Command-Oriented Architecture

Talk I gave at Maceió DEV Meetup #6. Not only about Command Bus/Command Interface or whatever you name it, but a compilation of cool articles I found that may help with understanding this architecture.

Resources and links:

- Command Bus by Shawn Mccool http://shawnmc.cool/command-bus
- Dev Discussions - The Command Bus https://www.youtube.com/watch?v=fbSYZFZCFS0
- Screaming Archirecture by Uncle Bob http://blog.8thlight.com/uncle-bob/2011/09/30/Screaming-Architecture.html
- The Clean Archirecture by Uncle Bob http://blog.8thlight.com/uncle-bob/2012/08/13/the-clean-architecture.html
- Laravel: From Apprentice to Artisan https://leanpub.com/laravel
- Commands and Domain Events (Laracasts) https://laracasts.com/series/commands-and-domain-events
- Task-based UIs https://cqrs.wordpress.com/documents/task-based-ui/
- CRUD is an antipattern by Mathias Verraes http://verraes.net/2013/04/crud-is-an-anti-pattern/

Transcript

1. Command-Oriented Architecture Maceió DEV Meetup #6
2. who am I? ➔ Tony Messias ~ @tony0x01 ➔ Building web stuff since ~2010
4. before we start... ➔ CRUD thinking ➔ MVC ➔ Commands/Events ➔ Clean Architecture
5. “CRUD is an antipattern” (Mathias Verraes)
6. “CRUD doesn't express behaviour. Avoid setters, and use expressive, encapsulated operations instead.”
7. <?php $order = new Order(); $order->setStatus('paid'); $order->setPaidAmount(120); $order->setPaidCurrency('EUR'); $order->setCustomer($customer);
8. <?php $order = new Order(); $money = new Money(120, new Currency('EUR')); $order->pay($customer, $money);
9. class CommentsController extends Controller { public function store($postId) { $post = Post::find($postId); $comment = new Comment([ 'message' => 'A new comment.', 'user_id' => Auth::user()->id ]); $post->comments()->save($comment); return redirect() ->route('posts.view, $post) ->withMessage('Your comment was successfully created'); } }
10. class CommentsController extends Controller { public function store($postId) { $post = Post::find($postId); $comment = new Comment([ 'message' => 'A new comment.', 'user_id' => Auth::user()->id ]); $post->comments()->save($comment); return redirect() ->route('posts.view, $post) ->withMessage('Your comment was successfully created'); } }
11. class CommentsController extends Controller { public function store($postId) { $post = Post::find($postId); $comment = new Comment(['message' => 'A new comment.']); $user = Auth::user(); $post->comment($user, $comment); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
12. class CommentsController extends Controller { public function store($postId) { $post = Post::find($postId); $comment = new Comment(['message' => 'A new comment.']); $user = Auth::user(); $post->comment($user, $comment); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
13. class Post extends Model { // ... public function comment(User $user, Comment $comment) { $comment->user_id = $user->id; $this->comments()->save($comment); } // ... }
14. class SendSMS { public function fire($job, $data) { $twilio = new Twilio_SMS($apiKey); $twilio->sendTextMessage(array( 'to' => $data['user']['phone_number'], 'message' => $data['message'], )); $user = User::find($data['user']['id']); $user->messages()->create([ 'to' => $data['user']['phone_number'], 'message' => $data['message'], ]); $job->delete(); } }
15. class SendSMS { public function fire($job, $data) { $twilio = new Twilio_SMS($apiKey); $twilio->sendTextMessage(array( 'to' => $data['user']['phone_number'], 'message' => $data['message'], )); $user = User::find($data['user']['id']); $user->messages()->create([ 'to' => $data['user']['phone_number'], 'message' => $data['message'], ]); $job->delete(); } }
16. class SendSMS { public function fire($job, $data) { $twilio = new Twilio_SMS($apiKey); $twilio->sendTextMessage(array( 'to' => $data['user']['phone_number'], 'message' => $data['message'], )); $user = User::find($data['user']['id']); $user->messages()->create([ 'to' => $data['user']['phone_number'], 'message' => $data['message'], ]); $job->delete(); } }
17. class SendSMS { function __construct(UserRepository $users, SmsCourierInterface $courier) { $this->users = $users; $this->courier = $courier; } public function fire($job, $data) { $user = $this->users->find($data['user']['id']); $user->sendSmsMessage($this->courier, $data['message']); $job->delete(); } }
18. use Illuminate\Database\Eloquent\Model; class User extends Model { public function sendSmsMessage(SmsCourierInterface $courier, $message) { $courier->sendMessage($this->phone_number, $message); return $this->messages()->create([ 'to' => $this->phone_number, 'message' => $message, ]); } }
19. class SmsTest extends PHPUnit_Framework_TestCase { public function test_user_can_send_sms_message() { $user = Mockery::mock('User[messages]'); $relation = Mockery::mock('StdClass'); $courier = Mockery::mock('SmsCourierInterface'); $user->shouldReceive('messages')->once()->andReturn($relation); $relation->shouldReceive('create')->once()->with(array( 'to' => '555-555-5555', 'message' => 'Test', )); $courier->shouldReceive('sendMessage')->once()->with( '555-555-5555', 'Test' ); $user->phone_number = '555-555-5555'; $user->sendSmsMessage($courier, 'Test'); } }
20. class SmsTest extends PHPUnit_Framework_TestCase { public function test_user_can_send_sms_message() { $user = Mockery::mock('User[messages]'); $relation = Mockery::mock('StdClass'); $courier = Mockery::mock('SmsCourierInterface'); $user->shouldReceive('messages')->once()->andReturn($relation); $relation->shouldReceive('create')->once()->with(array( 'to' => '555-555-5555', 'message' => 'Test', )); $courier->shouldReceive('sendMessage')->once()->with( '555-555-5555', 'Test' ); $user->phone_number = '555-555-5555'; $user->sendSmsMessage($courier, 'Test'); } }
21. class SmsTest extends PHPUnit_Framework_TestCase { public function test_user_can_send_sms_message() { $user = Mockery::mock('User[messages]'); $relation = Mockery::mock('StdClass'); $courier = Mockery::mock('SmsCourierInterface'); $user->shouldReceive('messages')->once()->andReturn($relation); $relation->shouldReceive('create')->once()->with(array( 'to' => '555-555-5555', 'message' => 'Test', )); $courier->shouldReceive('sendMessage')->once()->with( '555-555-5555', 'Test' ); $user->phone_number = '555-555-5555'; $user->sendSmsMessage($courier, 'Test'); } }
22. class SmsTest extends PHPUnit_Framework_TestCase { public function test_user_can_send_sms_message() { $user = Mockery::mock('User[messages]'); $relation = Mockery::mock('StdClass'); $courier = Mockery::mock('SmsCourierInterface'); $user->shouldReceive('messages')->once()->andReturn($relation); $relation->shouldReceive('create')->once()->with(array( 'to' => '555-555-5555', 'message' => 'Test', )); $courier->shouldReceive('sendMessage')->once()->with( '555-555-5555', 'Test' ); $user->phone_number = '555-555-5555'; $user->sendSmsMessage($courier, 'Test'); } }
23. be careful with MVC
24. your framework is not your architecture
25. $ tree rails/app rails/app ├── assets ├── controllers ├── helpers ├── mailers ├── models └── views
26. “this is a rails app”
27. Screaming Architecture
28. ok, but what does it have to do with Commands?
30. they are basically DTOs, with cool names
31. class CommentsController extends Controller { public function store($postId) { $user = Auth::user(); $post = Post::find($postId); $comment = new Comment(['message' => 'A new comment.']); $post->comment($user, $comment); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
32. class CommentsController extends Controller { public function store($postId) { $user = Auth::user(); $post = Post::find($postId); $comment = new Comment(['message' => 'A new comment.']); $post->comment($user, $comment); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
33. class CommentsController extends Controller { public function store($postId) { $user = Auth::user(); $post = Post::find($postId); $comment = new Comment(['message' => 'A new comment.']); $post->comment($user, $comment); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
34. class CommentsController extends Controller { public function store($postId) { $user = Auth::user(); $message = Input::get('message'); $command = new LeaveCommentCommand($user, $postId, $message); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
35. class LeaveCommentCommand { public $user; public $postId; public $message; public function __construct(User $user, $postId, $message) { $this->user = $user; $this->postId = $postId; $this->message = $message; } }
36. how do I execute them?
37. class CommentsController extends Controller { public function store($postId) { $user = Auth::user(); $message = Input::get('message'); $command = new LeaveCommentCommand($user, $postId, $message); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
38. use Illuminate\Foundation\Bus\DispatchesCommands; class CommentsController extends Controller { use DispatchesCommands; public function store($postId) { $user = Auth::user(); $message = Input::get('message'); $command = new LeaveCommentCommand($user, $postId, $message); $this->dispatch($command); return redirect() ->route('posts.index', $post) ->withMessage('Your comment was successfully created'); } }
39. what does dispatch do?
40. finds a handler for our command
41. one Command can be executed by one and only one Handler
42. LeaveCommentCommand LeaveCommentCommandHandler
43. class LeaveCommentCommandHandler { public function handle(LeaveCommentCommand $command) { $post = Post::find($command->postId); $comment = new Comment(['message' => $command->message]); $post->comment($command->user, $comment); } }
44. what if I want to notify the post creator about that new comment?
45. class LeaveCommentCommandHandler { private $mailer; function __construct(UserMailer $mailer) { $this->mailer = $mailer; } public function handle(LeaveCommentCommand $command) { $post = Post::find($command->postId); $comment = new Comment(['message' => $command->message]); $post->comment($command->user, $comment); $this->notifyPostCreator($post->creator, $post, $comment); } // ... }
46. class LeaveCommentCommandHandler { // ... private function notifyPostCreator( User $creator, Post $post, Comment $comment) { $this->mailer->sendTo( $creator->email, sprintf("New comment on [%s]", $post->title), sprintf("User @%s left a comment for you: \n%s", $comment->user->username, $comment->message) ); } }
47. works, but we can do better...
48. use Illuminate\Contracts\Events\Dispatcher; class LeaveCommentCommandHandler { private $events; function __construct(Dispatcher $events) { $this->events = $events; } public function handle(LeaveCommentCommand $command) { $post = Post::find($command->postId); $comment = new Comment(['message' => $command->message]); $post->comment($command->user, $comment); $this->dispatchEvents($post->releaseEvents()); } // ... }
49. use Illuminate\Contracts\Events\Dispatcher; class LeaveCommentCommandHandler { // ... private function dispatchEvents(array $events) { foreach ($events as $event) $this->events->fire($event); } }
50. class Post extends Model { use EventGenerator; public function comment(User $user, Comment $comment) { $comment->user_id = $user->id; $this->comments()->save($comment); $this->raise(new CommentWasLeft($post, $comment, $user)); } }
51. trait EventGenerator { protected $domainEvents = []; public function raise($event) { $this->domainEvents[] = $event; } public function releaseEvents() { $events = $this->domainEvents; $this->domainEvents = []; return $events; } }
52. events are also just DTOs
53. class CommentWasLeft { public $post; public $user; public $comment; public function __construct(Post $post, User $user, Comment $comment) { $this->post = $post; $this->user = $user; $this->comment = $comment; } }
54. but they can (and most of the time they do) have lots of listeners/handlers
55. class NotifyPostOwnerAboutNewCommentHandler { private $mailer; function __construct(UserMailer $mailer) { $this->mailer = $mailer; } public function handle(CommentWasLeft $event) { $this->mailer->sendTo( $event->post->creator->email, sprintf("New comment on [%s]", $event->post->title), sprintf("User @%s left a comment for you: \n%s", $event->user->username, $event->comment->message) ); } }
56. class EventServiceProvider extends ServiceProvider { /** * The event handler mappings for the application. * @param array */ protected $listen = [ CommentWasLeft::class => [ NotifyPostOwnerAboutNewCommentHandler::class ] ]; }
57. Recap: ➔ Boundaries interacts through commands; ➔ Command is executed by its handler; ➔ Command handlers fires/triggers domain events; ➔ Events are listened by event handlers/listeners.
58. $ tree app app ├── Commands ├── Console ├── Events ├── Exceptions ├── Handlers ├── Http ├── Providers ├── Services └── User.php
59. $ tree app/Commands app/Commands ├── Command.php └── LeaveCommentCommand.php $ tree app/Handlers app/Handlers ├── Commands │ └── LeaveCommentCommandHandler.php └── Events └── NotifyPostOwnerAboutNewCommentHandler.php
60. avoid CRUD thinking
61. $ tree app/Commands app/Commands ├── CreateUserCommand.php └── DeleteUserCommand.php └── UpdateUserCommand.php
64. class DeactivateInventoryItemCommand { public $userId; public $itemId; public $comment; public function __construct($userId, $itemId, $comment) { $this->userId = $userId; $this->itemId = $itemId; $this->comment = $comment; } }
65. you can easily use queues to speed up your requests.
66. use Illuminate\Contracts\Queue\ShouldBeQueued; class DeactivateInventoryItemCommand implements ShouldBeQueued { public $userId; public $itemId; public $comment; public function __construct($userId, $itemId, $comment) { $this->userId = $userId; $this->itemId = $itemId; $this->comment = $comment; } }
67. use Illuminate\Contracts\Queue\ShouldBeQueued; class NotifyPostOwnerAboutNewCommentHandler implements ShouldBeQueued { private $mailer; function __construct(UserMailer $mailer) { $this->mailer = $mailer; } public function handle(CommentWasLeft $event) { $this->mailer->sendTo( $event->post->creator->email, sprintf("New comment on [%s]", $event->post->title), sprintf("User @%s left a comment for you: \n%s", $event->user->username, $event->comment->message) ); } }
68. questions?
69. Resources ➔ Command Bus by Shawn Mccool ➔ Dev Discussions - The Command Bus ➔ Screaming Archirecture by Uncle Bob ➔ The Clean Archirecture by Uncle Bob ➔ Laravel: From Apprentice to Artisan
70. Resources ➔ Commands and Domain Events (Laracasts) ➔ Task-based UIs ➔ CRUD is an antipattern by Mathias Verraes
