Composing an API with Kotlin vol 2 (Advanced Kotlin Dev Day 2022)

Jetpack Compose is one of the best examples of an exciting Kotlin code base. It’s a real treasure trove of examples for using advanced Kotlin language features and conventions. In this talk, we’ll continue the exploration started in the prequel to learn more best practices around our favourite programming language.

More info and resources: https://zsmb.co/talks/composing-an-api-with-kotlin-vol-2/

Transcript

1. Márton Braun @zsmb13
   Developer Relations Engineer
   Google
   Composing
   an API with
   Kotlin
   VOL.2


   View Slide

2. Previously…
   goo.gle/composing-an-api-talk


   View Slide

3. Jetpack Compose
   is Android’s modern
   toolkit for building
   native UI.
   d.android.com/compose


   View Slide

4. Disclaimer
   Some of the code shown on these
   slides is simplified so that it fits.
   Check the implementation yourself!


   View Slide

5. goo.gle/code-search-compose


   View Slide

6. View Slide

7. Default arguments


   View Slide

8. Default arguments
   fun RoundedCornerShape(
   topStart: Dp = 0.dp,
   topEnd: Dp = 0.dp,
   bottomEnd: Dp = 0.dp,
   bottomStart: Dp = 0.dp
   )


   View Slide

9. Default arguments
   fun RoundedCornerShape(
   topStart: Dp = 0.dp,
   topEnd: Dp = 0.dp,
   bottomEnd: Dp = 0.dp,
   bottomStart: Dp = 0.dp
   )
   @Stable
   inline val Int.dp: Dp get() = Dp(value = this.toFloat())


   View Slide

10. Default arguments
    fun RoundedCornerShape(
    topStart: Dp = 0.dp,
    topEnd: Dp = 0.dp,
    bottomEnd: Dp = 0.dp,
    bottomStart: Dp = 0.dp
    )
    RoundedCornerShape(
    topEnd = 16.dp,
    )


    View Slide

11. Default arguments
    fun RoundedCornerShape(
    topStart: Dp = 0.dp,
    topEnd: Dp = 0.dp,
    bottomEnd: Dp = 0.dp,
    bottomStart: Dp = 0.dp
    )
    RoundedCornerShape(
    topEnd = 16.dp,
    bottomStart = 32.dp,
    )


    View Slide

12. Default arguments
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )


    View Slide

13. Default arguments
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )


    View Slide

14. Default arguments
    Text("Hello Compose!") @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )


    View Slide

15. Default arguments
    Hello Compose!
    Text("Hello Compose!") @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )


    View Slide

16. )
    Default arguments
    Text(
    text = "Hello Compose!",
    fontSize = 10.sp,
    Hello Compose!
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )


    View Slide

17. Text(
    text = "Hello Compose!",
    Default arguments
    Hello Compose!
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )
    fontSize = 10.sp,
    fontWeight = FontWeight.Bold,
    )


    View Slide

18. modifier = Modifier.width(50.dp),
    Text(
    text = "Hello Compose!",
    Default arguments
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )
    Hello
    Compose!
    50.dp
    fontSize = 10.sp,
    fontWeight = FontWeight.Bold,
    )


    View Slide

19. Default arguments
    modifier = Modifier.width(50.dp),
    fontSize = 10.sp,
    fontWeight = FontWeight.Bold,
    )
    Hello
    50.dp
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )
    maxLines = 1,
    Text(
    text = "Hello Compose!",


    View Slide

20. Default arguments
    Hello
    50.dp
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )
    modifier = Modifier.width(50.dp),
    fontSize = 10.sp,
    fontWeight = FontWeight.Bold,
    )
    maxLines = 1,
    Text(
    text = "Hello Compose!",


    View Slide

21. modifier = Modifier.width(50.dp),
    fontSize = 10.sp,
    fontWeight = FontWeight.Bold,
    )
    maxLines = 1,
    Text(
    text = "Hello Compose!",
    overflow = TextOverflow.Ellipsis,
    Default arguments
    Hello Co...
    50.dp
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )


    View Slide

22. Default & named arguments
    Hello Co...
    @Composable
    fun Text(
    text: String,
    modifier: Modifier = Modifier,
    color: Color = Color.Unspecified,
    fontSize: TextUnit = TextUnit.Unspecified,
    fontStyle: FontStyle? = null,
    fontWeight: FontWeight? = null,
    fontFamily: FontFamily? = null,
    letterSpacing: TextUnit = TextUnit.Unspecified,
    textDecoration: TextDecoration? = null,
    textAlign: TextAlign? = null,
    lineHeight: TextUnit = TextUnit.Unspecified,
    overflow: TextOverflow = TextOverflow.Clip,
    softWrap: Boolean = true,
    maxLines: Int = Int.MAX_VALUE,
    onTextLayout: (TextLayoutResult) -> Unit = {},
    style: TextStyle = LocalTextStyle.current
    )
    modifier = Modifier.width(50.dp),
    fontSize = 10.sp,
    fontWeight = FontWeight.Bold,
    )
    maxLines = 1,
    Text(
    text = "Hello Compose!",
    overflow = TextOverflow.Ellipsis,
    50.dp


    View Slide

23. Default & named arguments
    @Composable
    fun Button(
    onClick: () -> Unit,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    shape: Shape = ButtonDefaults.shape,
    colors: ButtonColors = ButtonDefaults.buttonColors(),
    elevation: ButtonElevation? = ButtonDefaults.buttonElevation(),
    border: BorderStroke? = null,
    contentPadding: PaddingValues = ButtonDefaults.ContentPadding,
    interactionSource: MutableInteractionSource =
    remember { MutableInteractionSource() },
    content: @Composable RowScope.() -> Unit
    )


    View Slide

24. Default & named arguments
    @Composable
    fun Button(
    onClick: () -> Unit,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    shape: Shape = ButtonDefaults.shape,
    colors: ButtonColors = ButtonDefaults.buttonColors(),
    elevation: ButtonElevation? = ButtonDefaults.buttonElevation(),
    border: BorderStroke? = null,
    contentPadding: PaddingValues = ButtonDefaults.ContentPadding,
    interactionSource: MutableInteractionSource =
    remember { MutableInteractionSource() },
    content: @Composable RowScope.() -> Unit
    )


    View Slide

25. Function types
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    shape: Shape = ButtonDefaults.shape,
    colors: ButtonColors = ButtonDefaults.buttonColors(),
    elevation: ButtonElevation? = ButtonDefaults.buttonElevation(),
    border: BorderStroke? = null,
    contentPadding: PaddingValues = ButtonDefaults.ContentPadding,
    interactionSource: MutableInteractionSource =
    remember { MutableInteractionSource() },
    content: @Composable RowScope.() -> Unit
    )
    @Composable
    fun Button(
    onClick: () -> Unit,
    ...,


    View Slide

26. m o d i f i e r : M o d i f i e r = M o d i f i e r ,
    e n a b l e d : B o o l e a n = t r u e ,
    s h a p e : S h a p e = B u t t o n D e f a u l t s . s h a p e ,
    c o l o r s : B u t t o n C o l o r s = B u t t o n D e f a u l t s . b u t t o n C o l o r s ( ) ,
    e l e v a t i o n : B u t t o n E l e v a t i o n ? = B u t t o n D e f a u l t s . b u t t o n E l e v a t i o n ( ) ,
    b o r d e r : B o r d e r S t r o k e ? = n u l l ,
    c o n t e n t P a d d i n g : P a d d i n g V a l u e s = B u t t o n D e f a u l t s . C o n t e n t P a d d i n g ,
    i n t e r a c t i o n S o u r c e : M u t a b l e I n t e r a c t i o n S o u r c e =
    r e m e m b e r { M u t a b l e I n t e r a c t i o n S o u r c e ( ) } ,
    Function types
    Button(onClick = { onBackClick(screenId) }) {
    Icon(
    imageVector = Icons.Rounded.ArrowBack,
    contentDescription = stringResource(R.string.back)
    )
    }
    @Composable
    fun Button(
    onClick: () -> Unit,
    content: @Composable RowScope.() -> Unit
    )
    ...,


    View Slide

27. Function types
    @Composable
    fun Button(
    onClick: () -> Unit,
    ...,
    content: @Composable RowScope.() -> Unit
    )
    Button(onClick = { onBackClick(screenId) }) {
    Icon(
    imageVector = Icons.Rounded.ArrowBack,
    contentDescription = stringResource(R.string.back)
    )
    }


    View Slide

28. Function types
    @Composable
    fun Button(
    onClick: () -> Unit,
    ...,
    content: @Composable RowScope.() -> Unit
    )
    Button(onClick = { onBackClick(screenId) }) {
    Icon(
    imageVector = Icons.Rounded.ArrowBack,
    contentDescription = stringResource(R.string.back)
    )
    }


    View Slide

29. Function types
    @Composable
    fun Button(
    onClick: () -> Unit,
    ...,
    content: @Composable RowScope.() -> Unit
    )
    Button(onClick = { onBackClick(screenId) }) {
    Icon(
    imageVector = Icons.Rounded.ArrowBack,
    contentDescription = stringResource(R.string.back)
    )
    }


    View Slide

30. Function types
    @Composable
    fun Button(
    onClick: () -> Unit,
    ...,
    content: @Composable RowScope.() -> Unit
    )
    Button(onClick = { onBackClick(screenId) }) {
    Icon(
    imageVector = Icons.Rounded.ArrowBack,
    contentDescription =
    )
    }
    stringResource(R.string.back)


    View Slide

31. Function types
    @Composable
    fun Button(
    onClick: () -> Unit,
    ...,
    content: @Composable RowScope.() -> Unit
    )
    Button(onClick = { onBackClick(screenId) }) {
    Text( )
    }
    stringResource(R.string.back)


    View Slide

32. Function types


    View Slide

33. Function types
    @Composable
    fun Title(snack: Snack, scroll: Int) {
    val offset = (maxOffset - scroll).coerceAtLeast(minOffset)
    Column(
    modifier = Modifier.graphicsLayer(translationY = offset)
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, scroll.value)


    View Slide

34. Function types
    @Composable
    fun Title(snack: Snack, scroll: Int) {
    val offset = (maxOffset - scroll).coerceAtLeast(minOffset)
    Column(
    modifier = Modifier.graphicsLayer(translationY = offset)
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, scroll.value)


    View Slide

35. Function types
    @Composable
    fun Title(snack: Snack, scroll: Int) {
    val offset = (maxOffset - scroll).coerceAtLeast(minOffset)
    Column(
    modifier = Modifier.graphicsLayer(translationY = offset)
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, scroll.value)


    View Slide

36. Function types
    @Composable
    fun Title(snack: Snack, scroll: Int) {
    val offset = (maxOffset – scroll
    Column(
    modifier = Modifier.graphicsLayer(translationY = offset)
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, scroll.value)
    ).coerceAtLeast(minOffset)


    View Slide

37. @Composable
    fun Title(snack: Snack, scrollProvider: () -> Int) {
    val offset = (maxOffset – scrollProvider()
    Column(
    modifier = Modifier.graphicsLayer(translationY = offset)
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, { scroll.value }
    Function types
    )
    ).coerceAtLeast(minOffset)


    View Slide

38. Function types
    @Composable
    fun Title(snack: Snack, scrollProvider: () -> Int) {
    val offset = (maxOffset – scrollProvider()).coerceAtLeast(minOffset)
    Column(
    modifier = Modifier.graphicsLayer(translationY = offset)
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, { scroll.value })


    View Slide

39. Function types
    @Composable
    fun Title(snack: Snack, scrollProvider: () -> Int) {
    val offset = (maxOffset – scrollProvider())
    Column(
    modifier = Modifier.graphicsLayer( )
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, { scroll.value })
    translationY = offset
    .coerceAtLeast(minOffset)


    View Slide

40. Function types
    @Composable
    fun Title(snack: Snack, scrollProvider: () -> Int) {
    Column(
    modifier = Modifier.graphicsLayer {
    }
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, { scroll.value })
    translationY = offset
    .coerceAtLeast(minOffset)
    val offset = (maxOffset - scrollProvider())


    View Slide

41. Function types
    @Composable
    fun Title(snack: Snack, scrollProvider: () -> Int) {
    Column(
    modifier = Modifier.graphicsLayer {
    translationY = offset
    }
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, { scroll.value })
    .coerceAtLeast(minOffset)
    val offset = (maxOffset - scrollProvider())


    View Slide

42. Function types
    @Composable
    fun Title(snack: Snack, scrollProvider: () -> Int) {
    Column(
    modifier = Modifier.graphicsLayer {
    translationY = offset
    }
    ) {
    Text(...)
    Text(...)
    Text(...)
    }
    }
    Title(snack, { scroll.value })
    .coerceAtLeast(minOffset)
    val offset = (maxOffset - scrollProvider())


    View Slide

43. Function types
    checkNotNull(inputStream) { "Stream must be opened before reading" }
    require(offset >= 0) { "Offset must not be negative (was $offset)" }
    map.getOrElse(key) { fetchDefaultValue() }


    View Slide

44. Delegates


    View Slide

45. Delegates
    val pi by lazy {
    sqrt(6 * (1..1_000_000_000).sumOf { 1.0 / it / it })
    }
    fun main() {
    println("I really like $pi")
    println("Twice the pi, double the flavour:")
    println(pi * 2)
    }


    View Slide

46. Delegates
    val pi by lazy {
    sqrt(6 * (1..1_000_000_000).sumOf { 1.0 / it / it })
    }
    fun main() {
    println("I really like $pi")
    println("Twice the pi, double the flavour:")
    println(pi * 2)
    }


    View Slide

47. Delegates
    val pi by lazy {
    sqrt(6 * (1..1_000_000_000).sumOf { 1.0 / it / it })
    }
    fun main() {
    println("I really like $pi")
    println("Twice the pi, double the flavour:")
    println(pi * 2)
    }
    I really like 3.14159264498239
    Twice the pi, double the flavour:
    6.28318528996478
    operator fun getValue(thisRef: T, property: KProperty<*>): V


    View Slide

48. Delegates
    val pi by lazy {
    sqrt(6 * (1..1_000_000_000).sumOf { 1.0 / it / it })
    }
    fun main() {
    println("I really like $pi")
    println("Twice the pi, double the flavour:")
    println(pi * 2)
    }
    operator fun getValue(thisRef: T, property: KProperty<*>): V


    View Slide

49. Delegates
    val pi by lazy {
    sqrt(6 * (1..1_000_000_000).sumOf { 1.0 / it / it })
    }
    fun main() {
    println("I really like $pi")
    println("Twice the pi, double the flavour:")
    println(pi * 2)
    }
    operator fun getValue(thisRef: T, property: KProperty<*>): V
    operator fun setValue(thisRef: T, property: KProperty<*>, value: V)


    View Slide

50. Delegates
    val pi by lazy {
    sqrt(6 * (1..1_000_000_000).sumOf { 1.0 / it / it })
    }
    fun main() {
    println("I really like $pi")
    println("Twice the pi, double the flavour:")
    println(pi * 2)
    }
    operator fun getValue(thisRef: T, property: KProperty<*>): V
    operator fun setValue(thisRef: T, property: KProperty<*>, value: V)


    View Slide

51. Delegates
    fun main() {
    val pi by lazy {
    sqrt(6 * (1..1_000_000_000).sumOf { 1.0 / it / it })
    }
    println("I really like $pi")
    println("Twice the pi, double the flavour:")
    println(pi * 2)
    }
    operator fun getValue(thisRef: T, property: KProperty<*>): V
    operator fun setValue(thisRef: T, property: KProperty<*>, value: V)


    View Slide

52. Delegates
    @Composable
    fun NameInput() {
    val name = remember { mutableStateOf("") }
    OutlinedTextField(
    value = name.value,
    onValueChange = { name.value = it },
    label = { Text("Name") }
    )
    }


    View Slide

53. @Composable
    fun NameInput() {
    val name = remember { mutableStateOf("") }
    OutlinedTextField(
    value = name.value,
    onValueChange = { name.value = it },
    label = { Text("Name") }
    )
    }
    Delegates
    MutableState


    View Slide

54. @Composable
    fun NameInput() {
    val name = remember { mutableStateOf("") }
    OutlinedTextField(
    value = name.value,
    onValueChange = { name.value = it },
    label = { Text("Name") }
    )
    }
    Delegates
    MutableState


    View Slide

55. Delegates
    @Composable
    fun NameInput() {
    var name: String by remember { mutableStateOf("") }
    OutlinedTextField(
    value = name.value,
    onValueChange = { name.value = it },
    label = { Text("Name") }
    )
    }
    MutableState


    View Slide

56. Delegates
    @Composable
    fun NameInput() {
    var name: String by remember { mutableStateOf("") }
    OutlinedTextField(
    value = name,
    onValueChange = { name = it },
    label = { Text("Name") }
    )
    }
    MutableState


    View Slide

57. Delegates
    interface State {
    val value: T
    }
    interface MutableState : State {
    override var value: T
    ...
    }


    View Slide

58. Delegates
    interface State {
    val value: T
    }
    interface MutableState : State {
    override var value: T
    ...
    }


    View Slide

59. Delegates
    interface MutableState : State {
    override var value: T
    ...
    }
    interface State {
    val value: T
    }


    View Slide

60. ...
    Delegates
    ) {
    this.value = value
    }
    interface MutableState : State {
    override var value: T
    ...
    }
    inline operator fun State.getValue( ): T = value
    inline operator fun MutableState.setValue(
    interface State {
    val value: T
    }
    value: T
    ...,


    View Slide

61. ...,
    ...
    thisObj: Any?,
    property: KProperty<*>
    thisObj: Any?,
    property: KProperty<*>,
    ) {
    this.value = value
    }
    Delegates
    inline operator fun State.getValue(
    ): T = value
    inline operator fun MutableState.setValue(
    value: T


    View Slide

62. Delegates
    val map = mutableMapOf()
    var name by map
    name = "Compose"
    println(map) // {name=Compose}


    View Slide

63. Delegates
    val map = mutableMapOf()
    var name by map
    name = "Compose"
    println(map) // {name=Compose}


    View Slide

64. Destructuring declarations


    View Slide

65. Destructuring declarations
    val (r, g, b, a) = Color(0x00E97FFF)


    View Slide

66. @JvmInline
    value class Color(val value: ULong) {
    ...
    }
    Destructuring declarations
    val (r, g, b, a) = Color(0x00E97FFF)


    View Slide

67. Destructuring declarations
    val (r, g, b, a) = Color(0x00E97FFF)
    @JvmInline
    value class Color(val value: ULong) {
    val red: Float get() { ... }
    val green: Float get() { ... }
    val blue: Float get() { ... }
    val alpha: Float get() { ... }
    ...
    }


    View Slide

68. ...
    Destructuring declarations
    val (r, g, b, a) = Color(0x00E97FFF)
    @JvmInline
    value class Color(val value: ULong) {
    val red: Float get() { ... }
    val green: Float get() { ... }
    val blue: Float get() { ... }
    val alpha: Float get() { ... }
    operator fun component1(): Float = red
    operator fun component2(): Float = green
    operator fun component3(): Float = blue
    operator fun component4(): Float = alpha
    }


    View Slide

69. @Composable
    fun NameInput() {
    var name by remember { mutableStateOf("") }
    OutlinedTextField(
    value = name,
    onValueChange = { name = it },
    label = { Text("Name") },
    )
    }
    Destructuring declarations
    MutableState


    View Slide

70. Destructuring declarations
    @Composable
    fun NameInput() {
    val (name, setName) remember { mutableStateOf("") }
    OutlinedTextField(
    value = name,
    onValueChange = { name = it },
    label = { Text("Name") },
    )
    }
    =
    MutableState


    View Slide

71. Destructuring declarations
    @Composable
    fun NameInput() {
    val (name: String, setName: (String) -> Unit) remember { mutableStateO
    OutlinedTextField(
    value = name,
    onValueChange = { name = it },
    label = { Text("Name") },
    )
    }
    MutableState
    =


    View Slide

72. Destructuring declarations
    @Composable
    fun NameInput() {
    val (name: String, setName: (String) -> Unit) remember { mutableStateO
    OutlinedTextField(
    value = name,
    onValueChange = setName,
    label = { Text("Name") },
    )
    }
    MutableState
    =


    View Slide

73. Destructuring declarations
    interface MutableState : State {
    override var value: T
    operator fun component1(): T = value
    operator fun component2(): (T) -> Unit = { value = it }
    }
    @Composable
    fun NameInput() {
    val (name: String, setName: (String) -> Unit) remember { mutableStateO
    OutlinedTextField(
    value = name,
    onValueChange = setName,
    label = { Text("Name") },
    )
    }
    MutableState
    =


    View Slide

74. Destructuring declarations
    interface MutableState : State {
    override var value: T
    operator fun component1(): T = value
    operator fun component2(): (T) -> Unit = { value = it }
    }
    @Composable
    fun NameInput() {
    val (name: String, setName: (String) -> Unit) remember { mutableStateO
    OutlinedTextField(
    value = name,
    onValueChange = setName,
    label = { Text("Name") },
    )
    }
    MutableState
    =


    View Slide

75. Destructuring declarations
    ConstraintLayout {
    val (button, text) = createRefs()
    Button(
    onClick = { /* Do something */ },
    modifier = Modifier.constrainAs(button) {
    top.linkTo(parent.top, margin = 16.dp)
    }
    ) {
    Text("Button")
    }
    Text("Text", Modifier.constrainAs(text) {
    top.linkTo(button.bottom, margin = 16.dp)
    })
    }


    View Slide

76. ConstraintLayout {
    val (button, text) = createRefs()
    Button(
    onClick = { /* Do something */ },
    modifier = Modifier.constrainAs(button) {
    top.linkTo(parent.top, margin = 16.dp)
    }
    ) {
    Text("Button")
    }
    Text("Text", Modifier.constrainAs(text) {
    top.linkTo(button.bottom, margin = 16.dp)
    })
    }
    Destructuring declarations
    Button(ref = button)
    Text(ref = text)
    16.dp


    View Slide

77. ConstraintLayout {
    val (button, text) = createRefs()
    Button(
    onClick = { /* Do something */ },
    modifier = Modifier.constrainAs(button) {
    top.linkTo(parent.top, margin = 16.dp)
    }
    ) {
    Text("Button")
    }
    Text("Text", Modifier.constrainAs(text) {
    top.linkTo(button.bottom, margin = 16.dp)
    })
    }
    Destructuring declarations


    View Slide

78. ConstraintLayout {
    Button(
    onClick = { /* Do something */ },
    modifier = Modifier.constrainAs(button) {
    top.linkTo(parent.top, margin = 16.dp)
    }
    ) {
    Text("Button")
    }
    Text("Text", Modifier.constrainAs(text) {
    top.linkTo(button.bottom, margin = 16.dp)
    })
    }
    this: ConstraintLayoutScope
    this: ConstrainScope
    this: ConstrainScope
    Destructuring declarations
    val (button, text) = createRefs()


    View Slide

79. val (button, text) = createRefs()


    View Slide

80. val (button, text) = createRefs()
    ConstrainedLayoutReference


    View Slide

81. val (button, text) = createRefs()
    ConstrainedLayoutReferences
    ConstrainedLayoutReference


    View Slide

82. val (button, text) = createRefs()
    ConstrainedLayoutReferences
    ConstrainedLayoutReference
    @LayoutScopeMarker
    class ConstraintLayoutScope {
    fun createRefs() = referencesObject
    private var referencesObject: ConstrainedLayoutReferences = ...
    inner class ConstrainedLayoutReferences internal constructor() {
    operator fun component1() = createRef()
    operator fun component2() = createRef()
    operator fun component3() = createRef()
    operator fun component4() = createRef()
    ...
    operator fun component16() = createRef()
    }
    fun createRef() = ConstrainedLayoutReference(childId++)
    ...
    }


    View Slide

83. val (button, text) = createRefs()
    ConstrainedLayoutReferences
    ConstrainedLayoutReference
    @LayoutScopeMarker
    class ConstraintLayoutScope {
    fun createRefs() = referencesObject
    private var referencesObject: ConstrainedLayoutReferences = ...
    inner class ConstrainedLayoutReferences internal constructor() {
    operator fun component1() = createRef()
    operator fun component2() = createRef()
    operator fun component3() = createRef()
    operator fun component4() = createRef()
    ...
    operator fun component16() = createRef()
    }
    fun createRef() = ConstrainedLayoutReference(childId++)
    ...
    }


    View Slide

84. val (button, text) = createRefs()
    ConstrainedLayoutReferences
    ConstrainedLayoutReference
    @LayoutScopeMarker
    class ConstraintLayoutScope {
    fun createRefs() = referencesObject
    private var referencesObject: ConstrainedLayoutReferences = ...
    inner class ConstrainedLayoutReferences internal constructor() {
    operator fun component1() = createRef()
    operator fun component2() = createRef()
    operator fun component3() = createRef()
    operator fun component4() = createRef()
    ...
    operator fun component16() = createRef()
    }
    fun createRef() = ConstrainedLayoutReference(childId++)
    ...
    }


    View Slide

85. Strongly typed APIs


    View Slide

86. Strongly typed APIs


    View Slide

87. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    CenterHorizontally
    BottomStart


    View Slide

88. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    CenterHorizontally
    BottomStart
    Hello Compose!


    View Slide

89. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    CenterHorizontally
    Hello Compose!
    BottomStart
    TopCenter
    CenterEnd
    ...


    View Slide

90. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    CenterHorizontally
    Hello Compose!
    Hello Compose!
    BottomStart
    TopCenter
    CenterEnd
    ...


    View Slide

91. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    CenterHorizontally
    Start
    End
    BottomStart
    TopCenter
    CenterEnd
    ...
    Hello Compose!
    Hello Compose!


    View Slide

92. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    CenterHorizontally
    Start
    End
    BottomStart
    TopCenter
    CenterEnd
    ...


    View Slide

93. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    this: BoxScope
    this: ColumnScope
    CenterHorizontally
    Start
    End
    BottomStart
    TopCenter
    CenterEnd
    ...


    View Slide

94. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    this: BoxScope
    CenterHorizontally
    Start
    End
    BottomStart
    TopCenter
    CenterEnd
    ...
    Alignment
    this: ColumnScope
    Alignment.Horizontal


    View Slide

95. Strongly typed APIs
    Box {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    Column {
    Text(
    text = "Hello Compose!",
    modifier = Modifier.align(Alignment. )
    )
    }
    this: BoxScope
    Alignment
    CenterHorizontally
    BottomStart
    Alignment.Horizontal
    this: ColumnScope


    View Slide

96. ...
    ...
    @Stable
    fun interface Alignment {
    fun align(size: IntSize, space: IntSize,
    layoutDirection: LayoutDirection): IntOffset
    @Stable
    fun align(size: Int, space: Int,
    layoutDirection: LayoutDirection): Int
    }
    @Stable
    fun align(size: Int, space: Int): Int
    }
    }
    Strongly typed APIs
    fun interface Horizontal {
    fun interface Vertical {
    // 1D Alignment.Horizontals
    val Start: Horizontal = BiasAlignment.Horizontal(-1f)


    View Slide

97. companion object {
    // 2D Alignments
    val TopStart: Alignment = BiasAlignment(-1f, -1f)
    val TopCenter: Alignment = BiasAlignment(0f, -1f)
    val TopEnd: Alignment = BiasAlignment(1f, -1f)
    val CenterStart: Alignment = BiasAlignment(-1f, 0f)
    val Center: Alignment = BiasAlignment(0f, 0f)
    val CenterEnd: Alignment = BiasAlignment(1f, 0f)
    val BottomStart: Alignment = BiasAlignment(-1f, 1f)
    val BottomCenter: Alignment = BiasAlignment(0f, 1f)
    val BottomEnd: Alignment = BiasAlignment(1f, 1f)
    // ...
    }
    ...
    ...
    // 1D Alignment.Horizontals
    val Start: Horizontal = BiasAlignment.Horizontal(-1f)
    fun interface Alignment {
    }
    }
    }
    Strongly typed APIs
    fun interface Horizontal {
    fun interface Vertical {


    View Slide

98. val TopStart: Alignment = BiasAlignment(-1f, -1f)
    val TopCenter: Alignment = BiasAlignment(0f, -1f)
    val TopEnd: Alignment = BiasAlignment(1f, -1f)
    val CenterStart: Alignment = BiasAlignment(-1f, 0f)
    val Center: Alignment = BiasAlignment(0f, 0f)
    val CenterEnd: Alignment = BiasAlignment(1f, 0f)
    val BottomStart: Alignment = BiasAlignment(-1f, 1f)
    val BottomCenter: Alignment = BiasAlignment(0f, 1f)
    val BottomEnd: Alignment = BiasAlignment(1f, 1f)
    fun interface Alignment {
    fun interface Horizontal { ... }
    fun interface Vertical { ... }
    companion object {
    // 2D Alignments
    // ...
    }
    }
    Strongly typed APIs
    // 1D Alignment.Horizontals
    val Start: Horizontal = BiasAlignment.Horizontal(-1f)
    val CenterHorizontally: Horizontal = BiasAlignment.Horizontal(0f)
    val End: Horizontal = BiasAlignment.Horizontal(1f)
    // 1D Alignment.Verticals
    val Top: Vertical = BiasAlignment.Vertical(-1f)
    val CenterVertically: Vertical = BiasAlignment.Vertical(0f)
    val Bottom: Vertical = BiasAlignment.Vertical(1f)


    View Slide

99. ● Composing an API with Kotlin vol. 1
    ● Jetpack Compose: Debugging Recomposition
    ● Code search: Jetpack Compose
    ● Compose API guidelines
    ● Kotlin for Jetpack Compose
    goo.gle/composing-an-api-talk
    goo.gle/compose-debug-recomposition
    goo.gle/code-search-compose
    goo.gle/compose-api-guidelines
    goo.gle/kotlin-for-compose
    Resources


    View Slide

100. Thank You!
     Márton Braun
     @zsmb13
     Composing an API with Kotlin
     VOL.2


     View Slide
