Let the application do the work, not the VCL

My talk at the 10th Varnish User Group Meeting in Rotterdam.

1. By Thijs Feryn Let the application do the work Not the VCL
2. Hi, I’m Thijs
3. I’m @ThijsFeryn on Twitter
4. I’m an Evangelist At
5. I’m an at Evangelist
6. I’m a at board member
7. Previously on Varnish
9. Varnish still considered a sysadmin responsibility
10. Developers Sysadmins
11. Architecture
12. When you respect HTTP
13. Collaboration & empathy AKA DevOps
14. Today
15. Twitter Bootstrap
17. Don’t cache header
18. Cache footer until 31/12/2015 23:59:59
19. Cache for a day
20. Cache for an hour
21. Expires: Thu, 31 Dec 2015 23:59:59 GMT Cache-Control: s-maxage=86400 Cache-Control: s-maxage=3600 Cache-Control: no-cache, no-store, s-maxage=0
22. <!DOCTYPE html> <html> <head> <title>The Demo</title> <meta name="viewport" content="width=device-width, initial-scale=1.0"> <meta http-equiv="Content-Type" content="text/html; charset=utf-8" /> <link rel="stylesheet" href="/css/bootstrap.min.css"> <link rel="stylesheet" href="/css/bootstrap-theme.min.css"> <script src="/js/jquery-2.1.4.min.js"></script> <script src="/js/bootstrap.min.js"></script> </head> <body> <nav class="navbar navbar-inverse navbar-fixed-top"> <div class="container"> <div class="navbar-header"> <button type="button" class="navbar-toggle collapsed" data-toggle="collapse" data-target="#navbar" aria-expanded="false" aria-controls="navbar"> <span class="sr-only">Toggle navigation</span> <span class="icon-bar"></span> <span class="icon-bar"></span> <span class="icon-bar"></span> </button> <a class="navbar-brand" href="#">Project name</a> </div> <div id="navbar" class="navbar-collapse collapse"> <form class="navbar-form navbar-right"> <div class="form-group"> <input type="text" placeholder="Email" class="form-control"> </div> <div class="form-group"> <input type="password" placeholder="Password" class="form-control"> </div> <button type="submit" class="btn btn-success">Sign in</button> </form> </div> </div> </nav> <div class="jumbotron"> <div class="container"> <h1>Hello, world!</h1> <p>This is a template for a simple marketing or informational website. It includes a large callout called a jumbotron and three supporting pieces of content. Use it as a starting point to create something more unique.</p> <p><a class="btn btn-primary btn-lg" href="#" role="button">Learn more &raquo;</a></p> </div> </div>
23. I’m a PHP guy
24. Silex micro- framework http://silex.sensiolabs.org
25. Twig templates http://twig.sensiolabs.org
26. <!DOCTYPE html> <html> <head> <title>The Demo</title> <meta name="viewport" content="width=device-width, initial-scale=1.0"> <meta http-equiv="Content-Type" content="text/html; charset=utf-8" /> <link rel="stylesheet" href="/css/bootstrap.min.css"> <link rel="stylesheet" href="/css/bootstrap-theme.min.css"> <script src=“/js/jquery-2.1.4.min.js"></script> <script src="/js/bootstrap.min.js"></script> </head> <body> <nav class="navbar navbar-inverse navbar-fixed-top"> {{ render_esi(url('nav')) }} </nav> <div class="jumbotron"> {{ render_esi(url('jumbotron')) }} </div> <div class="container"> {% block content %}{% endblock %} <hr> <footer> {{ render_esi(url('footer')) }} </footer> </div> </body> </html>
27. <!DOCTYPE html> <html> <head> <title>The Demo</title> <meta name="viewport" content="width=device-width, initial-scale=1.0"> <meta http-equiv="Content-Type" content="text/html; charset=utf-8" /> <link rel="stylesheet" href="/css/bootstrap.min.css"> <link rel="stylesheet" href="/css/bootstrap-theme.min.css"> <script src=“/js/jquery-2.1.4.min.js"></script> <script src="/js/bootstrap.min.js"></script> </head> <body> <nav class="navbar navbar-inverse navbar-fixed-top"> {{ render_esi(url('nav')) }} </nav> <div class="jumbotron"> {{ render_esi(url('jumbotron')) }} </div> <div class="container"> {% block content %}{% endblock %} <hr> <footer> {{ render_esi(url('footer')) }} </footer> </div> </body> </html> ESI tags
28. <!DOCTYPE html> <html> <head> <title>The Demo</title> <meta name="viewport" content="width=device-width, initial-scale=1.0"> <meta http-equiv="Content-Type" content="text/html; charset=utf-8" /> <link rel="stylesheet" href="/css/bootstrap.min.css"> <link rel="stylesheet" href="/css/bootstrap-theme.min.css"> <script src=“/js/jquery-2.1.4.min.js"></script> <script src="/js/bootstrap.min.js"></script> </head> <body> <nav class="navbar navbar-inverse navbar-fixed-top"> <esi:include src="http://localhost:8888/nav" /> </nav> <div class="jumbotron"> <esi:include src="http://localhost:8888/jumbotron" /> </div> <div class="container"> {% block content %}{% endblock %} <hr> <footer> <esi:include src="http://localhost:8888/footer" /> </footer> </div> </body> </html> ESI tags
29. <?php date_default_timezone_set('Europe/Brussels'); require_once __DIR__.'/../vendor/autoload.php'; use \Symfony\Component\HttpFoundation\Response; use \Silex\Provider; use \Silex\Application; $app = new Application(); $app->register(new TwigServiceProvider(), array( 'twig.path' => dirname(__DIR__).'/views', )); $app->register(new HttpFragmentServiceProvider()); $app->register(new UrlGeneratorServiceProvider()); $app->register(new SessionServiceProvider()); Init code
30. Base controller $app->get('/', function () use ($app) { $response = new Response($app['twig']->render('index.twig')); $response->setSharedMaxAge(3600); return $response; })->bind('home');
31. {% extends "layout.twig" %} {% block content %} <!-- Example row of columns --> <div class="row"> <div class="col-md-4"> <h2>Heading</h2> <p>Donec id elit non mi porta gravida at eget metus. Fusce dapibus, tellus ac cursus commodo, tortor mauris condimentum nibh, ut fermentum massa justo sit amet risus. Etiam porta sem malesuada magna mollis euismod. Donec sed odio dui. </p> <p><a class="btn btn-default" href="#" role="button">View details &raquo;</ a></p> </div> <div class="col-md-4"> <h2>Heading</h2> <p>Donec id elit non mi porta gravida at eget metus. Fusce dapibus, tellus ac cursus commodo, tortor mauris condimentum nibh, ut fermentum massa justo sit amet risus. Etiam porta sem malesuada magna mollis euismod. Donec sed odio dui. </p> <p><a class="btn btn-default" href="#" role="button">View details &raquo;</ a></p> </div> <div class="col-md-4"> <h2>Heading</h2> <p>Donec sed odio dui. Cras justo odio, dapibus ac facilisis in, egestas eget quam. Vestibulum id ligula porta felis euismod semper. Fusce dapibus, tellus ac cursus commodo, tortor mauris condimentum nibh, ut fermentum massa justo sit amet risus.</p> <p><a class="btn btn-default" href="#" role="button">View details &raquo;</ a></p> </div> </div> {% endblock %}
32. Navigation controller $app->get('/nav', function () use ($app) { //+ ADD MORE SESSION LOGIC $response = new Response($app['twig']->render('nav.twig')); $response->headers->addCacheControlDirective('no-cache',true); $response->headers->addCacheControlDirective('no-store',true); return $response; })->bind('nav');
33. <div class="container"> <div class="navbar-header"> <button type="button" class="navbar-toggle collapsed" data- toggle="collapse" data-target="#navbar" aria-expanded="false" aria- controls="navbar"> <span class="sr-only">Toggle navigation</span> <span class="icon-bar"></span> <span class="icon-bar"></span> <span class="icon-bar"></span> </button> <a class="navbar-brand" href="#">Project name</a> </div> <div id="navbar" class="navbar-collapse collapse"> <form class="navbar-form navbar-right"> <div class="form-group"> <input type="text" placeholder="Email" class="form- control"> </div> <div class="form-group"> <input type="password" placeholder="Password" class="form-control"> </div> <button type="submit" class="btn btn-success">Sign in</ button> </form> </div><!--/.navbar-collapse --> </div>
34. Jumbotron controller $app->get('/jumbotron', function () use ($app) { $response = new Response($app['twig']->render('jumbotron.twig')); $response->setSharedMaxAge(86400); return $response; })->bind('jumbotron');
35. <div class="container"> <h1>Hello, world!</h1> <p>This is a template for a simple marketing or informational website. It includes a large callout called a jumbotron and three supporting pieces of content. Use it as a starting point to create something more unique.</ p> <p><a class="btn btn-primary btn-lg" href="#" role="button">Learn more &raquo;</a></p> </div>
36. Footer controller $app->get('/footer', function () use ($app) { $response = new Response($app[‘twig']->render('footer.twig')); $response->setPublic(); $response->setExpires( DateTime::createFromFormat( "m-d H:i:s",'12-31 23:59:59', new DateTimeZone('Europe/London') ) ); return $response; })->bind('footer');
37. <p>&copy; {{ "now"|date("Y") }} Company, Inc.</p>
38. Full HTML returned, even without Varnish
39. How does it work?
40. vcl 4.0; backend default { .host = "127.0.0.1"; .port = "8888"; } sub vcl_recv { set req.http.Surrogate-Capability = “key=ESI/1.0"; return(hash); } sub vcl_backend_response { if (beresp.http.Surrogate-Control ~ "ESI/1.0") { unset beresp.http.Surrogate-Control; set beresp.do_esi = true; } } Simplified VCL
41. HttpFragmentServiceProvider
42. <?php date_default_timezone_set('Europe/Brussels'); require_once __DIR__.'/../vendor/autoload.php'; use \Symfony\Component\HttpFoundation\Response; use \Silex\Application; $app = new Application(); $app->register(new \Silex\Provider\TwigServiceProvider(), array( 'twig.path' => dirname(__DIR__).'/views', )); $app->register(new Silex\Provider\HttpFragmentServiceProvider()); $app->register(new Silex\Provider\UrlGeneratorServiceProvider()); $app->register(new Silex\Provider\SessionServiceProvider());
43. {{ render_esi(url('nav')) }} Controller name URL generator ESI rendering
44. curl -H "Surrogate-Capability: key=ESI/1.0" localhost:8888/ Sends Surrogate- Control response header back to Varnish ESI
45. Internal subrequest curl localhost:8888/
46. All ESI tags could be replaced with AJAX calls
48. More Javascript
49. More async
50. Graceful degradation
52. ESI without Varnish
53. CDN
54. HttpCacheServiceProvider
55. <?php date_default_timezone_set('Europe/Brussels'); require_once __DIR__.'/../vendor/autoload.php'; use \Symfony\Component\HttpFoundation\Response; use \Silex\Application; $app = new Application(); $app->register(new \Silex\Provider\TwigServiceProvider(), array( 'twig.path' => dirname(__DIR__).'/views', )); $app->register(new Silex\Provider \HttpCacheServiceProvider(), array( 'http_cache.cache_dir' => dirname(__DIR__).'/cache/', )); $app->register(new Silex\Provider\HttpFragmentServiceProvider()); $app->register(new Silex\Provider\UrlGeneratorServiceProvider()); $app->register(new Silex\Provider\SessionServiceProvider());
56. //$app->run(); $app['http_cache']->run();
