Upgrading Log-Analytics Clusters to OpenSearch (Amitai Stern, LogzIO) | RTA Summit 2023

Here at Logz.io, the open-source observability and security company, we run ElasticSearch for over 1300 companies in highly scalable multi-cloud deployments. With the license changes of 2021 we needed to migrate to an open-source platform, and OpenSearch was where we were going to contribute and what we wanted to run in production.

Many equate upgrading to OpenSearch from Elasticsearch in production as changing the tires on a moving bus. Upgrading has many risks, and if the cluster is in continuous production use, ingesting terabytes of data daily, the risks can seem overbearing.

In this talk, we will cover multiple upgrade strategies, including version requirements, and their pros and cons. Additionally, we will cover a different option, which is the way we, at Logz.io, upgraded all our clusters to OpenSearch without significant extra costs while minimizing risk. Not only did we upgrade to OpenSearch, but we also migrated our AWS workloads to Graviton2 instances.

Transcript

1. Upgrading log-analytics clusters
   to OpenSearch
   @amitaistern
   Amitai Stern
   Software Engineer and Telemetry
   Storage Team Lead at Logz.io


   View Slide

2. View Slide

3. 6.8 7.0.0 7.10 8.7
   7.11
   1.0.0 2.6


   View Slide

4. January 2021
   6.8 7.0.0 7.10 8.7
   7.11
   1.0.0 2.6


   View Slide

5. July 2021
   6.8 7.0.0 7.10 8.7
   7.11
   1.0.0 2.6
   January 2021


   View Slide

6. Apache 2.0-licensed open source
   Server Side Public License (SSPL)
   6.8 7.0.0 7.10 8.7
   7.11
   1.0.0 2.6


   View Slide

7. Supports both AMD64 and ARM64
   architectures
   Supports AMD64
   architecture
   6.8 7.0.0 7.10 8.7
   7.11
   1.0.0 2.6


   View Slide

8. 6.8 7.0.0 7.10 8.7
   7.11
   1.0.0 2.6


   View Slide

9. Log-Engine
   Application
   Kibana Query-Service
   Other
   Microservices
   search
   ingest
   Log Analytics Cluster Architecture
   Amazon S3
   (cluster snapshots)


   View Slide

10. Log-Engine
    Application
    Kibana Query-Service
    Other
    Microservices
    search
    ingest
    Log Analytics Cluster Architecture
    Amazon S3
    (cluster snapshots)


    View Slide

11. Preparing for the upgrade
    Index
    versions
    Deprecated
    APIs
    Breaking
    changes
    Test env
    Cluster
    Settings
    thresholds


    View Slide

12. Common Upgrading
    Strategies


    View Slide

13. Common Upgrading Strategies: Blue/Green
    Cluster Cluster
    read
    write


    View Slide

14. Common Upgrading Strategies: Blue/Green
    Cluster Cluster
    read
    write


    View Slide

15. Common Upgrading Strategies: In-Place
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes
    Cluster


    View Slide

16. Balancing
    Risk, Cost, and Speed


    View Slide

17. The Drain Method
    Data
    nodes
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.exclude._ip": "172.22.4.9"
    }
    }
    172.22.4.9


    View Slide

18. The Drain Method
    Data
    nodes
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.exclude._ip": "172.22.4.9",
    "indices.recovery.max_bytes_per_sec": "150mb"
    }
    }
    172.22.4.9


    View Slide

19. The Drain Method
    Data
    nodes
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": "172.33.14.1,172.22.4.9"
    }
    }
    172.22.4.9
    172.33.14.1


    View Slide

20. The Drain Method
    Data
    nodes
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": "172.33.14.1,172.22.4.9"
    }
    }


    View Slide

21. The Drain Method: Upgrade Process Overview
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": ""
    }
    }
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

22. The Drain Method: Upgrade Process Overview
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": "",
    "cluster.routing.allocation.exclude._ip": ""
    }
    }
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

23. The Drain Method: Upgrade Process Overview
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": "",
    "cluster.routing.allocation.exclude._ip": ""
    }
    }
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

24. The Drain Method: Upgrade Process Overview
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": "",
    "cluster.routing.allocation.exclude._ip": ""
    }
    }
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes
    "indices.recovery.max_bytes_per_sec": "300mb"


    View Slide

25. The Drain Method: Upgrade Process Overview
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": "",
    "cluster.routing.allocation.exclude._ip": ""
    }
    }
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes
    "indices.recovery.max_bytes_per_sec": "0mb"


    View Slide

26. The Drain Method: Upgrade Process Overview
    PUT _cluster/settings
    {
    "persistent": {
    "cluster.routing.allocation.include._ip": null,
    "cluster.routing.allocation.exclude._ip": null
    }
    }
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

27. The Drain Method: Upgrade Process Overview
    |
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes
    load balancer
    DNS record


    View Slide

28. The Drain Method: Upgrade Process Overview
    - New LB
    - OpenSearch Coordinator Nodes
    Data
    nodes
    load balancer
    Coordinator
    nodes
    Cluster
    manager
    nodes
    load balancer
    DNS record


    View Slide

29. - New LB
    - OpenSearch Coordinator Nodes
    - Override DNS record
    DNS record
    The Drain Method: Upgrade Process Overview
    Data
    nodes
    load balancer
    Coordinator
    nodes
    Cluster
    manager
    nodes
    load balancer


    View Slide

30. The Drain Method: Upgrade Process Overview
    - New LB
    - OpenSearch Coordinator Nodes
    - Override DNS record
    - Remove old Coordinating Nodes
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes
    load balancer


    View Slide

31. |
    The Drain Method: Upgrade Process Overview
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

32. The Drain Method: Upgrade Process Overview
    - Add 3 more Cluster manager Nodes
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

33. The Drain Method: Upgrade Process Overview
    - Add 3 more Cluster manager Nodes
    - Remove the old ones one at a time (elected one last)
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

34. The Drain Method: Upgrade Process Overview
    - Add 3 more Cluster manager Nodes
    - Remove the old ones one at a time (elected one last)
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

35. The Drain Method: Upgrade Process Overview
    - Add 3 more Cluster manager Nodes
    - Remove the old ones one at a time (elected one last)
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

36. The Drain Method: Upgrade Process Overview
    - Add 3 more Cluster manager Nodes
    - Remove the old ones one at a time (elected one last)
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

37. The Drain Method: Upgrade Process Overview
    - Add 3 more Cluster manager Nodes
    - Remove the old ones one at a time (elected one last)
    - Await Cluster Manager Node reelection
    Data
    nodes
    Coordinator
    nodes
    ???
    Cluster
    manager
    nodes


    View Slide

38. DONE :)
    The Drain Method: Upgrade Process Overview
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

39. |
    The Drain Method: Upgrade Process Overview
    Data
    nodes
    Coordinator
    nodes
    Cluster
    manager
    nodes


    View Slide

40. The Drain Method: Managing risk
    Log-Engine
    Application
    Kibana
    Query-Service
    search
    ingest
    Amazon S3
    (cluster snapshots)


    View Slide

41. Backup
    cluster
    Backup
    Log-Engine
    Application
    Kibana
    Query-Service
    search
    The Drain Method: Managing risk
    Log-Engine
    ingest
    Amazon S3
    (cluster snapshots)


    View Slide

42. Backup
    cluster
    Application
    Kibana
    Query-Service
    search
    The Drain Method: Managing risk
    Log-Engine
    ingest
    Amazon S3
    (cluster snapshots)
    Backup
    Log-Engine


    View Slide

43. The Drain Method: Managing risk
    Log-Engine
    Application
    Kibana
    Query-Service
    search
    ingest
    Amazon S3
    (cluster snapshots)


    View Slide

44. Backup
    cluster
    The Drain Method: Managing risk
    Log-Engine
    ingest
    Amazon S3
    (cluster snapshots)
    Backup
    Log-Engine
    Application
    Kibana
    Query-Service
    search


    View Slide

45. Backup
    cluster
    Application
    Kibana
    Query-Service
    search
    The Drain Method: Managing risk
    Log-Engine
    ingest
    Amazon S3
    (cluster snapshots)
    Backup
    Log-Engine


    View Slide

46. Backup
    cluster
    Backup
    Log-Engine
    Application
    Kibana
    Query-Service
    search
    The Drain Method: Managing risk
    ingest
    Amazon S3
    (cluster snapshots)


    View Slide

47. Backup
    Log-Engine
    Application
    Kibana
    Query-Service
    search
    The Drain Method: Managing risk
    ingest
    Amazon S3
    (cluster snapshots)
    Restore from Snapshot
    Backup
    cluster


    View Slide

48. Backup
    cluster
    Backup
    Log-Engine
    Application
    Kibana
    Query-Service
    search
    The Drain Method: Managing risk
    ingest
    Amazon S3
    (cluster snapshots)


    View Slide

49. Blue/Green In Place Drain
    Pros Fully revertable (instantly)
    Can replace hardware as
    well
    Fast (within a few hours)
    Cheap (0 extra nodes)
    Fully revertable (within
    hours)
    Rather fast (many hours)
    Can replace hardware as well
    Cheaper than Blue/Green
    Cons Slow upgrade (days/weeks)
    Complexity grows over time
    Double the cluster cost for
    the duration
    No rolling back
    No hardware change
    Costs more than In Place
    Complex upgrade process
    Complex rollback
    Summary
    Drain


    View Slide

50. Upgrading log-analytics clusters to
    OpenSearch
    Q&A
    @amitaistern
    Amitai Stern
    Software Engineer and Telemetry
    Storage Team Lead at Logz.io


    View Slide
