Stream processing made easy with riko

8th Light University talk on stream processing with riko

Transcript

1. Stream processing
   made easy with riko
   8th Light University - Chicago, IL
   May 30, 2017
   by Reuben Cummings
   @reubano #8LU


   View Slide

2. @reubano #8LU
   Who am I?
   Managing Director, Nerevu Development
   Programming in Python since 2011
   Author of several popular packages


   View Slide

3. streams


   View Slide

4. @reubano #8LU
   basic stream process
   1
   * 2 > 2 sum
   2
   3


   View Slide

5. @reubano #8LU
   2
   basic stream process
   * 2 > 2 sum
   2
   3


   View Slide

6. @reubano #8LU
   4
   basic stream process
   * 2 > 2 sum
   3


   View Slide

7. @reubano #8LU
   6 4
   basic stream process
   * 2 > 2 sum


   View Slide

8. @reubano #8LU
   4
   6
   basic stream process
   * 2 > 2 sum


   View Slide

9. @reubano #8LU
   10
   basic stream process
   * 2 > 2 sum


   View Slide

10. @reubano #8LU
    10
    basic stream process
    * 2 > 2 sum


    View Slide

11. constructing
    streams


    View Slide

12. >>> 'abracadabra'[0]
    'a'
    >>> 'hello 8th Light University'.split(' ')[0]
    'hello'
    >>> range(1, 11)[0]
    1
    >>> [{'x': x} for x in range(4)][0]
    {'x': 0}
    >>> ({'x': x} for x in range(4))
    at 0x103c10830>
    >>> next({'x': x} for x in range(4))
    {'x': 0}


    View Slide

13. processing
    streams


    View Slide

14. >>> [ord(x) for x in 'abracadabra']
    [97, 98, 114, 97, 99, 97, 100, 97, 98, 114,
    97]
    >>> [2 * x for x in range(1, 11)]
    [2, 4, 6, 8, 10, 12, 14, 16, 18, 20]
    >>> [x for x in range(1, 11) if x > 5]
    [6, 7, 8, 9, 10]
    >>> stream = ({'num': x} for x in range(4))
    >>> sum(s['num'] for s in stream)
    6


    View Slide

15. so what!


    View Slide

16. RSS feeds (feedly)


    View Slide

17. aggregators (kayak)


    View Slide

18. news feeds (linkedin)


    View Slide

19. frameworks


    View Slide

20. $ cat file.txt
    What is Lorem Ipsum?
    Lorem Ipsum is simply dummy text of the
    printing and typesetting industry. Lorem Ipsum
    has been the industry's standard dummy text
    ever since the 1500s, when an unknown printer
    took a galley of type and scrambled it to make
    a type specimen book. It has survived not only
    five centuries, but also the leap...


    View Slide

21. hello world
    Hadoop


    View Slide

22. >>> from mrjob.job import MRJob
    >>> from mrjob.step import MRStep
    >>>
    >>>
    >>> class MRWordCount(MRJob):
    ... def steps(self):
    ... kwargs = {
    ... 'mapper': self.mapper,
    ... 'combiner': self.combiner,
    ... 'reducer': self.reducer}
    ...
    ... return [MRStep(**kwargs)]
    ...
    ... def mapper(self, _, line):


    View Slide

23. >>>
    >>> class MRWordCount(MRJob):
    ... def steps(self):
    ... kwargs = {
    ... 'mapper': self.mapper,
    ... 'combiner': self.combiner,
    ... 'reducer': self.reducer}
    ...
    ... return [MRStep(**kwargs)]
    ...
    ... def mapper(self, _, line):
    ... for word in line.split(' '):
    ... yield word.lower(), 1
    ...
    ... def combiner(self, word, counts):


    View Slide

24. ... return [MRStep(**kwargs)]
    ...
    ... def mapper(self, _, line):
    ... for word in line.split(' '):
    ... yield word.lower(), 1
    ...
    ... def combiner(self, word, counts):
    ... yield word, sum(counts)
    ...
    ... def reducer(self, word, counts):
    ... yield word, sum(counts)
    >>>
    >>> if __name__ == '__main__':
    ... MRWordCount.run()


    View Slide

25. $ python hadoop_job.py file.txt
    '1500s' 1
    'a' 2
    'an' 1
    'and' 1
    'been' 1
    'book' 1
    'but' 1
    'centuries' 1
    'dummy' 1
    'ever' 1
    'five' 1
    'galley' 1


    View Slide

26. hello world
    Spark


    View Slide

27. >>> from operator import add
    >>> from pyspark.sql import SparkSession
    >>>
    >>> spark = SparkSession.builder.getOrCreate()
    >>> fpath = 'hdfs:///file.txt'
    >>>
    >>> stream = (spark.read.text(fpath).rdd
    ... .flatMap(lambda line: line.split(' '))
    ... .map(lambda word: (word.lower(), 1))
    ... .reduceByKey(add)
    ... .collect())


    View Slide

28. >>> stream[0]
    ('1500s', 1)


    View Slide

29. introducing
    riko
    github.com/nerevu/riko


    View Slide

30. github.com/nerevu/riko


    View Slide

31. @reubano #8LU
    riko


    View Slide

32. @reubano #8LU
    riko
    {
    'greeting':'hello',
    'location':'8th Light',
    'enthusiasm': 9
    }


    View Slide

33. pip install riko


    View Slide

34. obtaining data


    View Slide

35. 8th Light Blog
    https://8thlight.com/blog/feed/
    rss.xml


    View Slide

36. 8th Light Blog
    https://8thlight.com/blog/feed/
    rss.xml


    View Slide

37. >>> from riko.modules.fetch import pipe
    >>>
    >>> url = 'https://8thlight.com/blog/feed'
    >>> url += '/rss.xml'
    >>> stream = pipe(conf={'url': url})
    >>> item = next(stream)
    >>> item['author']
    'Rabea Gleissner'
    >>> item['published']
    'Fri, 26 May 2017 00:00:00 -0500'
    >>> item['title']
    'How to set up a React project without
    flipping tables'


    View Slide

38. transforming
    data


    View Slide

39. >>> from riko.collections import SyncPipe
    >>>
    >>> frule = {
    ... 'field': 'title',
    ... 'op': 'contains',
    ... 'value':'erlang'}
    >>>
    >>> stream = (
    ... SyncPipe('fetch', conf={'url': url})
    ... .filter(conf={'rule': frule})
    ... .output)


    View Slide

40. >>> item = next(stream)
    >>> item['title']
    'The Core of Erlang'
    >>> item['tags'][0]['term']
    'Coding'
    >>> item['link']
    'https://8thlight.com/blog/kofi-gumbs/
    2017/05/02/core-erlang.html'


    View Slide

41. hello world riko


    View Slide

42. >>> conf ={'url': 'file:///file.txt'}
    >>> tconf = {'delimiter': ' '}
    >>> rule = {'transform': 'lower'}
    >>> cconf = {'count_key': 'strtransform'}
    >>>
    >>> stream = (SyncPipe('fetchtext', conf=conf)
    ... .tokenizer(conf=tconf, emit=True)
    ... .strtransform(conf={'rule': rule})
    ... .count(conf=cconf)
    ... .output)
    >>>
    >>> next(stream)
    {'1500s': 1}


    View Slide

43. parallel
    processing


    View Slide

44. The Core of Erlang
    https://8thlight.com/blog/kofi-
    gumbs/2017/05/02/core-erlang.html


    View Slide

45. >>> from riko.modules import xpathfetchpage
    >>>
    >>> pipe = xpathfetchpage.pipe
    >>> xpath = '/html/body/section/div/div[1]'
    >>> xpath += '/div/div/article/div[3]/div'
    >>> xpath += '/ul[1]/li/a'
    >>>
    >>> xconf = {
    ... 'url': item['link'], 'xpath': xpath}
    >>>
    >>> stream = pipe(conf=xconf)


    View Slide

46. >>> next(stream)
    {'content': "Two Design Patterns You're
    Probably Already Using",
    'href': '/blog/becca-nelson/2017/05/22/two-
    design-patterns-youre-probably-already-
    using.html'}


    View Slide

47. >>> kwargs = {'conf': xconf}
    >>> parts = [
    ... {'value': 'http://8thlight.com'},
    ... {'subkey': 'href'}]
    >>>
    >>> fconf = {
    ... 'url': {'subkey': 'strconcat'},
    ... 'start': '', 'end': ''}
    >>>
    >>> stream = (
    ... SyncPipe('xpathfetchpage', **kwargs)
    ... .strconcat(conf={'part': parts})
    ... .fetchpage(conf=fconf)
    ... .output)


    View Slide

48. >>> kwargs = {'conf': xconf}
    >>> parts = [
    ... {'value': 'http://8thlight.com'},
    ... {'subkey': 'href'}]
    >>>
    >>> fconf = {
    ... 'url': {'subkey': 'strconcat'},
    ... 'start': '', 'end': ''}
    >>>
    >>> stream = (
    ... SyncPipe('xpathfetchpage', **kwargs)
    ... .strconcat(conf={'part': parts})
    ... .fetchpage(conf=fconf)
    ... .output)


    View Slide

49. >>> next(stream)['content'].decode('utf-8')
    'I came into this field from a very non-
    technical background. And when I say very
    non-technical, I mean that I was an
    elementary fine arts teacher. The most
    important calculation I performed on a daily
    basis was counting my kindergarteners when
    they lined up to leave to make sure I hadn’t
    lost any since the beginning of the class
    period.'


    View Slide

50. >>> from time import monotonic
    >>>
    >>> start = monotonic()
    >>> count = len(list(stream))
    >>> stop = monotonic() - start
    >>> count, stop
    (9, 0.4573155799989763)


    View Slide

51. >>> kwargs = {'conf': xconf, 'parallel': True}
    >>> start = monotonic()
    >>>
    >>> stream = (
    ... SyncPipe('xpathfetchpage', **kwargs)
    ... .strconcat(conf={'part': parts})
    ... .fetchpage(conf=fconf)
    ... .output)
    >>>
    >>> count = len(list(stream))
    >>> stop = monotonic() - start
    >>> count, stop
    (10, 0.2804829629985761)


    View Slide

52. async
    processing


    View Slide

53. pip install riko[async]


    View Slide

54. >>> from riko.bado import coroutine, react
    >>> from riko.collections import AsyncPipe
    >>>
    >>> @coroutine
    >>> def run(reactor):
    ... start = monotonic()
    ... flow = AsyncPipe(
    ... 'xpathfetchpage', **kwargs)
    ...
    ... stream = yield (flow
    ... .strconcat(conf={'part': parts})
    ... .fetchpage(conf=fconf)
    ... .output)
    ...


    View Slide

55. >>> @coroutine
    >>> def run(reactor):
    ... start = monotonic()
    ... flow = AsyncPipe(
    ... 'xpathfetchpage', **kwargs)
    ...
    ... stream = yield (flow
    ... .strconcat(conf={'part': parts})
    ... .fetchpage(conf=fconf)
    ... .output)
    ...
    ... count = len(list(stream))
    ... stop = monotonic() - start
    ... print((count, stop))


    View Slide

56. >>> react(run)
    (10, 0.2462857809982961)


    View Slide

57. @reubano #8LU
    Head to Head
    Spark, etc. Huginn riko
    installation complex moderate simple
    push/pull push push pull
    native ingestors few many many
    parallel ✔ ✔ ✔
    async ✔
    json serializable ✔ ✔
    distributed ✔


    View Slide

58. @reubano #8LU
    Reuben Cummings
    rcummings@nerevu.com
    https://www.reubano.xyz
    Thanks!


    View Slide
