one, two step

Transcript

1. one, two step. Henri Watson
2. $ whoami • Second year student at Abertay
 (HackSoc Secretary + Securi-Tay 2017 Organiser) • Intern at SkyScanner (Summer 2017) • I dig • Security UX • Embedded devices • Payments technologies • Public transportation
3. Most web apps implement some form of authentication system
4. Login forms come in all sorts of shapes and sizes
8. Not all login forms are equally secure
13. HTTPS only secures the transport layer
14. HTTPS does not protect data at rest
15. https://haveibeenpwned.com/
16. http://www.wired.co.uk/article/mark-zuckerberg-hacked-password-released
17. Static information can be stolen and reused
18. Static information is terrible for authentication
19. Two-Factor Authentication attempts to solve this problem
20. Something you know + Something you have
21. Keep the password, but add a physical layer
22. some people missed that “static information” slide
25. A different code is requested each time, so replay attacks don’t work
26. A different code is requested each time, so replay attacks don’t work (unless we can capture 20~30 login attempts)
27. One code does not reveal the remaining codes on the card
28. MITM is hard, phishing is so much easier
29. “We need to reactivate your card!”
31. Static data in a physical format is still static data
32. How can we quickly provide a user with a one time use code?
33. Users have phones, text them one-time use codes!
35. https://www.wired.com/2016/06/hey-stop-using-texts-two-factor-authentication/
36. SS7 attacks also allow your phone number to be hijacked without your carrier’s cooperation
37. SMS verification also causes problems when roaming/outwith service areas
38. Could we provide an initialisation vector at sign up?
39. Give the user a code generator!
40. http://www.tokenguard.com/images/tokens/SID700.gif http://www.intech.ro/site/images/otptoken/otp-token-c100.jpg
41. Both the website and the device have a shared secret key
42. The code is calculated by computing the HMAC of the current time using the shared secret key
43. As long as the key is not intercepted during the initial setup, the key can’t be externally determined
44. Fobs can be expensive and inconvenient
47. Many of these are based on the Time-based One-Time Password algorithm
48. Agree on five parameters: a secret key the current time an interval a hash function a token length
49. Our key is 012345ABCDEF, it is 04/06/2017 @ 11:39:58am (UTC), we’ll use a 30sec interval, sha1, and 6 digit tokens
50. 04/06/2017 @ 11:39:58am (UTC) is 1491478798 seconds since the UNIX epoch
51. 1,491,478,798 divided by our interval (30) results in 49,715,959
52. Compute HMAC-SHA1 (49715959, 012345ABCDEF) = e91433413775c646b2255cfa8bde51247796973e
53. Take the four least significant bits and use this as an offset in the original hash (e -> 1110 -> 14) (e91433413775c646b2255cfa8bde51247796973e)
54. Take four bytes starting from the offset and discard the most significant bit. (11000110 01000110 10110010 00100101)
55. The token is then the lowest 6 digits (pad from the left if needed) (2358076490)
56. If the code generated on both sides matches, all is good!
57. but what if the code generator is visible?
58. http://thedailywtf.com/images/remy/robotguys.png
59. This can be avoided by requiring user interaction.
60. HOTP uses a counter instead of a timestamp but can have sync issues
61. Some apps ask the user to approve logins on their phone.
62. https://9to5google.files.wordpress.com/2016/06/google-prompt-two-factor.png?w=1024&h=0
63. Early Yubikeys used an internal counter to generate codes in a similar fashion. https://static1.squarespace.com/static/54764dcde4b0ad59b84ad859/t/ 54eccc9ce4b0328389b9b398/1424805028325/YubiKey-Standard-1030x687.png? format=1500w
64. These are all still vulnerable to phishing
65. As the code generator works independently, it cannot verify the website’s identity
66. Challenge-Response protocols fix this issue
67. The Chip Authentication Program is used by several UK banks to verify transfers to new recipients https://www.barclays.co.uk/cs/Satellite? blobcol=urldata&blobkey=id&blobtable=MungoBlobs&blobwhere=1367516798251&ssbin ary=true
69. The Chip Authentication Program piggybacks the Chip and PIN process to generate an eight digit code
70. (Barclays UK Debit Card issued in 2015. Inspected using Cardpeek.) EMV-wide payment card application selector Visa Debit application, used for most transactions. Link application, used by UK-only ATMs. CAP application, used by online banking login.
71. After verifying the user’s PIN, the authenticator asks the card to sign a fake purchase
72. The cryptogram from this fake transaction is encoded as a token which can be verified by your bank
73. Phishing attacks are useless as the user has to independently confirm the amount and account number
74. What if we’d like to verify the domain name?
75. Some organisations (notably US DoD) have deployed PKCS#11 smartcards https://images-na.ssl-images-amazon.com/images/I/61rdJCNG5nL._SX355_.jpg
76. PKCS#11 smartcards have a limited number of identities and are generally unsuitable for use outwith their issuing organisation
77. U2F tries to be a modern version of PKCS#11 client authentication certificates
79. https://twitter.com/meixger/status/654587740365955072
81. The web browser acts as as middleman between the token and the web service
82. A unique private key is generated on the device for each account on each web service
83. As this key is based on the domain name, phishing attacks are impossible
84. https://developers.yubico.com/U2F/Protocol_details/Overview.html
85. The key generation process is fully handled by the token in hardware and can’t be extracted
86. First the user registers their key with a service
87. U2F Token Browser Server u2f.register(); Generate challenge Wait for press Generate reply Store token identity Validate challenge AJAX/form submit
88. The service now has a public key specific to this user on this service
89. When authenticating the user, we ask for another signature but pass the stored identity
90. U2F Token Browser Server u2f.sign(); Generate challenge Wait for press Generate reply Look up token identity Validate challenge AJAX/form submit
91. If an adversary is able to present a valid certificate for a domain, they could proxy your U2F signature
92. Browser MITM Server u2f.sign(); Generate challenge Look up token identity Validate challenge AJAX/form submit Proxy
93. TLS channel ID is a proposed spec to add self-signed client certs to the TLS handshake
94. U2F identities can additionally be pinned to a TLS channel ID
95. Browser MITM Server u2f.sign(); Generate challenge Look up token identity Validate challenge AJAX/form submit Proxy Create keypair Create keypair X keypair public key
96. Although hardware U2F tokens are difficult to use on smartphones, software tokens could be used
97. U2F has little support outside of Google Chrome (Firefox bug #1065729)
98. Thanks! @henriwatson
