  1. Network Slicing in 5GC Iwan Setiawan <stwn at unsoed.ac.id> A

    final presentation for Multimedia Wireless Networks course
  2. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) There

    are many abbreviations!
  3. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) 5GC

    = 5G Core (5G Core Network or 5G CN)
  4. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Contents

    • Service-based architecture • Network slicing in 5GC
  5. Service-Based Architecture

  6. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network Penttinen, 2019
  7. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network Protocol Data Unit (PDU) Session Penttinen, 2019
  8. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture Control Plane User Plane SDN Penttinen, 2019
  9. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture Control Plane User Plane SDN S-GW P-GW 4G Penttinen, 2019
  10. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture Control Plane User Plane SDN S-GW P-GW UPF SMF 4G
  11. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture Control Plane User Plane SDN UPF SMF P-GW C P-GW U S-GW C S-GW U CUPS = Control and User Plane Separation 4G +CUPS
  12. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network Service-oriented design Network functions Penttinen, 2019
  13. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network Service-oriented design Network functions Services Penttinen, 2019
  14. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network Service-oriented design Network functions Services Interfaces Penttinen, 2019
  15. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network Service-oriented design Network functions Services Interfaces Penttinen, 2019
  16. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network Service-oriented design Network functions Services Interfaces Penttinen, 2019
  17. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) NFV

    Infrastructure Common hardware UPF Management and Orchestration Virtual network functions Penttinen, 2019
  18. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture (SBA) • Service-oriented design: modular elements as virtualized functions or microservices • Service-oriented mechanism: elements serve one another • Service-based interface: a way to produce or consume services with request-respond method
  19. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network 1 2 3 4 AMF = Access and Mobility SMF = Session Management AUSF = Authentication PCF = Policy Control UDM = Unified Data Management NRF = Network Repository NEF = Network Exposure NSSF = Network Slice Selection AF = Application 5 Penttinen, 2019
  20. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Service-Based

    Architecture UE = User equipment AN = Access network DN = Data network NF NF NF Penttinen, 2019
  21. Network Slicing in 5GC

  22. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Generic

    5G Network Slicing Framework Foukas et al., 2017
  23. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Generic

    5G Network Slicing Framework Slice implementation Slice management and configuration Definition Deployment Network Slice Controller Foukas et al., 2017
  24. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) An

    Example of Network Slicing Penttinen, 2019
  25. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Network

    Slice (NS) Terms • NS Selection Funct. (NSSF): NF to select NSI serving the UE • NS Template (NST): logical NFs and resources linked to the services and network capabilities required* • NS Instance (NSI): an NS instance created fom NST • NS Selection Assistance Information (NSSAI) – Slice/Service Type (SST): eMBB (1), uRLLC (2), mMTC (3)** – Slice Differentiator (SD): additional differentiator if multiple network slices carry the same SST value * 3GPP TS 23.501 * https://mpirical.com/glossary
  26. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) NST

    SST 2 NSI Penttinen, 2019 SST 1 SST 3 NSSF NSSAI 1 2 3 4 a e f a g h b d e a f b c a e f g h b d
  27. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) https://futurenetworks.ieee.org/tech-focus/march-2018/orchestrating-5gc

  28. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Network

    Slicing in 5GC Shared NFs: AMF, NSSF, AUSF, UDM, AF Penttinen, 2019
  29. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) https://sdn.ieee.org/newsletter/december-2017/ntt-docomo-s-5g-experimentations-and-trials-on-network-slicing

  30. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Marie-Paule

    Odini, 2019
  31. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Marie-Paule

    Odini, 2019
  32. Conclusions

  33. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) Concluding

    Remarks • 5GC uses SDN and NFV in the SBA to support network slicing for multi use cases • NFs in 5GC can be created dynamically to provide network slice for each use case • Each network slice has different set of NFs, and it can share set of NFs with other slices
  34. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) https://comsoc.org/publications/ctn/overbooking-every-business-has-make-profit

  35. References

  36. Multimedia Wireless Networks (ET5907701) Iwan Setiawan (stwn at unsoed.ac.id) References

    [1] J. T. J. Penttinen, 5G Explained, Wiley, 2019. [2] X. Foukas, G. Patounas, A. Elmokashfi and M. K. Marina, "Network slicing in 5G: survey and challenges," in IEEE Commun. Magazine, vol. 55, no. 5, pp. 94-100, May 2017.
