How WebKit Works

How WebKit Works Adam Barth (abarth) October 30, 2012

What is WebKit? WebKit is a rendering engine for web
content WebKit is not a browser, a science project, or the solution to every problem HTML JavaScript CSS WebKit Rendering of a web page

WebCore (HTML, CSS, DOM, etc, etc) Major Components WTF (Data
structures, Threading primitives) Platform (Network, Storage, Graphics) JavaScriptCore (JavaScript Virtual Machine) Bindings (JavaScript API, Objective-C API) WebKit and WebKit2 (Embedding API) This talk

Life of Web Page Network Loader HTML Parser DOM Script
Render Tree CSS Graphics Context

Page Main Frame Document Pages, Frames, and Documents Frame Frame
Frame Document Document Document Frame Document

Lifecycle of a Frame Uninitialized Initial Document Provisional Ready to
Commit Committed Checking Policy • Committed is the quiescent state

How the Loader Works (Idealized) MemoryCache CachedResourceLoader CachedResource ResourceRequest ResourceLoader
ResourceHandle CachedResourceRequest The Loader is actually very messy and complicated, but we have a long-term project to clean up its nuttiness Platform-specific code

Tokenizer TreeBuilder How the HTML Parser Works Bytes Characters Tokens
Nodes DOM <body>Hello, <span>world!</span></body> StartTag: body Hello, StartTag: span world! EndTag: span body Hello, span world! body Hello, span world! 3C 62 6F 64 79 3E 48 65 6C 6C 6F 2C 20 3C 73 70 61 6E 3E 77 6F 72 6C 64 21 3C 2F 73 70 61 6E 3E 3C 2F 62 6F 64 79 3E

Preload Scanning for Fun and Profit Mary had a little
lamb Tokenizer TreeBuilder document.write("<textarea>"); Script execution can change the input stream Preload scanner tokenizes ahead • When parser is blocked on external scripts • Starts resource loads earlier

XSSAuditor Tokenizer TreeBuilder HTTP Request HTTP Response XSSAuditor XSSAuditor examines
token stream Looks for scripts that were also in the request • Assumes those scripts were reflected XSS • Blocks them

DOM + CSS → Render Tree body Hello, span world!
html head title Greeting img #footer { position: fixed; bottom: 0; left: 0 } body > span { font-weight: bold; } Render Block Render Inline Render Text Render Image Render Text bold Layout Render Block fixed

Anonymous RenderObjects div Hello, div world! Render Block Render Block
Render Text Render Block Render Text Anonymous • Not every RenderObject has a DOM Node • Every RenderBlock either: ◦ Has all inline children ◦ Has no inline children

LayerTree Render Block Render Inline Render Text Render Image Render
Text bold Render Block fixed Render Layer Render Layer • Sparse representation of RenderTree • Enables accelerated compositing, scrolling

Yet Another Tree: LineBoxTree <div>An old silent pond... A frog
jumps into the pond, splash! <b>Silence again.</b></div> InlineTextBox InlineTextBox InlineTextBox RootInlineBox RootInlineBox RootInlineBox InlineTextBox Render Block Render Text Render Inline Render Text bold • One RootInlineBox per line of text • List of inline flow and inline text boxes

Conclusion • WebCore's main processing pipeline: ◦ Loader and Parser
◦ CSS, DOM, and Script ◦ RenderTree, LayerTree, and InlineBoxes • Other major subsystems ◦ Accessibility, Editing, Events, CSS, Web Inspector ◦ Plugins, SVG, MathML, XSLT... • Other components ◦ WebKit, Bindings, Platform, JavaScriptCore, WTF ◦ ... 1.5 MLOC of C++ • Learn more: ◦ http://www.webkit.org/coding/technical-articles.html

Thanks! [email protected]
