Intro to Reactive programming in iOS using RxSwift

Intro to Reactive programming in iOS using RxSwift

Presentation of my talk @SwiftCairo Meetup about the reactive programming
what, why and how to use it in iOS.

Attia Mo

April 24, 2019
Tweet

More Decks by Attia Mo

Other Decks in Programming

Transcript

  1. A t t i a M o
    Quick Tips For Writing
    RxSwift.
    @AttiaMoTheDev

    View Slide

  2. A t t i a M o
    !#
    @AttiaMoTheDev

    View Slide

  3. A t t i a M o @AttiaMoTheDev
    $ Reactive Programming %
    & ReactiveX '
    ( RxSwift )
    * RxSwift ⌚﹠
    - Community
    / Resources
    Agenda .

    View Slide

  4. A t t i a M o @AttiaMoTheDev
    $ Reactive
    programming %.

    View Slide

  5. A t t i a M o @AttiaMoTheDev
    https://en.wikipedia.org/wiki/Reactive_programming

    View Slide

  6. A t t i a M o @AttiaMoTheDev

    View Slide

  7. A t t i a M o

    @AttiaMoTheDev
    ⚫ “Data streams and the propagation of change”.
    ⚫ “Event Based Model”.
    ⚫ “Asnyc Sequence Of Events”.

    View Slide

  8. A t t i a M o @AttiaMoTheDev
    & ReactiveX
    '

    View Slide

  9. A t t i a M o @AttiaMoTheDev
    http://reactivex.io

    View Slide

  10. A t t i a M o @AttiaMoTheDev
    http://reactivex.io

    View Slide

  11. WHAT’S YOUR
    LANGUAGE?

    A t t i a M o @AttiaMoTheDev

    View Slide

  12. A t t i a M o @AttiaMoTheDev
    ( RxSwift ⌚﹠

    View Slide

  13. Why to use RxSwift? Benefits and use cases
    Synchronize two requests ⏬
    However, despite the obvious powerful capabilities
    of KVO, the RXSwift creators solve this issue
    radically by minimizing the necessity to involve this
    API at all.
    Delegates required keeping in mind a huge amount
    of information, RxSwift managed to solve this
    problem completely. This library had introduced the
    ability to write code in the declarative style without
    increasing the size of the UIViewController and
    requiring the objc

    You’re bored of KVO/Delegates
    RP leads to writing less code.

    Since you can react to events in a declarative way you
    can avoid certain complications. Like nested callbacks,
    delegates, notifications, etc. For example, in the previous
    login process.

    Since Rx streams are immutable, you can just react to
    changes and create objects that are open to extensions
    and closed to modifications.

    Rx in MVVM and other MVC improvements like VIPER.
    You can bind objects of different architecture layers and
    the architecture remains clean.
    Cleaner Code & Architectures.
    Providing the synchronization for the calls can be
    difficult even for an experienced developer.

    If you are using RxSwift, you can simply use
    a zip operator that would combine the two
    observables and send an answer at the end of
    processing two API requests.
    A t t i a M o @AttiaMoTheDev
    https://medium.com/@leandromperez/why-use-rxswift-a176b553a705

    https://applikeysolutions.com/blog/rxswift-benefits-and-use-cases

    View Slide

  14. Why to use RxSwift? Benefits and use cases
    https://medium.com/@leandromperez/why-use-rxswift-a176b553a705

    https://applikeysolutions.com/blog/rxswift-benefits-and-use-cases
    Multi-threading is simplified.
    The structures provide different ways of
    publishing information. For instance, a
    PublishSubject or a BehaviorSubject. They are
    different ways of channeling events. The
    operations transform, decorate, compose, etc, the
    information. Like map, filter, concat, etc. The key is
    that everyone can use the same structures and
    operations. No matter what they put in them.
    Modular Code?
    Reactive programming is a way of working, it’s a
    design pattern, or a set of them for all that
    matters. You can create reusable compassable
    components because of the standard structures
    and operations. The same standardization comes
    in different languages and platforms. So If you
    learn Reactive Programming in Swift, you can take
    it with you to another platform and language.
    Multi-platform?
    Using RxSwift, you can react to changes on different
    threads. You do this with a lot less code, less
    complexity, less bugs. You can listen to an event on
    the main thread and react in background. Finally you
    can go back to the main thread to show the results.
    The resulting code can be very simple: you observeOn
    different Schedulers.
    A t t i a M o @AttiaMoTheDev

    View Slide

  15. A t t i a M o @AttiaMoTheDev
    * RxSwift )

    View Slide

  16. A t t i a M o @AttiaMoTheDev

    View Slide

  17. Observables are the heart of Rx. You’re
    going to spend some time discussing what
    observables are, how to create them, and
    how to use them.
    What is an
    observable?
    Observables.
    A t t i a M o @AttiaMoTheDev

    View Slide

  18. Lifecycle of an
    observable
    A t t i a M o @AttiaMoTheDev
    • An observable emits next events that
    contain elements. It can continue to do this
    until it either:
    • emits an error event and is terminated, or
    • emits a Completed event and is terminated.
    • Once an observable is terminated, it can no
    longer emit events.
    Observable Lifecycle

    View Slide

  19. A t t i a M o @AttiaMoTheDev
    • An observable emits next events that
    contain elements. It can continue to do this
    until it either:
    • emits an error event and is terminated, or
    • emits a Completed event and is terminated.
    • Once an observable is terminated, it can no
    longer emit events.
    Observable Lifecycle

    View Slide

  20. something that can act as
    both an observable and as an
    observer. And that something
    is called a Subject.
    What is Subjects?
    Subjects.
    A t t i a M o @AttiaMoTheDev

    View Slide

  21. • PublishSubject: Starts empty and only emits
    new elements to subscribers.
    • BehaviorSubject: Starts with an initial value and
    replays it or the latest element to new subscribers.
    • ReplaySubject: Initialized with a buffer size and
    will maintain a buffer of elements up to that size
    and replay it to new subscribers.
    • Variable: Wraps a BehaviorSubject, preserves
    its current value as state, and replays only the
    latest/initial value to new subscribers.
    Four subject types in
    RxSwift
    Subjects Types.
    A t t i a M o @AttiaMoTheDev

    View Slide

  22. A t t i a M o @AttiaMoTheDev

    View Slide

  23. Operators are the building blocks of Rx,
    which you can use to transform, process,
    and react to events emitted by observables.
    Just as you can combine simple arithmetic
    operators like +, -, and / to create complex
    math expressions, you can chain and
    compose together Rx's simple operators to
    express complex app logic.
    What is an
    Operators?
    Operators.
    A t t i a M o @AttiaMoTheDev

    View Slide

  24. Filtering Operators
    Transforming Operators
    Combining Operators
    Time Based Operators
    Operators Types
    Operators.
    A t t i a M o @AttiaMoTheDev

    View Slide


  25. A t t i a M o @AttiaMoTheDev

    View Slide


  26. A t t i a M o @AttiaMoTheDev

    View Slide


  27. A t t i a M o @AttiaMoTheDev

    View Slide


  28. A t t i a M o @AttiaMoTheDev

    View Slide


  29. A t t i a M o @AttiaMoTheDev

    View Slide

  30. Considering that schedulers are simply a
    context, which could be anything (a
    dispatch queue, thread, or a custom
    context), and that all operators
    transforming sequences need to preserve
    the implicit guarantees, you need to be
    sure you’re using the right scheduler.
    Schedulers.
    Schedulers.
    A t t i a M o @AttiaMoTheDev

    View Slide


  31. A t t i a M o @AttiaMoTheDev

    View Slide

  32. RxTest is a separate library from RxSwift. It’s
    hosted within the RxSwift repo but requires a
    separate pod install and import. RxTest
    provides many useful additions for testing
    RxSwift code, such as TestScheduler, which is
    a virtual time scheduler that gives you
    granular control over testing time-linear
    operations, and methods including next(_:_:),
    completed(_:_:), and error(_:_:)
    RxTest
    RxTest.
    A t t i a M o @AttiaMoTheDev

    View Slide


  33. A t t i a M o @AttiaMoTheDev

    View Slide

  34. A t t i a M o @AttiaMoTheDev
    - Community

    View Slide

  35. A t t i a M o @AttiaMoTheDev
    https://github.com/RxSwiftCommunity

    View Slide

  36. A t t i a M o @AttiaMoTheDev
    https://github.com/RxSwiftCommunity

    View Slide

  37. A t t i a M o @AttiaMoTheDev
    / Resources

    View Slide

  38. https://store.raywenderlich.com/products/rxswift
    RW-Book, Marin Todorov account and all the book
    authors.
    Realm Academy, Rxmarbles

    A t t i a M o @AttiaMoTheDev

    View Slide


  39. A t t i a M o @AttiaMoTheDev
    Learn & Master ⚔ the Basics of RxSwift in 10 Minutes
    https://rxmarbles.com/#throttle
    https://academy.realm.io/posts/try-swift-nyc-2017-krunoslav-zaher-modern-
    rxswift-architectures/
    https://www.codingame.com/playgrounds/929/reactive-programming-with-
    reactor-3/Intro
    https://github.com/mohammadZ74/MVVMRx_SampleProject

    View Slide

  40. A t t i a M o @AttiaMoTheDev
    $ Reactive Programming %
    & ReactiveX '
    ( RxSwift )
    * RxSwift ⌚﹠
    - Community
    / Resources
    Recap .

    View Slide

  41. Thanks.
    A t t i a M o @AttiaMoTheDev

    View Slide
