Arteries of the Forearm

This presentation describes the Arteries of the Forearm

Transcript

1. ARTERIES OF FOREARM (Radial & Ulnar)
2. Brachial artery Radial artery Ulnar artery Flexor retinaculum
3. Revision of Skeleton and Muscles of Front of Forearm
4. Skeleton of Forearm
5. Neck of radius Interosseous membrane Opening for passage of anterior interosseous artery Passage of posterior interosseous artery
6. Muscles & Arteries of front of Forearm
7. Lateral Medial Biceps brachii m. Pronator teres m. Flexor carpi radialis m Palmaris longus m. Flexor carpi ulnaris m Flexor digitorum superficialis m Radial artery Ulnar artery Radial artery Brachial artery Tendon of biceps brachii Brachioradialis m.
8. Brachialis Pronator teres Flexor carpi radialis Palmaris longus Flexor carpi ulnaris Flexor digitorum superficialis Flexor retinaculum Med. Lat. Supinator m Brachioradialis m Tendon of biceps brachii
9. Pronator teres Flexor carpi radialis (cut) Palmaris longus (cut) Flexor carpi ulnaris (Cut) Flexor digitorum superficialis (cut) Flexor digitorum profundus Flexor pollicis longus Pronator quadratus Flexor retinaculum Brachioradialis (cut) Deep muscles of forearm Medial Lateral Interosseous membrane
10. Description of Any Artery ➢Definition. ➢Course. ➢Surface anatomy. ➢Relations. ➢Branches. ➢Anastomoses.
11. Definition •Radial artery is the lateral artery in the forearm. •Ulnar artery is the medial artery in the forearm.
12. Course of an Artery It begins …………….. It passes …………….. It ends ………………...
13. Beginning of Arteries of Forearm
14. Brachial art Neck of radius Ulnar art. Radial art. Tendon of biceps brachii m Lateral Medial Cubital fossa
15. Course of The Arteries of Forearm
16. Brachial artery Radial artery Ulnar artery & nerve Tendon of biceps Lateral Medial
17. Radial Artery It is the lateral artery in the forearm.
18. Course of Radial Artery
19. Brachial artery Tendon of biceps It leaves forearm by passing backwards below the lower end of radius to reach anatomical snuff box Lateral Medial It begins as a smaller terminal branch of brachial artery at level of neck of radius It passes downwards and laterally
20. Anatomical snuff box Radial artery
21. Anatomical snuff box
22. Surface Anatomy of Radial Artery in the Forearm
23. Point 1: 1 cm below line of elbow (flexion crease), medial to tendon of biceps brachii Point 2: Lower end of radius, lateral to tendon of flexor carpi radialis
24. Relations of Radial Artery ➢Superficial (anterior). ➢Deep (posterior). ➢Lateral. ➢Medial.
25. Superficial (anterior) Relations
26. Radial artery Brachioradialis m. (upper 2/3 of forearm) Lateral Medial Skin & Fascia (cubital fossa) Skin & fascia (lower 1/3 of forearm)
27. Deep (posterior) Relations
28. 1-Tendon of biceps m. 2-Supinator m. 3-Pronator teres m. 4-Radial head of flexor digitorum superficialis m. 5-Flexor pollicis longus m. 6-Pronator quadratus m. 7-Lower end of radius Lateral Medial
29. Medial Relations of Radial Artery
30. Pronator teres m. Radial artery Tendon of flexor carpi radialis m Lateral Medial
31. Lateral Relations of Radial Artery
32. Radial artery Brachioradialis m Lateral Medial
33. Radial artery Superficial radial nerve Brachio-radialis m.(cut) Medial Lateral
34. Ulnar Artery It is the medial artery of the forearm.
35. Course of Ulnar Artery
36. Brachial artery Ulnar artery & nerve Tendon of biceps Pisiform bone It begins as a larger terminal branch of brachial artery at level of neck of radius It leaves forearm by passing lateral to pisiform bone (superficial to flexor retinaculum) Lateral Medial It passes downwards and medially It passes downwards
37. Surface Anatomy of Ulnar Artery
38. Point 1: 1 cm below line of elbow (flexion line), medial to tendon of biceps Point 3: Just lateral to pisiform bone Point 2: Junction between upper 1/3 & lower 2/3 of a line between medial epicondyle and pisiform bone
39. Relations of ulnar artery ➢Superficial (anterior). ➢Deep (posterior). ➢Medial. ➢Lateral.
40. Superficial (Anterior) Relations
41. Pronator teres m Skin & fascia Flexor carpi radialis m Palmaris longus m. Flexor digitorum superficialis m. Flexor carpi ulnaris m Lateral Medial Upper 1/3 Middle 1/3 Lower 1/3
42. Deep (posterior) Relations
43. Brachialis m. Flexor digitorum profundus m. Tendons of flexor digitorum profundus m. Flexor retinaculum Medial
44. Medial & Lateral Relations
45. Median nerve Tendons of flexor digitorum superficialis Ulnar nerve Lateral Medial Tendon of flexor carpi ulnaris Ulnar artery
46. Lateral Medial Flexor carpi ulnaris m Flexor digitorum superficialis m Ulnar artery
47. Branches of Radial and Ulnar Arteries
48. Radial Artery Ulnar Artery In the Forearm 1- Radial recurrent 1- Anterior & posterior ulnar recurrent 2- Anterior carpal 2- Anterior & posterior carpal 3- Muscular 3- Muscular 4- Superficial palmar 4- Common interosseous Dr. Sherif Fahmy
49. Branches of radial & ulnar arteries in forearm Radial recurrent br. Anterior carpal br. Superficial palmar br. Anterior & posterior ulnar recurrent brs. Anterior carpal br. Posterior carpal br. Common interosseous art. Radial Artery Ulnar artery Dr. Sherif Fahmy Anterior interosseous art. Posterior interosseous art Interosseous membrane
50. Common Interosseous Artery
51. Ulnar artery Common interosseous artery Posterior interosseous art. Anterior interosseous art. Common Interosseous Artery Lateral Medial
52. Course & branches of anterior interosseous artery Common interosseous art. Posterior interosseous artery Median artery Descending br. Anterior interosseous artery Anterior carpal arch Nutrient to radius Nutrient to ulna Ulnar artery Interosseous membrane Median nerve Lateral Medial Pierces interosseous membrane
53. Interosseous recurrent br. Posterior interosseous art. Course & branches of posterior interosseous artery Lateral epicondyle Posterior descending br. of profunda brachii Supinator m. Abductor pollicis longus Posterior interosseous nerve End of posterior interosseous artery Lateral
54. Anastomosis around elbow
55. Profunda brachii art Superior ulnar collateral art Inferior ulnar collateral Ulnar artery Radial artery Anterior & posterior descending brs of profunda brachii Ant.& post. Ulnar recurrent arteries Radial recurrent art. Interosseous recurrent art Brachial art. Lateral Medial
56. Anastomoses of Radial & Ulnar Arteries ➢Around Elbow. ➢Carpal arches. ➢Palmar arches.
