1. OPA-IPTables Extending OPA to manage IPTable rules through policy Urvil Patel Twitter: @UrvilPatel12 Github : urvil38
2. The Problems we trying to solve: • How to use policy to manage(insert/delete) IPTable rules? • How to query the rules which are stored in OPA? • In which format we are going to store IPTable rules into OPA? • Providing precise & easy to use interface(API) for doing all of this things.
3. Design Goals: • Simple Architecture and Fast • Low overhead on server [use as few resources(memory,CPU) as possible] • Stateless (mostly) • Clear Design • Provides as much as flexibility as possible
4. Architecture: • This extension contains HTTP Server which runs on port “33455”. • It provides following API: • POST /v1/iptables/insert?q= • POST /v1/iptables/delete?q= • GET /v1/iptables/list/{table_name}/{chain_name} • GET /v1/iptables/list/all?verbose= • POST /v1/iptables/json
5. Example: - We want to log every incoming packets of server running on port “9090”. iptables -t FILTER -I INPUT -p tcp --dport 9090 -j LOG --log-prefix "opa-iptables" -m comment --comment “log incoming traffic of web server running on port 9090” But, OPA requires to store this IPTable rules in JSON format.
6. There is an API for converting raw iptables rules to JSON formatted rule. curl -X POST localhost:33455/v1/iptables/json -d 'iptables -t FILTER -I INPUT -p tcp --dport 9090 -j LOG --log-prefix "opa-iptables" -m comment --comment "log incoming traffic of web server running on port 9090"' { "table": "filter", "chain": "INPUT", "destination_port": "9090", "jump": "LOG", "protocol": "tcp", "tcp_flags": {}, "ctstate": [ "" ], "match": [ "comment" ], "log_prefix": "opa-iptables", "comment": "log incoming traffic of web server running on port 9090" }
7. How to store rules into OPA? { "metadata":{ "_id":"..", . . . }, “rules" : [ . . . ] } This extension uses specific data structure called “RuleSet”. { "metadata": { "_id": "day123", "type":"logging", "owner":"bob", "user":["qa","dev"] }, "rules": [ { "table": "filter", "chain": "INPUT", "destination_port": "9090", "jump": "LOG", "protocol": "tcp", "log_prefix":"opa-iptables", "tcp_flags": {}, "ctstate": [ "" ], "match": [ "comment" ], "comment": "log incoming traffic" } ] }
8. How insertion/deletion of the rules works? Insertion API: POST /v1/iptables/insert?q= Content-Type: application/json Request Headers: Body: { “input”: { . . . } } queryPath Object pass to the query
9. package iptables import iptables.ruleset validate(user, secret) { userauth[user] == secret } logging_rules = result { validate(input.user, input.secret) set := ruleset[_] set.metadata.user[_] == input.user set.metadata.type == input.type result = set } curl -X POST http://127.0.0.1:33455/v1/iptables/insert?q=iptables/logging_rules -H 'Content-Type: application/json’ -d '{ "input" : { "type" : "logging", "user" : “qa”, "secret" : “secretqa” } }' policy.rego
10. { } ruleset.json policy.rego 1 Add RuleSet and policy into OPA
11. curl -X POST http://127.0.0.1:33455/v1/iptables/insert?q=iptables/logging_rules -H 'Content-Type: application/json’ -d '{ "input" : { "type" : "logging", "user" : “qa”, "secret" : “secretqa” } }' 2 Using Insertion API query the RuleSet from OPA
12. { "metadata": { "_id": "day123", "type":"logging", "owner":"bob", "user":["qa","dev"] }, "rules": [ { "table": "filter", "chain": "INPUT", "destination_port": "9090", "jump": "LOG", "protocol": "tcp", "log_prefix":"opa-iptables", "tcp_flags": {}, "ctstate": [ "" ], "match": [ "comment" ], "comment": "log incoming traffic" } ] } 3 OPA performs the query and returns appropriate ruleset according to query
13. Linux IPTable Module iptables -t FILTER -I INPUT -p tcp --dport 9090 -j LOG --log-prefix "opa-iptables" -m comment -- comment "log incoming traffic of web server running on port 9090" 4 opa-iptables extracts the iptables JSON formatted rules from the ruleset and converts it into valid iptables rules that we can insert into kernel. { "metadata": { "_id": "day123", "type":"logging", "owner":"bob", "user":["qa","dev"] }, "rules": [ { "table": "filter", "chain": "INPUT", "destination_port": "9090", "jump": "LOG", "protocol": "tcp", "log_prefix":"opa-iptables", "tcp_flags": {}, "ctstate": [ "" ], "match": [ "comment" ], "comment": "log incoming traffic" } ] }
14. Resources: • Project Repository • Tutorial • Documentation
