  1. Dissecting Blackberry Z10: 2-in-1 By Alexander Antukh & Yury Chemerkin

    Jun 30, 2013
  2. /whoami Alexander Antukh  Security Consultant  Offensive Security Certified

    Expert  Interests: kittens and stuff
  3. /whoami Yury Chemerkin  Experienced in :  Mobile Security

    and MDM  Cyber Security & Cloud Security  Compliance & Transparency  and Security Writing
  4. Dissecting Blackberry Z10 Agenda Blackberry OS review Shell Access The

    Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research 4
  5. Dissecting Blackberry Z10 Blackberry OS review Built on QNX! 5

     Tiny  Micro-kernel architecture  Virtual memory alloc for each process  POSIX-compilant QNX = MK + PM + processes
  6. Dissecting Blackberry Z10 Blackberry OS review That’s how the system

    looks like: 6
  7. Dissecting Blackberry Z10 Blackberry OS review That’s how the microkernel

    looks like: 7
  8. Dissecting Blackberry Z10 Agenda Blackberry OS review Shell Access The

    Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research 8
  9. Dissecting Blackberry Z10 Shell Access Extremely easy! 9  development

    mode  on  generate a 4096-bit RSA key (ssh-keygen/putty)  blackberry-connect <t> -password <p> -sshPublicKey <k>  ssh 169.254.0.1  nuts Even easier:  Dingleberry  nuts /accounts/devuser/
  10. Dissecting Blackberry Z10 Agenda Blackberry OS review Shell Access The

    Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research 10
  11. Dissecting Blackberry Z10 The Approaches 1. General permissions 11 

    SUID/SGID -rwxrwsrwx 1 root root  Writable files and folders "find all suid files" => "find / -type f -perm -04000 –ls” "find all sgid files" => "find / -type f -perm -02000 –ls” "find config* files" => "find / -type f -name \"config*\”” "find all writable folders and files" => "find / -perm -2 –ls” "find all writable folders and files in current dir" => "find . -perm -2 -ls"
  12. Dissecting Blackberry Z10 The Approaches 2. Fuzzers 12  IOCTL

    fuzzing • no params • overlong strings • pre-determined DWORDs Process 1924486014 (python3.2) terminated SIGSEGV code=1 fltno=11 ip=011c90c4(/usr/lib/ldqnx.so.2@ioctl+0x113c) mapaddr=000790c4. ref=00000000  Binary bit-/byteflipping (EDB-ID #7823)
  13. Dissecting Blackberry Z10 The Approaches 3.1. System utilities. BOFs 13

    Many missing: setuidgid, id, dumpifs… Many interesting: • confstr – current configuration including path, architecture and network info • dmc – digital media controller • fsmon – file system monitor • jsc – JavaScript engine for Webkit used on a device • ldo-msm – LDO Driver • mkdosfs – format a DOS filesystem (FAT-12/16/32) • mkqnx6fs – format a filesystem (for QNX6, however, is presented in Blackberry OS) • and also tools such as mount, on, nfcservice, nvs_write_bin and displayctl.
  14. Dissecting Blackberry Z10 The Approaches 3.1. System utilities. BOFs 14

    Process 57340127 (displayctl) terminated SIGSEGV code=1 fltno=11 ip=788293d2(/base/usr/lib/graphics/msm8960/displayHAL- r086.so@dsi_get_pclk_freq+0x121) mapaddr=000093d2. ref=00000008 Process 249935086 (nowplaying) terminated SIGSEGV code=1 fltno=11 ip=78102cce(/usr/sbin/nowplaying@main+0x19d) ref=00000000 Process 1545237780 (charge_monitor) terminated SIGSEGV code=1 fltno=11 ip=010b998c(/usr/lib/ldqnx.so.2@message_detach+0x8) mapaddr=0003998c. ref=00000028 Process 1543295477 (shutdown) terminated SIGSEGV code=1 fltno=11 ip=78117c3e(/proc/boot/shutdown-msm8960.so@pmic_ssbi_read+0x15) mapaddr=00001c3e. ref=ffffffff
  15. Dissecting Blackberry Z10 The Approaches 3.2. System utilities. Vulnerable syscalls.

    displayctl. 15
  16. Dissecting Blackberry Z10 The Approaches 3.2. System utilities. Vulnerable syscalls.

    nvs_write_bin. 16 Nonvolatile (sometimes written as "non-volatile") storage (NVS) - also known as nonvolatile memory or nonvolatile random access memory (NVRAM) - is a form of static random access memory whose contents are saved when a computer is turned off or loses its external power source. NVS is implemented by providing static RAM with backup battery power or by saving its contents and restoring them from an electrically erasable programmable ROM (EPROM)
  17. Dissecting Blackberry Z10 Agenda Blackberry OS review Shell Access The

    Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research 17
  18. Dissecting Blackberry Z10 Firmware from the inside Firmware update? Yes,

    please! MFCQ  QNX image 18
  19. Dissecting Blackberry Z10 Firmware from the inside Tools to deal

    with: 19 qfcm_parser.py  partitions! chkqnx6fs  info about the images dumpifs  IFS dump  https://github.com/intrepidusgroup/pbtools
  20. Dissecting Blackberry Z10 Firmware from the inside Pearls inside: 20

    ALL the scripts and configs can be read now!  .script (starting up)  ifs_variables.sh (sysvars)  os_device_image_check Microkernel itself
  21. Dissecting Blackberry Z10 Firmware from the inside 21 Pearls inside:

    Protected tools can be launched now! Bootrom Version: 0x0523001D (5.35.0.29) DeviceString: RIM BlackBerry Device BuildUserName: ec_agent BuildDate: Nov 3 2012 … IsInsecureDevice: false HWVersionOffset: 0x000000D4 NumberHWVEntries: 0x00000014 MemCfgTableOffset: 0x000000FC MemCfgTableSize: 0x00000100 Drivers: 0x00000010 [ MMC ] LDRBlockAddr: 0x2E02FE00 BootromSize: 0x00080000 BRPersistAddr: 0x2E0AFC00 persist-tool: insecure syscalls can be reproduced (read/dump data)
  22. Dissecting Blackberry Z10 Firmware from the inside 22 Pearls inside:

    Funny comments (code reviewers will like it) function setScreenScaling (width, height) { ... //ZOOM TO POINT IS FULL OF BUGS - Docs state that coordinates should only ever be in center of screen // TODO: Once the QML bug about not being to access the page values that are provided as a parameter to this slot is fixed ... // The zipfile.ZipFile.write() method has a bug where it raises struct.error: ushort format requires 0 <= number <= USHRT_MAX // Too many bytes for PNG signature. Potential overflow in png_zalloc() … and more
  23. Dissecting Blackberry Z10 Firmware from the inside 23 Pearls inside:

    Facebook – too much;)  IDs  Emails  Mobile phones  Secrets  Passwords Plaintext!
  24. Dissecting Blackberry Z10 Agenda Blackberry OS review Shell Access The

    Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research 24
  25. Dissecting Blackberry Z10 Playing with the browser  Webkit rendering

    engine  Vulnerabilities are just the same (i.e. as for Google Chrome) 25
  26. Dissecting Blackberry Z10 Playing with the browser Local file access

    from the browser 26 HTML page as an email attachment file://  nuts Currently the vulnerability is removed
  27. Dissecting Blackberry Z10 Agenda Blackberry OS review Shell Access The

    Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research 27
  28. Dissecting Blackberry Z10 Security on the Application Level BlackBerry Z10

    – Vulnerability in BlackBerry Protect Limited: by the inability of a potential attacker to force exploitation of the vulnerability without significant customer interaction and physical access to the device Affected Software  BlackBerry 10 OS version 10.0.10.261 and earlier, except version 10.0.9.2743  BlackBerry Z10 smartphone only 28 Currently the vulnerability is removed
  29. Dissecting Blackberry Z10 Security on the Application Level Special artifacts

    “.all” as a kind of logs  PATH : /pps/system/<name>/.all  Browsers : history  Networking : ID, flags, MACs  Device IDs : Hardware, PIN, Name, Serials, etc.  Video Chats : params, call details:  BlackBerry Bridge  SapphireProxy  Status, name, address, auth token, key  Autostart param  Routes: BB, BIS, BER: 127.0.0.2:188/189/187  Results : access to internal network, internal storage, media files, the rest (contacts, cal, .etc) in case of non-QNX device 29 Currently there is no details if it is solved Author’s opinion : can’t be solved or cracked in similar ways
  30. Dissecting Blackberry Z10 Agenda 30 Blackberry OS review Shell Access

    The Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research
  31. Dissecting Blackberry Z10 Funny with APIs  Useful ideas that

    make no enough sense  Merging permissions into one group  No way to emulate hardware inputs but results of pressing are strongly restricted if there are  Sandbox  Malware is a personal application subtype in terms of blackberry’s security  Sandbox protects only app data, while user data stored in shared folders 31
  32. Dissecting Blackberry Z10 Funny with APIs  Non-controlled activity by

    any permission  Accessing to data passed through the clipboard  Access to ‘Accounts’ leads to a ‘read’ access to contacts,messages, notebooks, calendar by default  MediaPlayer is a great way to access to the FS  Access to file system in many ways and most cases managing device’s resources  Camera activity,  Contact photos  Calendar event attachments  Message attachments (Email, BBM)  Saving records (camera photos, video, audios) 32
  33. Dissecting Blackberry Z10 Agenda 33 Blackberry OS review Shell Access

    The Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research
  34. Dissecting Blackberry Z10 Agenda 34 BlackBerry Old iOS BlackBerry QNX

    Android Quantity of Groups 55 16 7 4 Average perm per group 20 5 7 4 Efficiency 80,00 38,46 31,82 10,26 Totall permissions 1100 80 49 16 55 16 7 4 20 5 7 4 80,00 38,46 31,82 10,26 1100 80 49 16 0 200 400 600 800 1000 1200 0 10 20 30 40 50 60 70 80 90 100 BlackBerry MDM Quantity of Groups Average perm per group Efficiency Totall permissions
  35. Dissecting Blackberry Z10 Agenda 35 Blackberry OS review Shell Access

    The Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research
  36. Dissecting Blackberry Z10 Efficiency of security features  Activity 

    Common Min/Average/Max quantity :: 2 / 8 / 34  Additional Min/Average/Max quantity :: 0 / 2 / 7  Derived Min/Average/Max quantity :: 3 / 31 / 116  Permission  Common Min/Average/Max quantity :: 0 – 1 – 3  Additional Min/Average/Max quantity :: 1 – 0 – 1  Derived Min/Average/Max quantity :: 4 – 4 – 8  APIs  Common / Significant quantity :: 100 – 61  The most security unit is LED activity 36
  37. Dissecting Blackberry Z10 Efficiency of security features 37 6 21

    5 34 7 18 6 3 17 3 4 2 4 4 8 3 4 2 14 1 4 3 2 1 1 1 2 2 2 1 1 1 1 4 1 2 5 1 0 5 10 15 20 25 30 35 Ratio of common activities to permissions Q. of m.+a. activity Q. of m.+a. permission
  38. Dissecting Blackberry Z10 Efficiency of security features 38 6 116

    24 59 7 89 16 23 47 3 11 3 19 46 9 24 25 2 27 1 4 3 3 1 3 1 2 2 2 1 2 1 1 8 1 2 5 1 0 20 40 60 80 100 120 Ratio of derived activities to permissions Q. of derived activities Q. of derived perm
  39. Dissecting Blackberry Z10 Efficiency of security features 39 16,67 19,05

    60,00 5,88 14,29 5,56 16,67 66,67 11,76 66,67 25,00 50,00 25,00 25,00 50,00 33,33 50,00 250,00 7,14 16,67 3,45 12,50 5,08 14,29 3,37 6,25 8,70 4,26 66,67 9,09 66,67 5,26 2,17 88,89 4,17 8,00 250,00 3,70 0,00 50,00 100,00 150,00 200,00 250,00 % m+a activity vs perm % m+a derived activity vs perm
  40. Dissecting Blackberry Z10 Agenda 40 Blackberry OS review Shell Access

    The Approaches Firmware from the inside Playing with the browser Security on the application level Funny with APIs MDM capabilities Efficiency of security features Future research
  41. Dissecting Blackberry Z10 Future research 41 Image parser fuzzing Jailbreak

    IOCTL / syscalls further research Play more with SSH Blackberry Balance is not available yet Permission collision Overpemissioning by system applications and services Bypassing MDM features by both of previous
  42. Dissecting Blackberry Z10 Full articles … are available here (no

    SMS to send is required! Free for a very limited time!) 42 http://goo.gl/dP9iR Blackberry Z10 research http://goo.gl/PpXxg Blackberry and more
