Keeping Secrets with JavaScript - An Introduction to the WebCrypto API

With the web slowly maturing as a platform the demand for cryptography in the browser has risen, especially in a post-Snowden era. Many of us have heard about the upcoming Web Cryptography API but at the time of writing there seem to be no good introductions available. We will take a look at the proposed W3C spec and its current state of implementation.

Transcript

1. Tim Taubert
   @ttaubert
   Keeping secrets with JavaScript
   An Introduction to the WebCrypto API
   September 2014, Berlin
   February 2015, Brussels


   View Slide

2. WHY A CRYPTO API?


   View Slide

3. NOW WITH 100%
   MORE CRYPTO
   YET ANOTHER NOTES APP


   View Slide

4. //
   var NotesStorage = {
   load: function () {
   return localforage.getItem("notes");
   },
   save: function (notes) {
   return localforage.setItem("notes", notes);
   }
   };


   View Slide

5. NotesStorage.save([
   {title: "Return $200 to Alice"},
   {title: "Buy soy milk", due: "2014-09-15"}
   ]);


   View Slide

6. INTEGRITY


   View Slide

7. > sha256sum ubuntu-14.10-desktop-amd64.iso
   22ee4a41c010a027c7d298e3c985e9e5 \
   68c2a743ee0b0f97f0806285f44babb1


   View Slide

8. SHA-256
   CRYPTOGRAPHIC HASH FUNCTION


   View Slide

9. SHA-256
   "Lorem ipsum
   dolor sit amet" 0x8a995db78d0…
   (data)
   (digest)


   View Slide

10. // Compute a 256-bit digest.
    crypto.subtle.digest("SHA-256", data)
    .then(function (digest) {
    console.log(digest);
    });
    // Output: ArrayBuffer {byteLength: 32}
    W3C API EXAMPLE
    https://dvcs.w3.org/hg/webcrypto-api/raw-file/tip/spec/Overview.html


    View Slide

11. window.crypto.subtle
    “It is named SubtleCrypto to reflect the fact that many of these
    algorithms have subtle usage requirements in order to provide
    the required algorithmic security guarantees.”


    View Slide

12. save: function (buffer) {
    // Compute the SHA-256 digest.
    return crypto.subtle.digest("SHA-256", buffer)
    .then(function (digest) {
    return Promise.all([
    localforage.setItem("notes", buffer),
    localforage.setItem("notes_hash", digest)
    ]);
    });
    }


    View Slide

13. load: function () {
    var values = Promise.all([
    localforage.getItem("notes"),
    localforage.getItem("notes_hash")
    ]);
    return values.then(function ([notes, notes_hash]) {
    // Compute the SHA-256 digest for |notes|.
    return crypto.subtle.digest("SHA-256", notes)
    .then(function (digest) {
    if (compare(notes_hash, digest)) {
    return notes;
    }
    });
    });
    }


    View Slide

14. INTEGRITY &
    AUTHENTICITY


    View Slide

15. HMAC-SHA-256
    HASH-BASED MESSAGE AUTHENTICATION CODE


    View Slide

16. HMAC
    "Lorem ipsum
    dolor sit amet" 0x8a995db78d0…
    (data)
    (mac)
    0x1234567890a…
    (key)


    View Slide

17. // Compute a 256-bit HMAC.
    crypto.subtle.sign("HMAC", key, data)
    .then(function (mac) {
    console.log(mac);
    });
    // Output: ArrayBuffer
    // Verify an HMAC.
    crypto.subtle.verify("HMAC", key, mac, data)
    .then(function (valid) {
    console.log(valid);
    });
    // Output: bool
    W3C API EXAMPLE
    https://dvcs.w3.org/hg/webcrypto-api/raw-file/tip/spec/Overview.html


    View Slide

18. save: function (key, buffer) {
    // Generate a MAC using the given key.
    return crypto.subtle.sign("HMAC", key, buffer)
    .then(function (mac) {
    return Promise.all([
    localforage.setItem("notes", buffer),
    localforage.setItem("notes_mac", mac)
    ]);
    });
    }


    View Slide

19. load: function (key) {
    var values = Promise.all([
    localforage.getItem("notes"),
    localforage.getItem("notes_mac")
    ]);
    return values.then(function ([notes, notes_mac]) {
    // Verify the MAC using the given key.
    return crypto.subtle.verify("HMAC", key, notes_mac, notes)
    .then(function (valid) {
    if (valid) {
    return notes;
    }
    });
    });
    }


    View Slide

20. PASSWORDS ARE NOT
    CRYPTOGRAPHIC KEYS


    View Slide

21. KEY DERIVATION


    View Slide

22. // Derive a new key from a given key.
    crypto.subtle.deriveKey(algorithm,
    baseKey,
    derivedKeyType,
    extractable,
    keyUsages)
    .then(function (key) {
    console.log(key);
    });
    // Output: CryptoKey object
    W3C API EXAMPLE
    https://dvcs.w3.org/hg/webcrypto-api/raw-file/tip/spec/Overview.html


    View Slide

23. PBKDF2
    PASSWORD-BASED KEY DERIVATION


    View Slide

24. PBKDF2
    "rbW-fk8;#9" 0x8a995db78d0…
    (password) (key)
    0x572bf6e4ef8a…
    (salt)
    5000
    (iterations)


    View Slide

25. function deriveKey(pwKey, salt) {
    var params = {
    name: "PBKDF2",
    hash: "SHA-256",
    salt: salt,
    // The more iterations the slower, but also more secure.
    iterations: 5000
    };
    // The derived key will be used to compute HMACs.
    var alg = {name: "HMAC", hash: "SHA-256"};
    var usages = ["sign", "verify"];
    return crypto.subtle.deriveKey(
    params, pwKey, alg, false, usages);
    }


    View Slide

26. function retrievePWKey() {
    // We will derive a new key from it.
    var usages = ["deriveKey"];
    // Show a native password input dialog.
    return crypto.subtle.generateKey(
    "PBKDF2", false, usages);
    }


    View Slide

27. View Slide

28. function getSalt() {
    // Try to read a stored salt.
    return localforage.getItem("salt")
    .then(function (salt) {
    if (salt) {
    return salt;
    }
    // We should generate at least 8 bytes
    // to allow for 2^64 possible variations.
    var salt = crypto.getRandomValues(new Uint8Array(8));
    return localforage.setItem("salt", salt);
    });
    }


    View Slide

29. var params = Promise.all([
    // Get base key and salt.
    retrievePWKey(), getSalt()
    ]);
    var derivedKey = params.then(function ([pwKey, salt]) {
    // Do the PBKDF2 dance.
    return deriveKey(pwKey, salt);
    });
    derivedKey.then(function (key) {
    // Store notes using the generated key.
    NotesStorage.save(key, buffer);
    });


    View Slide

30. INTEGRITY,
    AUTHENTICITY &
    SECRECY


    View Slide

31. // Encrypt |data| under |key| using |alg|.
    crypto.subtle.encrypt(alg, key, data)
    .then(function (ct) {
    console.log(ct);
    });
    // Output: ArrayBuffer
    // Decrypt |data| using |key| and algorithm |alg|.
    crypto.subtle.decrypt(alg, key, data)
    .then(function (pt) {
    console.log(pt);
    });
    // Output: ArrayBuffer
    W3C API EXAMPLE
    https://dvcs.w3.org/hg/webcrypto-api/raw-file/tip/spec/Overview.html


    View Slide

32. AES-GCM
    ADVANCED ENCRYPTION STANDARD
    IN GALOIS/COUNTER MODE


    View Slide

33. AES-GCM
    "Lorem ipsum
    dolor sit amet" 0xb5c73a8820a…
    (data)
    (ciphertext + mac)
    0x1234567890a…
    (key)
    0xd877fa3e919…
    (nonce)


    View Slide

34. function deriveKey(pwKey, salt) {
    var params = {
    // …
    };
    // The derived key will be used for AES.
    var alg = {name: "AES-GCM", length: 256};
    var usages = ["encrypt", "decrypt"];
    return crypto.subtle.deriveKey(
    params, pwKey, alg, false, usages);
    }


    View Slide

35. save: function (key, buffer) {
    // Set up parameters.
    var nonce = crypto.getRandomValues(new Uint8Array(16));
    var alg = {name: "AES-GCM", iv: nonce};
    // Encrypt |buffer| under |key| using AES-GCM.
    return crypto.subtle.encrypt(alg, key, buffer)
    .then(function (notes_enc) {
    return Promise.all([
    localforage.setItem("notes", notes_enc),
    localforage.setItem("nonce", nonce)
    ]);
    });
    }


    View Slide

36. load: function (key) {
    var values = Promise.all([
    localforage.getItem("notes"),
    localforage.getItem("nonce")
    ]);
    return values.then(function ([enc_notes, nonce]) {
    var alg = {name: "AES-GCM", iv: nonce};
    return crypto.subtle.decrypt(alg, key, enc_notes)
    .then(null, function (err) {
    // Verification failed.
    });
    });
    }


    View Slide

37. \o/
    https://github.com/ttaubert/secret-notes


    View Slide

38. RECAP


    View Slide

39. COMPARE()
    SHA-256
    RENDER
    (digest)
    DISCARD
    LOAD NOTES LOAD HASH
    EQUAL?
    (yes)
    (no)
    STORAGE SAFE AGAINST CORRUPTIONS


    View Slide

40. HMAC-VERIFY
    RENDER
    DISCARD
    LOAD KEY LOAD MAC
    VALID?
    (yes)
    (no)
    STORAGE SAFE AGAINST TAMPERING
    LOAD NOTES


    View Slide

41. HMAC-VERIFY
    RENDER
    DISCARD
    LOAD SALT LOAD MAC
    VALID?
    (yes)
    (no)
    STORAGE SAFE AGAINST TAMPERING
    PROTECTED BY A USER-GIVEN PASSWORD
    LOAD NOTES
    PBKDF2
    (derived key)
    PW PROMPT


    View Slide

42. AES-GCM
    RENDER
    DISCARD
    LOAD SALT LOAD NONCE
    VALID?
    (yes)
    (no)
    STORAGE SAFELY ENCRYPTED BY
    A USER-GIVEN PASSWORD
    LOAD NOTES
    PBKDF2
    (derived key)
    PW PROMPT


    View Slide

43. @dreid
    20 years of abstinence-only cryptography education
    hasn't gotten us anything but an endless supply of
    bad crypto in production systems.


    View Slide

44. Stanford - Cryptography I + II
    by Dan Boneh
    https://www.coursera.org/course/crypto
    Introduction to Cryptography
    by Christof Paar
    https://www.youtube.com/channel/UC1usFRN4LCMcfIV7UjHNuQg/videos
    LEARNING RESOURCES


    View Slide

45. THANKS
    @ttaubert
    tim@timtaubert.de
    https://timtaubert.de/talks/keeping-secrets-with-javascript/


    View Slide
