Mission (Im)possible: Quality Decoupled Code with Drupal 7 (DrupalCamp Scotland)

We're all excited about Drupal 8 coming up soon and we want to be ready for it! How can we make sure our code is ready for it? How can we build modules that are backwards compatible with D7 and future proofed for D8?

Learn how to build code decoupled from your platform and use it with Drupal or any other framework.

Transcript

1. Marek Matulka


   View Slide

2. at
   @super_marek


   View Slide

3. View Slide

4. View Slide

5. View Slide

6. View Slide

7. http://photobucket.com/user/marcrobinsone/media/Drupal%20Comics/marcrobinsonegmailcom__drupalNinja.png.html


   View Slide

8. View Slide

9. View Slide

10. In order to create a good
    software, you have to know
    what the software is all
    about.
    – Eric Evans


    View Slide

11. How do we learn?


    View Slide

12. Stakeholders


    View Slide

13. Ask for examples...
    ...write stories!


    View Slide

14. Vocabulary


    View Slide

15. Ubiquitous Language
    Ubiquitous
    Language


    View Slide

16. Ubiquitous Language
    Ubiquitous
    Language
    Domain
    Expert
    Analyst
    Tester Developer
    Developer


    View Slide

17. Ubiquitous Language
    Ubiquitous
    Language
    Domain
    Expert
    Analyst
    Tester Developer
    Developer
    Application
    Code Acceptance
    Criteria
    Specs and
    documentation


    View Slide

18. Example?


    View Slide

19. Example
    Feature:
    In order to see correct prices
    As a visitor
    I need to be able to locate the nearest depot
    Scenario:
    Given I am visiting a product page for the first time
    And I got prompted to locate my nearest depot
    When I enter my post code
    Then I should see my local depot information


    View Slide

20. Example
    Feature:
    In order to see correct prices
    As a visitor
    I need to be able to locate the nearest depot
    Scenario:
    Given I am visiting a product page for the first time
    And I got prompted to locate my nearest depot
    When I enter my post code
    Then I should see my local depot information


    View Slide

21. Domain
    namespace Acme\Depot;
    interface DepotLocator
    {
    /**
    * @param string $postcode
    *
    * @return Depot
    */
    public function locateDepot($postcode);
    }


    View Slide

22. Implementation
    namespace Acme\MagentoAdapter;
    use Acme\Depot\DepotLocator;
    class MagentoDepotLocator implements DepotLocator
    {
    public function locateDepot($postcode)
    {
    return $this->entityMapper->mapDepot(
    $this->clientAdapter->findDepotByPostcode($postcode)
    );


    View Slide

23. why interface?


    View Slide

24. Layered Architecture
    “High level modules
    should not depend on
    lower level
    implementation”
    – Robert C. Martin
    User Interface
    Application
    Domain
    Infrastructure


    View Slide

25. Dependency Inversion
    Policy Layer

    Policy Service
    Mechanism
    Layer

    Mechanism
    Service
    Utility Layer


    View Slide

26. Layered Architecture
    User Interface
    Application
    Domain
    Infrastructure


    View Slide

27. Layered Architecture
    User Interface
    Application
    Domain
    Infrastructure


    View Slide

28. Clean Architecture
    Entities
    Use Cases
    Controllers
    Web


    View Slide

29. Clean Architecture
    Entities
    Use Cases
    Controllers
    Web
    Framework
    Drivers
    Interface
    Adapters
    Application
    Business
    Rules
    Enterprise
    Business
    Rules


    View Slide

30. Hexagonal Architecture
    UI Adapter
    Log Adapter
    Data Storage
    Adapter
    External Data
    Adapter
    Application
    Domain


    View Slide

31. Hexagonal Architecture
    Acme\Depot\DepotLocator
    Acme\MagentoAdapter\MagentoDepotLocator


    View Slide

32. Hexagonal Architecture
    Acme\Depot\DepotLocator
    Acme\MagentoAdapter\MagentoDepotLocator
    port
    adapter


    View Slide

33. Why clean architecture?


    View Slide

34. Why clean architecture?
    - your code is clean(er)
    - decoupled from framework
    - reusable
    - easy to test
    - easy to maintain
    - easy to change


    View Slide

35. View Slide

36. View Slide

37. symfony/dependency-injection
    symfony/config
    dependency injection


    View Slide

38. Dependency Injection
    - a standardised and centralised way of
    constructing objects in our application


    View Slide

39. Kernel
    public function boot()
    {
    $this->container = new ContainerBuilder();
    $this->container->compile();
    }


    View Slide

40. Kernel
    public function boot()
    {
    $this->container = new ContainerBuilder();
    $loader = new YamlFileLoader($this->container, new FileLocator('app/config'));
    $loader->load('parameters.yml');
    $this->container->compile();
    }


    View Slide

41. Kernel
    public function boot()
    {
    $this->container = new ContainerBuilder();
    $loader = new YamlFileLoader($this->container, new FileLocator('app/config'));
    $loader->load('parameters.yml');
    $loader = new XmlFileLoader($this->container, new FileLocator('app/config'));
    $loader->load('services.xml');
    $this->container->compile();
    }


    View Slide

42. Kernel
    public function boot()
    {
    $this->container = new ContainerBuilder();
    $loader = new YamlFileLoader($this->container, new FileLocator('app/config'));
    $loader->load('parameters.yml');
    $loader = new XmlFileLoader($this->container, new FileLocator('app/config'));
    $loader->load('services.xml');
    $this->container->registerExtension(new ApplicationExtension());
    $this->container->compile();
    }


    View Slide

43. Kernel
    public function boot()
    {
    $this->container = $this->buildContainer();
    }
    /**
    * @return ContainerBuilder
    */
    private function buildContainer()
    {
    $container = new ContainerBuilder();
    $loader = new YamlFileLoader($container, new FileLocator('app/config'));
    $loader->load('parameters.yml');
    $loader = new XmlFileLoader($container, new FileLocator('app/config'));
    $loader->load('services.xml');
    $container->registerExtension(new ApplicationExtension());
    $container->compile();
    return $container;
    }


    View Slide

44. Kernel
    public function boot()
    {
    if (file_exists($this->cachedContainerFileName)) {
    require $this->cachedContainerFileName;
    $this->container = new ProjectServiceContainer();
    } else {
    $container = $this->buildContainer();
    $dumper = new PhpDumper($container);
    file_put_contents($this->cachedContainerFileName, $dumper->dump());
    $this->container = $container;
    }
    }


    View Slide

45. Kernel
    public function boot()
    {
    if (file_exists($this->cachedContainerFileName)) {
    require $this->cachedContainerFileName;
    $this->container = new ProjectServiceContainer();
    } else {
    $container = $this->buildContainer();
    if ('dev' !== $container->getParameter('environment')) {
    $dumper = new PhpDumper($container);
    file_put_contents($this->cachedContainerFileName, $dumper->dump());
    }
    $this->container = $container;
    }
    }


    View Slide

46. parameters.yml
    application:
    database:
    name: acme-dev
    username: acme-dev
    password: S0m3R4nD0mP455
    host: localhost
    port: ~
    soap_client:
    wsdl: https://api.store.local/v1/?wsdl
    http_auth_username: acme-dev
    http_auth_password: S0m3R4nD0mP455
    username: acme-dev-user
    api_key: R4nD0mAp1K3y
    product_hydrator:
    product_url_snippet: http://store.local/product/{sku}
    product_image_url: http://store.local/media/catalog/product/uploads/


    View Slide

47. services.xml


    View Slide

48. symfony/console
    console commands


    View Slide

49. Import Handler
    class ImportAndPersistActionHandler
    {
    /**
    * @param ProductImporter $importer
    * @param ProductPersister $persister
    */
    public function __construct(ProductImporter $importer, ProductPersister $persister)
    {
    $this->importer = $importer;
    $this->persister = $persister;
    }
    public function importAndPersistProducts()
    {
    $productsList = $this->importer->importProducts();
    $this->persister->saveAll($productsList);
    }
    }


    View Slide

50. Console command
    class ImportAndPersistCommand extends Command
    {
    public function __construct(ImportAndPersistActionHandler $action)
    {
    $this->action = $action;
    parent::__construct();
    }
    protected function configure()
    {
    $this->setName('products:import');
    }
    protected function execute(InputInterface $input, OutputInterface $output)
    {
    $startTime = microtime(true);
    $this->action->importAndPersistProducts();
    $output->writeln(
    sprintf("Products import completed in %1.02fs.", microtime(true) - $startTime)
    );
    }
    }


    View Slide

51. app/console
    #!/usr/bin/php
    require_once (__DIR__ . '/../vendor/autoload.php');
    use Acme\Application\Kernel;
    use Symfony\Component\Console\Application;
    $kernel = new Kernel();
    $kernel->boot();
    $application = new Application();
    $application->addCommands([
    $kernel->getContainer()->get('acme.command.import_products'),
    $kernel->getContainer()->get('acme.command.delete_products'),
    $kernel->getContainer()->get('acme.command.depot_locate'),
    ]);
    $application->run();


    View Slide

52. symfony/filesystem
    persisting products


    View Slide

53. XML Writer
    class ProductXmlWriter implements ProductPersister
    {
    /**
    * @param Filesystem $filesystem
    * @param string $fileName
    */
    public function __construct(Filesystem $filesystem, string $fileName)
    {
    $this->filesystem = $filesystem;
    $this->fileName = $fileName;
    }
    /**
    * @param ProductList $productList
    */
    public function saveAll(ProductList $productList)
    {
    $this->filesystem->dumpFile($this->fileName, $this->renderXml($productList));
    }
    }


    View Slide

54. Why write XML?
    - fetching data from Magento and dumping
    it into xml file is quick
    - xml can be imported by Drupal’s feed
    importer


    View Slide

55. Why it didn’t work?
    - Feed importer was damn slow
    - 10k products imported in 4.5h
    - Scheduling import with Elysia Cron
    module was flaky
    - Scheduled feed importer would add
    products all over again
    - resources hungry!


    View Slide

56. Direct save to the db
    class DatabaseProductPersister implements ProductPersister
    {
    private $repository;
    /**
    * @param ProductRepository $repository
    */
    public function __construct(ProductRepository $repository)
    {
    $this->repository = $repository;
    }
    public function saveAll(ProductList $productList)
    {
    foreach ($productList as $product) {
    $this->repository->save($product);
    }
    }
    }


    View Slide

57. Why direct save to the db?
    - Drupal promises data structure won’t ever
    change
    - It’s fast - 40k products in 2 minutes
    - It works!


    View Slide

58. composer.json
    "require": {
    "php": ">=5.4.0",
    "symfony/console": "~2.5",
    "drush/drush": "7.*@dev",
    "symfony/finder": "~2.5",
    "symfony/dependency-injection": "~2.5",
    "symfony/config": "~2.5",
    "symfony/filesystem": "~2.6",
    "doctrine/dbal": "~2.5",
    "rhumsaa/uuid": "~2.8"
    },


    View Slide

59. container.php
    require_once DRUPAL_ROOT . '/../vendor/autoload.php';
    $kernel = new \Acme\Application\Kernel();
    $kernel->boot();
    variable_set('di_container', = $kernel->getContainer());


    View Slide

60. database.php
    $databases = [
    'default' =>
    [
    'default' =>
    [
    'database' => $conf['di_container']->getParameter('database.name'),
    'username' => $conf['di_container']->getParameter('database.username'),
    'password' => $conf['di_container']->getParameter('database.password'),
    'host' => $conf['di_container']->getParameter('database.host'),
    'port' => $conf['di_container']->getParameter('database.port'),
    'driver' => 'mysql',
    'prefix' => '',
    ],
    ],
    ];


    View Slide

61. settings.php
    ...
    include_once 'config/container.php';
    include 'database.php';
    ...


    View Slide

62. depot_locator.module
    function get_depot_json($postcode)
    {
    global $conf;
    $depotEntity = variable_get('di_container')
    ->get('acme.depot_locator')->locateDepot($postcode);
    $depot = $depotEntity->toArray();
    set_depot_cookies($depot);
    return ['depot' => $depot];
    }


    View Slide

63. Project folder structure


    View Slide

64. View Slide

65. View Slide

66. as a CMS platform
    Drupal is great!


    View Slide

67. Cherry pick what you need!
    Symfony Components


    View Slide

68. Try it yourself!
    Decoupled code


    View Slide

69. Right tool
    Choose wisely!


    View Slide

70. View Slide

71. https://speakerdeck.com/super_marek
    @super_marek


    View Slide
