1. Firmware Security Analysis 李倫銓 Alan, NiNi
2. About Linkit7697 LinkIt7697 是一塊針對物聯網應用的開發版，基於 MT7697 系統單晶片， 具有含浮點運算的 ARM Cortex-M4 微控制器， 並整合了 802.11b/g/n WiFi 無線網路與 Bluetooth 4.2 低功耗藍牙。
3. What is firmware ROM EPROM flash memory firmware firmware firmware Firmware is a piece of code stored in ROM, EPROM, flash memory. It may provide some functions to software to control hardware. Or, it may be the only program that will run on the embedded system.
4. Before starting…. 先把 firmware 燒上去
5. UART UART 1 UART 2 Tx Rx Tx Rx
6. UART UART 1 UART 2 Tx Rx 1 0 1 1 1 0 1
7. PC RAM BIOS Hard Disk MBR boot loader Boot loader
8. PC RAM BIOS Hard Disk MBR boot loader Boot loader BIOS 抓
9. PC RAM BIOS Hard Disk boot loader MBR Boot loader MBR BIOS 抓完
10. Boot loader PC RAM Hard Disk boot loader MBR MBR MBR 抓
11. Boot loader PC RAM Hard Disk boot loader MBR MBR Boot MBR 抓沒完
12. Boot loader PC RAM Hard Disk boot loader MBR MBR Boot MBR 再抓
13. Boot loader PC RAM Hard Disk boot loader MBR MBR Boot loader Boot loader完成載入
14. Boot loader DEMO
15. ARM ARM 架構有需多版本， 從最早的 ARMv1 到現在的 ARMv8 每個版本都有引入一些新的特色。
16. ARM ARM不賣晶片，而是靠授權架構賺錢， 實作則是由購買的公司進行(一般不能改架構)， CPU 名字跟架構版本沒有關係， 如 ARM7EJ 對應 ARMv5，ARM11 對應 ARMv6。
17. ARM 但 ARM11 之後改變了命名的方式，改為 Cortex-A Application profile Cortex-R Real-time profile Cortex-M Microcontroller profile
18. ARM ARM 有兩個模式 一個 ARM，一個 Thumb Thumb 是 ARM 的子集， ARM 一條指令需要 4Byte 的編碼 ， Thumb 則是 2 or 4 byte
19. ARM 00010400 <main>: 10400: b580 push {r7, lr} 10402: af00 add r7, sp, #0 10404: 4b03 ldr r3, [pc, #12] ; (10414 <main+0x14>) 10406: 0018 movs r0, r3 10408: f7ff ff68 bl 102dc <puts@plt> 1040c: 2300 movs r3, #0 1040e: 0018 movs r0, r3 10410: 46bd mov sp, r7 10412: bd80 pop {r7, pc} 000103fc <main>: 103fc: e92d4800 push {fp, lr} 10400: e28db004 add fp, sp, #4 10404: e59f000c ldr r0, [pc, #12] ; 10418 <main+0x1c> 10408: ebffffb3 bl 102dc <puts@plt> 1040c: e3a03000 mov r3, #0 10410: e1a00003 mov r0, r3 10414: e8bd8800 pop {fp, pc}
20. ARM 後來則增強為 Thumb2 ，code density 與 Thumb 接近 但有類似 ARM 的性能
21. ARM 快問快答
22. ARM http://infocenter.arm.com/help/topic/com.arm.doc.dui0553b/DUI0553.pdf http://infocenter.arm.com/help/topic/com.arm.doc.qrc0001m/QRC0001_UAL.pdf Cortex-M4 Manual ARM Thumb2 cheatsheet
23. ARM 暫存器 R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 2.1.3 Core registers
24. ARM 基本運算 opcode Rd, Rn opcode Rd, Rn, Op2
25. ARM MOV R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0x0000FA05 MOV R1, #0xFA05 3.5.6 MOV and MVN
26. ARM R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0x0000FA05 0x00000100 MOV R1, #0xFA05 MOV R5, #256 MOV 3.5.6 MOV and MVN
27. ARM R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0x0000FA05 0x0000BEEF 0x00000100 MOV R1, #0xFA05 MOV R5, #256 MOVW R3, #0xBEEF MOV 3.5.6 MOV and MVN
28. ARM R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0x0000FA05 0xDEADBEEF 0x00000100 MOV R1, #0xFA05 MOV R5, #256 MOVW R3, #0xBEEF MOVT R3, #0xDEAD MOV 3.5.6 MOV and MVN
29. ARM R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0x0000FA05 0xFFFFFFF0 0xDEADBEEF 0x00000100 MOV R1, #0xFA05 MOV R5, #256 MOVW R3, #0xBEEF MOVT R3, #0xDEAD MVN R2, #0xF MOV 3.5.6 MOV and MVN
30. ARM LDR/STR 只有 ldr 跟 str 可以存取記憶體 其他 opcode 的運算子都不能存取記憶體 3.4 Memory access instructions
31. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xFFFFFFF0 0xDEADBEEF 0x00000100 0x100 0x104 0xfaceb00c 0xdeadbeef LDR R1, [R5] 3.4 Memory access instructions
32. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xfaceb00c 0xFFFFFFF0 0xDEADBEEF 0x00000100 LDR R1, [R5] 0x100 0x104 0xfaceb00c 0xdeadbeef 3.4 Memory access instructions
33. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xfaceb00c 0xFFFFFFF0 0xDEADBEEF 0x00000100 LDR R1, [R5] STR R2, [R5,#4] 0x100 0x104 0xfaceb00c 0xdeadbeef 3.4 Memory access instructions
34. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xfaceb00c 0xFFFFFFF0 0xDEADBEEF 0x00000100 0x100 0x104 0xfaceb00c 0xFFFFFFF0 LDR R1, [R5] STR R2, [R5,#4] 3.4 Memory access instructions
35. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xfaceb00c 0xFFFFFFF0 0xDEADBEEF 0x00000100 0x100 0x104 0xfaceb00c 0xFFFFFFF0 LDR R1, [R5] STR R2, [R5,#4] LDR R2, [R5],#4 3.4 Memory access instructions
36. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xfaceb00c 0xfaceb00c 0xDEADBEEF 0x00000104 0x100 0x104 0x108 0xfaceb00c 0xFFFFFFF0 LDR R1, [R5] STR R2, [R5,#4] LDR R2, [R5],#4 3.4 Memory access instructions
37. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xfaceb00c 0xfaceb00c 0xDEADBEEF 0x00000104 0x100 0x104 0x108 0xfaceb00c 0xFFFFFFF0 LDR R1, [R5] STR R2, [R5,#4] LDR R2, [R5],#4 STR R2, [R5,#4]! 3.4 Memory access instructions
38. ARM LDR/STR R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 SP(R13) LR(R14) PC(R15) 0xfaceb00c 0xfaceb00c 0xDEADBEEF 0x00000108 0x100 0x104 0x108 0xfaceb00c 0xFFFFFFF0 0xfaceb00c LDR R1, [R5] STR R2, [R5,#4] LDR R2, [R5],#4 STR R2, [R5,#4]! 3.4 Memory access instructions
39. ARM 單位 10101010 10101010 10101010 10101010 10101010 10101010 10101010 1 BYTE 1 Half Word 1 Word LDR LDRH, LDRSH LDRB, LDRBH
40. ARM condition execution N -> negative Z -> zero C -> carry V -> overflow CMP R1, #3 LDREQ R1, [R5] 3.3.7 Condition execution
41. ARM condition execution N -> negative Z -> zero C -> carry V -> overflow if( r1 == 3 ) r1 = *r5 3.3.7 Condition execution
42. ARM condition execution CMP R1, #3 IT EQ LDREQ R1, [R5] N -> negative Z -> zero C -> carry V -> overflow 3.3.7 Condition execution
43. ARM condition execution N -> negative Z -> zero C -> carry V -> overflow if( r1 == 3 ) r1 = *r5 3.3.7 Condition execution
44. ARM condition execution CMP R1, #3 ITT EQ LDREQ R1, [R5] LDREQ R2, [R5] N -> negative Z -> zero C -> carry V -> overflow 3.3.7 Condition execution
45. ARM condition execution N -> negative Z -> zero C -> carry V -> overflow if( r1 == 3 ){ r1 = *r5 r2 = *r5 } 3.3.7 Condition execution
46. ARM condition execution CMP R1, #3 ITTE EQ LDREQ R1, [R5] LDREQ R2, [R5] ADDNE R1, #1 N -> negative Z -> zero C -> carry V -> overflow 3.3.7 Condition execution
47. ARM condition execution N -> negative Z -> zero C -> carry V -> overflow if( r1 == 3 ){ r1 = *r5 r2 = *r5 }else{ r1 += 1 } 3.3.7 Condition execution
48. ARM B{cond} lable 跳轉 BL{cond} lable 跳轉,把 return address 放進 LR BX{cond} Rm 跳轉 BXL{cond} Rm 跳轉,把 return address 放進 LR 3.10 Branch and control instructions
49. Find the main Literal Pool
50. Find the main
51. BONUS TIME
52. Secure Boot
53. Secure Boot 所以在 Bootloader 執行時 我們要確保即將掛載的 firmware 不是修改過的
54. Secure Boot Reset ROM Bootloader Bootloader input Signed? yes no Bootloader firmware input Signed? yes no Stop
 or Recover
55. Secure Boot Bootloader hash ##### encrypt flash memory key
56. Secure Boot Bootloader hash ##### encrypt flash memory key burn eFuse
57. Secure Boot Firmware digital signature hash ##### private key (on your PC) signature algorithm
58. Secure Boot Firmware digital signature hash ##### public key (in bootloader) signature algorithm Same?
59. Secure Boot But this is not the end……
60. Secure Boot Tegra X1
61. Secure Boot Tegra X1 USB Recovery Mode https://http.download.nvidia.com/tegra-public-appnotes/tegra-boot-flow.html#_error_handling_and_recovery_mode
62. Secure Boot Fusée Gelée:https://github.com/Qyriad/fusee-launcher ShofEL2:https://fail0verflow.com/blog/2018/shofel2/
