Practical APIs

Let's face it: with emerging publish channels like Google AMP or Facebook Instant Articles, it's not enough to just deliver a HTML representation of your content anymore. In this workshop you'll see why you need an API, what the benefits are, and at what you should aim when designing an API. We will extend the eZ Platforms REST API, look at its advantages and disadvantages and discuss other options.

Transcript

1. PRACTICAL
   API


   View Slide

2. WELCOME


   View Slide

3. API4EZ


   View Slide

4. URBAN ETTER
   @URBMC ON TWITTER
   @URBAN ON EZ
   COMMUNITY SLACK


   View Slide

5. View Slide

6. 4 PARTS


   View Slide

7. WHAT
   IS AN API


   View Slide

8. WHY
   DO I NEED AN
   API


   View Slide

9. HOW
   DO I CREATE AN
   API


   View Slide

10. EZ RICH TEXT


    View Slide

11. EXERCISES


    View Slide

12. EXERCISES
    > README.md
    > What to do
    > Bonus
    > Hints
    > Code


    View Slide

13. ABOUT
    INDIAN PALE ALE


    View Slide

14. INDIAN PALE ALE
    > High hop content
    > Tends to have more volume percent
    > Said to be brewed for long ship journeys to India


    View Slide

15. IPA


    View Slide

16. IPA-API


    View Slide

17. ABOUT
    BREW DOG


    View Slide

18. PUNK IPA


    View Slide

19. DEAD PONY CLUB (3.8%)


    View Slide

20. SIGGIBRÄU


    View Slide

21. WHAT
    IS AN API


    View Slide

22. TWITTER API
    GET https://api.twitter.com/1.1/statuses/show.json?
    id=21046285714025267


    View Slide

23. EZ PLATFORM REST API
    {
    "Content": {
    "_media-type": "application/vnd.ez.api.ContentInfo+json",
    "_href": "/api/ezp/v2/content/objects/86",
    "_remoteId": "73be2a5122ecd6a4a7ad1cef6b0393f1",
    "_id": 86,
    "ContentType": {
    "_media-type": "application/vnd.ez.api.ContentType+json",
    "_href": "/api/ezp/v2/content/types/18"
    },
    "Name": "Build a better performing site with continuous optimization",
    "Versions": {
    "_media-type": "application/vnd.ez.api.VersionList+json",
    "_href": "/api/ezp/v2/content/objects/86/versions"
    },
    "CurrentVersion": {
    "_media-type": "application/vnd.ez.api.Version+json",
    "_href": "/api/ezp/v2/content/objects/86/currentversion"
    }
    }
    }


    View Slide

24. PHP API
    $contentInfo = $contentService->loadContentInfo($contentId);
    echo $contentInfo->mainLocationId;


    View Slide

25. PHP API
    $myKitten = new Cat('Kitty');
    $myKitten->lookCute();


    View Slide

26. SQL
    SELECT id, name, review
    FROM ipa
    WHERE id = 57;


    View Slide

27. BASH API
    ln -s my/source my/target


    View Slide

28. APPLICATION
    PROGRAMMING
    INTERFACE


    View Slide

29. INTERFACE
    TO A PROGRAMM


    View Slide

30. PROGRAMMABLE


    View Slide

31. BUILDING BLOCKS
    A good API makes it easier to develop a program by
    providing all the building blocks, which are then put
    together by the programmer.
    — Wikipedia


    View Slide

32. SEPARATES
    INTERFACE AND
    IMPLEMENTATION


    View Slide

33. SPECIFICATION
    VS
    IMPLEMENTATION


    View Slide

34. WHAT
    VS
    HOW


    View Slide

35. AN API ONLY
    SPECIFIES
    WHAT


    View Slide

36. PHP REPRESENTATIONS
    > interface: specification
    > trait: implementation
    > class: specification + implementation


    View Slide

37. WHO WROTE A
    CLASS?


    View Slide

38. WE'RE DONE,
    RIGHT?


    View Slide

39. INTRODUCING
    DEMO CONTENT


    View Slide

40. View Slide

41. View Slide

42. CALL TO ACTION
    EXERCISE 1


    View Slide

43. WHY
    DO YOU NEED
    AN API


    View Slide

44. IF YOU'RE BUILDING A
    SLACK BOT


    View Slide

45. WHY YOU NEED AN API AS
    A
    PUBLISHER


    View Slide

46. View Slide

47. View Slide

48. View Slide

49. View Slide

50. View Slide

51. View Slide

52. DIFFERENT
    REPRESENTATIONS
    OF YOUR
    CONTENT


    View Slide

53. PROGRAMMABLE
    ACCESS TO
    YOUR CONTENT


    View Slide

54. CONTENT
    DELIVERY


    View Slide

55. REMEMBERING BUILDING BLOCKS
    A good API makes it easier to develop a program by
    providing all the building blocks, which are then put
    together by the programmer.
    — Wikipedia


    View Slide

56. BUZZWORD
    ALARM!


    View Slide

57. API
    FIRST


    View Slide

58. API
    AS A
    PRODUCT


    View Slide

59. HEADLESS
    CMS


    View Slide

60. BASICALLY
    THE SAME


    View Slide

61. PROGRAMMABLE
    ACCESS TO
    YOUR CONTENT


    View Slide

62. EZ REST API
    TO DELIVER CONTENT


    View Slide

63. WE'RE DONE,
    RIGHT?


    View Slide

64. REMEMBER
    > API specifies What not How
    > Programmable content delivery


    View Slide

65. My content is an
    ARTICLE
    not an
    EZ CONTENT OBJECT


    View Slide

66. LAYERED APIS


    View Slide

67. MOBILE APP USECASE
    > Request count matters
    > Verbosity of response matters


    View Slide

68. HIGH LEVEL API/ DOMAIN API
    [
    {
    "name": "Punk IPA",
    "review": 5,
    "brewery": "Brew Dog",
    "image": "http://www.ipaapi.io/images/punk-ipa.jpg",
    },
    {
    "name": "Dead Pony Club",
    "review": 4.5,
    "brewery": "Brew Dog",
    "image": "http://www.ipaapi.io/images/dead-pony-club.jpg"
    }
    ]


    View Slide

69. HIGH LEVEL API
    > Specified for a certain use case
    > No need to know internals
    > Not flexible
    > Needed info with one request
    > Only one format needs to be supported


    View Slide

70. LOW LEVEL API
    {
    "Content": {
    "_media-type": "application/vnd.ez.api.ContentInfo+json",
    "_href": "/api/ezp/v2/content/objects/86",
    "_remoteId": "73be2a5122ecd6a4a7ad1cef6b0393f1",
    "_id": 86,
    "ContentType": {
    "_media-type": "application/vnd.ez.api.ContentType+json",
    "_href": "/api/ezp/v2/content/types/18"
    },
    "Name": "Build a better performing site with continuous optimization",
    "Versions": {
    "_media-type": "application/vnd.ez.api.VersionList+json",
    "_href": "/api/ezp/v2/content/objects/86/versions"
    },
    "CurrentVersion": {
    "_media-type": "application/vnd.ez.api.Version+json",
    "_href": "/api/ezp/v2/content/objects/86/currentversion"
    }
    }
    }


    View Slide

71. LOW LEVEL API
    > One API for loads of use cases
    > Knowledge of some internals may be required
    > Very flexible
    > Different formats (XML or JSON)


    View Slide

72. LOW LEVEL API
    ✅


    View Slide

73. LET'S BUILD A
    DOMAIN API


    View Slide

74. HOW
    TO BUILD AN
    API


    View Slide

75. MY CONTENT IS
    AN ARTICLE
    AN IPA


    View Slide

76. PHP ENTITY (VALUE OBJECT)
    class IPA
    {
    public $id;
    public $name;
    public $review;
    }


    View Slide

77. ENTITY
    > Value objects
    > Service which "loads" value objects
    > Public attributes
    > eZ Publish Public API has the same architecture


    View Slide

78. CREATE PHP ENTITIES AS A SERVICE
    class IpaService
    {
    public function loadIpa($contentId)
    {
    $content = $contentService->loadContent($contentId);
    $ipa = new IPA();
    $ipa->name = $content->getFieldValue('title')->text;
    // ...
    }
    }


    View Slide

79. CALL TO ACTION
    EXERCISE 2


    View Slide

80. NOW WE HAVE A
    NORMALIZED
    ENTITY


    View Slide

81. CONVERT ENTITY
    TO NEEDED
    REPRESENTATION


    View Slide

82. WE'RE DONE,
    RIGHT?


    View Slide

83. WHAT ABOUT
    IMAGES


    View Slide

84. NOT POSSIBLE TO SEND
    ALL DATA IN JSON


    View Slide

85. => GIVE URL WHERE
    ADDITIONAL CONTENT
    CAN BE LOADED


    View Slide

86. IMAGES
    [
    {
    "name": "Punk IPA",
    "review": 5,
    "image": "http://www.ipaapi.io/images/punk-ipa.jpg"
    },
    {
    "name": "Dead Pony Club",
    "review": 4.5,
    "image": "http://www.ipaapi.io/images/dead-pony-club.jpg"
    }
    ]


    View Slide

87. CALL TO ACTION
    EXERCISE 3


    View Slide

88. REQUIREMENT
    > XML and JSON
    > Relationship between IPA and Brewery not clear


    View Slide

89. EZ REST API COMPONENT
    > Rest Controller
    > Rest Routing
    > Visitor pattern


    View Slide

90. VISITORS
    > Main target: Translate object
    > Visits objects of a graph, therefore a Visitor
    > Register as visitor with Symfony DIC tag


    View Slide

91. EZ REST VISITOR - BASIC
    public function visit(Visitor $visitor, Generator $generator, $data)
    {
    $generator->startObjectElement('ipa');
    $generator->startValueElement('name', $data->name);
    $generator->endValueElement('name');
    $generator->startValueElement('rating', $data->review);
    $generator->endValueElement('rating');
    $generator->endObjectElement('ipa');
    }


    View Slide

92. EZ REST VISITOR - MIME && HREF
    public function visit(Visitor $visitor, Generator $generator, $data)
    {
    $mediaType = 'ipa';
    $generator->startObjectElement('ipa', $mediaType);
    $visitor->setHeader('Content-Type', $generator->getMediaType($mediaType));
    $generator->startAttribute(
    'href',
    $this->router->generate('ezpublish_rest_ipa', array('contentId' => $data->id))
    );
    $generator->endAttribute('href');
    // ...
    $generator->endObjectElement('ipa');
    }


    View Slide

93. EZ REST CONTROLLER
    public function ipaAction($contentId)
    {
    $service = $this->container->get('app.ipa_service');
    $ipa = $service->loadIpa($contentId);
    return $ipa;
    }


    View Slide

94. EZ REST CONTROLLER: CACHEDVALUE
    public function ipaAction($contentId)
    {
    $service = $this->container->get('app.ipa_service');
    $ipa = $service->loadIpa($contentId);
    $contentService = $this->container->get('ezpublish.api.service.content');
    $locationId = $contentService->loadContentInfo($contentId)->mainLocationId;
    $cached = new CachedValue($ipa, ['locationId' => $locationId]);
    return $cached;
    }


    View Slide

95. CALL TO ACTION
    EXERCISE 4


    View Slide

96. ADVANTAGES OF EZ REST API
    > Support of Mime Types
    > XML or JSON format
    > Caching
    > Visitor pattern


    View Slide

97. DISADVANTAGES OF EZ REST API
    > Some HTTP knowlege (MIME types, headers) needed
    > Given URL prefix (at least when using legacy)
    > Verbose visitors


    View Slide

98. EZ RICH TEXT
    EZ XML TEXT


    View Slide

99. POWERFUL FEATURE
    OF EZ PLATFORM


    View Slide

100. EZ PUBLISH: EZXMLTEXT
     EZ PLATFORM:
     EZRICHTEXT


     View Slide

101. EZ RICH TEXT INTERNAL FORMAT



     Probably my favorite IPA. Some citrus and grapefruit notes. And just.... awsome.


     small




     View Slide

102. EZEMBED
     > means there can be "subviews" which get rendered
     independently
     > => override of templates !


     View Slide

103. EZEMBED
     HARD TO SERIALIZE
     => XML EVEN IN JSON
     REPRESENTATION


     View Slide

104. PROBLEM
     > A JSON representation contains XML tags
     > => How, not What


     View Slide

105. REPRESENTATIONS
     RENDERED BY
     EZ PLATFORM/ EZ
     PUBLISH


     View Slide

106. PROVIDE LINKS TO REPRESENTATIONS
     [
     {
     "name": "Punk IPA",
     "review": 5,
     "brewery": "Brew Dog",
     "image": "http://www.ipaapi.io/images/punk-ipa.jpg",
     "representations": {
     "html": "http://www.ipaapi.io/ipa/57",
     "google_amp": "http://www.ipaapi.io/amp/57"
     }
     }
     ]


     View Slide

107. PROBLEMS TO SOLVE
     > Different representations, different templates
     > Representations which do not support all content
     type embeds


     View Slide

108. EZ PLATFORM OVERRIDES
     CUSTOM REPRESENTATION
     MATCHER


     View Slide

109. CUSTOM MATCHER
     content_view:
     embed:
     amp_image:
     template: "AppBundle:Amp:image.html.twig"
     match:
     Identifier\ContentType: "image"
     app.matcher.representation: "amp"


     View Slide

110. CUSTOM MATCHER: CONTROLLER
     public function ipaAmpAction(Request $request, $contentId)
     {
     $ipa = $this->get('app.ipa_service')->getIpa($contentId);
     $this->get('app.matcher.representation')->setRepresentation('amp')
     $response = $this->render(
     'AppBundle:Amp:ipa.html.twig',
     [
     'content' => $ipa,
     ]
     );
     return $response;
     }


     View Slide

111. CUSTOM MATCHER: MATCHER
     class Representation extends MultipleValued
     {
     private $representationName;
     public function setRepresentationName($name)
     {
     $this->representationName = $name;
     }
     public function match(View $view)
     {
     return isset($this->values[$this->representationName]);
     }
     }


     View Slide

112. RICHTEXT WITH NORMAL IMAGES


     View Slide

113. RICHTEXT WITH OVERRIDDEN IMAGES


     View Slide

114. CALL TO ACTION
     EXERCISE 5


     View Slide

115. UNSOLVED PROBLEM
     > New embeddable content type means new override rule
     for every representation
     > Lot of empty templates for a new representation


     View Slide

116. EZRICHTEXT OUTPUTS
     > Different output: xhtml5, xhtml5_edit
     > Renderer used for different outputs


     View Slide

117. USE CUSTOM RENDERER
     TO
     CLEAN OUT UNSUPPORTED
     TYPES


     View Slide

118. RICHTEXT RENDERER
     > Priority 0: Link Renderer
     > Priority 10: Embed Renderer
     > New Priority 5: Embed Reducer


     View Slide

119. RICHTEXTREDUCER
     class RichTextReducer extends Render implements Converter
     {
     /**
     * Converts given $xmlDoc into another \DOMDocument object.
     */
     public function convert(DOMDocument $xmlDoc)
     {
     $embeds = $xmlDoc->getElementsByTagName('ezembed');
     foreach ($embeds as $embed) {
     $href = $embed->getAttribute('xlink:href');
     if (!$this->representation->supportsEmbed($href)) {
     $embed->parentNode->removeChild($embed);
     }
     }
     return $xmlDoc;
     }
     }


     View Slide

120. REGISTER RICHTEXTREDUCER
     app.richtext.converter.reducer:
     class: "AppBundle\Service\RichTextReducer"
     arguments:
     - "@ezpublish.fieldType.ezrichtext.renderer"
     tags:
     - {name: ezpublish.ezrichtext.converter.output.xhtml5, priority: 5}


     View Slide

121. CALL TO ACTION
     EXERCISE 6


     View Slide

122. TANK YOU
     @URBMC ON TWITTER
     @URBAN ON EZ
     COMMUNITY SLACK


     View Slide
