Butter bei die Fische. Ein Jahr Entwicklung und Produktion mit Docker

Butter bei die Fische. Ein Jahr Entwicklung und Produktion mit Docker

Vor etwa einem Jahr wurde bei der JUGH die damals sehr junge Technologie Docker vorgestellt, Basics und Start gezeigt. In der Zwischenzeit haben Johannes Unterstein und Patrick Busch ein Jahr intensiv mit Docker gearbeitet und auch Anwendungen damit in Produktion geschoben.

In diesen Slides teilen sie ihre Erkenntnisse: wie sie Docker einsetzen und welche positiven und negativen Erfahrungen sie dabei bereits gemacht haben.

Dabei gehen sie auf sinnvolle Anordnung von Docker-Befehlen ein, auf sinnvolle Docker-Registries, auf Staging und Verlinkung von Containern über Hardwaregrenzen hinweg, auf Continuous Deployment und all das andere lustige Zeug, was sie so mit Docker machen.

7c6d957f56a234a73c0a321bbdd5ebee?s=128

Johannes Unterstein

June 25, 2015
Tweet

More Decks by Johannes Unterstein

Other Decks in Technology

Transcript

  1. BUTTER BEI DIE FISCHE Ein Jahr Entwicklung und Produktion mit

    Docker Johannes Unterstein und Patrick Busch
  2. AGENDA How can we make a single tenant system suitable

    for multitenancy and scalable without changing the whole system?
  3. AGENDA • Introduction • Dockerizing the Application • Dockerizing the

    Infrastructure • Best Practices • Lessons Learned
  4. INTRODUCTION • One existing application • Have it available for

    several different legal entities • No way to implement multitenancy the existing application
  5. INTRODUCTION SOAP SQL STORED PROCEDURES NO CACHING flens/web flens/burg flens/db

  6. INTRODUCTION SOAP SQL STORED PROCEDURES NO CACHING SOAP SQL STORED

    PROCEDURES NO CACHING SOAP SQL STORED PROCEDURES NO CACHING etc. PROXY A B C
  7. DOCKERIZING THE APPLICATION

  8. VARIANT 1

  9. VARIANT 1 • Pros • Easy to understand/build/run/host • Cons

    • Separation • Scalability • Updates
  10. VARIANT 2

  11. VARIANT 2 • Pros • Scalability • Separation • Updates

    • Cons • Advanced connection between containers needed
  12. VARIANT 2 • Connection between containers • Not via docker

    linkage • Via /etc/host entry and environment variable • Interpreting startup shell script in container
  13. VARIANT 2 docker run -dP --env flensburgHost=someHost --env flensburgPort=1234 flens/web:1.23

  14. DOCKERIZING THE INFRASTRUCTURE

  15. VARIANT A

  16. VARIANT A FRONTEND MW/MANAGER REGISTRY EXECUTOR

  17. VARIANT A FRONTEND MW/MANAGER REGISTRY EXECUTOR builds the image stores

    the image runs the container
  18. VARIANT A • Classic approach • Running applications on the

    metal • Physical servers, each needs to be configured for the application • One server that runs the application containers
  19. VARIANT B

  20. VARIANT B • More flexibility • Every physical server is

    basically the same • Installation done via script in a few minutes each • Containers can then be run on any server • Images contain all the needed configuration
  21. VARIANT C

  22. VARIANT C *n

  23. VARIANT C • Multiple servers for the application containers •

    Better load distribution • Improved security
  24. VARIANT D PROXY *n PROXY PROXY ? FIREWALL FIREWALL FIREWALL

  25. VARIANT D • Configure containers to point to proxies •

    Proxies manage certificates • Proxies pass through containers • Allows multiple containers per system to run in parallel while they can be addressed on their own
  26. FULL SCALE *n BUILD IMAGES PROXY PROXY FIREWALL FIREWALL FIREWALL

  27. FULL SCALE *n BUILD IMAGES STORE IMAGES PUSH PROXY PROXY

    FIREWALL FIREWALL FIREWALL
  28. RUN CONTAINERS FULL SCALE *n BUILD IMAGES STORE IMAGES PUSH

    PULL *n *n *n PROXY PROXY FIREWALL FIREWALL FIREWALL
  29. ADDED BENEFITS • Self Service • Flexibility • Scalability •

    Security • A/B-Switching
  30. STAGING *n PUSH PULL *n PUSH PULL PRODUCTION STAGE

  31. STAGING *n PUSH PULL *n PUSH PULL PRODUCTION STAGE SHARED

    REGISTRY FOR INFRASTRUCTURE IMAGES
  32. STAGING • Easily duplicated environment • Use docker registry for

    infrastructure images • Release versioned images • Script checks that versions cannot be overwritten • Stage first approach
  33. BEST PRACTICES

  34. COMMON BASE IMAGES • Common stuff in common base image

    • As much as possible in base image • Define versions of tools explicitly • Lowers registry size
  35. GROUP COMMANDS • Try to combine commands with „&&“ •

    Less intermediate containers • Increases build performance • Lowers registry size
  36. GROUP COMMANDS RUN chmod u+x /home/app/start.sh RUN chown app:app /home/app/start.sh

  37. GROUP COMMANDS RUN chmod u+x /home/app/start.sh && \ chown app:app

    /home/app/start.sh
  38. ORDER COMMANDS • Stable commands as early as possible •

    ADD commands as late as possible • Caching increases build performance • Lowers registry size
  39. USE SCRIPTS docker run -d \ --read-only \ -p 127.0.0.1:30022:22

    \ -p 127.0.0.1:38080:8080 \ -v /docker/data/nginx:/var/lib/nginx \ -v /docker/logs/nginx:/var/log/nginx \ -v /docker/tmp:/tmp \ -v /docker/run:/var/run \ --name flens_web \ repository_host_name:8888/flens/web:1.0
  40. USE SCRIPTS flens web run 1.0

  41. USE SCRIPTS • Running containers can be complicated on the

    console • Scripts can improve readability and memorability • Improved speed and less failures • Reusability
  42. BUILD CONTINUOUS • Use scripts in continuous integration server as

    well • We use „Execute shell command“ jobs • e.g.: flens web build && flens web rerun
  43. USE PROXIES • Proxy on the physical machines (e.g. nginx)

    • Containers listen only to localhost device • Nginx handles incoming requests and passes on • Nginx handles security • More than one container of a given type • By symlinking nginx config files you can switch from one slot to another
  44. USE VOLUMES • Volumes are directories mounted from the physical

    host • Files in a volume are visible from inside the container (and writeable) • Useful for logging, syncing data, etc…
  45. READ-ONLY CONTAINERS • A read only container cannot write to

    its own file system • Can only write to volumes • Perfectly immutable containers are easily interchangable! • Build and distribute containers even more freely • No unexpected states, defined income -> defined outcome
  46. MAKE YOUR CONTAINERS FLEXIBLE • Use /etc/hosts defined hostnames instead

    of IP addresses • Use environment variables at startup (--env)
  47. LESSONS LEARNED

  48. QUIRKS OF DOCKERFILES • COPY vs ADD • ADD can

    be a URL, ADD extracts tar.gz files automatically • ENTRYPOINT vs CMD • CMD can be overwritten at startup, ENTRYPOINT cannot • Both are possible in a single Dockerfile • ENTRYPOINT/CMD syntax • determines if the executable is started directly or in a shell
  49. QUIRKS OF DOCKERFILES • COPY vs ADD • ADD can

    be a URL, ADD extracts tar.gz files automatically • ENTRYPOINT vs CMD • CMD can be overwritten at startup, ENTRYPOINT cannot • Both are possible in a single Dockerfile - this combines them! • ENTRYPOINT/CMD syntax • determines if the executable is started directly or in a shell
  50. CMD AND ENTRYPOINT CMD ping localhost => /bin/sh -c ‘ping

    localhost’ CMD[“ping”,”localhost”] => ping localhost ENTRYPOINT[“ping”] CMD [“localhost”] => ping localhost $ docker run container_name www.flens.de => ping www.flens.de
  51. TRUST YOUR OWN SKILLS • Young technology, many tutorials, everybody

    else knows it better • Linking is fine, but not for us • Configuring /etc/hosts at startup works wonders • Try to use your own solution
  52. DON’T USE LINKAGE • Not possible over real machine boundaries

    • Often leads to problems during startup • Use /etc/hosts and environment parameters
  53. DOCKER IN DOCKER • Our infrastructure builds docker images dynamically

    • Our infrastructure is dockerized • Do we need „docker in docker?“
  54. DOCKER IN DOCKER •Docker in docker is possible • docker

    run -- privileged flens/mw:1.23 •Container runs inside flens/mw •Problems during update of outer app
  55. DOCKER IN DOCKER •We used client/server docker communication •Client =

    flens/mw •Server = Docker of host system •Similar to boot2docker •All container runs on host system
  56. IT’S CHEAPER • We can use off the shelf servers

    • We can use virtualized servers • We can distribute easily over different server providers • Easily scalable
  57. IT’S BETTER • Release on touch of a button •

    Deployment on touch of a button • Transparent versioning of all apps • Transparency of OS environment running the apps • Environment is now part of dev process and versionable
  58. THANKS Cheers
