Breaking the Monolith: road to containerizing/serverless your app

Following simple patterns of good application design can allow you to scale your application for your customers easily. We'll dive into the 12 factor application design and demo how this applies to containers and deployments on Amazon ECS and Fargate. We'll take a look at tooling that can be used to simplfy your work flow and help you adopt the principles of the 12 factor application.

Transcript

1. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. 0 4 . 0 3 . 2 0 1 9 O S L O
2. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. O S L O 0 4 . 0 3 . 2 0 1 9 Breaking the Monolith Modern Application Design with Containers and the 12 factors app Sébastien Stormacq Technical Evangelist, AWS @sebsto #AWSDevDay M A D 4
3. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Best Software Architecture Practices Use declarative formats for setup automation, to minimize time and cost for new developers joining the project; Have a clean contract with the underlying operating system, offering maximum portability between execution environments; Are suitable for deployment on modern cloud platforms, obviating the need for servers and systems administration; Minimize divergence between development and production, enabling continuous deployment for maximum agility; And can scale up without significant changes to tooling, architecture, or development practices.
4. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
5. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. The 12 factor application I. Codebase One codebase w/ revision control, many deploys II. Dependencies Explicitly declare and isolate dependencies III. Config Store config in the environment IV. Backing services Treat backing services as attached resources V. Build, release, run Strictly separate build and run stages VI. Processes Execute the app as one or more stateless processes VII. Port binding Export services via port binding VIII. Concurrency Scale out via the process model IX. Disposability Fast startup and graceful shutdown X. Dev/prod parity Keep environments as similar as possible XI. Logs Treat logs as event streams XII. Admin processes Run admin/management tasks as one-off processes
6. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. You know what’s great for a 12 factor app?
7. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
8. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. RUNNING A SINGLE CONTAINER
9. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task RUNNING CONTAINERS
10. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. RUNNING CONTAINERS AT SCALE WITH ECS Availability Zone #1 Availability Zone #2 Availability Zone #3 Scheduling and Orchestration Cluster Manager Placement Engine
11. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. ECS AMI Docker agent ECS agent ECSTask ECSTask ECSTask ECSTask EC2 Instance
12. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. ECS AMI Docker agent ECS agent EC2 Instance ECS AMI Docker agent ECS agent EC2 Instance ECS AMI Docker agent ECS agent EC2 Instance Scheduling and Orchestration Cluster Manager Placement Engine
13. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. “Just launch 10 copies of my container distributed across three availability zones and connect them to this load balancer” X 10
14. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. One codebase tracked in revision control, many deploys
15. Deployed Version Code Version Control
16. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Staging / QA Production Dev #1 Dev #2
17. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Explicitly declare and isolate dependencies
18. Dependencies Binaries Code Application Bundle
19. Dependency Declaration: Node.js package.json npm install # - or - yarn install
20. Dependency Declaration: Python requirements.txt pip install
21. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Dependencies Dependencies Binaries Code
22. Dependency Declaration & Isolation: Docker Dockerfile docker build
23. Development Production docker run
24. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Store config in the environment
25. Development Configuration Production Configuration Development Production
26. Development Production Same container deployed to both environments. Configuration is part of the environment on the host.
27. At runtime the container gets config from the environment.
28. Application code pulls from the environment Environment is customized when docker runs a container
29. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Treat backing services as attached resources
30. PostgreSQL app1 Host app2 3rd party service Treat local services just like remote third party ones
31. PostgreSQL app1 app2 Load balancer Use CNAMES for maximum flexibility and easy reconfiguration postgres.mycompany.com app2.mycompany.com
32. Easily create and maintain custom maps of your applications Before Version 2 After Version 2
33. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Strictly separate build and run stages
34. Build Dependencies Binaries Code
35. Release Config Release Build Artifact + = Tagged image stored in ECR
36. Amazon Elastic Container Service Config
37. Run Task Definition Release v1 Task Definition Release v2
38. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Execute the app as one or more stateless processes
39. Stateful container stores state in local disk or local memory. Workload ends up tied to a specific host that has state data. eu-west-1b Container 1 Disk eu-west-1c eu-west-1a
40. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Stateful data Use services: • Amazon RDS • Amazon DynamoDB • Amazon ElasticCache • Amazon ElasticSearch • Amazon S3 • ……
41. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Export services via port binding
42. Port 32456 Port 32457 Port 32458
43. Port 32768 Port 33487 Port 32192 Port 32794 Port 32781 Match: /api/users* Match: /api/auth*
44. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Scale out via the process model
45. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. RUNNING CONTAINERS AT SCALE WITH ECS Availability Zone #1 Availability Zone #2 Availability Zone #3 Scheduling and Orchestration Cluster Manager Placement Engine
46. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Scaling Instance Container 1 Instance Instance Instance Instance Instance + Container 1 Container 1 Container 1 Container 1 Container 1
47. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Maximize robustness with fast startup and graceful shutdown
48. Responsive Graceful Shutdown Fast Launch
49. Fast Launch Minimize the startup time of processes: • Scale up faster in response to spikes • Ability to move processes to another host as needed • Replace crashed processes faster
50. Responsive, Graceful Shutdown Should respond to SIGTERM by shutting down gracefully
51. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Keep development, staging, and production as similar as possible
52. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Dev #1 Dev #2 Staging / QA Production
53. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Staging / QA Production Dev #1 Dev #2 Local Application Remote
54. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Treat logs as event streams
55. Docker connects container’s stdout to a log driver Containerized code writes to stdout
56. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CLOUDWATCH LOGS CONFIGURATION Use the awslogs driver to send stdout from your application to Cloudwatch logs Create a log group in Cloudwatch Configure the log driver in your task definition Remember to add permissions via the Task Execution Role { "family": "scorekeep", ... "containerDefinitions": [ { "name":“scorekeep-frontend", ... "logConfiguration": { "logDriver": "awslogs", "options": { "awslogs-group": "scorekeep", "awslogs-region": “us-east-1", "awslogs-stream-prefix": "scorekeep/frontend“}} }, { "name":“scorekeep-api", ... "logConfiguration": { "logDriver": "awslogs", "options": { "awslogs-group": "scorekeep", "awslogs-region": “us-east-1", "awslogs-stream-prefix": "scorekeep/api"}} } ]} Task Definition
57. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CLOUDWATCH LOGS Logs Tab in the Task Detail Page View logs in the ECS or Cloudwatch Console
58. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Run admin/management tasks as one-off processes
59. Admin / management processes are inevitable: • Migrate database • Repair some broken data • Once a week move database records older than X to cold storage • Every day email a report to this person
60. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
61. Building Blocks for Containerized 12 Factor apps Compute Developer Tools Logging & Monitoring Storage & Database Networking & API Proxy AWS Elastic Beanstalk AWS Fargate Amazon ECS Amazon DynamoDB Amazon S3 Amazon ElastiCache Amazon RDS Amazon ECR Amazon EKS AWS X-Ray AWS CodeBuild AWS CodePipeline AWS Cloud9 Amazon CloudWatch AWS CloudTrail Amazon SQS Amazon SNS Amazon MQ Amazon API Gateway Elastic Load Balancing Amazon Route 53 AWS Step Functions
62. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
63. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Sébastien Stormacq Technical Evangelist, AWS @sebsto
