VMworld 2017 PBO1757BU - Configuring a Hybrid Cloud with VMware Cloud Foundation

Presented at VMworld 2017.
Recording at https://youtu.be/2-4Fnmt2tBU

Transcript

1. Ryan Johnson
   Staff Technical Marketing Architect, VMware, Inc.
   VCIX6-DCV, VCIX6-NV, VCAP65.-DCV, VCAP7/6-CMA
   VCP7-CMA, VCP6*-*
   @tenthirtyam
   PBO1757BE
   Configuring a Hybrid Cloud with
   VMware Cloud Foundation


   View Slide

2. • This presentation may contain product features that are currently under development.
   • This overview of new technology represents no commitment from VMware to deliver these
   features in any generally available product.
   • Features are subject to change, and must not be included in contracts, purchase orders, or
   sales agreements of any kind.
   • Technical feasibility and market demand will affect final delivery.
   • Pricing and packaging for any new technologies or features discussed or presented have not
   been determined.
   Disclaimer
   2


   View Slide

3. What exactly is ”Hybrid Cloud?”
   Hybrid
   Private Public


   View Slide

4. Hybrid
   >


   View Slide

5. Hybrid Cloud
   5
   Adoption of public or private clouds without creating cloud silos.
   Hybrid Cloud Platform
   Consistent and
   simple to operate
   Private Cloud Public Cloud
   Compatible across
   on- and off-premises
   Workload Ready


   View Slide

6. Designing and Building
   a Hybrid Cloud is often
   the Bottleneck


   View Slide

7. VMware Cloud Foundation
   Compute Storage Network
   Cloud Management
   Lifecycle Automation
   Public Cloud
   Private Cloud


   View Slide

8. Run Your Apps and Workloads Anywhere
   100% Owned 100% Operated
   Consolidate and Migrate
   Migrate more of your private cloud
   workloads to the public cloud
   Reduce and Eliminate
   Run all of your apps and
   workloads in the public cloud
   Maintain and Expand
   Run select apps and workloads
   in the public cloud
   VMware gives you ultimate cloud flexibility and freedom.
   Expand
   Maintain Migrate
   Consolidate Outsource


   View Slide

9. VMware Cloud Foundation
   Broad Ecosystem of Hardware Partners and Cloud Service Providers
   Private Cloud Public Cloud
   A single platform powering on-premises and public clouds.
   Simple, consistent operational experience that leverages existing tools, skills, people, and investments
   Private Cloud Public Cloud
   Seamlessly extend Cloud Foundation into the public cloud and consume as a service


   View Slide

10. © 2017 VMware Inc. All rights reserved. | Slide 10
    Automated Deployment and Bring Up of the Private Cloud
    Physical
    Deployment
    Power On
    Validation
    Customer
    Info Input
    Management
    Cluster Built
    SDDC Ready
    VMware Cloud Foundation
    APP APP APP
    • Rack fully assembled or
    delivered to customer
    • Power and networking
    connected per site survey
    • SDDC Manager
    brought up
    • System checked
    against known good
    inventory
    • DOA’s or other
    discrepancies identified
    • Datacenter parameters
    such as DNS, Active
    Directory, NTP etc.
    input by customer
    • IP address ranges and
    networks for
    Management, vMotion,
    vSAN and VXLAN
    • vSphere, NSX, vSAN,
    brought online
    • vSAN datastore created
    • Management packs installed
    & configured
    • Availability settings
    management configured


    View Slide

11. © 2017 VMware Inc. All rights reserved. | Slide 11
    Customer
    Delivery
    Automation
    Initialized
    Customer
    Request
    Automated
    Platform Build
    SDDC Ready
    VMware Cloud Foundation
    APP APP APP
    • Final Validations
    • Customer Portal Updates
    • Systems and Credentials
    • 100% Operational
    • Inventory Selection
    • Networks and IP
    Addresses Selected
    • Hosts Validation and
    Preparation
    • SDDC Manager
    Brought Online
    • Region Selection
    • Environmental
    Parameters Set
    • Cost Calculated
    • API Keys Validated
    • Deployment Initiated
    • vSphere, NSX, vSAN,
    Configured and Brought
    Online
    • Availability Settings
    Configured
    Automated Deployment and Bring Up in the Public Cloud


    View Slide

12. Building Hybrid Cloud with VMware Solutions on IBM Cloud
    12
    Compatible. Managed. Distributed.
    Cloud
    Foundation
    Cloud
    Foundation
    IBM Cloud
    Region 1
    Cloud
    Foundation
    Workload Portability Between Clouds
    Region 2
    Cloud
    Foundation
    Region 3
    Cloud
    Foundation
    Access to All
    IBM Cloud
    Services
    Private Cloud


    View Slide

13. Building Hybrid Cloud with VMware Cloud on AWS
    13
    13
    Compatible. Managed. Distributed.
    Cloud
    Foundation
    Cloud
    Foundation
    IBM Cloud
    Region 1
    Cloud
    Foundation
    Workload Portability Between Clouds
    Region 2
    Cloud
    Foundation
    Region 3
    Cloud
    Foundation
    Private Cloud
    Access to All Amazon Web Services


    View Slide

14. Demo
    Deploying an Instance
    of VMware Cloud Foundation on IBM Cloud


    View Slide

15. Some Design Considerations
    Hybrid Cloud with VMware Cloud Foundation
    Network
    Transport
    Core Network
    Services
    Content
    Delivery
    Extending
    Cloud Management
    Extending
    Cloud Operations


    View Slide

16. © 2017 VMware Inc. All rights reserved. | Slide 16
    Isolated
    No network connection from
    private cloud to public cloud resources.
    (Not so hybrid. J)
    Network Transport Options
    Hybrid Cloud with VMware Cloud Foundation
    Direct Connect
    Dedicated network connection from
    private cloud to public cloud resources.
    IPsec VPN
    Secured network connection from
    private cloud to public cloud resources
    over the Internet.


    View Slide

17. Direct Connect
    17
    Hybrid Cloud Connectivity
    On-Premises
    Private Cloud
    Interconnect
    Provider
    Public Cloud
    Provider


    View Slide

18. Direct Connect Example
    18
    Hybrid Cloud Connectivity
    Palo Alto, CA
    Private Cloud
    Equinix San Jose, CA
    IBM Cloud


    View Slide

19. Direct Connect with IBM Cloud Example
    19
    Hybrid Cloud Connectivity
    Palo Alto, CA
    Private Cloud
    Equinix San Jose 02, CA
    IBM Cloud
    Interconnect Edge
    10.254.9.50
    XCR
    10.254.9.49
    BBR
    50.97.17.79
    Arista DCS
    7050S
    169.254.1.218
    169.254.1.122
    Portable Gateway
    10.160.52.65
    TORs
    Private Network
    TORs
    Public Network
    TORs
    VCF-SP
    Public FCR
    Public Edge
    On-Prem Edge
    Internet
    TORs
    VCP Uplink
    VCF
    Core
    1 GbE Equinix Interconnect
    MTU 9000
    BGP Peering for Route Advertisements
    Edge
    Firewalls


    View Slide

20. Core Network Services
    20
    Isolation vs. Integration
    Public Cloud Instance
    Directory Services
    Network Time Protocol
    Domain Name Services
    Private Cloud Instance
    Directory Services
    Network Time Protocol
    Domain Name Services


    View Slide

21. Core Network Services
    21
    Hybrid Cloud with VMware Cloud Foundation
    Private Cloud Instance x
    Corporate Directory Services
    Public Cloud Instance x
    Provider Directory Services
    Corporate Network Time Protocol Provider Network Time Protocol
    Read-Only Corporate Directory Services
    Corporate Domain Names Services
    demo.vmware.com
    Provider Domain Name Services
    bluemix.vmware.com
    Corporate Cloud Foundation Instance
    pao01.demo.vmware.com
    Provider Cloud Foundation Instance
    sjc01.bluemix.vmware.com


    View Slide

22. vSphere Content Library
    vSphere Content Library
    Content Delivery
    22
    Using the Content Library in the Hybrid Cloud
    Templates / Customization Specs Templates / Customization Specs
    Private Cloud Public Cloud
    os-win-2012-r2-x64
    os-lnx-rhel-7-x64
    os-lnx-centos-7-x64
    …
    os-win-2012-r2-x64
    os-lnx-rhel-7-x64
    os-lnx-centos-7-x64
    …
    Synchronization
    vRealize Automation Blueprints vRealize Automation Blueprints
    Export
    Consumed By
    Consumed By
    Import


    View Slide

23. Personalized IT Service Catalog for App Teams
    Self service catalog that delivers personalized application and cloud infrastructure services


    View Slide

24. Extending the Cloud Management Portal
    24
    Hybrid Cloud
    vRealize
    Automation
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    Private Cloud Instance x
    NSX
    Manager
    vCenter
    Server
    vRA
    Proxy
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    Public Cloud Instance x
    NSX
    Manager
    vCenter
    Server
    vRA
    Proxy


    View Slide

25. Extending the Cloud Management Portal
    25
    Configure vRealize Automation
    .1
    Add Endpoints
    § vCenter Server
    § NSX Manager
    § and association.
    Manage Compute Resources
    § Collect Inventory
    § View or Add Reservations
    Create Fabric Group
    § Add Fabric Administrators
    § Assign Compute Resources
    Configure Reservations
    § Allocate Resources to
    a Business Group in a Tenant
    Consume!
    § Build
    § Deploy
    § Manage
    1
    STEP
    2
    STEP
    3
    STEP
    4
    STEP
    5
    STEP


    View Slide

26. View Slide

27. View Slide

28. View Slide

29. View Slide

30. View Slide

31. View Slide

32. View Slide

33. View Slide

34. Demo
    Extending vRealize Automation Blueprints
    to VMware Cloud Foundation on IBM Cloud


    View Slide

35. Extending the Cloud Operations
    35
    Hybrid Cloud
    vRealize
    Operations
    Analytics Cluster
    Private Cloud
    vRealize
    Automation
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    Public Cloud Instance
    vRealize
    Operations
    Remote Collector
    vRealize
    Log Insight
    Cluster
    NSX
    Manager
    vCenter
    Server
    vRA
    Proxy
    vRealize
    Log Insight
    Cluster
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    ESXi
    Host
    Public Cloud Instance x
    vRealize
    Operations
    Remote Collectors
    NSX
    Manager
    vCenter
    Server
    vRA
    Proxy
    vRealize
    Log Insight
    Cluster


    View Slide

36. Expanding Resources
    36
    Hybrid Cloud with VMware Cloud Foundation
    Workload Domain
    vSphere vSAN
    NSX
    Provider Portal
    Add Server
    Add Host
    2
    SDDC Manager
    Add Resources
    Expand Workload Domain
    Setting Value
    CPU 52 Ghz
    Memory 0.5 TB
    Disk 8 TB Your account will be charged.
    Number of bare metal servers to add.
    Estimated Cost
    $4000/mo
    Uses the Cloud Foundation APIs


    View Slide

37. Demo
    Expanding SDDC Resources
    for VMware Cloud Foundation on IBM Cloud


    View Slide

38. Public Cloud with VMware Cloud Foundation
    Self-Managed or Managed Service
    Launched or Scheduled in Portal or by Provider
    Automated by APIs
    vSphere, NSX, vSAN and SDDC Manager
    Transparent to Workloads
    Automated Upgrade and Patch
    Hybrid Cloud with VMware Cloud Foundation
    Private Cloud with VMware Cloud Foundation
    Self-Managed
    Scheduled in SDDC Manager
    Automated by SDDC Manager
    vSphere, NSX, vSAN and SDDC Manager
    Transparent to Workloads


    View Slide

39. Demo
    Updating and Patching
    VMware Cloud Foundation on IBM Cloud


    View Slide

40. © 2017 VMware Inc. All rights reserved. | Slide 40
    VMware Cloud
    Foundation on
    Public Clouds
    Agility
    Compatability
    Common Management
    Consistent and Compatible Extension of Your Data Center


    View Slide
