Calculating the Value of Pie: Real-Time Survey Analysis With Apache Kafka (Danica Fine, Confluent) | RTA Summit 2023

These days, it’s difficult to keep up with friends and family, even more so when important things are involved––like pie. Do you find yourself wishing that you could quickly and efficiently poll your loved ones, peers, and colleagues for their pastry preferences? Look no further. This talk explores how to create an interactive, real-time survey bot with Telegram and Apache Kafka® and how to analyze the survey responses using ksqlDB.

Kafka Producers and Consumers are the main ingredients that come together to make an interactive Telegram bot that issues on-demand surveys to friends and family. Survey responses are written to Kafka in real-time where ksqlDB helps to measure, mix, and knead the data––serving up a fresh and delicious result that we can consume immediately! In this session, you’ll see the entire pipeline from start to finish, learning how to think about data and use schemas, how to configure Producers and Consumers, and how to use ksqlDB for both stateless and stateful processing.

Come along to see how this recipe for real-time survey analysis comes together––and how you, too, can calculate the value of pie!

Transcript

1. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Calculating the Value of Pie Real-Time Survey Analysis With Apache Kafka®
2. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ I like houseplants.
3. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ I also like baking.
4. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/
5. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Google Forms?
6. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Google Forms?
7. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Kafka- and Telegram-based Survey-issuing Application?
8. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Surveying the Problem Landscape • Surveys are EVERYWHERE • Great business value ◦ External: what do your customers think of your product? ◦ Internal: how are your employees doing? • Often batch-processed
9. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Real Time Survey Analysis
10. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/
11. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Enhanced Recipe ? !
12. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Kafka? What’s that?
13. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Kafka? What’s that? A distributed event streaming platform.
14. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ A distributed event streaming platform.
15. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Paradigm Shift Batch Processing Realtime Processing Batch Result Batch Result PROCESSOR … … PROCESSOR Realtime Update Realtime Update Realtime Update Realtime Update
16. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ A distributed event streaming platform.
17. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Thinking in Events • Natural way to reason about things • Indicate that something has happened ◦ When ◦ What/Who • Immutable pieces of information
18. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Thinking in Events • Natural way to reason about things • Indicate that something has happened ◦ When ◦ What/Who • Immutable pieces of information
19. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ A distributed event streaming platform.
20. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ • Topics ◦ Basic storage unit ◦ Read/Write: ▪ Producer and consumer clients ▪ Completely decoupled • Partitions ◦ Immutable, append-only logs ◦ Data is replicated at this level Kafka Storage P0 P1 P2 Kafka Topic
21. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Recipe ? !
22. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ ! Recipe ?
23. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Kafka, but make it simple. • Fully-managed, cloud-based Kafka • Auxiliary tools: ◦ Kafka Connect ◦ ksqlDB ◦ Schema management
24. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ ! Recipe ?
25. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Knowing Your Pie Data
26. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ survey-entries { "doc": "Contains individual survey entries for a user and survey question.", "fields": [ { "name": "survey_id", "type": "string" }, { "name": "user_id", "type": "string" }, { "name": "name", "type": "string" }, { "default": null, "name": "company", "type": ["null","string"] }, { "default": null, "name": "location", "type": ["null","string"] }, { "name": "response", "type": "string" } ], "name": "surveyEntry", "namespace": "survey.bot", "type": "record" }
27. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ survey-respondents { "doc": "Respondents to survey questions.", "fields": [ { "name": "user_id", "type": "string" }, { "name": "name", "type": "string" }, { "default": null, "name": "company", "type": ["null","string"] }, { "default": null, "name": "location", "type": ["null","string"] } ], "name": "surveyRespondent", "namespace": "survey.bot", "type": "record" }
28. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ survey-responses { "doc": "Contains individual survey responses for a user and survey question.", "fields": [ { "name": "survey_id", "type": "string" }, { "name": "user_id", "type": "string" }, { "name": "response", "type": "string" } ], "name": "surveyResponse", "namespace": "survey.bot", "type": "record" }
29. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ survey-questions { "doc": "Details for a single question survey.", "fields": [ { "name": "survey_id", "type": "string" }, { "name": "question", "type": "string" }, { "name": "summary", "type": "string" }, { "name": "options", "type": { "items": "string", "type": "array" } }, { "name": "enabled", "type": "boolean" } ], "name": "surveyQuestion", "namespace": "survey.bot", "type": "record" }
30. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Creating a Survey { "survey_id": "1", "question": "Which Thanksgiving Pie is your favorite?", "summary": "Thanksgiving Pie", "options": [ "Pumpkin Pie", "Pecan Pie", "Apple Pie", "Thanksgiving Leftover Pot Pie", "Other" ], "enabled": true }
31. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Building a Telegram Bot
32. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Telegram as a Producer • python-telegram-bot library ◦ Wrapper for Telegram API ◦ Define conversation handlers • Produce data to Kafka ◦ Capture data using conversation handlers ◦ Create survey-entry message, serialize, and produce
33. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Conversation Handler survey_handler = ConversationHandler( entry_points = [CommandHandler(survey, survey_command)], states = { SURVEY_STATE.NAME: [ MessageHandler(filters.TEXT & ~filters.COMMAND, name_command), CommandHandler('cancel', cancel_command) ], ... SURVEY_STATE.RESPONSE: [ MessageHandler(filters.Regex( "^(Pumpkin Pie|Pecan Pie|Apple Pie|Thanksgiving Leftover Pot Pie|Other)$") ), response_command), CommandHandler('cancel', cancel_command) ], SURVEY_STATE.CONFIRM: [ CommandHandler('y', confirm_command), CommandHandler('n', cancel_command) ] }, fallbacks=[CommandHandler('cancel', cancel_command)] )
34. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Command Handler async def name_command(update: Update, context: ContextTypes.DEFAULT_TYPE) -> None: # capture and store name data context.user_data['name'] = update.message.text # get chat_id as user_id context.user_data['user_id'] = update.message.chat_id # prompt for company information await update.message.reply_text( "Enter the company that you work for or use /skip to go to the next question." ) return SURVEY_STATE.COMPANY
35. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Producer Code def send_entry(entry): # send survey entry message try: # set up Kafka producer for survey entries producer = clients.producer(clients.entry_serializer()) # prep key and value for message k = str(metadata.get('survey_id')) value = SurveyEntry.dict_to_entry(entry) logger.info("Publishing survey entry message for key %s", k) producer.produce(config['topics']['survey-entries'], key=k, value=value) except Exception as e: logger.error("Got exception %s", e) raise e finally: producer.poll() producer.flush()
36. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Taking a Thanksgiving Survey
37. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/
38. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ ! Recipe ?
39. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ ksqlDB Processing
40. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Load Stream of survey-entries CREATE STREAM survey_entries WITH ( kafka_topic = 'survey-entries', value_format = 'AVRO' );
41. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Extracting Respondents CREATE STREAM survey_respondents WITH ( kafka_topic = 'survey-respondents', value_format = 'AVRO' ) AS SELECT user_id, name, company, location FROM survey_entries EMIT CHANGES;
42. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Extracting Respondents CREATE STREAM survey_respondents WITH ( kafka_topic = 'survey-respondents', value_format = 'AVRO' ) AS SELECT user_id, name, company, location FROM survey_entries EMIT CHANGES;
43. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Extracting Respondents CREATE STREAM survey_respondents WITH ( kafka_topic = 'survey-respondents', value_format = 'AVRO' ) AS SELECT user_id, name, company, location FROM survey_entries EMIT CHANGES;
44. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Extracting Respondents CREATE STREAM survey_respondents WITH ( kafka_topic = 'survey-respondents', value_format = 'AVRO' ) AS SELECT user_id, name, company, location FROM survey_entries EMIT CHANGES;
45. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Extracting Responses CREATE STREAM survey_responses WITH ( kafka_topic = 'survey-responses', value_format = 'AVRO' ) AS SELECT user_id, survey_id, response FROM survey_entries EMIT CHANGES;
46. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Questions Table CREATE TABLE survey_questions ( id STRING PRIMARY KEY ) WITH ( kafka_topic = 'survey-questions', value_format = 'AVRO' );
47. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Analysis CREATE TABLE survey_results_live WITH ( kafka_topic='survey-results-live', value_format='AVRO' ) AS SELECT question AS question, HISTOGRAM(response) AS results FROM survey_entries GROUP BY question EMIT CHANGES;
48. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Results What is your Favorite Thanksgiving Pie? { Pumpkin Pie=1, Pecan Pie=1, ... Apple Pie=3 } { Pumpkin Pie=1, Pecan Pie=1, ... Apple Pie=4 } { Pumpkin Pie=2, Pecan Pie=1, ... Apple Pie=4 } { Pumpkin Pie=2, Pecan Pie=2, ... Apple Pie=4 } ...
49. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Analysis CREATE TABLE survey_results_live WITH ( kafka_topic='survey-results-live', value_format='AVRO' ) AS SELECT question AS question, HISTOGRAM(response) AS results FROM survey_entries GROUP BY question EMIT CHANGES;
50. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Analysis CREATE TABLE survey_results_final WITH ( kafka_topic='survey-results-final', value_format='AVRO' ) AS SELECT question AS question, HISTOGRAM(response) AS results FROM survey_entries WINDOW TUMBLING (SIZE 48 HOURS, GRACE PERIOD 10 MINUTE) GROUP BY question EMIT FINAL;
51. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Analysis CREATE TABLE survey_results_final WITH ( kafka_topic='survey-results-final', value_format='AVRO' ) AS SELECT question AS question, HISTOGRAM(response) AS results FROM survey_entries WINDOW TUMBLING (SIZE 48 HOURS, GRACE PERIOD 10 MINUTE) GROUP BY question EMIT FINAL;
52. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Alerting with Telegram • Kafka Connect ◦ Connects Kafka and external systems ◦ Independent framework ◦ Configuration-based • Kafka Connect HTTP Sink Connector ◦ Fully-managed in Confluent Cloud ◦ Migrates the events from the survey_results_final topic as they happen !
53. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Alerting with Telegram • Kafka Connect ◦ Connects Kafka and external systems ◦ Independent framework ◦ Configuration-based • Kafka Connect HTTP Sink Connector ◦ Fully-managed in Confluent Cloud ◦ Migrates the events from the survey_results_final topic as they happen !
54. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Recipe ? !
55. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Recipe++ ? !
56. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Stream Processing Use Case Recipes
57. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Looking to get started? LinkTree Resources
58. dfine@confluent.io @TheDanicaFine linkedin.com/in/danica-fine/ Questions?
