  1. BTLEJUICE: THE
    BLUETOOTH SMART
    MITM FRAMEWORK
    DAMIEN CAUQUIL - CERT-UBIK

    View Slide

  2. /ME
    Senior researcher at CERT-UBIK (ECONOCOM)
    Head of Research and Development
    Focus on Bluetooth Smart since 2014
    Twitter (me): @virtualabs
    Twitter CERT-UBIK: @iotcert

    View Slide

  3. AGENDA
    Bluetooth Smart (or Low Energy) 101
    Bluetooth Smart vs. Bluetooth Classic
    Why sniffing sucks
    Man-in-the-Middle attacks on BTLE
    BtleJuice MitM framework
    Live demos !

    View Slide

  4. BLUETOOTH SMART (LE) 101

    View Slide

  5. BLUETOOTH CLASSIC VS. BLUETOOTH SMART
    Both defined in the Bluetooth 4.0+ Specs
    Bluetooth Smart was designed for low power devices
    (Low Energy)
    Bluetooth Smart is lighter than Bluetooth Classic
    Bluetooth Smart is widely used in tiny embedded devices

    View Slide

  6. MANY BLUETOOTH SMART DEVICES USE BTLE

    View Slide

  7. BLUETOOTH CLASSIC VS. BLUETOOTH SMART

    View Slide

  8. BLUETOOTH SMART MAIN FEATURES
    Frequency Hopping Spread Spectrum to avoid
    interferences (FHSS)
    Encrypted communications (Security Manager Protocol)
    Simple communications through Services and
    characteristics (GAP/GATT)
    One connection at a time

    View Slide

  9. FREQUENCY HOPPING SPREAD SPECTRUM
    Devices synchronize first ...
    ... then both of them hop from channel to channel
    Difficult to sniff an existing connection between two
    devices !

    View Slide

  10. View Slide

  11. View Slide

  12. SECURITY MANAGER PROTOCOL

    View Slide

  13. SECURITY MANAGER PROTOCOL
    Devices exchange pairing information (JustWorks, PIN,
    OOB)
    Devices authenticate the link
    Keys are distributed and long-term keys stored
    One must sniff this exchange to break the encryption
    keys (CrackLE)

    View Slide

  14. THE HARD TRUTH IS:
    Few devices use encryption but do not require it (failed
    pairing is OK)
    Almost all devices are not strongly authenticated by
    mobile applications or other devices
    BD address is o en the only check performed to ensure
    authenticity
    Sniffing-based attacks are difficult to perform in the wild

    View Slide

  15. BLUETOOTH SMART
    MAN-IN-THE-MIDDLE

    View Slide

  16. WHY BTLE SNIFFING SUCKS
    Ubertooth: $120
    Adafruit Bluefruit sniffer: $30 (non-standard PCAP)
    btproxy: only works for Bluetooth Classic, not BTLE
    Encryption: sniff first then decrypt

    View Slide

  17. View Slide

  18. BLUETOOTH SMART MAN-IN-THE-MIDDLE
    1. Connect to the device
    2. Create a dummy device
    with same services and
    characteristics
    3. Wait for connection and
    forward

    View Slide

  19. INTRODUCING BTLEJUICE FRAMEWORK
    Noble for central and Bleno for dummy
    Standard BT 4.0+ adapters for both central and dummy
    Websocket to forward GATT operations (and more)
    Supports bonding (JustWorks) for Bluez 5.x and Linux
    kernel 4.x

    View Slide

  20. ARCHITECTURE

    View Slide

  21. HOLD ON, A SIMILAR TOOL EXISTS !
    Presented @ BHUSA 2016 by Slawomir Jasek
    I just discovered it yesterday (thanks to its author)
    Same libs, same requirements
    I just discovered it yesterday (thanks to its author)
    Same goal, different tools
    More tricks with Bleno and Noble
    http://www.gattack.io/
    https://en.wikipedia.org/wiki/Multiple_discovery

    View Slide

  22. EASY SETUP
    $ s
    u
    d
    o a
    p
    t
    -
    g
    e
    t i
    n
    s
    t
    a
    l
    l b
    l
    u
    e
    t
    o
    o
    t
    h b
    l
    u
    e
    z \
    l
    i
    b
    b
    l
    u
    e
    t
    o
    o
    t
    h
    -
    d
    e
    v l
    i
    b
    u
    d
    e
    v
    -
    d
    e
    v
    $ s
    u
    d
    o n
    p
    m i
    n
    s
    t
    a
    l
    l -
    g b
    t
    l
    e
    j
    u
    i
    c
    e

    View Slide

  23. BTLEJUICE WEB UI
    (uses Ange Albertini's HEXII)

    View Slide

  24. BTLEJUICE FEATURES
    Live GATT operations and data sniffing
    Burp-like interception mode allows data manipulation
    Web user interface
    Python bindings (2.x & 3.x)
    Node.js bindings (ES6)

    View Slide

  25. REQUIREMENTS
    Two-machine setup (we can use a VM too)
    Two Bluetooth 4.0+ adapters (CSR 4.0+ ideally)
    Node >= v4.3.0

    View Slide

  26. MAN-IN-THE-MIDDLE BENEFITS
    Works with any Bluetooth 4.0+ adapters
    Intercepting GATT reads and writes are way easier
    Supports bonding/encryption !
    Compatible with tests using a Faraday cage
    BD address spoofing is possible =)

    View Slide

  27. CREATING THE PERFECT DUMMY
    (OR HOW TO CLONE A DEVICE)
    Connect BtleJuice Proxy to target device ...
    No more advertisement, frequency hopping active !
    BD address can be spoofed using CSR adapters
    We can advertise a new device with same address while
    connected to the original one ὠ

    View Slide

  28. PYTHON BINDINGS
    class MySniffingInterface(SniffingInterface):
    def __init__(self, host, port, target):
    SniffingInterface.__init__(self, host, port, target)
    def on_data_read(self, service, characteristic, data):
    print('[<][%s - %s] %s' % (service, characteristic, data))
    def on_data_write(self, service, characteristic, data, offset, without
    print('[>][%s - %s] %s' % (service, characteristic, data))
    def on_notification_data(self, service, characteristic, data):
    print('[!][%s - %s] %s' % (service, characteristic, data))
    def on_subscribe_notification(self, service, characteristic, enabled):
    print('[N][%s - %s] %s' % (service, characteristic, enabled))

    View Slide

  29. NODE.JS BINDINGS
    class MySniffingInterface extends btlejuice.SniffingInterface {
    onClientConnected(client) {
    console.log('** Connection from '+client);
    }
    onClientLeft(client) {
    console.log('** Disconnection from '+client);
    }
    onRead(service, characteristic, data) {
    console.log('[<][%s - %s] %s', service, characteristic, hexiify(data))
    }
    onWrite(service, characteristic, data) {
    console.log('[>][%s - %s] %s', service, characteristic, hexiify(data))
    }

    View Slide

  30. ON-THE-FLY DATA MODIFICATION
    def on_before_read(self, service, characteristic, offset):
    if service.lower() == '180f' and \
    characteristic.lower()=='2a19':
    self.batt_level -= 1
    if self.batt_level < 0:
    self.batt_level = 100
    raise HookForceResponse(chr(self.batt_level))
    def on_before_subscribe(self, service, characteristic, enabled):
    # dismiss
    raise HookForceResponse()

    View Slide

  31. KNOWN LIMITATIONS
    Noble does not support long writes (>22 bytes)
    Induced latency (BTLE to websocket then back to BTLE)
    May be tricky to use when devices keep connections or
    advertise during a short delay

    View Slide

  32. BTLEJUICE LIVE

    View Slide

  33. MY TEST DEVICES
    Device Bonding Auth Interception Replay
    Gablys Lite ? ? ? ?
    Wistiki ? ? ? ?
    MasterLock
    4400D
    ? ? ? ?
    Padlock ? ? ? ?
    Smartlock ? ? ? ?

    View Slide

  34. DEMO: GABLYS LITE

    View Slide

  35. GABLYS LITE
    Bonding supported, but not required
    No strong authentication
    Anyone may make this tag beep
    Denial of service attack found through replay

    View Slide

  36. DEMO: WISTIKI

    View Slide

  37. WISTIKI
    Bonding required
    Bonding provides strong authentication
    Tag is declared lost when connection is lost

    View Slide

  38. MY TEST DEVICES
    Device Bonding Auth Interception Replay
    Gablys Lite NO ADDRESS YES YES
    Wistiki REQUIRED STRONG NO NO
    MasterLock
    4400D
    ? ? ? ?
    Padlock ? ? ? ?
    Smartlock ? ? ? ?

    View Slide

  39. MASTERLOCK 4400D
    Encrypted communications (AES-CCM)
    No bonding required
    Authentication through challenge/response
    Long writes through characteristics
    Available a short amount of time

    View Slide

  40. DEMO: PADLOCK

    View Slide

  41. PADLOCK
    Everything sent in plaintext
    Authentication based on BD address
    No bonding required
    Stays active once a client connected

    View Slide

  42. MY TEST DEVICES
    Device Bonding Auth Interception Replay
    Gablys Lite NO ADDRESS YES YES
    Wistiki REQUIRED STRONG NO NO
    MasterLock
    4400D
    NO STRONG NO NO
    Padlock NO ADDRESS YES YES
    Smartlock ? ? ? ?

    View Slide

  43. SMARTLOCK
    Data partly transmitted unencrypted
    Authentication based on advertisement data
    No bonding required

    View Slide

  44. MY TEST DEVICES
    Device Bonding Auth Interception Replay
    Gablys Lite NO ADDRESS YES YES
    Wistiki REQUIRED STRONG NO NO
    MasterLock
    4400D
    NO STRONG NO NO
    Padlock NO ADDRESS YES YES
    Smartlock NO ADVERT. YES YES

    View Slide

  45. SUMMARY

    View Slide

  46. BTLEJUICE AS A SECURITY TOOL
    Useful to determine a device's behavior
    Allows data sniffing and manipulation
    Allows replay attacks
    Supports bonding

    View Slide

  47. BTLEJUICE AS AN ATTACK TOOL
    Can bypass BD address authentication
    Can be instrumented to automate attacks
    Requires generic hardware but at least two machines
    Known limitations due to Noble and Bleno limitations

    View Slide

  48. FUTURE WORK
    Improve BtleJuice's proxy reliability
    Solve the two-machine problem
    Improve user interfaces and bindings
    Moar testing (need feedback !)

    View Slide

  49. QUESTIONS ?

    View Slide

  50. CONTACT
    [email protected]
    @virtualabs (https://twitter.com/virtualabs)
    @iotcert (https://twitter.com/iotcert)

    View Slide

  51. USEFUL LINKS
    https://github.com/DigitalSecurity/btlejuice
    https://github.com/DigitalSecurity/btlejuice-node-bindings
    https://github.com/DigitalSecurity/btlejuice-python-bindings
    http://www.silabs.com/Support%20Documents/RegisteredDocs/UG103.14.pd
    https://www.bluetooth.com/specifications/adopted-specifications
    http://lacklustre.net/projects/crackle/
    http://www.gattack.io/
