During this talk we will figure out what is TensorFlow, how it works - key concepts and how it flow. We will find out what is hidden behind the magic words - "Artificial Neural Network". What additional tools you can use for visualisation and more stuff.

A9e23925dc5753d5925cb6ef55d71765?s=128

Sergey Kibish

November 26, 2016
Tweet

Transcript

  1. Tensor Must Flow Sergey Kibish Transact Pro, GDG Riga @s_kibish

  2. What is TensorFlow?

  3. TensorFlow Is a library for distributed computations Dedicated for Machine

    Learning, but can be used not only for it Apache 2.0 3
  4. Where it can work? 4

  5. Who use it? Google - RankBrain (search ranking on google.com)

    Google - SmartReply (automatic email responses) Google - On-Device Vision for OCR (real- time translation) 5
  6. Tensor

  7. Tensor It is a matrix It is a 2-dimensional array

    It is a 2-dimensional Tensor 7 m = [[1, 2, 3], [4, 5, 6], [7, 8, 9]]
  8. Flow

  9. Flow Computations are described with graph Nodes – mostly mathematical

    operations (but not only) Edges – input/output relation between nodes 9
  10. Flow x y mul 10

  11. Flow 11 x = tf.constant([[2.,2.]], name="x") y = tf.constant([[3.],[3.]], name="y")

    out = tf.matmul(x, y, name="mul")
  12. Flow 12 print out Tensor("mul:0", shape=(1, 1), dtype=float32) tf.get_default_graph().as_graph_def()

  13. Flow node { name: "x" op: "Const" attr { key:

    "dtype" value { type: DT_FLOAT } } ... } node { name: "y" op: "Const" attr { key: "dtype" value { type: DT_FLOAT } } ... } node { name: "mul" op: "MatMul" input: "x" input: "y" ... } 13
  14. Flow 14

  15. Session

  16. Session Graph must be placed in session to do computation

    Session places operations on Devices (CPU, GPU) 16
  17. Session 17 x = tf.constant([[2.,2.]], name="x") y = tf.constant([[3.],[3.]], name="y")

    out = tf.matmul(x, y, name="mul") with tf.Session() as session: v = session.run(out) v array([[ 12.]], dtype=float32)
  18. More TensorFlow way?

  19. 19 x = tf.placeholder(dtype=tf.float32, shape=(1,2), name="x") y = tf.placeholder(dtype=tf.float32, shape=(2,1),

    name="y") v = tf.Variable([[0.]], dtype=tf.float32, name="out") out = tf.matmul(x, y, name="mul") update = tf.assign(v, out, name="update") init_op = tf.initialize_all_variables() with tf.Session() as sess: sess.run(init_op) sess.run(update, feed_dict={x: [[2.,2.]], y: [[3.],[3.]]}) print sess.run(v) [[ 12.]]
  20. TensorFlow way 20

  21. TensorBoard

  22. TensorBoard 22

  23. What else? Checkpoints 23

  24. Checkpoint (Save) 24 saver = tf.train.Saver() … with tf.Session() as

    sess: …# training here saver.save(sess, "/tmp/simple_ann.ckpt")
  25. Checkpoint (Restore) 25 saver = tf.train.Saver() … with tf.Session() as

    sess: saver.restore(sess, "/tmp/simple_ann.ckpt") … # training here
  26. Artificial Neural Network

  27. Problem 27

  28. Data 28 x1 x2 y 2,557 3,676 0 10,567 15,323

    1 4,873 5,212 0 … … …
  29. ANN x2 b w2 w3 x1 w1 y 29

  30. ANN x2 b ∑ w2 w3 x1 w1 σ y

    30
  31. Simple ANN (1/2) 31 x = tf.placeholder("float",[None, 2]) y =

    tf.placeholder("float",[None, 1]) W = tf.Variable(tf.zeros([2, 1])) b = tf.Variable(tf.ones([1, 1])) activation = tf.nn.sigmoid(tf.matmul(x, W)+b) cost = tf.reduce_sum(tf.square(activation - y))/100 optimizer = tf.train.RMSPropOptimizer(.01).minimize(cost) init = tf.initialize_all_variables()
  32. Simple ANN (2/2) 32 with tf.Session() as sess: sess.run(init) for

    i in range(100): train_data = sess.run(optimizer, feed_dict={x: X, y: np.reshape(Y, [100, 1])}) result = sess.run(activation, feed_dict={x:X}) rounded = [round(x) for x in result] print rounded
  33. What about image recognition? 33

  34. MNIST MNIST for Beginners MNIST for Experts 34

  35. Is it easy to start with? 35

  36. No. 36

  37. What to do? 37

  38. Solutions http://tflearn.org http://keras.io 38

  39. Example (Keras) 39 model = Sequential() model.add(Dense(1, input_dim=2, init='uniform', activation='sigmoid'))

    model.compile(optimizer='rmsprop', loss='binary_crossentropy') model.fit(X, Y, nb_epoch=100, batch_size=len(X), verbose=2)
  40. Example (Keras) 40 predictions = model.predict(X) rounded = [round(x) for

    x in predictions]
  41. Source http://bit.ly/tf-example-devfestby-2016 41

  42. Another cool tool

  43. http://playground.tensorflow.org/ 43

  44. Production?

  45. TensorFlow Serve 45

  46. TensorFlow in cloud 46

  47. Q&A Sergey Kibish Transact Pro, GDG Riga @s_kibish

  48. Thank you! Sergey Kibish Transact Pro, GDG Riga @s_kibish
