How to Compare Fuzzers

SAPLING'24

Transcript

1.  1 How to Compare Fuzzers Rahul Gopinath https://rahul.gopinath.org rahul@gopinath.org @rahul@gopinath.org with mutation analysis
2. 2 How to Compare Fuzzers Rahul Gopinath https://rahul.gopinath.org rahul@gopinath.org @rahul@gopinath.org with mutation analysis
3. Monzo Each node is a service
4. https://blog.qualys.com/vulnerabilities-threat-research/2023/09/04/qualys-top-20-exploited-vulnerabilities Bugs ... Are a Fact of Life
5. Bugs ... How Do We Remove Them? Report all violations All reported violations are true Guarantees of resulting artefacts False Alarms Dynamic Analysis Software Testing Static Analysis Type Checking Missing cases
6. 6 Input ✓ ✘ @app.route('/admin') def admin(): username = request.cookies.get("username") if not username: return {"Error": "Specify username in Cookie"} username = urllib.quote(os.path.basename(username)) url = "http://permissions:5000/permissions/{}".format(username) resp = requests.request(method="GET", url=url) # "superadmin\ud888" will be simpli fi ed to "superadmin" ret = ujson.loads(resp.text) if resp.status_code == 200: if "superadmin" in ret["roles"]: return {"OK": "Superadmin Access granted"} else: e = u"Access denied. User has following roles: {}".format(ret["roles"]) return {"Error": e}, 401 else:return {"Error": ret["Error"]}, 500 Software Testing -- Key to Bug Removal
7. struct { type: error; payload_length: 4; payload[HELO]; } HeartbeatMessage; struct { type: response; payload_length: 64k; payload[HELO..dafdf..maybe...a..secret key...in...the...memory...or...other.. sensitive...information...that...the.. attacker..is..interested...in...afdfdf adfdfdf..and..other..random..junk]; } HeartbeatMessage; 7 Input ✓ ✘ Testing struct { type: request; payload_length: 64k; payload[HELO]; } HeartbeatMessage; /* Allocate memory for the response, size is 1 byte * message type, plus 2 bytes payload length, plus * payload, plus padding */ buffer = OPENSSL_malloc(1 + 2 + payload + padding); bp = buffer; /* Enter response type, length and copy payload */ *bp++ = TLS1_HB_RESPONSE; s2n(payload, bp); memcpy(bp, pl, payload); /* Random padding */ RAND_pseudo_bytes(p, padding); r = dtls1_write_bytes(s, TLS1_RT_HEARTBEAT, buffer, 3 + payload + padding);
8. @app.route('/admin') def admin(): username = request.cookies.get("username") if not username: return {"Error": "Specify username in Cookie"} username = urllib.quote(os.path.basename(username)) url = "http://permissions:5000/permissions/{}".format(username) resp = requests.request(method="GET", url=url) # "superadmin\ud888" will be simpli fi ed to "superadmin" ret = ujson.loads(resp.text) if resp.status_code == 200: if "superadmin" in ret["roles"]: return {"OK": "Superadmin Access granted"} else: e = u"Access denied. User has following roles: {}".format(ret["roles"]) return {"Error": e}, 401 else:return {"Error": ret["Error"]}, 500 [ ; x 1 - G P Z + w c c k c ] ; , N 9 J + ? # 6 ^ 6 \ e ? ] 9 l u 2 _ % ' 4 G X " 0 V U B [ E / r ~ f A p u 6 b 8 < { % s i q 8 Z h . 6 { V , h r ? ; {Ti.r3PIxMMMv6{xS^+'Hq!AxB"YXRS@! Kd6;wtAMefFWM(`|J_<1~o}z3K(CCzRH J I I v H z > _ * . \ > J r l U 3 2 ~ e G P ? lR=bF3+;y$3lodQ<B89!5"W2fK*vE7v{')KC- i,c{<[~m!]o;{.'}Gj\(X}EtYetrpbY@aGZ1{P! A Z U 7 x # 4 ( R t n ! q 4 n C w q o l ^ y 6 } 0 | Ko=*JK~;zMKV=9Nai:wxu{J&UV#HaU)*Bi C < ) , ` + t * g k a < W = Z . % T 5 W G H Z p I 3 0 D < P q > & ] B S 6 R & j ? # t P 7 i a V } - } ` \ ? [ _ [ Z ^ L B M P G - FKj'\xwuZ1=Q`^`5,$N$Q@[!CuRzJ2D|vBy! ^ z k h d f 3 C 5 P A k R ? V ( ( - % > < h n | 3='i2Qx]D$qs4O`1@fevnG'2\11Vf3piU37@ 5 : d f d 4 5 * ( 7 ^ % 5 a p \ z I y l " ' f , $ee,J4Gw:cgNKLie3nx9(`efSlg6#[K"@Wjh Z}r[Scun&sBCS,T[/3]KAeEnQ7lU)3Pn,0)G/ 6N-wyzj/MTd#A;r Program Fuzzing 8 https://www.fuzzingbook.org/html/Fuzzer.html
9. @app.route('/admin') def admin(): username = request.cookies.get("username") if not username: return {"Error": "Specify username in Cookie"} username = urllib.quote(os.path.basename(username)) url = "http://permissions:5000/permissions/{}".format(username) resp = requests.request(method="GET", url=url) # "superadmin\ud888" will be simpli fi ed to "superadmin" ret = ujson.loads(resp.text) if resp.status_code == 200: if "superadmin" in ret["roles"]: return {"OK": "Superadmin Access granted"} else: e = u"Access denied. User has following roles: {}".format(ret["roles"]) return {"Error": e}, 401 else:return {"Error": ret["Error"]}, 500 Fuzzing Trash deck technique: 1950s - Gerald Weinberg Crash? 9
10. 10 Variety of Fuzzers Publications from 2023-2024
11. 11 Which Fuzzer Should We Use? Exponential growth in fuzzing literature Cumulative publications in fuzzing Cumulative published vulnerabilities
12. 12 Which Evaluation Metric Should I Use? • Comparable • Ground truth • Unbiased • Budget friendly
13. 13 New CVEs Found? CVE, short for Common Vulnerabilities and Exposures, is a list of publicly disclosed computer security fl aws.
14. 14 • Comparable • Ground truth • Unbiased • Budget friendly Which Fuzzer Should I Use? New CVEs ? ?
15. 15 Evaluate Fuzzers Based on the Speci fi ed Goal Coverage?
16. 16 • Gets saturated quickly (Signal is lost) • Is reachability sufficient? • Limited evaluation of complex input conditions involved in expressing bugs • Are more complex coverage techniques needed? Coverage?
17. 17 • Comparable • Ground truth • Unbiased • Budget friendly Which Fuzzer Should I Use? New CVEs ? ? Coverage
18. 18 Synthetic Bugs? Evaluate Fuzzers Based on the Speci fi ed Goal
19. 19 Synthetic Bugs? LAVA: Large-scale Automated Vulnerability Addition • What kind of bugs should be seeded? • What about unknown kinds of bugs? • Where should these bugs be seeded?
20. 20 • Comparable • Ground truth • Unbiased • Budget friendly Which Fuzzer Should I Use? New CVEs ? ? Coverage Synthetic (LAVA) ? ?
21. 21 Curated Bug Benchmarks? Evaluate Fuzzers Based on the Speci fi ed Goal
22. 22 Known Bug Benchmarks? E.g. Magma
23. 23 Known Bug Benchmarks? • Gets outdated quickly (overfitting by fuzzers) • Significant effort in creating and maintaining • Biased as to where and what kind of bugs are present "When a measure becomes a target it ceases to be a good measure" Goodhart's law
24. 24 • Comparable • Ground truth • Unbiased • Budget friendly Which Fuzzer Should I Use? New CVEs ? ? Coverage Synthetic (LAVA) ? ? Benchm arks (M AGM A) ?
25. 25 New Bugs in Existing Benchmarks Evaluate Fuzzers Based on the Speci fi ed Goal
26. 26 New Bugs in Existing Benchmarks • No ground truth • Bug distribution is dependent on external factors • Can lead researchers to postpone publication of vulnerabilities • Feedback can't be used to decide budgeting.
27. 27 • Comparable • Ground truth • Unbiased • Budget friendly Which Fuzzer Should I Use? New CVEs ? ? Coverage Synthetic (LAVA) ? ? Benchm arks (M AGM A) ? New Bugs in old Benchm arks ? Can
29. 29 Fuzzing Your Fuzzer a.k.a. Mutation Testing
30. 30 unsigned int len = message_length(msg); if (len < MAX_BUF_LEN) { copy_message(msg); } else { // Invalid length, handle error } What Is Mutation Testing? IDEA: Induce a program variation with each valid token replacement
31. 31 unsigned int len = message_length(msg); if (len < MAX_BUF_LEN + 1) { copy_message(msg); } else { // Invalid length, handle error } What Is Mutation Testing? Fixes for independent bugs are almost always simple. Finite syntactic size for faults
 (aka. competent programmer hypothesis): Gopinath, Jensen, and Groce Mutations: How Close are they to Real Faults? 2014 ISSRE
32. 32 unsigned int len = message_length(msg); if (len < MAX_BUF_LEN) { copy_message(msg); } else { // Invalid length, handle error } What Is Mutation Testing? (1) IDEA: Induce a program variation with each valid token replacement
33. 33 unsigned int len = message_length(msg); if (len < >= MAX_BUF_LEN) { copy_message(msg); } else { // Invalid length, handle error } What Is Mutation Testing? (2) IDEA: Induce a program variation with each valid token replacement
34. 34 unsigned int len = message_length(msg); if (len < MAX_BUF_LEN + 1) { copy_message(msg); } else { // Invalid length, handle error } What Is Mutation Testing? (3) IDEA: Induce a program variation with each valid token replacement
35. 35 unsigned int len = message_length(msg); if (len < MAX_BUF_LEN + 16) { copy_message(msg); } else { // Invalid length, handle error } What Is Mutation Testing? Complex bugs are almost always coupled to simpler bugs. Finite semantic depth for failures
 aka. Coupling e ff ect hypothesis: Gopinath, Jensen, and Groce Mutations: How Close are they to Real Faults? 2017 ICST
36. 36 Parameter Interactions in Faults
37. 37 Mutation Testing Process m4 m3 m2 m1 I1 I2 I4 I3 I5 Generate Mutants Generate Fuzz Inputs > Detect Differences from Original > Mutation Score = Detected Mutants / Generated Mutants Original
38. 38 M mutants (1 input) Number of Mutants Executions Total Campaign Effort for mutation testing = MxN program executions Mutation Testing Challenge N inputs (1 mutant) Number of Inputs Executions
39. 39 What Is The Problem? Computation: Fuzzing -- More executions the better Mutation testing -- Execute each input per mutation Solution: 1) Perform coverage analysis fi rst; remove trivial mutants 2) Evaluate independent (non-interacting) mutations simultaneously 3) Remove redundancy in executions
40. https://rahul.gopinath.org Traditional execution 40 m1 m2 m3 Setup for T1 Setup for T2 Actual tests Mutants are executed in parallel But a majority of time spent in initialization (an average 7 times the test execution time) (Bell 2014)
41. https://rahul.gopinath.org Split-Stream Execution 41 Setup for T1 Setup for T2 Actual tests Execute tests in parallel Fork off mutants as they are encountered T1 T2 Gopinath, Jensen, Groce “Topsy Turvy: A faster and smarter algorithm” ICSE 2016
42. https://rahul.gopinath.org Split-Stream Execution 42
43. 43 • Comparable • Ground truth • Unbiased • Budget friendly Mutation Testing New CVEs ? ? Coverage Synthetic (LAVA) ? ? Benchm arks (M AGM A) ? New Bugs in old Benchm arks ? M utation Testing ?
45. 45 Seeded Fault Benchmarks • Easy to fine-tune a fuzzer to overfit • Faults are rarely similar to real faults • Based on bugs we know about! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
46. 46 Mutation Analysis • Easy to fine-tune a fuzzer to overfit • Faults are rarely similar to real faults • Based on bugs we know about! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
47. 47 Mutation Analysis • Easy to fine-tune a fuzzer to overfit Very large number of faults • Faults are rarely similar to real faults • Based on bugs we know about! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
48. 48 Mutation Analysis • Not easy to fine-tune • Faults are rarely similar to real faults • Based on bugs we know about! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
49. 49 Mutation Analysis • Not easy to fine-tune • Faults are rarely similar to real faults Evidence that mutants are similar to real faults. • Based on bugs we know about! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
50. 50 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • Based on bugs we know about! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
51. 51 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • Based on bugs we know about! All possible faults, including unknown ones! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
52. 52 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • All possible faults, including unknown ones! • Human bias in bug curation • Limited supply • Bug interactions requiring deduplication
53. 53 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • All possible faults, including unknown ones! • Human bias in bug curation No human bias in introduced faults! • Limited supply • Bug interactions requiring deduplication
54. 54 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • All possible faults, including unknown ones! • No human bias in introduced faults! • Limited supply • Bug interactions requiring deduplication
55. 55 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • All possible faults, including unknown ones! • No human bias in introduced faults! • Limited supply As many as required! Including higher order ones! • Bug interactions requiring deduplication
56. 56 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • All possible faults, including unknown ones! • No human bias in introduced faults! • As many as required! Including higher order ones! • Bug interactions requiring deduplication
57. 57 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • All possible faults, including unknown ones! • No human bias in introduced faults! • As many as required! Including higher order ones! • Bug interactions requiring deduplication All mutants are evaluated indepdently
58. 58 Mutation Analysis • Not easy to fine-tune • Evidence that mutants are similar to real faults. • All possible faults, including unknown ones! • No human bias in introduced faults! • As many as required! Including higher order ones! • All mutants are evaluated indepdently
