The Conf 2018 - Building your own flavored Markdown with Ruby

Markdown is a nice and simple markup language that tries to re-use some earlier plaintext formatting conventions used in emails and documentation, as a markup syntax to convert to many different targets, from the most common: HTML, to the less known LaTeX or as a PDF E-Book writing solution.

While not all markdown is born the same, few standards exists, but each one with their own set of extensions and quirks. You are going to learn how to build yet another one that suits your own needs, by following the path of GitLab Kramdown.

Transcript

1. View Slide

2. @brodock
   blog.gabrielmazetto.eti.br
   Gabriel Mazetto !
   2


   View Slide

3. 3
   Photo by Grillot edouard


   View Slide

4. View Slide

5. View Slide

6. View Slide

7. 7
   Building your own
   Flavored Markdown
   with Ruby


   View Slide

8. What is Markdown?
   8


   View Slide

9. “Markdown is intended to be an
   easy-to-read and easy-to-write
   text to HTML markup
   language”
   9
   Markdown


   View Slide

10. What is a Markup
    Language?
    10


    View Slide

11. “A markup language is a system
    for annotating a document in a
    way that is syntactically
    distinguishable from the text.”
    11
    Markup Language


    View Slide

12. Welcome to Markdown
    ———————————————————
    This is a **simple** markup that supports _formatting_ using
    just plain text symbols.
    Not all markdowns are born the same, while the [original syntax]
    (https://daringfireball.net/projects/markdown/syntax) is mostly
    unchanged between the many different **flavors**, many have
    their own **extensions** and can interpret things like _multiple
    spaces_ or headers differently.
    ```ruby
    puts "There is also many ways to share code snippets"
    ```


    View Slide

13. Welcome to Markdown
    ———————————————————
    This is a **simple** markup that supports _formatting_ using
    just plain text symbols.
    Not all markdowns are born the same, while the [original syntax]
    (https://daringfireball.net/projects/markdown/syntax) is mostly
    unchanged between the many different **flavors**, many have
    their own **extensions** and can interpret things like _multiple
    spaces_ or headers differently.
    ```ruby
    puts "There is also many ways to share code snippets"
    ```


    View Slide

14. Text to HTML
    conversion?
    14

    …


    View Slide

15. 15
    Let’s try to convert a very simple
    Markdown document


    View Slide

16. Input:
    This is a very simple text with _emphasis_ here also
    *emphasis* on something else and a really **important**
    message here.
    Expected Output:
    This is a very simple text with emphasis here also
    emphasis on something else and a really
    important message here.


    View Slide

17. 1. Anything surrounded by _ or *
    (single digit) should be modified
    to be surrounded by and


    2. Anything surrounded by **
    should be modified to be
    surrounded by and

    17
    Experiment Rules


    View Slide

18. Let’s see the places
    where we should
    modify the text
    18


    View Slide

19. This is a very simple text with _emphasis_ here also
    *emphasis* on something else and really **important**
    message here.


    View Slide

20. Tentative solution:
    Use Find and Replace
    20


    View Slide

21. ### First tentative
    content = "This is a very simple text with _emphasis_ here also *emphasis* on
    something else and really **important** message here."
    content.gsub!('_', '')
    # => "This is a very simple text with emphasis here also *emphasis* on
    something else and really **important** message here."
    content.gsub!('*', '')
    # => "This is a very simple text with emphasis here also emphasis
    on something else and really important message here."
    content.gsub!('**', '')
    # => "This is a very simple text with emphasis here also emphasis
    on something else and really important message here."


    View Slide

22. View Slide

23. • We can find and replace _ but If
    we try to find just the * we can’t
    easily distinguish between the
    ones that needs to be to the
    others that needs to be

    • Alternative: find the ones with two
    repeating first, convert and then
    the single digit ones respectively.
    23
    Tentative solution:
    Use find and replace


    View Slide

24. The order we
    process the rules,
    DOES matter
    24


    View Slide

25. ### Second tentative
    content = "This is a very simple text with _emphasis_ here also *emphasis* on
    something else and really **important** message here."
    content.gsub!('**', '')



    # => "This is a very simple text with _emphasis_ here also *emphasis* on
    something else and really important message here."

    content.gsub!('_', '')

    # => "This is a very simple text with emphasis here also *emphasis* on
    something else and really important message here."

    content.gsub!('*', '')
    # => "This is a very simple text with emphasis here also emphasis
    on something else and really important message here."


    View Slide

26. View Slide

27. ### Third tentative
    content = "This is a very simple text with _emphasis_
    here also *emphasis* on something else and really
    **important** message here."
    content.gsub!(/\*\*|_|\*/, '**' => '', '_' =>
    '', '*' => ‘')
    # => "This is a very simple text with emphasis
    here also emphasis on something else and
    really important message here."


    View Slide

28. This is a very simple text with _emphasis_ here also
    *emphasis* on something else and really **important**
    message here.
    Output:
    This is a very simple text with emphasis here also
    emphasis on something else and really
    important message here.


    View Slide

29. View Slide

30. We can’t use simple find and
    replace as the symbols are
    ambiguous: _, * and ** can be
    either a start or an ending symbol
    30
    Tentative solution:
    Use find and replace


    View Slide

31. Some way to be able to substitute
    _ for and its second
    occurrence for , you need
    to keep a memory state while
    reading the stream of characters.
    31
    Whats missing


    View Slide

32. Let’s try to use
    RegExp with
    “patterns”…
    32


    View Slide

33. • /\*\*|_|\*/ will match
    all the special characters we
    needed, but without holding
    state of first/second match.
    33
    Regular Expression


    View Slide

34. • /(\*\*)(.*)(\*\*)/
    we expect it to match content
    surrounded by **

    • /(_|\*)(.*)(_|\*)/
    we expect it to match content
    surrounded by * or _
    34
    Regular Expression


    View Slide

35. /(\*\*)(.*)(\*\*)/
    35
    formatting
    symbols
    capture groups
    . matches any character
    * repeats zero or more


    View Slide

36. /(_|\*)(.*)(_|\*)/
    36
    formatting
    symbols
    capture groups
    . matches any character
    * repeats zero or more
    | logical “or”


    View Slide

37. ### Fourth tentative
    content = "This is a very simple text with _emphasis_ here also
    *emphasis* on something else and really **important** message here."
    content.gsub!(/(\*\*)(.*)(\*\*)/, '\2')
    # => "This is a very simple text with _emphasis_ here also *emphasis*
    on something else and really important message here.”
    content.gsub!(/(_|\*)(.*)(_|\*)/, '\2')
    # => "This is a very simple text with emphasis_ here also
    *emphasis on something else and really important
    message here.”


    View Slide

38. 38
    "This is a very simple text with
    emphasis_ here also
    *emphasis on something else
    and really important
    strong> message here."


    View Slide

39. View Slide

40. /(_|\*)(.*)(_|\*)/
    40
    . matches any character
    * repeats zero or more (greedy operator)
    | logical “or”
    matches every element of the text until the end of it, it
    will fail to find the last capture group, than it will
    backtrack (discard elements) until the RegExp is satisfied.


    View Slide

41. /(_|\*)(.*?)(_|\*)/
    41
    . matches any character
    * repeats zero or more (greedy operator)
    ? after a greedy operator makes it lazy
    | logical “or”
    lazy matcher will expand the dot at least once, and
    continue to evaluate the rest of the RegExp, if it fails it will
    backtrack, but instead of removing, it will expand again


    View Slide

42. ### Fifth tentative
    content = "This is a very simple text with _emphasis_ here also
    *emphasis* on something else and really **important** message here."
    content.gsub!(/(\*\*)(.*?)(\*\*)/, '\2')
    # => "This is a very simple text with _emphasis_ here also *emphasis*
    on something else and really important message here."
    content.gsub!(/(_|\*)(.*?)(_|\*)/, '\2')
    # => "This is a very simple text with emphasis here also
    emphasis on something else and really important
    strong> message here."


    View Slide

43. View Slide

44. We can still improve
    it…
    44


    View Slide

45. /(_|\*)(.*?)(_|\*)/
    45
    formatting symbols not
    guaranteed to match


    View Slide

46. /(_|\*)(.*?)(\1)/
    46
    \1 content of first capture group match
    when the symbol on the first capture group is * the
    second capture will look for * only.


    View Slide

47. Things can get complicated for
    block level markups
    47


    View Slide

48. Welcome to Markdown
    ———————————————————
    ```ruby
    puts "There is also many ways to **share** code snippets"
    ```
    | This is a table | With columns |
    |——————————-————————————————-—|—————————————-————————-|
    | How will you convert this | Into an actual table? |
    | How about som ``` ambiguous | symbols inside |
    | And **formating** | |


    View Slide

49. Let’s talk about compilers


    View Slide

50. “Compiler is a program that
    can read a program in one
    language (source code) and
    translate it into an equivalent
    program in another language
    (machine code)”
    50


    View Slide

51. ‣ Lexical Analyser (Scanner)
    ‣ Syntax Analyzer (Parser)
    ‣ Semantic Analyzer
    ‣ Intermediate Code
    Generation
    ‣ Code Generation
    ‣ Code Optimizer
    51
    Fundamental parts of a
    compiler


    View Slide

52. 52
    Program text input
    Lexical Analysis
    Syntax Analysis
    file
    characters
    tokens
    Context Handling
    AST
    Intermediate Code Gen.
    annotated AST
    Intermediate Code
    IC
    IC optimization
    Code generation
    Target code
    optimization
    IC
    symbol instructions
    Machine Code
    Generation
    symbol instructions
    Executable code output
    bit patterns
    file


    View Slide

53. 53
    We need only a slice of it


    View Slide

54. 54
    How a generic Markdown
    to HTML transpiler looks
    like
    Program text input
    Lexical Analysis
    Syntax Analysis
    file
    characters
    tokens
    HTML Conversor
    HTML Document file
    AST
    HTML


    View Slide

55. 55
    Program text input
    Lexical Analysis
    Syntax Analysis
    file
    characters
    tokens
    HTML Conversor
    HTML Document file
    AST
    HTML


    View Slide

56. A scanner needs to identify only
    a finite set of valid token/lexeme
    that belongs to the language
    rules.
    56
    Understanding how a
    Scanner works…


    View Slide

57. • Token: a string with an assigned
    meaning. Structured as tuple
    with a type and an optional value
    (ex: keyword, literals, numbers,
    operators…)
    • Lexeme: A lexeme is a sequence
    of characters in the source
    program that matches the
    pattern for a token
    57
    Glossary


    View Slide

58. 58
    A simple scanner example


    View Slide

59. Rules:
    1. "Word" token is formed by a
    consecutive stream of ASCII
    characters
    2.Accepts only US keyboard
    visible ASCII characters.
    3.Spaces or special characters
    are a token separator
    59
    Simple scanner example:

    Return only words from a
    text.


    View Slide

60. Content —> Word | Separator
    Word —> Char
    Char —> [a-zA-Z]
    Separator —> [!@#$%^&*()-_=+ ]
    60
    EBNF Grammar


    View Slide

61. 61
    Program text input
    Lexical Analysis
    Syntax Analysis
    file
    characters
    tokens
    HTML Conversor
    HTML Document file
    AST
    HTML


    View Slide

62. This text is in *bold*
    62
    Example of how the tokens
    are parsed…
    ['This', 'text', 'is', 'in', '*', 'bold', '*']
    [{0: 'This'}, {5: 'text'},
    {10: 'is'}, {13: 'in'},
    {16: '*'}, {17: 'bold'}, {21: '*'}]


    View Slide

63. 63
    Tokenization


    View Slide

64. Input: This is a simple
    text: Hello World!
    Tokens:

    (content
    (word This)
    (word is)
    (word a)
    (word simple)
    (word text)
    (word Hello)
    (word World))
    64
    Representation using

    s-expression syntax


    View Slide

65. 65
    AST


    View Slide

66. After tokenization, tokens are
    converted to a tree structure, and
    they can be annotated with
    information required by later steps.

    Few use-case exemples: error
    handling (displaying the file and line
    number), dynamic typing inference,
    ambiguous grammars (context
    dependent), transformations, etc.
    66
    Why compilers have AST?


    View Slide

67. When we generate a header token
    and it’s placed inside an AST, we
    can annotate it with the header
    level it represents, for example.
    Image token only has the URL but
    there is probably an alternate text
    after it that can be combined into a
    single in the AST.
    67
    Few other markdown
    specific examples


    View Slide

68. How can we use
    that all in real life?
    68


    View Slide

69. View Slide

70. 70
    https://gitlab.com/gitlab-com/gitlab-docs


    View Slide

71. 71
    Introducing GitLab Kramdown:

    https://gitlab.com/gitlab-org/gitlab_kramdown


    View Slide

72. Many things we talked here
    before were instrumental to
    the Kramdown implementation
    72


    View Slide

73. 73
    Program text input
    Lexical Analysis
    Syntax Analysis
    file
    characters
    tokens
    HTML Conversor
    HTML Document file
    AST
    HTML


    View Slide

74. Kramdown differentiates Span
    Parsers from Block Parsers.
    The Parser delegates pattern
    matching to the StringScanner,
    and it generates an AST in the
    form of Kramdown::Document
    and Kramdown::Element.
    74
    Kramdown::Parser


    View Slide

75. 75
    Let’s see some source-code


    View Slide

76. 76
    Questions?


    View Slide

77. If you want to learn more:

    https://gitlab.com/gitlab-org/
    gitlab_kramdown
    77


    View Slide

78. 78
    Thank You :)


    View Slide
