Jun2022 [Slides]: ACR Image Scanning with Trivy and DevOps by Arindam Mitra

Check out the full write-up on Arindams blog: https://dev.to/arindam0310018/devops-acr-trivy-1o05

These are the slides from this meetup: https://www.meetup.com/de-DE/microsoft-azure-zurich-user-group/events/286652334/

In this session, Arindam demonstrates how to scan docker Images in Azure Container Registry with Aquasec Trivy using Azure DevOps Pipelines.
The low, medium, high and critical CVEs (Common Vulnerabilities and Exposures) scan report are stored in a storage account with datetime stamps. If for some reasons, the application team accepts the risk and wants to skip the low and medium vulnerabilities from the scan report, all we have to do is list the respective CVEs in the .trivyignore file and run the pipeline again to scan. The listed CVEs will no longer be in the scan report.

About Arindam:
Arindam is an Azure Cloud & DevOps Architect, Blogger and Speaker. He likes to call himself an infrastructure geek who is passionate about technology. He travelled across the world working in different roles and currently lives in Switzerland where he is engaged as an Infrastructure and Cloud DevOps Specialist.

Links:
Blog: https://dev.to/arindam0310018
Linkedin: https://www.linkedin.com/in/arindam-mitra-28981095/
Sessionize: https://sessionize.com/arindam0310018/
Twitter: https://twitter.com/arindam0310018
Github: https://github.com/arindam0310018

Transcript

1. ACR & SCAN
   IMAGES IN ACR
   WITH TRIVY AND
   DEVOPS


   View Slide

2. HELLO!
   I am Arindam Mitra
   Today, I will be talking on ACR and How to Scan Images in ACR using Trivy and DevOps.
   You can look me at:
   : https://www.linkedin.com/in/arindam-mitra-28981095/
   : https://github.com/arindam0310018
   : https://dev.to/arindam0310018/-my-contributions--3bgp
   : https://sessionize.com/arindam0310018
   2


   View Slide

3. AGENDA
   3
   ARCHITECTURE
   CONCEPTS
   QUESTIONS
   USE CASES AND AUTOMATION
   LIVE DEMO
   BEST PRACTISES
   Any Questions Please ?
   Live Demo: Experience in Real Time ?
   Use Cases and Automation around Azure Container Registry (ACR) ?
   Best Practises: Azure Container Registry (ACR) ?
   Network Architecture of Azure Container Registry (ACR) ?
   Concepts and Components of Azure Container Registry (ACR) ?


   View Slide

4. ➢ Is Azure Container Registry a Private Container ?
   ➢ What does Azure Container Registry Support ?
   ➢ Tiers and Differences
   ➢ Automatic Image Build
   ➢ Security
   ➢ Costs
   CONCEPTS
   4


   View Slide

5. ➢ Public or Private Endpoint ?
   ➢ Public Endpoint with IP Whitelisting ?
   ➢ Private Endpoint ?
   ➢ Hub or Spoke – Where will the ACR reside ?
   ➢ Design by Shared Subscriptions ?
   ➢ Design by Dedicated Subscriptions and Environments ?
   ➢ Peering “Must Know” Concepts ?
   ➢ One ACR Across all Environments ?
   ARCHITECTURE
   5


   View Slide

6. ➢ One ACR with Private Endpoint in Hub
   ➢ All Spokes will be Peered to HUB (Which is Obvious)
   ➢ Per Application, there will be Service Principal to build and
   Push Images to ACR.
   ➢ Service Principal will have ACRPULL and ACRPUSH Role
   Based Access Control (RBAC) on the Resource Group
   Containing Hub ACR or Hub ACR itself.
   ARCH DESIGN: HUB & SPOKE
   6


   View Slide

7. ➢ Shared Subscription = Multiple Application Segregated
   using Resource Group.
   ➢ One ACR with Private Endpoint in Shared Subscription.
   ➢ All Applications in the Shared Subscription will consume the
   same ACR.
   ➢ Per Application, there will be Service Principal to build and
   Push Images to ACR.
   ➢ Service Principal will have ACRPULL and ACRPUSH Role
   Based Access Control (RBAC) on the Resource Group
   Containing ACR or On the Resource (ACR) itself.
   ARCH DESIGN: SHARED SUBS
   7


   View Slide

8. ➢ Dedicated Subscription = One Application Per Environment
   and Per Subscription
   ➢ One ACR with Private Endpoint in Per Application and
   Environment Dedicated Subscription.
   ➢ For Example: Application having a Dedicated “Non-Prod”
   and “Prod” Subscription. So there will be 2 ACRs.
   ➢ Non-Prod Subscription can further have “Dev”, “QA”,
   “UAT/PRE-PROD” Environment categorized in Resource
   Groups.
   ➢ Per Environment, there will be Service Principal to build and
   Push Images
   ➢ Service Principal will have ACRPULL and ACRPUSH Role
   Based Access Control (RBAC) on the Resource Group
   Containing ACR or On the Resource (ACR) itself.
   ARCH DESIGN: DEDICATED SUBS
   8


   View Slide

9. ➢ One ACR with Private Endpoint in Per Application Dedicated
   Subscription (Prod) but Shared Virtual Network (VNet).
   ➢ Consider Application having a Dedicated “Non-Prod” and
   “Prod” Subscription.
   ➢ Non-Prod Subscription can further have “Dev”, “QA”,
   “UAT/PRE-PROD” Environment categorized in Resource
   Groups.
   ➢ Shared VNet will then be Peered with DEV, QA, UAT/PRE-
   PROD, and PROD VNet.
   ➢ Per Environment, there will be Service Principal to build and
   Push Images
   ➢ Service Principal will have ACRPULL and ACRPUSH Role
   Based Access Control (RBAC) on the Resource Group
   Containing ACR or On the Resource (ACR) itself.
   ARCH DESIGN: ALL IN ONE ACR
   9


   View Slide

10. ➢ Image Tagging
    ➢ Image Scanning
    ➢ Approval as who can push the Image with Event
    Notification.
    ➢ Retention of Images
    BEST PRACTISES
    10


    View Slide

11. ➢ Use Case(s): Hosts images to “Build Infrastructure at Scale“:-
    ➢ Web App for Containers
    ➢ ACI Instance - Container Groups and Containers
    ➢ AKS - HPA and KEDA
    ➢ Azure Container Apps
    ➢ Automations:-
    ➢ Powershell
    ➢ Terraform
    ➢ Biceps
    USE CASES AND AUTOMATIONS
    11


    View Slide

12. ➢ Scan Image Vulnerabilities in ACR Using TRIVY and AZURE
    DEVOPS
    ➢ Blog Link: https://dev.to/arindam0310018/devops-
    acr-trivy-1o05
    ➢ Github: https://github.com/arindam0310018/ACR-
    Trivy
    LIVE DEMO DETAILS
    12


    View Slide

13. “LETS
    EXPERIENCE IN
    REAL TIME !!!
    13
    13


    View Slide

14. “Any Questions please, happy to
    answer to the best of my
    knowledge.
    14
    14


    View Slide

15. CREDITS
    Special THANK YOU to MANUEL MEYER and THOMAS
    HAFERMALZ for the providing the opportunity to speak @
    AZURE ZURICH USER GROUP In Person Session.
    15


    View Slide

16. 16
    THANK YOU!!!
    For any further questions?
    You can write me at:
    mail2arindam2003@yahoo.com
    arindam0310018@gmail.com


    View Slide
