What’s new with ConstraintLayout 2.0 CA.apk #6 株式会社ノハナ 瀬戸優之 @seto_hi
自己紹介 • 瀬戸優之 Seto HiroYUKI @seto_hi • Androidエンジニア 兼 アプリデザイナー
• 株式会社ノハナ ◦ 一組でも多くの家族に笑顔を届ける • Material Design大好き • DroidKaigi 2018でConstraintLayoutの内部実装を解説 • Google I/O 2018 参加組
ConstraintLayout 2.0 正式発表!
ConstraintLayout 2.0 正式発表! ライブラリの公開はまだ
Helper機能追加 1. Layout Manipulation 2. Post-Layout Manipulation 3. Rendering or
Decorating
1.Layout Manipulation • Viewのレイアウトを簡単にする機能 ◦ ex. Barrier(1.1~) • app:constaint_referenced_ids に対象のViewのidを指定するだけ
• Linear(LinearLayout風) • Flow(FlexboxLayout風)
2.Post-Layout Manipulation • レイアウト後の操作 • app:constaint_referenced_ids に対象のViewのidを指定するだけ • Fly-in ◦
初回レイアウト時にアニメーションする • Layer ◦ 指定したViewにアニメーションなどをかけれる • Circler Reveal ◦ Circler Reveal
3.Rendering or Decorating • Viewの背景などに描画ができる • app:constaint_referenced_ids に対象のViewのidを指定するだけ
Layout Management
Layout Management • ~1.1 ◦ layoutファイルを2つ用意 ◦ ConstraintSetを使ってコード上で管理 ▪ 各状態ごとに
ConstraintSet.clone(context, layout) ▪ 状態を変える場合には ConstraintSet.applyTo(ConstrainLayout)
Layout Management • 2.0~ ◦ layoutファイルを2つ用意 ◦ xmlにStateを書く ◦ ConstraintLayout.setLayoutDescription(xml)
◦ 状態を変える場合には ConstraintLayout.setState(id)
None
None
新ViewGroup MotionLayout
セッション動画を見て! (29:10~) https://youtu.be/ytZteMo4ETk
MotionLayout • Animationが簡単にできるView ◦ ConstraintLayoutを継承 • 2つ以上の状態間をアニメーションできる ◦ KeyFrameの追加もできる •
Android Studio側のUIも便利 ◦ KeyFrameの追加 ◦ 開始・終了タイミングの変更 ◦ デザイナーでもアニメーション組めるのでは?
セッション動画を見て! (29:10~) https://youtu.be/ytZteMo4ETk
1.1と 何が変わるか
何が変わるか • ~1.1 ◦ 柔軟にレイアウトできる ネストを浅くするためのViewGroup • 2.0~ ◦ 他のViewGroupの機能を網羅
◦ 更に+αの機能がある ▪ Layout、Decoration、Animation ◦ アニメーションに特化したMotionLayout
結論 すべてのViewGroupを ConstraintLayoutに 置き換える時が来た
結論 すべてのViewGroupを ConstraintLayoutに 置き換える時が来た かもしれない
※Stableでない ライブラリの ご利用は計画的に
以上!
