    Reducer
    newState
    Action
    initialState
    Result
    MVPI with Initial State


    View Slide

29. @ragdroid
    @droidconBos
    View Presenter Data
    State {
    loading = true
    refreshing = false
    items = EMPTY
    emptyStateVisible = false
    errorMsg = “”
    }
    UIEvent
    Reducer
    newState
    Action
    Result
    oldState
    MVPI with Old State


    View Slide

30. @ragdroid
    @droidconBos
    View Presenter Data
    Start
    Reducer
    newState
    LoadItems
    Loading
    Loading
    initialState
    State {
    loading = true
    refreshing = false
    items = EMPTY
    emptyStateVisible = false
    errorMsg = “”
    }


    View Slide

31. @ragdroid
    @droidconBos
    View Presenter Data
    State {
    loading = true
    refreshing = false
    items = EMPTY
    emptyStateVisible = false
    errorMsg = “”
    }
    Start
    Reducer
    newState
    Loading
    initialState
    Loading
    LoadItems


    View Slide

32. @ragdroid
    @droidconBos
    View Presenter Data
    Reducer
    Empty
    Start
    Result : [ ]
    Empty
    oldState
    newState
    State {
    loading = true
    refreshing = false
    items = EMPTY
    emptyStateVisible = false
    errorMsg = “”
    }
    LoadItems


    View Slide

33. @ragdroid
    @droidconBos
    View Presenter Data
    State {
    loading = false
    refreshing = false
    items = EMPTY
    emptyStateVisible = true
    errorMsg = “”
    }
    Start
    Result : [ ]
    Reducer
    newState
    oldState
    Empty
    Empty
    LoadItems


    View Slide

34. @ragdroid
    @droidconBos
    View Presenter Data
    Pull
    To
    Refresh
    Reducer
    newState
    RefreshItems
    oldState
    Refreshing
    Refreshing
    State {
    loading = false
    refreshing = false
    items = EMPTY
    emptyStateVisible = true
    errorMsg = “”
    }


    View Slide

35. @ragdroid
    @droidconBos
    View Presenter Data
    Pull
    To
    Refresh
    Reducer
    newState
    RefreshItems
    oldState
    Refreshing
    Refreshing
    State {
    loading = false
    refreshing = true
    items = EMPTY
    emptyStateVisible = true
    errorMsg = “”
    }


    View Slide

36. @ragdroid
    @droidconBos
    View Presenter Data
    Pull
    To
    Refresh
    Reducer
    newState
    RefreshItems
    Result : [ ]
    oldState
    RefreshEmpty
    RefreshEmpty
    State {
    loading = false
    refreshing = true
    items = EMPTY
    emptyStateVisible = true
    errorMsg = “”
    }


    View Slide

37. @ragdroid
    @droidconBos
    View Presenter Data
    State {
    loading = false
    refreshing = false
    items = EMPTY
    emptyStateVisible = true
    errorMsg = “”
    }
    Pull
    To
    Refresh
    Reducer
    newState
    RefreshItems
    Result : [ ]
    oldState
    RefreshEmpty
    RefreshEmpty


    View Slide

38. @ragdroid
    @droidconBos
    View Presenter Data
    State {
    loading = true
    refreshing = false
    items = EMPTY
    emptyStateVisible = false
    errorMsg = “”
    }
    UIEvent
    Reducer
    newState
    Action
    Result
    oldState
    MVPI with Concurrent Events
    UIEvent Action
    Result
    oldState
    newState


    View Slide

39. @ragdroid
    @droidconBos
    Rules of Thumb


    View Slide

40. @ragdroid
    @droidconBos
    Plain Objects
    Must have a type which is not undefined
    Convey intention of user
    User triggers Actions
    Action


    View Slide

41. @ragdroid
    @droidconBos
    Immutable : List / Object nothing is mutable
    Set representing the state of View
    Any change is triggered only by dispatching an action
    State


    View Slide

42. @ragdroid
    @droidconBos
    Function of previous state & result (action/ partialState)
    f(previousState, Result) = new State
    Return current state for unknown result
    Reducer


    View Slide

43. @ragdroid
    @droidconBos
    Code


    View Slide

44. @ragdroid
    @droidconBos
    interface View {
    /**
    * Expose various intents
    */
    fun pullToRefreshIntent(): Observable
    fun loadingIntent(): Observable
    fun render(state: State)
    }
    View


    View Slide

45. @ragdroid
    @droidconBos
    fun pullToRefreshIntent(): Observable =
    refreshLayout.refreshes()
    .map { ignored -> true }
    View
    fun loadingIntent(): Observable =
    Observable.just(true)


    View Slide

46. @ragdroid
    @droidconBos
    data class State(
    val loading: Boolean,
    val items: List,
    val loadingError: Throwable?,
    val pullToRefreshing: Boolean,
    val pullToRefreshError: Throwable?,
    val emptyStateVisible: Boolean)
    State


    View Slide

47. @ragdroid
    @droidconBos
    sealed class Result {
    object Loading: Result()
    object LoadingEmpty: Result()
    data class LoadingError(val throwable: Throwable): Result()
    data class LoadingComplete(val characters: List):
    Result()
    object PullToRefreshing: Result()
    object PullToRefreshEmpty: Result()
    data class PullToRefreshError(val throwable: Throwable):
    Result()
    data class PullToRefreshComplete(val characters: List):
    Result()
    }
    Result


    View Slide

48. @ragdroid
    @droidconBos
    fun attachView(view: View) {
    val loadingResult = subscribeToLoading()
    val pullToRefreshResult = subscribeToPullToRefresh()
    val allResultObservable =
    Observable.merge(loadingResult, pullToRefreshResult)
    subscribeToStates(allResultObservable)
    }
    Presenter


    View Slide

49. @ragdroid
    @droidconBos
    interface Repository {
    fun loadItems(): Observable>
    }
    Repository


    View Slide

50. @ragdroid
    @droidconBos
    fun subscribeToLoading(): Observable =
    view.loadingIntent()
    .flatMap {
    repository.loadItems()
    .map { items ->
    if (items.isEmpty())
    Result.LoadingEmpty
    else
    Result.LoadingComplete(items)
    }
    }
    .onErrorReturn { Result.LoadingError(it) }
    Presenter


    View Slide

51. @ragdroid
    @droidconBos
    fun subscribeToPullToRefresh(): Observable {
    return view.pullToRefreshIntent()
    .flatMap {
    repository.loadItems()
    .map { items ->
    if (items.isEmpty())
    Result.PullToRefreshEmpty
    else
    Result.PullToRefreshComplete(items)
    }
    .startWith(Result.PullToRefreshing)
    }
    .onErrorReturn { Result.PullToRefreshError(it) }
    }
    Presenter


    View Slide

52. @ragdroid
    @droidconBos
    fun subscribeToStates(allResultObservable): Disposable {
    return allResultObservable
    .scan(State.init()) {
    previousState, result ->
    reducer(previousState, result)
    }
    .observeOn(UISched)
    .subscribe(
    { state ->
    view.render(state)
    },
    { Timber.e(it) }
    )
    }
    Presenter


    View Slide

53. @ragdroid
    @droidconBos
    fun reducer(previousState: State, result: Result): State =
    when (result) {
    is Result.Loading -> previousState.copy(
    loading = true,
    loadingError = null)
    is Result.LoadingError -> previousState.copy(
    loading = false,
    loadingError = result.throwable)
    is Result.LoadingComplete -> previousState.copy(
    loading = false,
    loadingError = null,
    items = result.characters)
    is Result.LoadingEmpty -> previousState.copy(
    loading = false,
    loadingError = null,
    items = emptyList(),
    emptyStateVisible = true)
    ...
    }
    Presenter


    View Slide

54. @ragdroid
    @droidconBos
    fun reducer(previousState: State, result: Result): State =
    when (result) {
    ...
    is Result.PullToRefreshing -> previousState.copy(
    loading = false,
    pullToRefreshing = true,
    pullToRefreshError = null)
    is Result.PullToRefreshError -> previousState.copy(
    pullToRefreshing = false,
    pullToRefreshError = result.throwable)
    is Result.PullToRefreshComplete -> previousState.copy(
    pullToRefreshing = false,
    pullToRefreshError = null,
    items = result.characters)
    is Result.PullToRefreshEmpty -> previousState.copy(
    pullToRefreshing = false,
    loadingError = null,
    items = emptyList(),
    emptyStateVisible = true
    )
    }
    Presenter


    View Slide

55. @ragdroid
    @droidconBos
    fun render(state: State) {
    binding.model = state
    when {
    state.pullToRefreshError != null -> return@render
    state.emptyStateVisible -> return@render
    state.loadingError != null -> {
    //show error
    return@render
    }
    else -> {
    //show list
    }
    }
    }
    View


    View Slide

56. @ragdroid
    @droidconBos
    Why MVI?
    Hannes Dorfmann MVI Series


    View Slide

57. @ragdroid
    @droidconBos
    State Problem


    View Slide

58. @ragdroid
    @droidconBos
    Orientation Changes


    View Slide

59. @ragdroid
    @droidconBos
    Navigation & Pop Backstack


    View Slide

60. @ragdroid
    @droidconBos
    Process Death


    View Slide

61. @ragdroid
    @droidconBos
    Immutability


    View Slide

62. @ragdroid
    @droidconBos
    Debuggable


    View Slide

63. @ragdroid
    @droidconBos
    Testability


    View Slide

64. @ragdroid
    @droidconBos
    Conclusion


    View Slide

65. @ragdroid
    @droidconBos
    If you model your system as pure functions,
    you will get a finite state machine
    - @ragdroid
    Try to avoid side-effects and
    model your screens as pure functions.
    - @ragdroid
    MVI is MVP or MVVM done right.
    - @_riteshhh
    MVI prevents us from misusing
    patterns like MVP or MVVM.
    - @_riteshhh


    View Slide

66. @ragdroid
    @droidconBos
    http://hannesdorfmann.com/android/mosby3-mvi-1 - Hannes Dorfmann
    http://fragmentedpodcast.com/tag/hannes-dorfmann/ - Hannes Dorfmann
    https://www.youtube.com/watch?v=0IKHxjkgop4 - Jake Wharton
    https://www.youtube.com/watch?v=64rQ9GKphTg - Benoit Quenaudon
    https://github.com/oldergod - Benoit Quenaudon
    https://egghead.io/courses/getting-started-with-redux - Dan Abramov
    References


    View Slide

67. @ragdroid
    @droidconBos
    https://github.com/ragdroid/klayground
    Demo


    View Slide

68. FUELED
    http://fueled.com/garima
    garima@fueled.com
    THANK YOU


    View Slide
