An Emerging Architecture Pattern for Agile Integration: Cell-based Architecture

A cell-based architecture is a composable unit of architecture that is self-contained. The cell is independently scalable. It’s independently deployable. It’s independently governed. It is part of an ecosystem of cells. A cell-based architecture is a common pattern that any enterprise can connect architecture, implementation, and deployment by making autonomous development teams, self-directed, that own their own technology, completely independent of others.

Transcript

1. INTEGRATION SUMMIT 2019 Emerging Architecture Patterns API-centric & Cell-based INTEGRATION Asanka Abeysinghe Deputy CTO & VP, Architecture - CTO Office
2. Objectives #1 look at: API-centric #2 introduce: Cell-based architecture
3. picture credit: https://www.flickr.com/
4. Motivation
5. Centralized & Layered picture credit: https://www.flickr.com/photos/kaktuslampa/
6. Not enough support for Agility
7. picture credit: https://www.flickr.com/photos/69929929@N06/ Powerpoint Architects
8. picture credit: https://www.flickr.com/photos/johnerlandsen/ Reality of the Enterprise
9. Brownfield > Greenfield picture credit: https://www.apstra.com/home/landscape-of-meadow-field-with-the-changing-environment-2/ Legacy, monolithic Microservices, sprawl
10. Reference Implementations picture credit: https://www.marinersmuseum.org/
11. picture credit: http://unlocked.footlocker.com/ Underutilization of the Technology
12. Gap: architecture | development | deployment picture credit: https://www.flickr.com/photos/28994379@N02/
13. picture credit: https://www.solarpowerworldonline.com/2017/07/georgia-contractor-sells-farmers-solar-tough-market/ Dependency management
14. picture credit: https://www.flickr.com/photos/tiocfaidh_ar_la_1916/ Architecture Patterns
15. Timeline
16. Background: Layered Architecture
17. picture credit: https://www.flickr.com/photos/23119666@N03/ A platform with an agile team 100 APIs, 60 message flows, 80 services, n DBs Multi-tenanted, 3 active tenants First release after 3 years
18. picture credit: https://www.flickr.com/photos/imcountingufoz/ Rise of Microservices
19. Pragmatic Microservices Netflix: APIs Uber: Edge Gateway eBay: API Facade Gartner: Mini Services
20. Background: Layered Architecture with MSA
21. Background: Segmented Architecture BS-1 BS-2 BS-n G-1 G-2 US-1 US-n
22. Platform of Platforms Platform (shared capabilities) Project 1 Project 2 Project 3 Project n Platform (shared capabilities) Project 1 Project 2 Project 3 Project n Platform (shared capabilities) Project 1 Project 2 Project 3 Project n Platform (shared capabilities) Project 1 Project 2 Project 3 Project n CI/CD User Store
23. API Maturity Model Technical APIs Partially Business APIs Business APIs Isolated Applications Unstructured Integration Module-based Architecture Service- oriented Architecture (SOA) Microservice Architecture (MSA) Open APIs APIs as a Business Monolithic Applications Sockets File Sharing Message Que. DB Replication EJB RMI COM/COM+ CORBA WebDev SOAP ESB BPEL BAM REST AMQP MQTT WAF REST OAS ServiceMesh gRPC GraphQL
24. picture credit: https://www.flickr.com/photos/ableman/
25. Making of…… picture credit: https://commons.wikimedia.org/wiki/User:Frank_Schulenburg CC BY 3.0
26. picture credit: https://www.cricindex.com/john-buchanan-cricket-coach/
27. 2014 2018
29. Building the Concept
30. Business vs technical services picture credit: https://www.flickr.com/photos/arpadlukacs/
31. Service: Technical definition A code exposes through an interface that describes a collection of operations that are network accessible using a standardized messaging protocol.
32. Service: Business definition Software components that can be spontaneously discovered, combined, and recombined to provide a solution to a business problem.
33. Microservice: Technical definition A microservice must have a single purpose and be loosely coupled in design and deployed independently of other microservices. "Micro" is a concept of scope rather than size.
34. Microservice: Business definition Microservices is an approach to application development in which a large application is built as a suite of modular components or services. These services are built around business capabilities.
35. Group of (Micro)services
36. The cell is the basic structural, functional, and biological unit of all known living organisms
37. Cell-based Reference Architecture
38. Component: Atomic Units A component represents a process or business logic running in a container, serverless environment, or an existing runtime. A component is designed based on a specific scope, which can be independently run and reused at the runtime.
39. Cell: Units of Enterprise Architecture A cell is a collection of components, grouped from design and implementation into deployment. A cell is independently deployable, manageable, and observable.
40. Cell: Units of Enterprise Architecture A cell is an immutable application component that can be built, deployed and managed as a complete unit. The cell consists of multiple services, managed APIs, ingress and egress policies (including routing, throttling, access control), security trust domain, deployment policies, rolling update policies and external dependencies. The cell definition captures all of these in a standard technology- neutral fashion.
41. Cell:Component 1:M 1:1
42. Connected Cells picture credit: https://www.medicalnewstoday.com/
43. Control Plane: - Signaling of the network - Makes decisions about the traffic flow Data Plane: - Forwards traffic between hops - Takes data packets picture credit: https://www.flickr.com/photos/teflon/ Management Plane: - Configure - Observeabiltty, Monitor
44. Inter and Intra Cell communication Cell-mesh Global-mesh
45. Connected Cells Cell gateway (ingress) Sidecar (egress) Adaptor (egress) Ambassador (egress)
46. API-centric Architecture Pull APIs - RESTful HTTP, gRPC Push APIs - Events JMS, AMQP, SMTP - Streams Kafka, MQTT
47. Gateway Pattern picture credit: https://www.flickr.com/photos/ell-r-brown/
48. Automated Governance (Re)-enables Flow Policy Store (Registry) Observability (Monitoring/
 Analytics) Policy
 Enforcement (GW) Automated governance is made of three things: A source of truth: Policy store/registry Enforcement of the policy Gateway or plugin attempting to keep the desired state Observability How close to the desired state are we?
49. Security of Cells picture credit: https://www.flickr.com/photos/laurelfan/ https://www.flickr.com/photos/sahdblunders/
50. Security of Cells
51. Developer Experience (DX) of a Cell
52. Creating Cells Brand new Cell Existing (micro)services Update an existing Cell Create a new version
54. Lifecycle of a Cell
56. picture credit: https://www.flickr.com/photos/rincon_de_lula/
57. Structured Agility Versioned Components Versioned Cells Dependency managed Autowired Reusable Enhanced MSA & CNA
58. Cell-based Enterprise Architecture
60. Cell Types Cell Type Components Logic Microservices, Functions, MicroGateways, lightweight storages Integration MicroESB or other integration microservices, lightweight storage and/or cache Legacy Existing systems, legacy services External SaaS and partner systems Data RDBMS, NoSQL, File, Message Broker* Identity IDP, user stores Channel Web Apps, IoT, mobile apps
61. Reference Implementation L0
63. Reference Implementation L1
65. Cells and Podular Organizations
66. Self-contained Deployable as a unit Independently elastic Data, control & management plane Summary: Cell-based Architecture
67. picture credit: https://www.flickr.com/photos/josephmorris/ Just a (steady) start https://github.com/wso2/reference-architecture
68. INTEGRATION SUMMIT 2019 “Organizations which design systems … are constrained to produce designs which are copies of the communication structures of these organizations.” - M. Conway
69. INTEGRATION SUMMIT 2019 THANK YOU wso2.com @asankama
