1. Cleaning up a huge ruby
   application
   RubyKaigi 2019
   @shia


   View Slide

2. •Sangyong Sim(@shia)
   •Cookpad Inc.
   •Software Engineer
   •i18n team of w.r-l.o, elixirschool
   !2


   View Slide

3. !3


   View Slide

4. Index
   •about cookpad_all
   •define the code want to delete
   •what makes it difficult
   •what we try & solve
   !4


   View Slide

5. cookpad_all


   View Slide

6. View Slide

7. View Slide

8. cookpad_all
   !8
   cookpad
   (web)
   pantry
   (api)
   kuroko
   (batch)
   papa
   (admin)
   mobile
   shared


   View Slide

9. cookpad_all
   •Make a bug to fix a bug
   •Gems are too old version which have no feature we
   want, and it's hard to update
   •A lot of monkey patch to Object, String, gems
   !9


   View Slide

10. Project Odaiba


    View Slide

11. Project Odaiba
    •Clean up codes
    •Let it work on (docker) container
    •Extract system/services which mixed in it
    !11


    View Slide

12. Project Odaiba
    •Clean up codes
    ‣ Today's topic
    •Let it work on (docker) container
    •Extract system/services which mixed in it
    !12


    View Slide

13. the code we want to delete


    View Slide

14. the code we may delete
    •Known unnecessary code
    •Unknown unnecessary code
    ‣ Executed meaningless code
    ‣ Not executed code
    !14


    View Slide

15. the code we may delete
    •Known unnecessary code
    •Unknown unnecessary code
    ‣ Executed meaningless code
    ‣ Not executed code
    !15


    View Slide

16. the code we may delete
    •Known unnecessary code
    •Unknown unnecessary code
    ‣ Executed meaningless code
    ‣ Not executed code
    !16


    View Slide

17. Why delete code?


    View Slide

18. why delete code?
    •Reduce code to understand
    •Reduce library dependency
    •Fast test, fast boot
    !18


    View Slide

19. why delete code?
    •Better productivity
    !19


    View Slide

20. What makes it difficult?


    View Slide

21. What makes it difficult?
    •High cost(especially time)
    •Low priority
    •Continuously growing
    !21


    View Slide

22. What makes it difficult?
    !22
    if condition_seem_not_to_be_false
    # ..
    else
    foo_without_bar
    end


    View Slide

23. What makes it difficult?
    !23
    def foo
    # ...
    end
    def foo_with_bar
    # ...
    end
    alias_method_chain :foo, :bar
    alias_method_chain :foo, :bar
    # =>
    alias_method :foo_without_bar, :foo
    alias_method :foo, :foo_with_bar


    View Slide

24. What makes it difficult?
    •High cost(especially time)
    •Low priority
    •Continuously growing
    !24


    View Slide

25. What makes it difficult?
    •High cost(especially time)
    •Low priority
    •Continuously growing
    !25


    View Slide

26. What makes it difficult?
    !26


    View Slide

27. What makes it difficult?
    •High cost(especially time)
    •Low priority
    •Continuously growing
    !27


    View Slide

28. What we can do?


    View Slide

29. What can we do
    •Low priority
    ‣ Raise priority
    •Continuously growing
    •High cost(especially time)
    !29


    View Slide

30. What can we do
    •Low priority
    ‣ Raise priority
    •Continuously growing
    ‣ Continuously delete code
    •High cost(especially time)
    !30


    View Slide

31. What can we do
    •Low priority
    ‣ Raise priority
    •Continuously growing
    ‣ Continuously delete code
    •High cost(especially time)
    ‣ Auto detect potential unused code to reduce cost
    !31


    View Slide

32. What we try


    View Slide

33. Let continuously delete code


    View Slide

34. KitchenCleaner
    •Auto-detect potential unused code
    •Guess people related these code
    •Open issue or ping assignee
    •Give context as much as possible for decision
    making
    !34


    View Slide

35. KitchenCleaner
    !35


    View Slide

36. KitchenCleaner
    !36


    View Slide

37. KitchenCleaner
    !37


    View Slide

38. Target code
    •Controller which has no pv in a year
    •Batch class which have no execution history in 3
    month
    •Unused (chanko) unit
    !38


    View Slide

39. Target developer
    •List up authors from "git log"
    •Filter out who quited the job
    •Random assign from it
    !39


    View Slide

40. Current status
    •Target code is reducing, but not fast
    •It leaves a good context
    !40


    View Slide

41. Logging code execution on
    production


    View Slide

42. !42
    ko1: It seems to be possible to find out unused codes on
    production environment by iseq lazy loading introduced
    in Ruby 2.4
    shia: Why not? Let's try!
    ko1: I wrote the patch on my way to work.


    View Slide

43. Ship it!!!!


    View Slide

44. IseqLogger
    •Logging when iseq first executed.
    !44


    View Slide

45. Wait, What is "iseq"?


    View Slide

46. InstructionSequence(iseq)
    •A compiled sequence of instructions for the Ruby
    Virtual Machine.
    !46


    View Slide

47. InstructionSequence(iseq)
    !47
    # sample.rb
    class Cat
    def sleep?
    true
    end
    end


    View Slide

48. InstructionSequence(iseq)
    !48
    > puts RubyVM::InstructionSequence.compile_file('sample.rb').disasm
    == disasm: #@sample.rb:1 (1,0)-(5,3)> (catch: FALSE)
    ...
    == disasm: #@sample.rb:1 (1,0)-(5,3)> (catch: FALSE)
    ...
    == disasm: # (catch: FALSE)
    ...


    View Slide

49. InstructionSequence(iseq)
    !49

    -
    - sleep?


    View Slide

50. Logging code execution
    !50
    # sample.rb
    class Cat # <- executed
    def sleep? # <- not executed
    true
    end
    def go_out # <- executed
    # ...
    end
    end
    Cat.new.go_out


    View Slide

51. Logging code execution
    !51
    // https://github.com/ruby/ruby/blob/v2_4_3/vm_core.h#L415-L424
    static inline const rb_iseq_t *
    rb_iseq_check(const rb_iseq_t *iseq)
    {
    #if USE_LAZY_LOAD
    if (iseq->body == NULL) {
    rb_iseq_complete((rb_iseq_t *)iseq);
    }
    #endif
    return iseq;
    }


    View Slide

52. Logging code execution
    !52
    static inline const rb_iseq_t *
    rb_iseq_check(const rb_iseq_t *iseq)
    {
    @@ -419,6 +429,11 @@ rb_iseq_check(const rb_iseq_t *iseq)
    if (iseq->body == NULL) {
    rb_iseq_complete((rb_iseq_t *)iseq);
    }
    +#endif
    +#if USE_EXECUTED_CHECK
    + if ((iseq->flags & ISEQ_FL_EXECUTED) == 0) {
    + rb_iseq_executed_check_dump((rb_iseq_t *)iseq);
    + }
    #endif


    View Slide

53. Performance
    •Impact to performance is almost zero.
    •Boot time might be slower.
    ‣ In our case, logging via File I/O gives 2~3% slower
    boot time.
    !53


    View Slide

54. Transfer logs
    app fluentd Redshift
    •log to file when it triggered.
    •{ created_at:, filename:, lineno:, label: }
    !54


    View Slide

55. Generate report
    •What we need
    ‣ Which iseq is used or not
    ‣ Base on latest source code
    !55


    View Slide

56. Logging code execution
    !56
    Iseq = Struct.new(:path, :lineno, :label)
    def traverse(results, iseq)
    results << Iseq.new(iseq.absolute_path.sub(PROJECT_BASE_PATH + '/', ''),
    iseq.first_lineno, iseq.label)
    iseq.each_child do |child|
    traverse(results, child)
    end
    results
    end
    iseq = RubyVM::InstructionSequence.compile_file(some_path)


    View Slide

57. Logging code execution
    !57
    { created_at: ..., filename: 'sample.rb', lineno: 1, label: 'main' }
    { created_at: ..., filename: 'sample.rb', lineno: 1, label: '' }
    { created_at: ..., filename: 'sample.rb', lineno: 2, label: 'sleep?' }
    { created_at: ..., filename: 'sample.rb', lineno: 1, label: 'main' }
    { created_at: ..., filename: 'sample.rb', lineno: 1, label: '' }
    Executed iseqs
    Iseqs from latest code


    View Slide

58. Logging code execution
    !58


    View Slide

59. Logging code execution
    !59


    View Slide

60. Logging code execution
    !60


    View Slide

61. Logging code execution
    !61


    View Slide

62. Judge which log is usable
    •How to judge which log is usable or not?
    !62


    View Slide

63. Judge which log is usable
    •How to judge which log is usable or not?
    ‣ Let log usable if previous log have same filename +
    lineno + label with latest source code.
    !63


    View Slide

64. Judge which log is usable
    !64
    # revision A
    # monthly_batch.rb
    # ...
    # recipe.rb
    class Recipe
    def author_name
    author.name
    end
    end
    # revision B
    # monthly_batch.rb
    # ...
    # recipe.rb
    class Recipe
    def author_name
    author.name
    end
    def author_id
    author.id
    end
    end


    View Slide

65. Judge which log is usable
    !65
    Logs
    - 4/19, recipe.rb, L1, “”, revision A
    - 4/19, recipe.rb, L2, “”, revision A
    - 4/19, monthly_batch.rb, L1, “”, revision A
    - 4/20, recipe.rb, L1, “”, revision B
    - 4/20, recipe.rb, L6, “”, revision B
    # revision B
    # monthly_batch.rb
    # ...
    # recipe.rb
    class Recipe
    def author_name
    author.name
    end
    def author_id
    author.id
    end
    end


    View Slide

66. Judge which log is usable
    •In our case, only 65% of files updated in a year
    •Assume file which rarely updated might have
    unused codes then frequently updated one
    !66


    View Slide

67. Good point
    •We could find out which template rendered or not!!
    !67


    View Slide

68. Bad point
    •Need to build Ruby
    •Using iseq for detecting could miss some cases we
    want
    !68


    View Slide

69. Bad point
    !69
    # It has dead condition
    if some_method_returns_always_false
    not_called_in_if
    else
    always_called
    end
    # What we want
    always_called
    not_called_in_if


    View Slide

70. Bad point
    !70
    # It has dead condition
    if some_method_returns_always_false
    not_called_in_if
    else
    always_called
    end
    not_called_in_if
    # What we want
    always_called
    not_called_in_if


    View Slide

71. Bad point
    •Need to build Ruby
    •Using iseq for detecting could miss some cases we
    want
    !71


    View Slide

72. Logging code execution on
    production per line!!


    View Slide

73. !73
    mame: I think coverage is enough for that use case.
    shia: I'm worry about degrade performance by coverage,
    because it tries to hook when every line execution.
    mame: How about remove hook after it triggered once?


    View Slide

74. Ship it!!!!


    View Slide

75. First of all...


    View Slide

76. Let cookpad_all
    to use Ruby 2.6!!!!!!


    View Slide

77. Oneshot coverage
    •It just work as same as normal coverage, but it
    only check line executed or not.
    ‣ It removes hook after triggered.
    !77


    View Slide

78. Oneshot coverage
    !78
    require "coverage"
    Coverage.start(oneshot_lines: true)
    load "test.rb"
    p Coverage.result
    # {"test.rb"=>{:oneshot_lines=>[2,
    10, 3, 4, 11]}}
    # 1: # test.rb
    # 2: def foo(n)
    # 3: if n <= 10
    # 4: p "n < 10"
    # 5: else
    # 6: p "n >= 10"
    # 7: end
    # 8: end
    # 9:
    # 10: foo(1)
    # 11: foo(2)


    View Slide

79. Transfer logs
    app DynamoDB Redshift
    •Send log when:
    ‣ per 1 hour
    ‣ after batch execution finished
    •{ filename:, md5_hash:, executed_lines: }
    !79
    per 1 hour per 1 day


    View Slide

80. Transfer logs
    app DynamoDB Redshift
    •Use dynamoDB:
    ‣ Sending logs per line is not practical approach in this case
    ‣ Send data to Redshift as daily snapshot
    •{ filename:, md5_hash:, executed_lines: }
    !80
    per 1 hour per 1 day
    Purge per day


    View Slide

81. How to merge logs
    !81
    Case: need to merge
    - DynamoDB => "recipe.rb-somehash": [1,2,3,5,9]
    - Coverage.result => "recipe.rb-somehash": [1,2,3,6,7,8]
    - New data => "recipe.rb-somehash": [1,2,3,5,9,6,7,8]
    Case: Don't need to merge
    - DynamoDB => "recipe.rb-somehash": [1,2,3,5,9]
    - Coverage.result => "recipe.rb-somehash": [1,2,3]


    View Slide

82. Transfer logs
    app DynamoDB Redshift
    •Use dynamoDB:
    ‣ Sending logs per line is not practical approach in this case
    ‣ Send data to Redshift as daily snapshot
    •{ filename:, md5_hash:, executed_lines: }
    !82
    per 1 hour per 1 day
    Purge per day


    View Slide

83. Generate report
    •What we need
    ‣ Which line is used or not
    ‣ Base on latest source code
    !83


    View Slide

84. Generate report
    !84


    View Slide

85. Judge which log is usable
    •How to judge which log is usable or not?
    !85


    View Slide

86. Judge which log is usable
    •In our case, only 65% of files updated in a year
    •Assume file which rarely updated might have
    unused codes then frequently updated one
    !86


    View Slide

87. Judge which log is usable
    •Use md5 hash whether log is usable or not
    !87


    View Slide

88. Good point
    •No need to build Ruby!
    •Per line logs give us much more information
    !88


    View Slide

89. Bad point
    •Too many number of logs
    •Hard to find unused file (than IseqLogger)
    !89


    View Slide

90. Bad point
    !90
    1: class Recipe
    2: def name
    3: @name
    4: end
    5:
    6: def author
    7: @author
    8: end
    9:end


    View Slide

91. Bad point
    !91
    1: class Recipe
    2: def name
    3: @name
    -: end
    -:
    6: def author
    7: @author
    -: end
    -:end


    View Slide

92. Bad point
    !92
    # oneshot coverage
    1: class Recipe
    2: def name
    3: @name
    -: end
    -:
    6: def author
    7: @author
    -: end
    -:end
    # IseqLogger
    class Recipe # <- Executed
    def name # <- Not executed
    @name
    end
    def author # <- Not executed
    @author
    end
    end


    View Slide

93. Current status
    •Running on production
    !93


    View Slide

94. Performance Impact
    !94


    View Slide

95. Performance Impact
    !95


    View Slide

96. Coverband
    •https://github.com/danmayer/coverband/
    •We don't use this:
    ‣ oneshot coverage is not supported, yet
    ‣ verbose toolkit to us
    ‣ might loss unused information with not changed file
    !96


    View Slide

97. oneshot_coverage
    •https://github.com/riseshia/oneshot_coverage
    •Provide minimum toolkit for logging
    •Support (only) oneshot coverage mode
    •Focus on how to emit data from app
    !97


    View Slide

98. Auto-detect unused codes on production
    is not almighty.


    View Slide

99. Rome was not built in a day


    View Slide

100. !100


     View Slide

101. !101


     View Slide

102. !102


     View Slide

103. This is everyone's achievement.


     View Slide

104. Summary


     View Slide

105. !105
     •Low priority
     ‣ Let code cleaning be a part of project.
     •Continuously growing
     ‣ Let developers remove their own unused codes per month
     •High cost(especially time)
     ‣ Auto detect potential unused code on production to reduce cost
     Summary


     View Slide

106. Conclusion
     !106


     View Slide

107. It is necessary to work hard for cleaning codes
     !107


     View Slide

108. It is necessary to work hard for cleaning codes
     !108
     It is necessary to work little more


     View Slide
