  1. App to App Designing Local APIs on Android Ty Smith

    Android Engineer at Twitter 1 @tsmith
  2. 2 @tsmith

  3. 3 @tsmith

  4. 4 @tsmith

  5. Integration Requirements • Get Note(s) • List Notes • Create/Update

    Notes • Delete Notes • Account Sync • Get Preferences 5 @tsmith
  6. Android Components Needed 1. Intents 2. Content Provider 3. Account

    Manager 4. Sync Adapter 5. Inter Process Communication 6. Permissions 6 @tsmith
  7. Intents Overview • Simple message between two components • Bundle

    - key/value data • Limited payload size (1MB) • Inefficient for batch operations • Defined Action 7 @tsmith
  8. Intents Standard Actions • ACTION_SEND • ACTION_SEND_MULTIPLE • ACTION_VIEW •

    ACTION_EDIT 8 @tsmith
  9. Editing Intent Sender public void editImage(String mimeType, Uri imageUri) {

    Intent intent = new Intent(Intent.ACTION_EDIT); intent.setType(mimeType); intent.setData(imageUri); startActivityForResult(intent, RESULT_CODE); } 9 @tsmith
  10. Editing Intent Receiver <activity android:name=".ui.IntentActivity" > <intent-filter> <action android:name="android.intent.action.ACTION_EDIT" />

    <category android:name="android.intent.category.DEFAULT" /> <data android:mimeType="image/*" /> </intent-filter> </activity> 10 @tsmith
  11. Editing Intent Receiver @Override protected void onNewIntent(Intent intent) { switch(intent.getAction())

    { case Intent.ACTION_EDIT: if (intent.getType().startsWith("image/")) { editImage(intent.getData()); setResult(RESULT_OK, intent); finish(); } } } 11 @tsmith
  12. Editing Intent Sender @Override protected void onActivityResult(int requestCode, int resultCode,

    Intent data) { if (requestCode = RESULT_CODE && RESULT_OK == resultCode) { Uri imageUri = data.getData(); //Update UI with new image } } 12 @tsmith
  13. Intents Edit Caveats • Use copy of file • Don’t

    rely on setResult() • Use a ContentObserver • Check for file modified 13 @tsmith
  14. Intents Custom Actions com.example.action.note.* list - view - new -

    create edit - update - delete 14 @tsmith
  15. Intents Custom Actions public void newNoteWithContent(Uri image) { Intent intent

    = new Intent(); intent.setAction(NEW_NOTE); intent.putExtra(Intent.EXTRA_TITLE, "LET ME EXPLAIN YOU INTENTS"); intent.putExtra(Intent.EXTRA_TEXT, "¯\_()_/¯"); intent.setData(image); startActivityForResult(intent); } 15 @tsmith
  16. Content Provider A well defined database access layer • SQLite

    • Interact with large volumes of data • Authority 16 @tsmith
  17. Content Provider URI content:// com.example / users / 1 Scheme

    Authority Data Id 17 @tsmith
  18. Content Provider Query public Cursor query(Uri uri, String[] projection, String

    selection, String[] selectionArgs, String sortOrder) { SQLiteQueryBuilder queryBuilder = new SQLiteQueryBuilder(); switch (URIMatcher.match(uri)) { USERS_LIST: queryBuilder.setTables(MyDBHandler.TABLE_USERS); } Cursor cursor = queryBuilder.query(myDB.getReadableDatabase(), projection, selection, selectionArgs, null, null, sortOrder); cursor.setNotificationUri(getContext().getContentResolver(), uri); return cursor; } 18 @tsmith
  19. Content Resolver Query Uri uri = Uri.parse("content://com.example/users"); String[] projection =

    new String[]{"username", “email”}; String selection = “name LIKE ?”; String[] args = new String[]{"Ty"}; String sort = “email ASC”; getContentResolver().query(uri, projection, selection, args, sort); 19 @tsmith
  20. Content Provider Serving Files @Override public ParcelFileDescriptor openFile(Uri uri, String

    mode) throws FileNotFoundException { File path = new File(getContext().getCacheDir(), uri.getEncodedPath()); int imode = 0; if (mode.contains("w")) { imode |= ParcelFileDescriptor.MODE_WRITE_ONLY; if (!path.exists()) { try { path.createNewFile(); //TODO: Handle IOException } } if (mode.contains("r")) imode |= ParcelFileDescriptor.MODE_READ_ONLY; if (mode.contains("+")) imode |= ParcelFileDescriptor.MODE_APPEND; return ParcelFileDescriptor.open(path, imode); } 20 @tsmith
  21. Content Resolver Getting Files ContentResolver resolver = getContentResolver(); URI imageUri

    = Uri.parse("content://com.example/images/1"); String mode = "rw+" ParcelFileDescriptor pfd = resolver.openFileDescriptor(imageUri, mode); FileDescriptor fileDescriptor = pfd.getFileDescriptor(); InputStream fileStream = new FileInputStream(fileDescriptor); //Magic here! 21 @tsmith
  22. Account Manager • Accessible Account • Authentication Token • Consistency

    22 @tsmith
  23. Providing your own Accounts • AbstractAccountAuthenticator • AccountAuthenticatorActivity 23 @tsmith

  24. 24 @tsmith

  25. AbstractAccountAuthenticat or addAccount @Override public Bundle addAccount(AccountAuthenticatorResponse response, String accountType,

    String authTokenType, String[] requiredFeatures, Bundle options) throws NetworkErrorException { final Intent intent = new Intent(mContext, AuthenticatorActivity.class); intent.putExtra(AuthenticatorActivity.ARG_ACCOUNT_TYPE, accountType); intent.putExtra(AuthenticatorActivity.ARG_AUTH_TYPE, authTokenType); intent.putExtra(AuthenticatorActivity.ARG_IS_ADDING_NEW_ACCOUNT, true); intent.putExtra(AccountManager.KEY_ACCOUNT_AUTHENTICATOR_RESPONSE, response); final Bundle bundle = new Bundle(); bundle.putParcelable(AccountManager.KEY_INTENT, intent); return bundle; } 25 @tsmith
  26. AbstractAccountAuthenticat or getAuthToken @Override public Bundle getAuthToken(AccountAuthenticatorResponse response, Account account,

    String authTokenType, Bundle options) throws NetworkErrorException { final AccountManager am = AccountManager.get(mContext); String authToken = am.peekAuthToken(account, authTokenType); if (TextUtils.isEmpty(authToken)) { final String password = am.getPassword(account); if (password != null) { authToken = serverAuthenticate.userSignIn(account.name, password, authTokenType); } } ... 26 @tsmith
  27. AbstractAccountAuthenticat or getAuthToken ... if (!TextUtils.isEmpty(authToken)) { final Bundle result

    = new Bundle(); result.putString(AccountManager.KEY_ACCOUNT_NAME, account.name); result.putString(AccountManager.KEY_ACCOUNT_TYPE, account.type); result.putString(AccountManager.KEY_AUTHTOKEN, authToken); return result; } ... 27 @tsmith
  28. AbstractAccountAuthenticat or getAuthToken ... final Intent intent = new Intent(mContext,

    AuthenticatorActivity.class); intent.putExtra(AccountManager.KEY_ACCOUNT_AUTHENTICATOR_RESPONSE, response); intent.putExtra(AuthenticatorActivity.ARG_ACCOUNT_TYPE, account.type); intent.putExtra(AuthenticatorActivity.ARG_AUTH_TYPE, authTokenType); final Bundle bundle = new Bundle(); bundle.putParcelable(AccountManager.KEY_INTENT, intent); return bundle; } 28 @tsmith
  29. AccountAuthenticatorActivit y Success private void finishLogin(String accountName, String accountType, String

    password, String authToken, String authTokenType) { Account account = new Account(accountName, accountType); if (getIntent().getBooleanExtra(ARG_IS_ADDING_NEW_ACCOUNT, false)) { accountManager.addAccountExplicitly(account, password, null); } accountManager.setPassword(account, password); accountManager.setAuthToken(account, authTokenType, authToken); Intent intent = new Intent(); intent.putExtra(AccountManager.KEY_ACCOUNT_NAME, userName); intent.putExtra(AccountManager.KEY_ACCOUNT_TYPE, ACCOUNT_TYPE); intent.putExtra(AccountManager.KEY_AUTHTOKEN, authToken); setAccountAuthenticatorResult(intent.getExtras()); setResult(RESULT_OK, intent); finish(); } 29 @tsmith
  30. Sync Adapter • Sync App and Web Service • User

    visible syncing • Network/battery optimized • Provided to third party apps • Schedule and GCM 30 @tsmith
  31. Sync Adapter public class ImagesSyncAdapter extends AbstractThreadedSyncAdapter { private final

    AccountManager accountManager; public TvShowsSyncAdapter(Context context, boolean autoInitialize) { super(context, autoInitialize); accountManager = AccountManager.get(context); } @Override public void onPerformSync(Account account, Bundle extras, String authority, ContentProviderClient provider, SyncResult syncResult) { String authToken = accountManager.blockingGetAuthToken(account, AccountGeneral.AUTHTOKEN_TYPE_FULL_ACCESS, true); List<Images> images = getImagesFromServer(authToken); updateImagesOnDisk(provider, images); } } 31 @tsmith
  32. Sync Adapter public class ImagesSyncService extends Service { private static

    final Object syncAdapterLock = new Object(); private static ImagesSyncAdapter syncAdapter = null; @Override public void onCreate() { synchronized (syncAdapterLock) { if (syncAdapter == null) syncAdapter = new ImagesSyncAdapter(getApplicationContext(), true); } } @Override public IBinder onBind(Intent intent) { return syncAdapter.getSyncAdapterBinder(); } } 32 @tsmith
  33. Sync Adapter res/xml/sync_adapter.xml <sync-adapter xmlns:android="http://schemas.android.com/apk/res/android" android:contentAuthority="com.example.images.provider" android:accountType="com.example.sync_example" android:userVisible="true" android:allowParallelSyncs="false" android:isAlwaysSyncable="false"

    android:supportsUploading="true"/> 33 @tsmith
  34. Sync Adapter AndroidManifest.xml <service android:name=".syncadapter.ImagesSyncService" android:exported="true"> <intent-filter> <action android:name="android.content.SyncAdapter" />

    </intent-filter> <meta-data android:name="android.content.SyncAdapter" android:resource="@xml/sync_adapter" /> </service> 34 @tsmith
  35. Sync Adapter Sync Every Hour int interval = 3600; ContentResolver.addPeriodicSync(account,

    AppContract.AUTHORITY, new Bundle(), interval); 35 @tsmith
  36. Sync Adapter Jitter int jitteredInterval = 3600 + new Random().nextInt(300);

    ContentResolver.addPeriodicSync(account, AppContract.AUTHORITY, new Bundle(), jitteredInterval); 36 @tsmith
  37. Binding Services for IPC • Android Interface Definition Language (AIDL)

    • Communicate between process or app • Directly call defined RPC methods • Requires consumer to contain interface 37 @tsmith
  38. Binding Services Create AIDL interface RemoteMessageService { void passMessage(String "message");

    } 38 @tsmith
  39. Binding Services Implement AIDL public class MessageBinder implements RemoteMessageService.Stub() {

    public void passMessage(String message) { Log.d(TAG, message); } } 39 @tsmith
  40. Binding Services Expose Interface public class RemoteService extends Service {

    @Override public IBinder onBind(Intent intent) { return new MessageBinder; } } 40 @tsmith
  41. Binding Services Connecting private ServiceConnection connection = new ServiceConnection() {

    public void onServiceConnected(ComponentName className, IBinder service) { service = IRemoteService.Stub.asInterface(service); } public void onServiceDisconnected(ComponentName className) { service = null; } } public void onResume() { bindService(new Intent(this, RemoteMessageService.class), connection, Context.BIND_AUTO_CREATE); } public void onPause() { unbindService(connection); service = null; } 41 @tsmith
  42. Permissions • Inform the User • Mitigate Exploits 42 @tsmith

  43. Permissions Levels • Normal • Dangerous • Signature • SignatureOrSystem

    43 @tsmith
  44. Permissions Custom <permission android:name="com.example.perm.READ" android:label="@string/permission_label" android:description="@string/permission_description" android.protectionLevel="dangerous" android:permissionGroup="com.example.permission-group.MYAPP_DATA" /> •

    Can be used to restrict access to various services and components • Required to interact with app that declares it • Can be checked programatically or via Manifest. 44 @tsmith
  45. Permissions Enforcing Programitcally int canProcess = getContext().checkCallingPermission("com.example.perm.READ"); if (canProcess !=

    PERMISSION_GRANTED) { throw new SecurityException("Requires Custom Permission"); } • checkCallingOrSelfPermission() can leak permissions 45 @tsmith
  46. Permissions Enforcing via XML <permission android:name="com.example.perm.READ" android:permissionGroup="com.example.permission-group.MYAPP_DATA" android:protectionLevel="dangerous" /> <permission

    android:name="myapp.permission.WRITE" android:permissionGroup="com.example.permission-group.MYAPP_DATA" android:protectionLevel="dangerous" /> <provider android:name=".data.DataProvider" android:exported="true" android:authorities="com.example.data.DataProvider" android:readPermission="com.example.perm.READ" android:writePermission="com.example.perm.WRITE" /> 46 @tsmith
  47. Debugging Tips • Debugging app integrations is hard • Logging

    is your friend • Test with mock integrations • Communicate your data contracts • Seek User Feedback • Analytics and Crash Reporting 47 @tsmith
  48. Integration Requirements • Get Note(s) (Intent & Content Provider) •

    List Notes (Intent) • Create/Update Notes (Intent & Content Provider) • Delete Notes (Intent & Content Provider) • Account Sync (Account Manager & Sync Adapter) • Get Preferences (Content Provider and bound Services) 48 @tsmith
  49. Resources Example App Dashclock for Evernote Android Developer Docs on

    AIDL Write your own Android Authenticator 49 @tsmith
  50. Thanks! Ty Smith @tsmith 50 @tsmith
