Modeling Pub/Sub system with F# and CQRS (on micro-scale)

Almost all APIs that are built in different companies have a lot in common, but when you have to open several projects, they are very different. Query and error handling, interaction with domain objects and infrastructure layers, etc. shouldn't be so different. All this fake difference only complicates the understanding of the components of the project and their interaction. In this talk, I will share how we build APIs that support different semantic models(Request/Response and Pub/Sub) and various protocols exchange (HTTP/WebSockets/AMQP). I will also try to unlock the potential of the CQRS architectural pattern and explain why we apply it to almost all API projects.

Transcript

1. Modeling Pub/Sub system
   with F#
   and CQRS (on micro scale)
   by @antyadev


   View Slide

2. The Problem
   Almost all APIs that are built in different companies have a lot in common, but
   when you have to open several projects, they are very different.
   Query and error handling, interaction with domain objects and infrastructure
   layers, etc. shouldn't be so different.
   All this fake difference only complicates the understanding of the components
   of the project and their interaction.


   View Slide

3. @antyadev
   antyadev@gmail.com


   View Slide

4. Data Feed
   WebSites/Terminals


   View Slide

5. Data Feed
   F#
   F#
   WebSites/Terminals
   F#


   View Slide

6. Agenda
   CQRS in 5 mins
   F# and CQRS(on micro scale)
   Advantages and disadvantages


   View Slide

7. CQRS


   View Slide

8. View Slide

9. View Slide

10. View Slide

11. View Slide

12. View Slide

13. CQRS
    (on micro scale)


    View Slide

14. Incidents


    View Slide

15. WebScokets
    DB


    View Slide

16. Subscribe


    View Slide

17. View Slide

18. { incident }


    View Slide

19. push
    { incident }


    View Slide

20. Command
    Command


    View Slide

21. Command Event


    View Slide

22. Incidents
    Domain


    View Slide

23. type IncidentType = Goal | Corner | Penalty | RedCard | YellowCard
    type ParticipantRole = Home | Away
    type Incident = {
    Id: IncidentId
    GameId: GameId
    Type: IncidentType
    ParticipantId: ParticipantId
    ParticipantRole: ParticipantRole option
    TimeInGame: DateTime
    GamePart: GamePart option
    }


    View Slide

24. type Query =
    | Incident of IncidentId
    | IncidentsForGames of GameId[] * IncidentType[] * LimitsParams
    type Command =
    | AddIncident of IncidentArgs
    | RemoveIncident of IncidentId
    | Subscribe of GameId[] * IncidentType[]
    | Unsubscribe of SubscriptionId
    type DomainEvent =
    | IncidentAdded of Incident * subscriptionsToNotify:SubscriptionId[]
    | IncidentRemoved of IncidentId
    | SubscriptionCreated of SubscriptionId
    | SubscriberAdded of SubscriptionId * subscribersCount:uint32
    | SubscriptionRemoved of SubscriptionId
    | SubscriberRemoved of SubscriptionId * subscribersCount:uint32


    View Slide

25. type ParserError =
    | GameIdFormat of originValues:string[]
    | IncidentIdFormat of originValues:string[]
    | IncidentTypeFormat of originValues:string[]
    type DomainError =
    | IncidentCantBeCreated of gameId:int * typeId:int
    | LimitsOutOfRange of top:int * maxTop:int * skip:int
    | GameNotFound of gameId:int
    | IncidentNotFound of incidentId:int
    | IncidentsForGamesNotFound of gameIds:int[]
    type AppError =
    | Parser of ParserError
    | Domain of DomainError
    static member create(e: ParserError) = e |> Parser
    static member create(e: DomainError) = e |> Domain
    static member createResult(e: DomainError) = e |> Domain |> Error
    static member createResult(e: ParserError) = e |> Parser |> Error


    View Slide

26. Project development with familiar backbone
    Domain | Commands | Queries | Events
    CommandHandler | QueryHandler
    CQRS
    (on micro scale)


    View Slide

27. In every project you will see
    the following structure
    CQRS
    (on micro scale)


    View Slide

28. Domain
    Queries
    Commands
    Events
    Errors
    Command Handler
    Query Handler


    View Slide

29. Command Handler
    CQRS
    (on micro scale)


    View Slide

30. Command Handler
    Command -> DomainEvent


    View Slide

31. Command Handler
    Command -> Result


    View Slide

32. Command Handler
    Command -> Async>


    View Slide

33. Command Handler
    Command -> Async>
    TOP LEVEL CONSTRAINT which force
    any new functionality to return result


    View Slide

34. type Command =
    | AddIncident of IncidentArgs
    | RemoveIncident of IncidentId
    | Subscribe of GameId[] * IncidentType[]
    | Unsubscribe of SubscriptionId
    type DomainEvent =
    | IncidentAdded of Incident * subscriptionsToNotify:SubscriptionId[]
    | IncidentRemoved of IncidentId
    | SubscriptionCreated of SubscriptionId
    | SubscriberAdded of SubscriptionId * subscribersCount:uint32
    | SubscriptionRemoved of SubscriptionId
    | SubscriberRemoved of SubscriptionId * subscribersCount:uint32


    View Slide

35. let handle (command) =
    match command with
    | AddIncident args -> DomainEvent.IncidentAdded
    | RemoveIncident id -> DomainEvent.IncidentRemoved
    | Subscribe (gamesIds, incTypes) -> DomainEvent.SubscriptionCreated
    | Unsubscribe id -> DomainEvent.SubscriptionRemoved
    type Command =
    | AddIncident of IncidentArgs
    | RemoveIncident of IncidentId
    | Subscribe of GameId[] * IncidentType[]
    | Unsubscribe of SubscriptionId
    type DomainEvent =
    | IncidentAdded of Incident * subscriptionsToNotify:SubscriptionId[]
    | IncidentRemoved of IncidentId
    | SubscriptionCreated of SubscriptionId
    | SubscriberAdded of SubscriptionId * subscribersCount:uint32
    | SubscriptionRemoved of SubscriptionId
    | SubscriberRemoved of SubscriptionId * subscribersCount:uint32


    View Slide

36. type CommandHandler(storage: IStorage, subscriptions: Subscriptions) =
    let handle (command) = asyncResult {
    match command with
    | AddIncident params ->
    let! game = storage.FindGame(params.GametId) with
    match game with
    | Some game ->
    let! event = IncidentDomain.add(params, game, subscriptions)
    publishEvent(event)
    return event
    | None -> return! GameNotFound(params.GametId) |> AppError.create
    }
    member x.Handle(command) = handle(command)


    View Slide

37. type CommandHandler(storage: IStorage, subscriptions: Subscriptions) =
    let handle (command) = asyncResult {
    match command with
    | AddIncident params ->
    let! game = storage.FindGame(params.GametId) with
    match game with
    | Some game ->
    let! event = IncidentDomain.add(params, game, subscriptions)
    publishEvent(event)
    return event
    | None -> return! GameNotFound(params.GametId) |> AppError.create
    }
    member x.Handle = handle


    View Slide

38. type CommandHandler(storage: IStorage, subscriptions: Subscriptions) =
    let handle (command) = asyncResult {
    match command with
    | AddIncident params ->
    match! storage.FindGame(params.GametId) with
    | Some game ->
    let! event = IncidentDomain.add(params, game, subscriptions)
    publishEvent(event)
    return event
    | None -> return! GameNotFound(params.GametId) |> AppError.create
    }
    member x.Handle = handle


    View Slide

39. type CommandHandler(storage: IStorage, subscriptions: Subscriptions) =
    // handle: Command -> Async>
    let handle (command) = asyncResult {
    match command with
    | AddIncident params ->
    match! storage.FindGame(params.GametId) with // Task>
    | Some game ->
    // Result
    let! event = IncidentDomain.add(params, game, subscriptions)
    publishEvent(event)
    return event
    | None -> return! GameNotFound(params.GametId) |> AppError.create
    }
    member x.Handle = handle


    View Slide

40. type CommandHandler(storage: IStorage, subscriptions: Subscriptions) =
    // handle: Command -> Async>
    let handle (command) = asyncResult {
    match command with
    | CreateIncident params ->
    match! storage.FindGame(params.GametId) with // Task>
    | Some game ->
    // Result
    let! event = IncidentDomain.add(params, game, subscriptions)
    publishEvent(event)
    return event
    | None -> return! GameNotFound(params.GametId) |> AppError.create
    }
    member x.Handle = handle


    View Slide

41. type CommandHandler(storage: IStorage, subscriptions: Subscriptions) =
    let eventStream = new Subject()
    let publishEvent (event) = eventStream.OnNext(event)
    // handle: Command -> Async>
    let handle (command) = asyncResult {
    match command with
    | CreateIncident params ->
    match! storage.FindGame(params.GametId) with // Task>
    | Some game ->
    // Result
    let! event = IncidentDomain.add(params, game, subscriptions)
    publishEvent(event)
    return event
    | None -> return! GameNotFound(params.GametId) |> AppError.create
    }
    member x.Handle = handle
    member x.EventStream = eventStream :> IObservable


    View Slide

42. type CommandHandler(storage: IStorage, subscriptions: Subscriptions) =
    let eventStream = new Subject()
    let publishEvent = eventStream.OnNext
    // handle: Command -> Async>
    let handle (command) = asyncResult {
    match command with
    | CreateIncident params ->
    match! storage.FindGame(params.GametId) with // Task>
    | Some game ->
    // Result
    let! event = IncidentDomain.add(params, game, subscriptions)
    publishEvent(event)
    return event
    | None -> return! GameNotFound(params.GametId) |> AppError.create
    }
    member x.Handle = handle
    member x.EventStream = eventStream :> IObservable


    View Slide

43. Command Handler
    Handle: Command -> Async
    EventStream: IObservable
    WebScokets


    View Slide

44. Command Handler
    WebSockets Middleware AMQP Middleware
    connections
    connections
    EventStream: IObservable
    Dictionary
    Dictionary


    View Slide

45. Command Handler
    IncidentAddedEvent {
    SubscriptionId = 5,6,7
    Incident: { … }
    }
    EventStream: IObservable
    WebSockets Middleware AMQP Middleware
    connections
    connections
    Dictionary
    Dictionary


    View Slide

46. Decoupled components
    via Pub/Sub messaging (IObservable)
    publishEvent(event)
    CQRS
    (on micro scale)


    View Slide

47. Query Handler
    CQRS
    (on micro scale)


    View Slide

48. Query Handler
    Query -> Async>


    View Slide

49. type QueryHandler(storage: InStorage) =
    let response (incidents: Incident[]) =
    incidents |> Array.map(Incident.toContractType)
    let handle (query) = asyncResult {
    match query with
    | Incident id ->
    match! storage.FindIncident(id) with
    | Some incident -> return response [| incident |]
    | None -> return response(Array.empty)
    }
    member x.Handle = handle


    View Slide

50. API Response
    CQRS
    (on micro scale)


    View Slide

51. Your Server as a function
    CQRS
    (on micro scale)


    View Slide

52. Your Server as a function
    HttpRequest -> HttpResponse


    View Slide

53. Your Server as a function
    HttpRequest -> Async


    View Slide

54. Your Server as a function
    HttpRequest -> Query -> QueryHandler -> Async


    View Slide

55. Your Server as a function
    HttpRequest -> Query
    -> QueryHandler
    -> Async>
    -> Async


    View Slide

56. HttpRequest -> Query
    -> QueryHandler
    -> Async>
    -> Async
    WebSocketRequest -> Query
    -> QueryHandler
    -> Async>
    -> Async
    AMQPRequest -> Query
    -> QueryHandler
    -> Async>
    -> Async


    View Slide

57. HttpRequest -> Query
    -> QueryHandler
    -> Async>
    -> Async
    WebSocketRequest -> Query
    -> QueryHandler
    -> Async>
    -> Async
    AMQPRequest -> Query
    -> QueryHandler
    -> Async>
    -> Async


    View Slide

58. Error
    responses


    View Slide

59. type ParserError =
    | GameIdFormat of originValues:string[]
    | IncidentIdFormat of originValues:string[]
    | IncidentTypeFormat of originValues:string[]
    type DomainError =
    | IncidentCantBeCreated of gameId:int * typeId:int
    | LimitsOutOfRange of top:int * maxTop:int * skip:int
    | GameNotFound of gameId:int
    | IncidentNotFound of incidentId:int
    | IncidentsForGamesNotFound of gameIds:int[]
    type AppError =
    | Parser of ParserError
    | Domain of DomainError
    static member create(e: ParserError) = e |> Parser
    static member create(e: DomainError) = e |> Domain
    static member createResult(e: DomainError) = e |> Domain |> Error
    static member createResult(e: ParserError) = e |> Parser |> Error


    View Slide

60. module HTTPErrorResponse =
    let map (error: AppError) = ...
    let fromDomainError (error: DomainError) =
    match error with
    | IncidentCantBeCreated ->
    new HttpResponseMessage(HttpStatusCode.BadReqeust, { ... })
    let fromParserError (error: ParserError) =
    match error with
    | GameIdFormat ids ->
    new HttpResponseMessage(HttpStatusCode.BadReqeust, { ... })
    | IncidentIdFormat ids ->
    new HttpResponseMessage(HttpStatusCode.BadReqeust, { ... })
    match error with
    | Domain e -> fromDomainError(e)
    | Parser e -> fromParserError(e)


    View Slide

61. Testing


    View Slide

62. Input -> Output
    Command -> Event


    View Slide

63. []
    let ``CommandHandler on AddIncident should return IncidentAdded if related game exist`` () =
    let cmdHandler = TestHelper.createCommandHandler()
    let game = TestHelper.createGame(id = 777)
    let incident = TestHelper.createIncident(id = 1, gameId = 777)
    asyncResult {
    let! gameEvent = Command.AddGame(game) |> cmdHandler.Handle
    let! incidentEvent = Command.AddIncident(incident) |> cmdHandler.Handle
    test <@ match incidentEvent with
    | IncidentAdded _ -> true
    | _ -> false @>
    }
    |> TestHelper.runTest


    View Slide

64. What about
    non-trivial cases
    with no output?


    View Slide

65. Testing
    Log Events


    View Slide

66. logger.Warning("Test message")
    logger.Warning("Test message")
    logger.Warning("Test message")
    InMemoryLogger
    .Should()
    .HaveMessage("Test message")
    .Appearing().Times(3)
    .WithLevel(LogEventLevel.Information)


    View Slide

67. []
    let ``Agent should be able to reconnect automatically and join the cluster`` () = async {
    let coordinatorDep = Dependency.createFor(NodeType.Coordinator)
    let (agentDep, loggerBuffer) = Dependency.createWithInMemoryLogger(NodeType.Agent)
    let server = MqttTests.startMqttServer()
    // we start one agent
    let! agent = Agent.init(agentDep, [| scenario |], agentSettings)
    Agent.startListening(agent) |> Async.Start
    // we stop mqtt server
    MqttTests.stopMqttServer server
    // and wait some time
    do! Async.Sleep(5_000)
    // spin up the mqtt server again to see that agent will reconnect
    let server = MqttTests.startMqttServer()
    let! coordinator = Coordinator.init(coordinatorDep, [| scenario |], coordinatorSettings,
    [| scenarioSettings |], customSettings)
    // waiting on reconnect
    do! Async.Sleep(2_000)
    let! statsResult = Coordinator.run(coordinator)
    let allStats = statsResult |> Result.defaultValue Array.empty


    View Slide

68. Property based
    testing


    View Slide

69. Property based testing
    []
    let ``Subscription filter correctness verification`` (allTypes: IncidentType[],
    typesToSubscribe: IncidentType[]) =
    type IncidentType = Goal | Corner | Penalty | RedCard | YellowCard


    View Slide

70. Property based testing
    allTypes: [Goal; Corner; Penalty],
    typesToSubscribe: [Corner]) =
    type IncidentType = Goal | Corner | Penalty | RedCard | YellowCard


    View Slide

71. Property based testing
    allTypes: [Goal; Corner; Penalty; Corner;],
    typesToSubscribe: [RedCard; YellowCard]) =
    type IncidentType = Goal | Corner | Penalty | RedCard | YellowCard


    View Slide

72. []
    let ``Subscription filter corectness verification`` (game: Game,
    allTypes: IncidentType list,
    typesToSubscribe: IncidentType list) =
    let cmdHandler = createCmdHandler()
    let incidents = allTypes
    |> List.map(fun x -> TestHelper.createIncidents(event)
    Command.AddGame(game) |> cmdHandler.Handle |> ignore
    Command.Subscribe([|game.Id|], typesToSubscribe) |> cmdHandler.Handle |> ignore
    let receivedIncidents =
    incidents
    |> List.map(fun x -> Command.AddIncident(x) |> cmdHandler.Handle
    |> retrieveIncidents
    |> List.sum
    let shouldReceive =
    if List.isEmpty(typesToSubscribe) // subscribed on all types
    then incidents.Length
    else
    let machedTypes = Set.intersect (set allTypes) (set typesToSubscribe)
    incidents
    |> List.choose(fun x -> if machedTypes.Contains(enum x.IncidentTypeId) then
    Some 1 else None)
    |> List.sum
    receivedIncidents = shouldReceive


    View Slide

73. Part III
    Advantages and disadvantages


    View Slide

74. We stopped
    write frameworks
    with unlimited extensibility
    to cover cases from future


    View Slide

75. We stopped
    write frameworks
    No abstract factories
    No factory method


    View Slide

76. We stopped
    write frameworks
    No interfaces per class


    View Slide

77. We stopped
    write frameworks
    No interfaces like
    ISimpleIdentifiable


    View Slide

78. We stopped
    write frameworks
    Instead, we build our private
    world where we know everything


    View Slide

79. Simpler reading
    let publishMsg = Json.serialize
    >> Zip.compress
    >> RabbitMq.createMsg topicName
    >> client.Publish


    View Slide

80. Simpler reading
    let validate (context: NBomberContext) =
    context.Scenarios
    |> checkEmptyName
    >>= checkDuplicateName
    >>= checkEmptyStepName
    >>= checkDuration
    >>= checkConcurrentCopies
    >>= fun _ -> Ok context
    |> Result.mapError(AppError.create)


    View Slide

81. Simpler testing


    View Slide

82. Type Driven
    Development


    View Slide

83. module CardGame =
    type Suit = Club | Diamond | Spade | Heart
    type Rank = Two | Three | Four | Five | Six | Seven | Eight
    | Nine | Ten | Jack | Queen | King | Ace
    type Card = Suit * Rank
    type Hand = Card list
    type Deck = Card list
    type Player = { Name:string; Hand:Hand}
    type Game = {Deck:Deck; Players: Player list}
    type Deal = Deck -> (Deck*Card)
    type PickupCard = (Hand*Card) -> Hand


    View Slide

84. Anonymous Types
    let data = {| X = 1; Y = 2 |}
    let data1 = {| data with Y = 3 |} // {| X:Int; Y:Int |}
    let data2 = {| data with Z = 3 |} // {| X:Int; Y:Int; Z:Int |}


    View Slide

85. type User = { Age: int }
    let user = { Age = 1 }
    let anonymous = {| user with Y=1 |} // {| Age:Int; Y:Int |}
    Anonymous Types


    View Slide

86. Expressive API
    with
    Explicit Effects


    View Slide

87. Option - to represent cases when something may exist
    but also may not.
    Result - to represent operations which could
    be success or fail.
    Choice - to model operations which return
    different values depending on the input
    Async - to represent asynchronicity as an effect (in
    addition people quite often use F# Async to model
    impure operations as alternative to IO monad)


    View Slide

88. Previously working in C# we
    were forced
    to use name conventions


    View Slide

89. // if method starts with Find then in case of not found
    // it returns null
    public User FindUser(int userId)
    // if method starts with Get then in case of not found
    // it throws Exception
    public User GetUser(int userId)


    View Slide

90. // if method starts with Try
    // it means that operation can fail and
    // and exception will be not thrown
    public bool TryParse(string json, out Config config)
    // in this case the exception will be thrown
    public Config Parse(string json)


    View Slide

91. let findUser (userId): Async, AppError>>
    let parse (json): Result


    View Slide

92. Monad
    Comprehensions


    View Slide

93. option {
    let! x = getSomething()
    let! y = getSomethingElse()
    let! z = andYetGetSomethingElse()
    // Code will only hit this point if the three
    // operations above return Some value
    return x + y + z
    }


    View Slide

94. type QueryHandler(storage: IStorage) =
    let handle (query) = asyncResult {
    match query with
    | Incidents (eventIds, incidentTypes, limits) ->
    // vLimits: Result
    let! vLimits = QueryValidation.validateLimits(limits)
    // incidents: Async>
    let! incidents = storage.FindIncidents(eventIds, incidentTypes, vLimits)
    let data = incidents |> Array.map(Incident.toContractType)
    return { Data = data }
    }
    member x.Handle = handle


    View Slide

95. THANKS
    @antyadev
    antyadev@gmail.com


    View Slide
