IPC on macOS

Transcript

1. IPC on macOS


   View Slide

2. Before we dive in
   The Berkeley Software Distribution (BSD) is an operating
   system based on early Unix.


   View Slide

3. BSD became the basics for several open-source OS:
   FreeBSD, OpenBSD, NetBSD, DragonFly BSD, TrueOS and
   Darwin


   View Slide

4. Darwin is an open-source Unix-like operating system
   first released by Apple in 2000


   View Slide

5. Darwin forms the core set of components upon which
   macOS, iOS, watchOS, tvOS, iPadOS and audioOS are
   based


   View Slide

6. View Slide

7. BSD supports POSIX standard, so POSIX APIs are
   avaliable to us on macOS.


   View Slide

8. POSIX == Portable Operating System Interface


   View Slide

9. Available IPC techniques


   View Slide

10. BSD
    1. BSD sockets
    2. BSD pipes
    3. BSD signals


    View Slide

11. Other low level
    1. Shared Memory + Semaphores for large resources
    (like movie)


    View Slide

12. Darwin low-level
    1. Mach Ports


    View Slide

13. The Mach port object is the underlying primitive used for
    all interprocess communication in macOS


    View Slide

14. High-level macOS-specific
    1. Apple Events
    2. High-performance counterpart of Apple Events —
    CFMessagePort and friends
    3. Distributed Notifications
    4. Distributed objects (NSConnection and friends)
    5. XPC (C API and Objective-C API)


    View Slide

15. Even higher level
    no explicit setup for communication
    1. NSPasteboard
    2. Services API


    View Slide

16. BSD Sockets
    You can implement inter-process communication using
    BSD sockets via:
    — POSIX API (socket() and friends)
    — Core Foundation API (CFSocket and friends; also used
    for networking)


    View Slide

17. BSD Pipes
    One-way communication. 2 types:
    — Unnamed pipe (example: command line shell cat
    magic.txt | grep -e Gwendoyln sends the contents of
    magic.text to the grep command)
    — Named pipe is a special type of file without any
    content on filesystem


    View Slide

18. BSD signals
    Usually a process terminates on receiving a signal. But it
    can implement a signal handler function to override this
    behaviour.
    Used by OS kernel to tell the process about an exception
    (like division by 0). Command line kill command is
    another example of using signals.
    The signal namespace is just one integer, so collisions
    are very possible.
    Not recommended to use signals for IPC.


    View Slide

19. Shared Memory + Semaphores
    A process allocates a memory region, that can be read
    and written by other processes.
    Advantages:
    * data is never copied
    * any process with appropriate permission can read and
    write
    Disadvantage:
    * fragile—if it is corrupted, all processes are corrupted
    Access it from one process, use more conventional IPC.


    View Slide

20. Mach Ports
    Available APIs:
    — Darwin C API
    — Core Foundation — CFMachPort and friends
    — Foundation — NSMachPort and friends


    View Slide

21. Darwin C API: sending
    natural_t data;
    mach_port_t port;
    struct {
    mach_msg_header_t header;
    mach_msg_body_t body;
    mach_msg_type_descriptor_t type;
    } message;
    message.header = (mach_msg_header_t) {
    .msgh_remote_port = port,
    .msgh_local_port = MACH_PORT_NULL,
    .msgh_bits = MACH_MSGH_BITS(MACH_MSG_TYPE_COPY_SEND, 0),
    .msgh_size = sizeof(message)
    };


    View Slide

22. message.body = (mach_msg_body_t) {
    .msgh_descriptor_count = 1
    };
    message.type = (mach_msg_type_descriptor_t) {
    .pad1 = data,
    .pad2 = sizeof(data)
    };
    mach_msg_return_t error = mach_msg_send(&message.header);
    if (error == MACH_MSG_SUCCESS) {
    // ...
    }


    View Slide

23. Darwin C API
    Not recommended to use directly: interfaces will change
    with kernel updates.


    View Slide

24. CFMachPort & NSMachPort


    View Slide

25. Apple Events


    View Slide

26. Apple Events
    NSAppleEventManager *appleEventManager = [NSAppleEventManager sharedAppleEventManager];
    [appleEventManager setEventHandler:self
    andSelector:@selector(handleAppleEvent:withReplyEvent:)
    forEventClass:kInternetEventClass
    andEventID:kAEGetURL];


    View Slide

27. View Slide

28. CFMessagePort


    View Slide

29. CFMessagePort
    High-performance counterpart of Apple Events


    View Slide

30. private struct RemoteServerPortName {
    static let client = "com.hideez.port.client"
    static let server = "com.hideez.port.server"
    }
    private var inPort: CFMessagePort?
    func startListening() {
    guard nil == inPort else {
    return
    }
    inPort = CFMessagePortCreateLocal(
    nil, RemoteServerPortName.client as CFString!, getInMessageCallback(), nil, nil)
    let runLoopSource = CFMessagePortCreateRunLoopSource(nil, inPort, 0);
    CFRunLoopAddSource(CFRunLoopGetCurrent(), runLoopSource, CFRunLoopMode.commonModes);
    }
    func getInMessageCallback() -> CFMessagePortCallBack {
    return {(port: CFMessagePort?, messageId:Int32, data: CFData?,
    _: UnsafeMutableRawPointer?) -> Unmanaged? in
    RemoteServer.shared.handleInMessage(port: port, messageId: messageId, data: data)
    }
    }


    View Slide

31. func postMessage(message: RemoteMessageOut,
    waitForResponse wait: Bool = false) -> RemoteServerResponse? {
    guard let outPort = CFMessagePortCreateRemote(
    nil, RemoteServerPortName.server as CFString!) else {
    return nil
    }
    var respData: Unmanaged? = Unmanaged.passRetained(CFDataCreate(nil, nil, 0)!)
    CFMessagePortSendRequest(
    outPort,
    message.id.rawValue,
    (message.data ?? Data()) as CFData,
    30.0,
    wait ? 30.0 : 0.0,
    wait ? CFRunLoopMode.defaultMode.rawValue : nil,
    &respData)
    let data = respData!.takeUnretainedValue() as Data
    CFMessagePortInvalidate(outPort)
    return data.isEmpty ? nil : NSKeyedUnarchiver.unarchiveObject(with: data) as? [String : Any]
    }


    View Slide

32. Distributed Notifications


    View Slide

33. [NSDistributedNotificationCenter default addObserver:self
    selector:@selector(_openPreferences)
    name:notificationName
    object:nil];


    View Slide

34. distributedNotificationCenter.postNotificationName(@"NotificationName",
    object: nil,
    userInfo: userInfo,
    deliverImmediately: true)


    View Slide

35. Distributed objects
    Deprecated and has
    !!!


    View Slide

36. Distributed objects
    NSConnection and friends
    are deprecated and have
    !!!


    View Slide

37. XPC
    Available APIs:
    — C API (use from C, C++ code)
    — Objective-C API (use from Objective-C, Swift)


    View Slide

38. Obj-C XPC — modern API
    — Protocol-oriented(!)
    — Available since 10.8 (year of 2012)
    — API of choice for IPC on macOS


    View Slide

39. View Slide

40. View Slide

41. View Slide

42. IPC workshop


    View Slide

43. Thank you!


    View Slide
