Resiliency and Availability Design Patterns

We have traditionally built robust software systems by trying to avoid mistakes and by dodging failures when they occur in production or by testing parts of the system in isolation from one another. Modern methods and techniques take a very different approach based on resiliency, which promotes embracing failure instead of trying to avoid it. Resilient architectures enhance observability, leverage well-known patterns such as graceful degradation, timeouts and circuit breakers but also new patterns like cell-based architecture and shuffle sharding. In this session, will review the most useful patterns for building resilient software systems and especially show the audience how they can benefit from the patterns.

Transcript

1. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. N O R D I C S
2. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Resiliency and Availability Design Patterns for the Cloud Adrian Hornsby Sr. Technical Evangelist Amazon Web Services
3. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Distributed Systems are hard
4. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Complex systems Amazon Twitter Netflix
5. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Partial failure mode
6. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Resiliency: Ability for a system to handle and eventually recover from unexpected conditions
7. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. How do we build resilient software systems?
8. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. …
9. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. “Quality is not an act, it is a habit” Aristotle, some time around 350BC
10. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. https://aws.amazon.com/wellarchitected
11. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about Multi-AZ
12. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-AZ architecture Region Availability zone a Availability zone b Availability zone c Instances Instances Instances DB Instance DB instance standby
13. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-AZ architecture Region Availability zone a Availability zone b Availability zone c Instances Instances Instances DB Instance DB instance standby X
14. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-AZ architecture Region Availability zone a Availability zone b Availability zone c Instances Instances Instances DB Instance DB instance standby X
15. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-AZ architecture Region Availability zone a Availability zone b Availability zone c Instances Instances Instances DB Instance X
16. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-AZ architecture • Enables fault-tolerant applications • AWS regional services designed to withstand AZ failures • Leveraged by most AWS regional services (S3, DynamoDB, ELBs, …) Region Availability zone a Availability zone b Availability zone c Instances Instances Instances DB Instance DB instance standby
17. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region Availability zone a Availability zone b Availability zone c Application
18. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region Availability zone a Availability zone b Availability zone c Application
19. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Cascading Failures
20. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Better to react without reacting
21. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region Availability zone a Availability zone b Availability zone c Application
22. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. But Why?
23. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. 3 AZ’s is better than 2
24. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region Availability zone a Availability zone b Availability zone c Application Requires 8 Instances
25. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region Availability zone a Availability zone b Availability zone c Application Requires 6 Instances
26. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about auto scaling
27. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Auto-Scaling Fixed Variable
28. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Availability zone 1 Auto Scaling group AWS Region Availability zone 2 Auto-scaling for self-healing X
29. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
30. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about decoupling and async
31. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Process A Process B Process A Process B Synchronous Asynchronous Waiting Working Continues get or fetch result Get result Decoupling with async pattern
32. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. API: {DO foo} PUT JOB: {JobID: 0001, Task: DO foo} API: {JobID: 0001} GET JOB: {JobID: 0001, Task: DO foo} {JobID: 0001, Result: bar} Cache node Worker Instance Worker Instance Queue/Streaming API Instance API Instance API Instance
33. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Push Notification User Worker Instance Worker Instance API Instance API Instance Cache node Fetch results API Instance Queue/Streaming
34. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Degrade & prioritize traffic with queues Worker Instance Worker Instance API Instance API Instance API Instance High Priority Queue Low Priority Queue
35. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about timeouts, backoff & retries!
36. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Users App DB Conn Pool INSERT INSERT INSERT INSERT What happens if the DB “slows down”? Timeout client side Timeout backend side ? ?
37. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. User 1 App DB Conn Pool INSERT Timeout client side = 10s Timeout backend side = default = Infinite Retry INSERT Retry INSERT ERROR: Failed to get connection from pool Retry
38. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
39. https://dev.mysql.com/doc/connector-j/5.1/en/connector-j-reference-configuration-properties.html
40. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Set the timeouts!
41. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. How else could we have prevented the error? User 1 DB Conn Pool INSERT Retry INSERT Retry INSERT Retry ERROR: Failed to get connection from pool
42. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. User 1 DB Conn Pool INSERT Timeout client side = 10s Timeout backend side = 10s Wait 2s before Retry INSERT INSERT Wait 4s before Retry Wait 8s before Retry Wait 16s before Retry Backing off between retries Releasing connections Backoff
43. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. No jitter With jitter https://aws.amazon.com/blogs/architecture/exponential-backoff-and-jitter/ Simple Exponential Backoff is not enough: Add Jitter
44. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Example: add jitter 0-1000ms def get_item(self, url, n=1): MAX_TRIES = 12 try: res = requests.get(url) except: if n > MAX_TRIES: return None n += 1 time.sleep((2 ** n) + (random.randint(0, 1000) / 1000.0)) return self.get_item(url, n) else: return res
45. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Idempotent operation No additional effect if it is called more than once with the same input parameters.
46. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Circuit Breaker • Wrap a protected function call in a circuit breaker object, which monitors for failures. • If failures reach a certain threshold, the circuit breaker trips. Producer Circuit Breaker Consumer Connection Monitoring Timeouts Breaking Circuit
47. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. https://spring.io/guides/gs/circuit-breaker/
48. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about health checking!
49. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Auto Scaling group Service A Availability zone 1 Auto Scaling group AWS Region Service A Availability zone 2 Service B Service B database Email Probing for health Cluster
50. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shallow health check Instance Cache node Email database Cluster Are you healthy? yes
51. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shallow health check Instance Cache node Email database Cluster Are you healthy? yes
52. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Deep health check Instance Cache node Email database Cluster Are you healthy? yes Are you healthy? yes yes yes yes
53. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Deep health check Instance Cache node Email database Cluster Are you healthy? no Are you healthy? no yes yes yes
54. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Prioritize shallow health checks during hard times. Cache.
55. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about load shedding.
56. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
57. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
58. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Cheaply reject excess work
59. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
60. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Be careful when selecting the right metric
61. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Don’t be overly optimistic and take on more than you can. Find an operational metric to reject what you cannot take in. Favor cached and static content Prioritize ELB health check (shallow) pings In an overload situation you have precious resources, do not let any of it go to waste. Load Shedding
62. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Service Degradation & Fallbacks
63. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about databases!
64. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Database Federation Users DB Products DB Instance Instance Instance DB Instance DB instance read replica DB Instance DB instance read replica
65. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Database Sharding User ShardID 002345 A 002346 B 002347 C 002348 B 002349 A C B A Instance Instance Instance DB Instance DB instance read replica DB Instance DB instance read replica DB Instance DB instance read replica
66. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Read / Write separation DB Instance DB instance read replica DB instance read replica DB instance read replica Instance Instance Instance Supports degradation through Read-Only mode
67. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Transient state does not belong in the database.
68. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about shuffle sharding.
69. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
70. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. X X X X X X X X ♤ ♡ ♢ ⚀ ⚁ ⚂ ⚃ ♧ ♢
71. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Cascading Failures
72. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Measure for this: blast radius
73. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
74. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Cell-based architecture X X ♤ ♡ ♢ ⚀ ⚁ ⚂ ⚃ ♧ ♢
75. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shuffle sharding X X ♤ ♡ ♢ ⚀ ⚁⚂ ⚃ ♡ ♤ ♧ ♢ ⚀⚂ ♧ ⚁⚃ ♢ ♢ ♡ ♧ ♢
76. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shuffle sharding Nodes = 8 Shard size = 2 Combinations = 28 Overlap % customers 0 53.6% 1 42.8% 2 3.6%
77. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shuffle sharding Nodes = 100 Shard size = 5 Combinations = 75 million! Overlap % customers 0 77% 1 21% 2 1.8% 3 0.06% 4 0.0006% 5 0.0000013%
78. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shuffle sharding
79. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about chaos!
80. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Fire Drills
81. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. GameDay at Amazon Creating Resiliency Through Destruction https://www.youtube.com/watch?v=zoz0ZjfrQ9s
82. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Chaos engineering https://github.com/Netflix/SimianArmy
83. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. “Chaos Engineering is the discipline of experimenting on a distributed system in order to build confidence in the system’s capability to withstand turbulent conditions in production.” http://principlesofchaos.org
84. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Failure injection • Start small & build confidence • Application level • Host failure • Resource attacks (CPU, memory, …) • Network attacks (dependencies, latency, …) • Region attacks • “Paul” attack
85. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Plan for the worst, prepare for the unexpected.
86. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
87. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.
88. Thank you! © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Adrian Hornsby @adhorn https://medium.com/@adhorn https://speakerdeck.com/adhorn/patterns-for-building-resilient-software-systems-2019
