Scaling GeoServer in the cloud clustering state of the art - FOSS4G 2023

GeoServer deployments in the cloud and kubernetes are becoming the norm, while the amount of data published is also growing, both in terms of layers and size of data. As a result, the need for scaling up is becoming more and more common.

This presentation covers GeoServer clustering approaches, comparing the available options and their suitability to different environments. We will cover: * Managing the GeoServer configuration, stable configuration with planned upgrades versus dynamic runtime changes. * Deployment options (monolithic, separate tiling, microservice oriented) * Dynamic configuration clustering with JMS, external database storage, and distributed memory.

Attend this presentation to get an update on GeoServer cloud and clustering options, and pick the option that is the best match for your specific use case.

Transcript

1. Andrea Aime Simone Giannecchini GeoSolutions Scaling GeoServer in the cloud: clustering state of the art
2. GeoSolutions Enterprise Support Services Deployment Subscription Professional Training Customized Solutions GeoNode • Offices in Italy & US, Global Clients/Team • 30+ collaborators, 25+ Engineers • Our products • Our Offer
3. Affiliations We strongly support Open Source, it Is in our core We actively participate in OGC working groups and get funded to advance new open standards We support standards critical to GEOINT
4. Introduction
5. GeoServer, can in run in the cloud • Not cloud native • But ready to deploy in the cloud • Databases • Blob storage support • COG • GeoServer cloud: kubernetes, microservice and more cloud readiness facilities → see dedicated presentation
6. GeoServer clustering • OGC services are (mostly!) stateless • Exception(s) • WPS async requests • Importer async requests • Do we need a clustering plugin? • Most of the time, no
7. Static configuration case
8. The backoffice/production model • Backoffice environment (aka TEST or STG) • Set up new layers • Design their styles for optimal output and performance • Setup metadata and descriptions correctly • Test everything carefully before going live
9. The backoffice/production model • Production environment • Static, shared configuration • For the few async requests, shared state in external database • Auto-scale as you see fit
10. Putting it all together • Version control data directory (checkout when ready): git, svn, whatever • Rolling reload production
11. But pay attention to • Keep data separate from configuration • Keep logs separate, and each node uses a different file • Number of layers, rolling restart can take some time DATA LOGS TILE CACHES CONFIGURATION ENV PARAM
12. Tile cache deployment, opt 1 GS/GWC GS/GWC GS/GWC Shared file system GS/GWC Seeding • Most relaxed layout • Shared filesystem can have issues with heavy concurrent writers • Can work, if the cluster mostly reads • Separate, dedicated machines for focused seeding (temporary docker images)
13. Tile cache deployment, opt 2 GS/GWC FS • Layout useful for short lived caches and fragile network filesystems • Duplicates work to get better stability • Common cases, weather forecast Memory cache GS/GWC FS Memory cache GS/GWC FS Memory cache Load balancer
14. Tile cache deployment, opt 3 GWC Dedicated filesystem • Layout useful for few layers (GWC config is XML files) • Optimal hardware usage • Double configuration effort (automate using REST) GS GS GS Load balancer • Want to have GWC read configuration directly from GeoServer instead? Good idea, funding wanted!
15. No no, I need to change config in production all the time!
16. Do you really do though? • In our experience, most of the time, you do not! (well, not at a high rate!) • You can use static configuration with dynamic data loading, filtering and styling
17. I receive new data continuously! • Fine, why set up a new layer for each data batch though? • If structure is regular • Use dimensions (time, elevation, custom ones) • Use client side filtering • Much better option to keep time moving windows (e.g., last 3 months of data) T1 Tn T2
18. Work on the mosaic index • Just record new entries and remove older ones in the database • No need to touch the configuration T1 Tn T2 Tn + 1 OUT! IN!
19. “Mosaics” everywhere • Storage options • Image mosaic store (STAC index too) • (Partitioned) database tables • Vector mosaic store (external storage)
20. Different uses -> different views • You “just” need to filter data • GeoFence plugin can filter layer based on the user by alphanumeric/spatial
21. Client limitations? Trick them! • Clients that cannot deal with dimensions, or vendor parameters (e.g. CQL_FILTER) • Use the “parameter extractor” community module /geoserver/tiger/wms/H11?SERVICE=WMS… /geoserver/tiger/wms?SERVICE=WMS &CQL_FILTER=CFCC=’H11’&...
22. Client allows to change style! • You allow users to change the style of the maps? • Just use &sld and &sld_body in your requests • Or parametric styles! “env” function is your friend!
23. But if you really need to change configuration all the time, then…
24. Typical use case • Case A: • The application allows users to upload their custom data • They are responsible for its configuration • Hopefully many small data sets • Case B: • Hum… wait, haven’t really met another case yet! (maybe tell me during the Q&A at the end?)
25. Clustering community modules • Not enough traction to have a dedicated maintainer • Few deployments use either of them JMS clustering JDBC clustering
26. JMS config • Loads data directory from XML files • Sends JMS messages to distribute changes
27. • Copies the catalog into a database • Loads configuration on demand • Caching (too slow otherwise, many queries) • hz-cluster sibling module sends drop cache messages JDBC config
28. Some testing
29. Testing WMS requests • Using ne-styles repository: • Natural Earth Data • CSS styling • Political map
30. Configuration cases • Data volumes • Case A: ne-styles as is (25 layers) • Case B: “ne” workspace duplicated up to 40.000 layers • Clustering • Vanilla/JMS config • JDBCConfig • Builds: 2.24.x nightly, June 24th 2023
31. Load testing results • Mostly unaffected by number of layers • JDBCConfig between 10% and 20% slower • JDBCConfig was 50% slower with with lots of layers, has improved! JDBCConfig couple years ago
32. Startup times with 40k layers • JDBC Config has constant startup time, does not load config → 13 seconds • Vanilla/JMS proportional to number of layers: → 56 seconds (would take longer on a completely cold disk) • Experimental new XML config loader in GeoServer cloud that could do better than this.
33. Administrative GUI access, 40k layers • Access to home page as admin: • JDBCConfig: 72 seconds • Vanilla/JMS: 1 second • Access to layers page as admin • JDBCConfig: 300 secs! • Vanilla/JMS: 2 seconds
34. The future: eat your cake and have it too!
35. Reality check - 1 • GeoServer code built to have the full catalog in memory • Code expects it’s quick to: • Get any configuration, eventually multiple times per request • Get the full list of anything (layers, workspaces, stores, styles, …) • Makes it hard to have any solution based on external storage
36. Reality check - 2 • A small amount of deployments actually need dynamic configuration changes in production • Core developers are already busy with GIS • Configuration data structures changes over time (core modules) → don’t want a clustering plugin that needs to be constantly aligned with core changes
37. Idea: Hazelcast distributed memory • Will use the same serialization as GeoServer configuration for messaging (maintained across configuration changes) • Declare distributed Maps, let HZ do the message passing for us • Distribution library, among other things: • Distributed data structures, with “near cache” • Distributed locks • Messaging • Integration with various clouds
38. Idea: Hazelcast distributed memory GS1 GS2 GS..n Hazelcast Distributed catalog near cache Distributed catalog near cache Distributed catalog near cache
39. Conclusions
40. Let’s summarize • Most of the time, use static data directory, share, load balance, auto-scale, live happily • When you really need to change configuration at runtime, JMS cluster or JDBCConfig, with some limitations • Moving forward, we’re going to develop a new plugin that hopefully matches low maintenance with good performance
41. The End Questions? andrea.aime@geosolutionsgroup.com info@geosolutionsgroup.com
