InfluxDB: Making time series fun

InfluxDB: Making time series fun

Lindsay Holmwood

November 08, 2013
Tweet

More Decks by Lindsay Holmwood

Other Decks in Technology

Transcript

  1. InfluxDB
    Making time
    series fun

    View full-size slide

  2. Time series
    database

    View full-size slide

  3. Like:
    RRDtool (C)
    Graphite (Python)
    OpenTSDB (Java)
    KairosDB (Java)

    View full-size slide

  4. Written in Go

    View full-size slide

  5. What makes
    it neat?

    View full-size slide

  6. Metrics + Events
    (Numerical + Textual)

    View full-size slide

  7. Client libraries
    Go, Java, JavaScript, Ruby

    View full-size slide

  8. Horizontally scalable*

    View full-size slide

  9. Single binary

    View full-size slide

  10. Getting started

    View full-size slide

  11. play.influxdb.org*

    View full-size slide

  12. # Download
    wget http://s3.amazonaws.com/influxdb/influxdb_latest_amd64.deb
    # Install
    sudo dpkg -i influxdb_latest_amd64.deb

    View full-size slide

  13. # Verify
    pgrep -f -l influxdb
    32333 /usr/bin/influxdb \
    -pidfile /opt/influxdb/shared/influxdb.pid \
    -config /opt/influxdb/shared/config.json
    # Manage
    sudo service influxdb stop
    sudo service influxdb start
    sudo service influxdb status

    View full-size slide

  14. Writing data

    View full-size slide

  15. #!/usr/bin/env ruby
    require 'rubygems'
    require 'influxdb'
    require 'json'

    View full-size slide

  16. #!/usr/bin/env ruby
    require 'rubygems'
    require 'influxdb'
    require 'json'
    database = "dev"
    name = "sine"
    influxdb = InfluxDB::Client.new("localhost", 8086, "auxesis", "foobarbaz", database)

    View full-size slide

  17. #!/usr/bin/env ruby
    require 'rubygems'
    require 'influxdb'
    require 'json'
    database = "dev"
    name = "sine"
    influxdb = InfluxDB::Client.new("localhost", 8086, "auxesis", "foobarbaz", database)
    loop do
    data = {
    :value => Value.next,
    }
    result = influxdb.write_point(name, data)
    sleep 1
    end

    View full-size slide

  18. #!/usr/bin/env ruby
    require 'rubygems'
    require 'influxdb'
    require 'json'
    # Create an enumerator that emits a sine wave
    Value = (0..360).to_a.map {|i| Math.send(:sin, i / 10.0) * 10 }.each
    database = "dev"
    name = "sine"
    influxdb = InfluxDB::Client.new("localhost", 8086, "auxesis", "foobarbaz", database)
    loop do
    data = {
    :value => Value.next,
    }
    result = influxdb.write_point(name, data)
    sleep 1
    end

    View full-size slide

  19. #!/usr/bin/env ruby
    require 'rubygems'
    require 'influxdb'
    require 'json'
    # Create an enumerator that emits a sine wave
    Value = (0..360).to_a.map {|i| Math.send(:sin, i / 10.0) * 10 }.each
    database = "dev"
    name = "sine"
    influxdb = InfluxDB::Client.new("localhost", 8086, "auxesis", "foobarbaz", database)
    loop do
    data = {
    :value => Value.next,
    }
    result = influxdb.write_point(name, data)
    if not (200..299).include?(result.code.to_i)
    p result
    exit 1
    end
    sleep 1
    end

    View full-size slide

  20. Reading data

    View full-size slide

  21. query = "select * from sine where time > now() - 1m;"
    q = CGI.escape(query)

    View full-size slide

  22. database = 'dev'
    query = "select * from sine where time > now() - 1m;"
    q = CGI.escape(query)
    username = 'auxesis'
    password = 'foobarbaz'

    View full-size slide

  23. database = 'dev'
    query = "select * from sine where time > now() - 1m;"
    q = CGI.escape(query)
    username = 'auxesis'
    password = 'foobarbaz'
    cmd = []
    cmd << 'curl -s'
    cmd << "'http://localhost:8087/db/#{database}/series?u=#{username}&p=#{password}&q=#{q}'"
    command = cmd.join(' ')
    puts command
    system(command)
    puts

    View full-size slide

  24. curl -s 'http://localhost:8087/db/dev/
    series?u=auxesis&p=foobarbaz&q=select+%2A
    +from+k+where+time+%3E+now%28%29+-+1m%3B'

    View full-size slide

  25. [{"name":"k","columns":["time","sequence_number","value"],"points":[[1383889088856,970,-4.193609160732313],
    [1383889087853,969,-5.078965903906221],[1383889086850,968,-5.913575298651244],
    [1383889085848,967,-6.689098203780243],[1383889084846,966,-7.397785850778934],
    [1383889083843,965,-8.032557266939547],[1383889082839,964,-8.587070026099294],
    [1383889081837,963,-9.055783620066238],[1383889080834,962,-9.434014817545556],
    [1383889079832,961,-9.717984457438632],[1383889078829,960,-9.904855208971565],
    [1383889077825,959,-9.992759921366277],[1383889076823,958,-9.980820279793964],
    [1383889075820,957,-9.869155581206488],[1383889074809,956,-9.658881542360705],
    [1383889073805,955,-9.352099151945389],[1383889072803,954,-8.951873678196819],
    [1383889071800,953,-8.462204041751706],[1383889070797,952,-7.887982859754165],
    [1383889069792,951,-7.234947560442451],[1383889068788,950,-6.509623056662469],
    [1383889067786,949,-5.719256551095638],[1383889066783,948,-4.871745124605095],
    [1383889065780,947,-3.975556831214329],[1383889064777,946,-3.0396460881104708],
    [1383889063774,945,-2.0733642060675876],[1383889062767,944,-1.0863659542407975],
    [1383889061765,943,-0.08851309290403876],[1383889060762,942,0.9102241619984788],
    [1383889059759,941,1.8998667579543773],[1383889058756,940,2.8705265132772846],
    [1383889057753,939,3.8125049165494014],[1383889056750,938,4.7163900309419615],
    [1383889055747,937,5.573150535176614],[1383889054744,936,6.374225961502389],
    [1383889053741,935,7.1116122290598245],[1383889052738,934,7.777941618010928],
    [1383889051735,933,8.36655638536056],[1383889050732,932,8.87157528692351],
    [1383889049730,931,9.287952340772405],[1383889048727,930,9.611527245021165],
    [1383889047724,929,9.839066946186161],[1383889046721,928,9.968297942787993],
    [1383889045718,927,9.997929001426693],[1383889044715,926,9.92766405835907],
    [1383889043713,925,9.758205177669755],[1383889042710,924,9.491245536478946],
    [1383889041707,923,9.129452507276277],[1383889040704,922,8.676441006416674],
    [1383889039701,921,8.136737375071053],[1383889038698,920,7.515734153521483],
    [1383889037695,919,6.819636200681355],[1383889036692,918,6.05539869719601],
    [1383889035689,917,5.230657651576964],[1383889034686,916,4.353653603728932],
    [1383889033683,915,3.433149288198954],[1383889032681,914,2.478342079829598],
    [1383889031678,913,1.4987720966295235],[1383889030674,912,0.5042268780681123],
    [1383889029671,911,-0.4953564087836742]]}]

    View full-size slide

  26. database = 'dev'
    query = "select * from sine where time > now() - 1m;"
    q = CGI.escape(query)
    username = 'auxesis'
    password = 'foobarbaz'
    cmd = []
    cmd << 'curl -s'
    cmd << "'http://localhost:8087/db/#{database}/series?u=#{username}&p=#{password}&q=#{q}'"
    cmd << '| jsonpp'
    command = cmd.join(' ')
    puts command
    system(command)
    puts

    View full-size slide

  27. [
    {
    "name": "sine",
    "columns": [
    "time",
    "sequence_number",
    "value"
    ],
    "points": [
    [
    1383889204933,
    1085,
    0.9983341664682815
    ],
    [
    1383889203929,
    1084,
    0
    ],
    [
    1383889202193,
    1083,
    -9.917788534431157
    ],
    [
    1383889201190,
    1082,
    -9.740490378683264
    ]
    ]
    }
    ]

    View full-size slide

  28. Other things

    View full-size slide

  29. Multiple databases

    View full-size slide

  30. User management

    View full-size slide

  31. Cluster admin
    Database admin
    Database user

    View full-size slide

  32. Clustering in
    December

    View full-size slide

  33. Production ready
    in January

    View full-size slide
