Unit Test your code, even your UI

Unit Test your code,
even your UI
@stan_kocken

View Slide

Testing
Instrumentation (on Android Device)
Unit Tests (on JVM)

View Slide

Unit Testing on JVM
Run quickly
Allow TDD (Test Driven Development)
Easy to add on your build process (CI)

View Slide

app
↳ src
↳ main
↳ test
↳ java
↳ com.skocken.junittest
↳ ExampleUnitTest
Test hierarchy

View Slide

Build Variants
Android Studio
Conﬁgure
View > Tools Windows >
Test Artifact: Android Instrumentation Tests
Unit Tests

View Slide

Android Studio
Execute
app
↳ src
↳ main
↳ test
↳ java
↳ ExampleUnitTest
Right click
> Run ‘All tests’
(or Run ‘Junit’)

View Slide

Gradle
Execute
./gradlew testDebugUnitTest
…
BUILD SUCCESSFUL
Total time: 2.057 secs
test{flavor}{build_type}UnitTest

View Slide

app
↳ src
↳ main
↳ test
↳ java
↳ ExampleUnitTest
public class ExampleUnitTest { 
@Test 
public void addition_isCorrect() throws Exception { 
assertEquals(4, 2 + 2); 
} 
}
OK

View Slide

TDD
Add a test
Run (should fail)
Write code to ﬁx it
Run (should succeed)
Refactor code
(Test Driven Development)

View Slide

Basic class
public class Plane { 
 
private final String mName; 
 
public Plane(String name) { 
mName = name; 
} 
 
}
Alt + Enter
> Create Test
> JUnit4

View Slide

Basic test
public class PlaneTest { 
 
 
}
 
@Test 
public void testShouldCompareName() { 
Plane plane = new Plane("A380"); 
assertTrue(plane.sameAs("A380")); 
assertFalse(plane.sameAs("B747")); 
}
Alt + Enter
> Create method ‘sameAs’

View Slide

Add ‘sameAs’
 
 
mName = name; 
}
 
 
}
 
public boolean sameAs(String name) { 
return false; 
} 

View Slide

Run Test
public class PlaneTest {
 
@Test 
}
}
!

View Slide

Fix ‘sameAs’
 
 
mName = name; 
}
 
public boolean sameAs(String name) { 
return false;
 
} 
 
}
// return false;
return name != null && name.equals(mName);

View Slide

Run Test
 
@Test 
}
}
OK

View Slide

Add some Android logs
 
 
mName = name; 
}
 
public boolean sameAs(String name) {
 
return name != null && name.equals(mName); 
} 
 
}
Log.v("Plane", "compare with: " + name);

View Slide

Run Test
 
@Test 
}
}
!
java.lang.RuntimeException: Method v in android.util.Log not mocked.
at android.util.Log.v(Log.java)
at com.skocken.junittest.Plane.sameAs(Plane.java:14)
at com.skocken.junittest.PlaneTest.testShouldCompareName(PlaneTest.java:13)

View Slide

Mock android.jar - build.gradle
android { 
…
testOptions { 
unitTests.returnDefaultValues = true 
} 
}

View Slide

Run Test
 
@Test 
}
}
OK

View Slide

Run Test, with “null”
 
@Test 
public void testShouldCompareName() { … } 
 
@Test 
public void testShouldCompareNameNull() { 
Plane plane = new Plane(null); 
assertTrue(plane.sameAs(null)); 
} 
 
}
!

View Slide

Fix ‘sameAs’
 
 
mName = name; 
}
 
public boolean sameAs(String name) {
Log.v("Plane", "compare with: " + name); 
return name != null && name.equals(mName);
 
} 
 
}
// return name != null && name.equals(mName);
return TextUtils.equals(mName, name);

View Slide

Run Test
 
@Test 
public void testShouldCompareName() {
assertFalse(plane.sameAs(“B747"));
} 
 
@Test 
public void testShouldCompareNameNull() { 
Plane plane = new Plane(null); 
assertTrue(plane.sameAs(null)); 
} 
 
}
!

View Slide

build.gradle
android { 
…
testOptions { 
unitTests.returnDefaultValues = true 
} 
}
public static boolean equals(CharSequence a, CharSequence b) { 
… 
}
public static boolean equals(CharSequence a, CharSequence b) { 
return false; 
}
TextUtils.java
Mock of TextUtils.java

View Slide

Solutions
TextUtils → custom method
(or library like Apache Common)
Need to replace every calls
More code “duplicate”
“just because” of the test
Tests clean, no change

View Slide

Solutions
Robolectric
Not “exactly” Android
A bit slower (~ +3sec)
No change on code to test

View Slide

Example

View Slide

Board
play(Player player, int x, int y)
Player getPlayer(int x, int y)
int getPlayLeft()
Player getWinner()

View Slide

Tests
public class GameBoardTest extends TestCase {
 
private GameBoard mSubject;
 
@Before 
public void setUp() throws Exception { 
mSubject = new GameBoard(); 
}
 
@Test 
public void testSetPlayer() throws Exception {
assertEquals(GameBoard.Player.EMPTY, mSubject.getPlayer(0, 0));
mSubject.play(GameBoard.Player.J1, 0, 0);
assertEquals(GameBoard.Player.J1, mSubject.getPlayer(0, 0)); 
}
 
}
Fix your tests now

View Slide

Tests
public class GameBoardTest extends TestCase { 
 
private GameBoard mSubject; 
 
@Before 
} 
 
@Test 
public void testSetPlayer() throws Exception { … } 
 
@Test 
public void testGetNbPlayLeft() throws Exception { 
assertEquals(9, mSubject.getNbPlayLeft()); 
mSubject.play(GameBoard.Player.J1, 2, 2); 
} 
 
}
Fix your tests now

View Slide

Tests
public class GameBoardTest extends TestCase { 
 
private GameBoard mSubject; 
 
@Before 
} 
 
… 
 
@Test 
public void testGetWinnerInCol() throws Exception { 
assertNull(mSubject.getWinner()); 
assertEquals(mSubject.getWinner(), GameBoard.Player.J1); 
} 
 
}
Fix your tests now

View Slide

AI
constructor: (GameBoard board, Player aiPlayer)
playNext()

View Slide

Tests
public class AITest extends TestCase { 
 
private static final GameBoard.Player PLAYER_AI = GameBoard.Player.J2; 
 
private GameBoard mGameBoard; 
 
private AI mAI; 
 
@Before 
mGameBoard = new GameBoard(); 
mAI = new AI(mGameBoard, PLAYER_AI); 
} 
 
}

View Slide

Tests
public class AITest extends TestCase {
 
… 
Fix your tests now
@Test 
public void testPlayNextWithEmpty() throws Exception { 
GameBoard.Player[][] initBoard = 
{ 
{__, __, __}, 
{__, __, __}, 
{__, __, __} 
 
}; 
mGameBoard.setBoard(initBoard); 
mAI.playNext();
assertEquals(PLAYER_AI, mGameBoard.getPlayer(1, 1)); 
} 
 
}

View Slide

Tests
@Test 
public void testPlayWinnerMove() throws Exception { 
GameBoard.Player[][] initBoard = 
{ 
{J1, IA, J1}, 
{IA, IA, J1}, 
{J1, __, __} 
 
}; 
mGameBoard.setBoard(initBoard); 
 
mIA.playNext();
 
assertEquals(IA, mGameBoard.getPlayer(1, 2)); 
assertEquals(IA, mGameBoard.getWinner()); 
} 
 
}
Fix your tests now
public class AITest extends TestCase {
 
… 

View Slide

Go Further
Improve your AI
Increase board size
…

View Slide

Android UI

View Slide

Activity

View Slide

BaseActivity:1600+ lines
A base activity that handles common
functionality in the app. This includes the
navigation drawer, login and authentication,
Action Bar tweaks, amongst others.

View Slide

God Object

View Slide

How to do differently?
View Proxy
Touch Android View
No business logic
DataProvider
Access Data
Store state
Presenter
Data to ViewProxy

View Slide

Architecture
Presenter
DataProvider ViewProxy
Activity View
Strong Reference
Weak Reference
Other “Strong” Reference on DataProvider, Presenter or
ViewProxy forbidden. Use WeakReference.
OK

View Slide

Example

View Slide

v1: Activity
public class OriginalActivity extends Activity 
implements View.OnClickListener { 
 
private final GameBoard mGameBoard = new GameBoard(); 
 
private final GameBoard.Player mCurrentPlayer = GameBoard.Player.J1; 
 
private final AI mAI = new AI(mGameBoard, GameBoard.Player.J2); 
 
private ViewGroup mBoxesLayout; 
 
@Override 
protected void onCreate(Bundle savedInstanceState) { 
super.onCreate(savedInstanceState); 
setContentView(R.layout.activity_main); 
mBoxesLayout = (ViewGroup) findViewById(R.id.boxes_layout); 
} 
 
@Override 
protected void onResume() { 
super.onResume(); 
refreshBoard(); 
} 
 
@Override 
public void onClick(View v) { 
Object x = v.getTag(R.id.tag_x); 
Object y = v.getTag(R.id.tag_y); 
if (x instanceof Integer && y instanceof Integer) { 
play((int) x, (int) y); 
} 
} 
 
private void play(int x, int y) { 
mGameBoard.play(mCurrentPlayer, x, y); 
mAI.playNext(); 
refreshBoard(); 
}
private void refreshBoard() { 
int size = mGameBoard.getSize(); 
for (int y = 0; y < size; y++) { 
for (int x = 0; x < size; x++) { 
GameBoard.Player player = mGameBoard.getPlayer(x, y); 
 
int boxType; 
switch (player) { 
case EMPTY: 
boxType = BoardDef.BOX_EMPTY; 
break; 
case J1: 
boxType = BoardDef.BOX_CROSS; 
break; 
case J2: 
boxType = BoardDef.BOX_ROUND; 
break; 
default: 
continue; 
} 
setBoxValue(x, y, boxType); 
} 
} 
} 
 
private void setBoxValue(int x, int y, int boxType) { 
ViewGroup rowLayout = (ViewGroup) mBoxesLayout.getChildAt(y); 
View boxView = rowLayout.getChildAt(x); 
 
int bgColor; 
switch (boxType) { 
case BoardDef.BOX_CROSS: 
bgColor = Color.RED; 
boxView.setOnClickListener(null); 
break; 
case BoardDef.BOX_ROUND: 
bgColor = Color.BLUE; 
break; 
default: 
bgColor = Color.GRAY; 
boxView.setOnClickListener(this); 
break; 
} 
boxView.setBackgroundColor(bgColor); 
boxView.setTag(R.id.tag_x, x); 
boxView.setTag(R.id.tag_y, y); 
} 
}

View Slide

DataProvider Presenter ViewProxy
v2: Creation
refreshBoard()
getGameBoard() setBoxValue(
int x, int y,
int boxType);

View Slide

DataProvider Presenter ViewProxy
v2: User click box
onSelectBox(int x, int y)
play(int x, int y)
refreshBoard()
…

View Slide

v2: Deﬁnition
public interface BoardDef { 
 
int BOX_EMPTY = 0; 
 
int BOX_CROSS = 1; 
 
int BOX_ROUND = 2; 
 
interface IPresenter extends BaseDef.IPresenter { 
 
void refreshBoard(); 
 
void onSelectBox(int x, int y); 
} 
 
interface IDataProvider extends BaseDef.IDataProvider { 
 
GameBoard getGameBoard(); 
 
void play(int x, int y); 
} 
 
interface IView extends BaseDef.IView { 
 
void setBoxValue(int x, int y, int boxType); 
} 
}

View Slide

v2: DataProvider
public class BoardDataProvider 
extends BaseDataProvider 
implements BoardDef.IDataProvider { 
 
private final GameBoard mGameBoard = new GameBoard(); 
 
private final GameBoard.Player mCurrentPlayer =
GameBoard.Player.J1; 
 
private final AI mAI = new AI(mGameBoard,
GameBoard.Player.J2); 
 
@Override 
public GameBoard getGameBoard() { 
return mGameBoard; 
} 
 
@Override 
public void play(int x, int y) { 
mGameBoard.play(mCurrentPlayer, x, y); 
mAI.playNext(); 
getPresenter().refreshBoard(); 
} 
} 

View Slide

public class BoardPresenter  
extends BasePresenter 
implements BoardDef.IPresenter { 
 
public BoardPresenter(Activity activity, 
BoardDef.IDataProvider provider, BoardDef.IView view) { 
super(activity, provider, view); 
} 
 
@Override 
public void onResume() { 
refreshBoard(); 
} 
 
@Override 
public void onSelectBox(int x, int y) { 
getProvider().play(x, y); 
} 
 
@Override 
public void refreshBoard() { 
GameBoard gameBoard = getProvider().getGameBoard(); 
int size = gameBoard.getSize(); 
for (int y = 0; y < size; y++) { 
for (int x = 0; x < size; x++) { 
setBoxValue(gameBoard, y, x); 
} 
} 
}
v2: Presenter

View Slide

public class BoardPresenter  
extends BasePresenter 
implements BoardDef.IPresenter { 
 
public BoardPresenter(Activity activity, 
BoardDef.IDataProvider provider, BoardDef.IView view) { 
super(activity, provider, view); 
} 
 
@Override 
public void onResume() { 
refreshBoard(); 
} 
 
@Override 
public void onSelectBox(int x, int y) { 
getProvider().play(x, y); 
} 
 
@Override 
public void refreshBoard() { 
GameBoard gameBoard = getProvider().getGameBoard(); 
int size = gameBoard.getSize(); 
for (int y = 0; y < size; y++) { 
for (int x = 0; x < size; x++) { 
setBoxValue(gameBoard, y, x); 
} 
} 
}
v2: Presenter
private void setBoxValue(GameBoard gameBoard, int y, int x) { 
GameBoard.Player player = gameBoard.getPlayer(x, y); 
int boxValue; 
switch (player) { 
case EMPTY: 
boxValue = BoardDef.BOX_EMPTY; 
break; 
case J1: 
boxValue = BoardDef.BOX_CROSS; 
break; 
case J2: 
boxValue = BoardDef.BOX_ROUND; 
break; 
default: 
return; 
} 
getView().setBoxValue(x, y, boxValue); 
} 
}

View Slide

public class BoardViewProxy extends BaseViewProxy 
implements BoardDef.IView, View.OnClickListener { 
 
public BoardViewProxy(Activity activity) { 
super(activity); 
} 
 
@Override 
int x = (Integer) v.getTag(R.id.tag_x); 
int y = (Integer) v.getTag(R.id.tag_y); 
getPresenter().onSelectBox(x, y); 
}
v2: ViewProxy
@Override 
public void setBoxValue(int x, int y, int boxType) { 
ViewGroup boxLayout = findViewByIdEfficient(R.id.boxes_layout); 
ViewGroup rowLayout = (ViewGroup) boxLayout.getChildAt(y); 
 
int bgColor; 
break; 
break; 

View Slide

public class BoardViewProxy extends BaseViewProxy 
implements BoardDef.IView, View.OnClickListener { 
 
public BoardViewProxy(Activity activity) { 
super(activity); 
} 
 
@Override 
int x = (Integer) v.getTag(R.id.tag_x); 
int y = (Integer) v.getTag(R.id.tag_y); 
getPresenter().onSelectBox(x, y); 
}
v2: ViewProxy
@Override 
public void setBoxValue(int x, int y, int boxType) { 
ViewGroup boxLayout = findViewByIdEfficient(R.id.boxes_layout); 
ViewGroup rowLayout = (ViewGroup) boxLayout.getChildAt(y); 
 
int bgColor; 
break; 
break; 
default: 
bgColor = Color.GRAY; 
boxView.setOnClickListener(this); 
break; 
} 
boxView.setBackgroundColor(bgColor); 
boxView.setTag(R.id.tag_x, x); 
boxView.setTag(R.id.tag_y, y); 
}
}

View Slide

Improve clarity
To test it easily!
Why split my god object
Activity?

View Slide

Tests: setup
public class BoardDataProviderTest extends TestCase { 
 
private BoardDef.IPresenter mPresenter; 
 
private BoardDataProvider mDataProvider; 
 
@Before 
mPresenter = Mockito.mock(BoardDef.IPresenter.class); 
 
mDataProvider = new BoardDataProvider(); 
mDataProvider.setPresenter(mPresenter); 
}

View Slide

Tests: setup
public class BoardPresenterTest extends TestCase { 
 
private BoardDef.IDataProvider mDataProvider; 
 
private BoardDef.IView mBoardView; 
 
private BoardPresenter mBoardPresenter; 
 
@Before 
mDataProvider = Mockito.mock(BoardDef.IDataProvider.class); 
mBoardView = Mockito.mock(BoardDef.IView.class); 
 
mBoardPresenter = new BoardPresenter(mDataProvider, mBoardView); 
}

View Slide

Tests: setup
public class BoardViewProxyTest extends TestCase { 
 
private View mContentView; 
 
private BoardDef.IPresenter mPresenter; 
 
private BoardViewProxy mViewProxy; 
 
@Before 
mPresenter = Mockito.mock(BoardDef.IPresenter.class); 
 
mContentView = Mockito.mock(View.class); 
Activity mockActivity = Mockito.mock(Activity.class); 
when(mockActivity.findViewById(android.R.id.content)) 
.thenReturn(mContentView); 
 
mViewProxy = new BoardViewProxy(mockActivity); 
mViewProxy.setPresenter(mPresenter); 
}

View Slide

Test the UI
Android stuffs
TextView
ImageView
…
View Proxy
Already Tested by
framework team

View Slide

Test the UI
View Proxy Mock
Mock
Mock

View Slide

Tests ViewProxy
@Test 
public void testSetBoxValue() throws Exception {
ViewGroup boxesViewGroup = Mockito.mock(ViewGroup.class);
when(mContentView.findViewById(R.id.boxes_layout)).thenReturn(boxesViewGroup); 
ViewGroup firstRowViewGroup = Mockito.mock(ViewGroup.class);
ViewGroup secondRowViewGroup = Mockito.mock(ViewGroup.class);
ViewGroup thirdRowViewGroup = Mockito.mock(ViewGroup.class);
when(boxesViewGroup.getChildAt(0)).thenReturn(firstRowViewGroup);
when(boxesViewGroup.getChildAt(1)).thenReturn(secondRowViewGroup);
when(boxesViewGroup.getChildAt(2)).thenReturn(thirdRowViewGroup); 
View firstRowFirstColView = Mockito.mock(View.class); 
View secondRowSecondColView = Mockito.mock(View.class); 
View thirdRowSecondColView = Mockito.mock(View.class); 
when(firstRowViewGroup.getChildAt(0)).thenReturn(firstRowFirstColView); 
when(secondRowViewGroup.getChildAt(1)).thenReturn(secondRowSecondColView); 
when(thirdRowViewGroup.getChildAt(1)).thenReturn(thirdRowSecondColView); 
mViewProxy.setBoxValue(0, 0, BoardDef.BOX_CROSS); 
mViewProxy.setBoxValue(1, 1, BoardDef.BOX_ROUND); 
mViewProxy.setBoxValue(1, 2, BoardDef.BOX_EMPTY); 
assertBackgroundColor(Color.RED, firstRowFirstColView); 
assertBackgroundColor(Color.BLUE, secondRowSecondColView); 
assertBackgroundColor(Color.GRAY, thirdRowSecondColView); 
} 
private void assertBackgroundColor(int expectedColor, View view) { 
ArgumentCaptor colorArg = ArgumentCaptor.forClass(Integer.class); 
verify(view).setBackgroundColor(colorArg.capture()); 
assertEquals("The background expectedColor is not correct", 
expectedColor, (int) colorArg.getValue()); 
}

View Slide

Code Coverage
Highlight part of code not tested
The percentage is (quite) useless
Display in Android Studio

View Slide

Android Studio
Execute
app
↳ src
↳ main
↳ test
↳ java
↳ ExampleUnitTest
Right click
> Run ‘All tests’ with Coverage
(or Run ‘Junit’ with Coverage)

View Slide

Singleton
Goal: be able to mock it

View Slide

Common Singleton patterns
public class MyManager { 
 
private static class SingletonHolder { 
 
private static final MyManager INSTANCE = new MyManager(); 
} 
 
private MyManager() { 
} 
 
public static MyManager getInstance() { 
return SingletonHolder.INSTANCE; 
} 
 
public void myMethod() { 
 
} 
}
Testable?
// or
public enum MyManager { 
INSTANCE; 
 
} 
}

View Slide

My testable Singleton pattern
public class MyManager { 
 
private MyManager() { 
} 
 
public static MyManager getInstance() { 
return Singleton.getInstance(MyManager.class); 
} 
 
} 
}

View Slide

Test
public class GameBoard { 
 
... 
 
MyManager.getInstance().myMethod(); 
} 
 
}
public class GameBoardTest extends TestCase {
 
... 
 
@Test 
public void testShouldCallMockSingleton() {
MyManager managerMock = Mockito.mock(MyManager.class);
Singleton.setInstance(MyManager.class, managerMock); 
mSubject.myMethod();
verify(managerMock, times(1)).myMethod(); 
} 
 
}

View Slide

Credits
@stan_kocken
Presentation pattern: github.com/StanKocken/Presentation
TicTacToe Example: github.com/StanKocken/TicTacToe
Singleton: github.com/StanKocken/39d604bcf8c814a48859
Leak Canary: github.com/square/leakcanary
Presentation pattern co-writer: Marc Olory

View Slide

Unit Test your code, even your UI

Unit Test your code, even your UI

Stan Kocken

More Decks by Stan Kocken

Other Decks in Programming

Featured

Transcript
