  1. GENERATION OF ELECTRICITY FROM POPULOUS AREAS USING PIEZOELECTRICITY Gen. Pio

    del Pilar National High School
  2. Contents › Introduction › Methodology › Results and Discussion › Summary and Conclusion › Recommendation

    › Bibliography
  3. What is piezoelectricity? › “Piezo” -press or squeeze › “Electricity”- natural force

    producing light, heat, chemical decomposition, etc PIEZOELECTRICITY electrical energy produced from mechanical pressure
  4. Background of the Study Developing countries such as the Philippines

    are going through high energy demands brought by its economic growth. As a result, the country is experiencing insufficiency in supplying these necessities. Thus, the country is in need to find future alternative energy sources.
  5. Textbook on Crystal Physics by Voigt (1910) became the basis

    when dealing with the complex electromechanical relationships in Piezoelectric crystal.
  6. Recent applications of Piezoelectricity › Piezoelectric Mats in Shibuya Station in

    Tokyo, Japan › Low-powered and small scale devices such as microphones
  7. None
  8. Piezoelectric Crystals in Gas Ignition Systems

  9. Pick-ups: Phonograph & Acoustic

  10. Purpose of the Study The study aims to provide an

    alternative source of energy to supply electricity to a neighborhood community.
  11. Statement of the Problem This study aims to: ›  Generate

    electricity using piezoelectric material such as ceramic transducers. ›  Investigate the efficiency of the small scale prototype of a piezoelectric mat consisting of PZT circular plates (diaphragm) layered on top of latex rubber mat as piezoelectric generator that will be used to provide electrical charge for the 3W LED light bulb. ›  Measure (1) the mechanical stress applied (2) the voltage, and energy.
  12. Significance of the Study This study is beneficial to the

    country not only in solving energy-related problems which will lead to resolving environmental and economic crisis.
  13. Cost Comparison of Electrical Billings Philippines U.S.A Bill Days 30

    34 Kwh Used 2507 3905 Average Kwh/day 83.5 144.9 Cost per day $16.51/ P671.44 $12.11/ P492.50 Cost per Kwh $0.20/ P8.13 $0.11/ P4.47 Total Cost of Kwh $495.37 / P20146.04 $411.58/ P16738.41
  14. Methodology › Research Design This study used the experimental method of

    research for a fact that mechanical stress (tapping) on the piezoelectric material was related to the electrical energy induced in the prototype. The greater the number of tapping, and the harder it is, the more energy is induced. It real-life situation, the more mechanical stress the people will exert on the proposed piezomat, the greater the energy can be harnessed.
  15. Research Paradigm

  16. Figure 1. The prototype A consisted of 24 pieces PZT

    transducers
  17. Figure 2. The life size prototype B consisted of 72

    transducers
  18. Procedures 1 • Inducing and storing voltage 2 • Measuring the voltage

    3 • Computing for the electrical energy
  19. Results and Discussions Figure 3. Voltage produced by tapping a

    0.08-g PZT, the time is in deka-second
  20. Figure 4. Voltage produced by tapping a 0.4-g PZT, the

    time is in deka-second
  21. Table 1. Possible Voltage that can be harnessed by two

    prototypes PROTOTYPE A PROTOTYPE B Transducer Maximum Voltage Transducer Maximum Voltage 19 pcs 0.4-g PZT 19 x 7.5 V = 142.5 V 20 pcs 0.4-g PZT 20 x 7.5 V = 150 V 5 pcs 0.08 PZT 5 x 0.9 V = 4.5 V 52 pcs 0.08 PZT 52 x 0.9 V = 46.8 V TOTAL 147 V TOTAL 196.8 V
  22. Electrical Energy U = 2*Fo *ΔLo *[(3M / m) +

    1] (Equation 1) Fo = kT *ΔLo (Equation 2) U : the energy Fo : the force applied on the transducer ΔLo :the maximum nominal displacement without external force M : the additional mass on the transducer M : the mass of the transducer
  23. Table 2. Theoretically computed amounts of electrical energy by each

    PZT transducer Quantity 0.4-g PZT Transducer 0.08-g PZT Transducer kT 0.5 N/m 0.5 N/m ΔLo 5x10-3 m 4x10-3 m Fo 2.5x10-3 N 2.0x10-3 N U 5.6 J 18 J
  24. Table 3. Possible electrical energy that can be harnessed by

    two prototypes PROTOTYPE A PROTOTYPE B Transducer Energy Transducer Energy 19 pcs 0.4-g PZT 19 x 5.6 J = 106.4 J 20 pcs 0.4-g PZT 52 pcs 0.08 PZT 5 pcs 0.08 PZT 5 x 18 J = 90 J 20 x 5.6 J = 112 J 52 x 18 J = 936 J TOTAL 196.4 J TOTAL 1048 J
  25. Recommendations › Use other piezoelectric materials other than PZT transducers › Improve

    the existing prototypes A and B initially proposed by the researchers › Identify other contributing factors in the production of voltage and electrical energy of these piezoelectric materials
  26. Rochelle Salt

  27. Stack Actuator

  28. Cantilever Beam

  29. Thank you

  30. BIBLIOGRAPHY ›  Caston, T. (2011). Piezoelectric energy harvesting floor mat

    November 10, 2012 http://www.eeweb.com/project/thomas_caston/piezoelectric-energy-harvesting- floor-mat ›  Chang, E. (January 16, 2009). Generate electricity by walking. December 2, 2012 ›  http://emilychang.com/2009/01/generate-electricity-by-walking/ ›  Chee Y., Otis B.P., Rabaey J.M., Roundy S., & Wright P. (nd) A 1.9 GHz RF Transmit Beacon using environmentally scavenged energy. ›  Chow, E. (2008). Pedestrian power will generate holiday lights at shibuya station, tokyo October 5, 2012 http://gizmodo.com/5105052/pedestrian-power-will- generate-holiday-lights-at-shibuya-station-tokyo ›  Cunningham, C. (2008). How to make piezo crystals at home October 7, 2012 http://blog.makezine.com/2008/07/31/how-to-make-piezo-crystal/ ›  Hult, J. (2011), ―People to watch: Kohei Hayamizu of Soundpower Corporation‖. Retrieved from http://www.examiner.com/article/people-to-watch-kohei-hayamizu- of-soundpower-corporation November 30, 2012. ›  Katz A. (2004) Residential Piezoelectric Energy Sources November 30, 2012 ›  Mail Foreign Service (2008).The power of commuter... japan uses energy- generating floor to help power subway October 13, 2012 http:// www.dailymail.co.uk/news/article-1094248/the-power--commuter-Japan-uses- energy-generating-floor-help-power-subway-html
  31. ›  Nu-Way Systems and Design Recycle Inc. (2010). LED lights

    vs. incandescent light bulbs vs. CFLs. December 2, 2012 http:// www.designrecycleinc.com/led%20comp%20chart.html 24 ›  Oscillate (2012) November 30, 2012 http://en.wikipedia.org/wiki/ Oscillate ›  Polarity Symbol (2012) November 30, 2012 http://en.wikipedia.org/wiki/ Polarity_symbols ›  Resonance (2012) November 30, 2012 http://en.wikipedia.org/wiki/ Resonance ›  Roundy S., & Wright P.K., (2004) A piezoelectric vibration based generator for wireless electronics. Smart Materials and Structures, 13, 1131-1142. ›  Skjoidan L. (nd). Foot powering tokyo train station October 5, 2012 http://www.celcias.com/article/foot-powering-tokyo-station ›  The Morgan Crucible Company (2009). Piezoelectric materials November 10, 2012 http://www.morganelectroceramics.com/ ›  Zorina, Y. (2000). Mass of a car. December 2, 2012 ›  http://hypertextbook.com/facts/2000/YanaZorina.shtml
